1997 FORD ASPIRE service

*
[PI00560(ALL)05/95]
Table of ContentsIntroduction ...................................................... 1
Instrumentation ................................................ 7
Electronic Sound Systems ........................... 19
Controls and Features .................................. 31
Seating and Safety Restraints .................... 57
Starting ............................................................. 93
Driving ........................................................... 105
Roadside Emergencies ................................ 121
Maintenance and Care ............................... 145
Capacities and Specifications ................... 199
Reporting Safety Defects
(U.S. Only) .................................................... 209
Customer Assistance ................................... 211
Accessories .................................................... 223
Quick Index .................................................. 233
Index ............................................................... 243
Service Station Information --
1.3L Engine ................................................... 260
File:01icpif.ex
Update:Tue Mar 4 08:50:44 1997

1
Introduction
*
[II00300(ALL)01/96]
Ford's Commitment to You
*
[II00400(ALL)01/96]
At Ford Motor Company, excellence is the
continuous commitment to achieve the best
result possible. It is dedication to learning what
you want, determination to develop the right
concept, and execution of that concept with care,
precision, and attention to detail. In short,
excellence means being the standard by which
others are judged.
*
[II00500(ALL)01/96]
Our Guiding Principles
*
[II00600(ALL)01/96]
q
Quality comes first.For your satisfaction, the
quality of our products and services must be
our number one priority.
*
[II00700(ALL)01/96]
q
You are the focus of everything we do.Our
work must be done with you in mind,
providing better products and services than
our competition.
*
[II00750(ALL)01/96]
q
Continuous improvement is essential to our
success.We must strive for excellence in
everything we do: in our products Ð in their
safety and value Ð and in our services, our
human relations, our competitiveness, and
our profitability.
*
[II00800(ALL)01/96]
q
Employee involvement is our way of life.
We are a team. We must treat one another
with trust and respect.
*
[II00900(ALL)01/96]
q
Dealers and suppliers are our partners.We
must maintain mutually beneficial
relationships with dealers, suppliers, and our
other business associates.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997

3 %
*
[II01090(ALL)01/96]
Canadian Owners Ð French Version
*
[II01100(ALL)01/96]
French Owner Guides can be obtained from your
dealer or by writing to Ford Motor Company of
Canada, Limited, Service Publications, P.O. Box
1580, Station B, Mississauga, Ontario L4Y 4G3.
%
*
[II02400(ALL)01/96]
Your Maintenance Schedule and
Record Booklet
*
[II02500(ALL)03/96]
TheMaintenance Schedulebooklet lists the
services that are most important for keeping
your vehicle in good condition. A record log is
also provided to help you keep track of all
services performed.
%
*
[II02600(ALL)01/96]
About the Warranties
*
[II02700(ALL)01/96]
Your vehicle is covered by three types of
warranties:Basic Vehicle Warranty,Extended
Warrantieson certain parts, andEmissions
Warranties.
%*
[II03100(ALL)01/96]
Read yourWarranty Information Bookletcarefully
to find out about your vehicle's warranties and
your basic rights and responsibilities.
*
[II03250(ALL)03/96]
If you lose yourWarranty Information Booklet,you
can get a new one free of charge. Contact any
Ford or Lincoln-Mercury dealer, or refer to the
addresses and phone numbers on the first page
of this Owner's Guide.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997

