1997 FORD ASPIRE service

30
*
[AS36900(ALL)08/95]
Some FM radio stations advertise a
ªrounded-offº frequency which is not the
frequency they actually broadcast on. For
example, a radio station that is assigned a
frequency of 98.7 MHz may call itself ªRadio 99º
even though 99.0 MHz is not an allowable FM
broadcast frequency.
%
*
[AS37000(ALL)08/95]
Important Warranty and Service
Information
*
[AS37050(ALL)07/90]
q
Warranty
*
[AS37100(ALL)08/95]
Your sound system is warranted for three years
or 36,000 miles (60,000 kilometers), whichever
comes first. Consult your vehicle warranty
booklet for further information. Ask your dealer
for a copy of this limited warranty.
*
[AS37150(ALL)07/90]
q
Service
*
[AS37200(ALL)04/96]
At Ford, we stand behind our audio systems
with a comprehensive service and repair
program. If anything should go wrong with
your Ford audio system, return to your dealer
for service. There is a nationwide network of
qualified Ford authorized repair centers to assist
you.
File:04icasf.ex
Update:Tue Mar 4 08:51:43 1997

69
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
%
*
[SS11700(ALL)05/96]
Air Bag Supplemental Restraint
System (SRS)
[SS11950(ALL)05/96]
Important Air Bag Precautions
*
[SS11960(ALL)05/96]
Your vehicle is equipped with a supplemental
restraint system designed to work with the
safety belts to help protect you and your right
front seat passenger in the event of a collision.
The Air Bag Supplemental Restraint System is
primarily designed to reduce certain upper body
injuries.
*
[SS11970(ALL)05/96]
WARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, failure to do so may increase the
risk of personal injury in the event of a
collision.
*
[SS11980(ALL)05/96]
WARNING
Do not place objects or mount equipment
on or near the air bag covers that may
come into contact with an inflating air
bag. Failure to follow these instructions
may increase the risk of personal injury in
the event of a collision.
*
[SS12000(ALL)05/96]
WARNING
Do not attempt to service, repair, or
modify the air bag Supplemental Restraint
System or its fuses. See your Ford or
Lincoln-Mercury dealer.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

74 %
*
[SS12650(ALL)05/96]
A problem with the system is indicated by one
or more of the following:
[SS12675(ALL)05/96]
q
the readiness light will either flash or stay lit,
[SS12690(ALL)05/96]
q
the readiness light will not light immediately
after ignition is turned on,
%*
[SS12700(ALL)05/96]
q
a group of five beeps will be heard. The tone
pattern will repeat periodically until the
problem and light are repaired.
*
[SS12800(ALL)05/96]
If any of these things happen, even
intermittently, have the Air Bag Supplemental
Restraint System serviced at your Ford or
Lincoln-Mercury dealer immediately. Unless
serviced, the system may not function properly
in the event of a collision.
*
[SS13000(ALL)05/96]
Disposal of Air Bags and Air Bag
Equipped Vehicles
*
[SS13100(ALL)05/96]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer. Air bags MUST BE disposed of by
qualified personnel.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

101 [TO09550(ALL)01/96]
half page art:0032161-C
The location of the fuel pump shut-off switch (U.S. vehicle
shown Ð Canadian vehicles similar)
*
[TO09600(ALL)03/96]
WARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
[TO09650(ALL)02/96]
If your engine cranks but does not start after a
collision or major jolt:
*
[TO09700(ALL)03/96]
1. Turn the key in the ignition to the LOCK
position.
*
[TO09750(ALL)03/96]
2. Check under the vehicle for leaking fuel.
[TO09800(ALL)01/96]
3. If you do not see or smell fuel, remove the
door covering the fuel pump shut-off switch
compartment by pressing the tab toward the
rear seat. Push down the red reset button on
the fuel pump shut-off switch.
File:08ictof.ex
Update:Tue Mar 4 08:54:32 1997

103
*
[TO12100(ALL)01/96]
Have the exhaust and body ventilation systems
checked whenever:
*
[TO12200(ALL)01/96]
q
your vehicle is raised for service
*
[TO12300(ALL)01/96]
q
the sound of the exhaust system changes
*
[TO12400(ALL)01/96]
q
your vehicle has been damaged in a collision
*
[TO12500(ALL)01/96]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
[TO12600(ALL)01/96]
If you must allow your engine to idle for long
periods of time, be sure you are in an open area
and open the windows at least one inch
(25 mm). Also, adjust the heating or air
conditioning to bring in outside air.
[TO12700(ALL)01/96]
If you are using the heater, set the fan speed on
1, 2, or 3 with the function lever on the position
of your choice and the air door control lever in
the fresh (outside air) position.
[TO12900(ALL)04/96]
If you are using the air conditioner, set the fan
speed on 1, 2, or 3 with the function lever in the
position of your choice. Set the air door control
lever in theN(outside air) position.
File:08ictof.ex
Update:Tue Mar 4 08:54:32 1997

106
*
[GF02300(ALL)02/96]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
[GF02400(ALL)02/97]
Occasional brake noise is normal and does not
indicate a performance concern with the vehicle's
brake system. In normal operation, automotive
brake systems may emit occasional or
intermittent squeal or groan noises when the
brakes are applied. Such noises are usually
heard during the first few brake applications in
the morning; however, they may be heard at any
time while braking and can be aggravated by
environmental conditions such as cold, heat,
moisture, road dust, salt or mud. If a
ªmetal-to-metalº or ªcontinuous grindingº sound
is present while braking, the brake linings may
be worn-out and should be inspected by a
qualified service technician.
[GF03000(ALL)01/96]Anti-lock Brake System (ABS)
(If equipped)
[GF03050(ALL)02/97]
On vehicles equipped with an antilock braking
system (ABS), a noise from the hydraulic pump
motor and pulsation in the pedal may be
observed during ABS braking events. Pedal
pulsation coupled with noise while braking
under panic conditions or on loose gravel, wet
or snowy roads is normal and indicates proper
functioning of the vehicle's antilock brake
system. If the vehicle has continuous vibration or
shudder while braking, felt mainly in the
steering wheel, the vehicle most likely needs
service.
[GF03100(ALL)01/96]
The Anti-lock Brake System (ABS) prevents the
brakes from locking up. Whenever your wheels
start to lock during maximum braking, the
File:09icgff.ex
Update:Tue Mar 4 08:54:55 1997

139 %
*
[ER12275(ALL)02/96]
WARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[ER12280(ALL)02/96]
WARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[ER12285(ALL)02/96]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[ER12290(ALL)01/96]
WARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[ER12295(ALL)02/96]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
%*
[ER12300(ALL)02/96]
Preparing Your Vehicle
*
[ER12305(ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

143
%*
[ER12450(ALL)02/96]
Towing Your Vehicle
[ER12500(ALL)01/96]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
Suggested towing options include wheel lift
towing or flat bed towing.
[ER12550(ALL)01/96]
two third page art:0032214-A
The proper towing procedures