4 %
*
[II04000(ALL)03/96]
Ford Extended Service Plan
*
[II04100(ALL)04/96]
More Protection for Your Vehicle
*
[II04200(ALL)04/96]
You can get more protection for your new car or
light truck by purchasing a Ford Extended
Service Plan (Ford ESP). Ford ESP is the only
extended service program with the Ford name
on it and the only service contract backed by
Ford Motor Company.
*
[II04300(ALL)04/96]
Ford ESP is an optional service contract, backed
and administered by Ford. It provides:
*
[II04400(ALL)04/96]
q
protection against repair costs after your
Bumper to Bumper Warranty expires;
*
[II04500(ALL)04/96]
and
*
[II04600(ALL)04/96]
q
other benefits during the warranty period
(such as: reimbursement for rentals; coverage
for certain maintenance and wear items).
*
[II04700(ALL)04/96]
You may purchase Ford ESP from any
participating Ford Motor Company dealer. There
are several Ford ESP plans available in various
time-and-mileage combinations. Each plan can be
tailored to fit your own driving needs, including
reimbursement benefits for towing and rental.
(In Hawaii, rules vary. See your dealer for
details.)
*
[II04800(ALL)04/96]
When you purchase Ford ESP, you receive
peace-of-mind protection throughout the United
States and Canada, provided by a network of
more than 5,100 participating Ford Motor
Company dealers.
*
[II04850(ALL)04/96]
NOTE: Repairs performed outside the United
States and Canada are not eligible for
ESP coverage.
*
[II04900(ALL)04/96]
This information is subject to change, ask your
dealer for complete details about Ford ESP
coverage.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997

13 %
*
[IS05300(ALL)03/96]
Check Engine Warning Light
*
[IS05400(ALL)04/96]
This light illuminates when the electronic engine
control system is not working properly. This is
the computer system that controls the operating
conditions of the engine.
*
[IS05450(ALL)01/96]
one inch art:0030175-B
Check engine warning light
*
[IS05600(ALL)04/96]
This light illuminates briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
illuminate when you turn the ignition to the ON
position or if it illuminates and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
*
[IS05800(ALL)04/96]
If the light flashes briefly while you are driving,
it means that the condition is no longer present.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997

14 %
*
[IS05825(ALL)03/96]
Air Bag Readiness Light
*
[IS05850(ALL)03/96]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
[IS05875(ALL)01/96]
one inch art:0032124-A
Air bag readiness light
[IS05900(ALL)01/96]
Rear Window Defroster Indicator Light
(If equipped)
[IS05925(ALL)01/96]
When the rear window defroster is activated, the
indicator light in the instrument cluster
illuminates. After the rear window is clear, push
the defroster switch to turn off the defroster. The
light in the cluster goes out.
[IS05950(ALL)01/96]
one inch art:0032125-A
Rear window defroster indicator light
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997

15 %
*
[IS05975(ALL)01/96]
Anti-lock Brake System Warning Light
(If equipped)
[IS06000(ALL)04/96]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light illuminates. When the engine is started, the
Anti-lock Brake System (ABS) control unit
determines if all components of the system are
operating correctly. The warning light could
remain on up to 60 seconds.
[IS06025(ALL)01/96]
one inch art:0032123-B
Anti-lock brake system light
*
[IS06050(ALL)03/96]
WARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[IS06060(ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997

17 %
*
[IS06400(ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS06500(ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS06600(ALL)04/96]
The pointer normally moves from C (cold) into
the normal band as your vehicle warms up.
Under most driving conditions, the pointer
should stay in the normal band. If you are
driving in heavy traffic or on an extended grade
in hot weather, the pointer may reach to the top
of the normal band.
*
[IS06700(ALL)04/96]
If, under any circumstances, the pointer moves
above the normal band, the engine is
overheating and continued operation may cause
engine damage.
*
[IS06800(ALL)03/96]
If your engine overheats:
*
[IS06900(ALL)03/96]
1. Pull off the road as soon as safely possible.
*
[IS07000(ALL)01/96]
2. Turn off the engine.
*
[IS07100(ALL)01/96]
3. Let the engine cool.
*
[IS07200(ALL)01/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. (SeeEngine coolantin the
Index.) If you do not follow these
instructions, you or others could be injured.
*
[IS07300(ALL)04/96]
5. Refer toAdding Engine Coolantin the
Maintenance and Carechapter. Add as much
coolant as your engine needs. If the engine
continues to overheat, have the cooling
system serviced.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
