Downloaded from www.Manualslib.com manuals search engine BE03H−03
Z09299
Left/Light
Adjustment
Switch
Control Switch
Z04379
Z04380
− BODY ELECTRICALPOWER MIRROR CONTROL SYSTEM
BE−57
1996 TOYOTA T100 (RM449U)
INSPECTION
1. INSPECT MIRROR SWITCH CONTINUITY
Left side:
Switch positionTester connectionSpecified condition
UP3 − 4
1 − 8Continuity
DOWN1 − 3
4 − 8Continuity
LEFT3 − 4
1 − 7Continuity
RIGHT1 − 3
4 − 7Continuity
Right side:
Switch positionTester connectionSpecified condition
UP3 − 4
1 − 5Continuity
DOWN1 − 3
4 − 5Continuity
LEFT3 − 4
1 − 6Continuity
RIGHT1 − 3
4 − 6Continuity
If continuity is not as specified, replace the switch.
2. INSPECT MIRROR MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and negative (−) lead to terminal 1. Check that the mirror
turns to left side.
(b) Remove the polarity, check that the mirror turns to right
side.

Downloaded from www.Manualslib.com manuals search engine BO0FD−02
BO0632
BO0633
15°
45°
N15359
BO−50
− BODYSEAT BELT
1996 TOYOTA T100 (RM449U)
INSPECTION
CAUTION:
Replace the seat belt assembly (outer belt, inner belt, bolts
or nuts and sill−bar) if it has been used in a severe impact.
The entire assembly should be replaced even if damage is
not obvious.
1. All seat belts:
RUNNING TEST (IN SAFE AREA)
(a) Fasten the seat belts.
(b) Drive the car at 10 mph (16 km/h) and make a very hard
stop.
(c) Check that the seat belt is locked and cannot be extended
at this time.
HINT:
Conduct this test in a safe area. If the belt does not lock, remove
the belt mechanism assembly and conduct the following static
check. Also, whenever installing a new belt assembly, verify the
proper operation before installation.
2. All seat belts:
STATIC TEST
(a) Make sure that the belt locks when pulled out quickly.
(b) Remove the locking retractor assembly.
(c) Tilt the retractor slowly.
(d) Make sure that the belt can be pulled out at a tilt of 15 de-
grees or less, and cannot be pulled out at over 45 degrees
of tilt.
If a problem is found, replace the assembly.
3. Except driver’s seat belt:
STATIC TEST
(a) Pull out the whole belt, release it slightly and then pull it
out again.
(b) Make sure that the belt cannot be extended further.
If a problem is found, replace the assembly.
4. Manual type seat belt:
TEST
(a) Adjust the belt to the proper length.
(b) Apply a firm load to the belt.
(c) Make sure that the belt does not extend.

Downloaded from www.Manualslib.com manuals search engine AC0GN−02
I02282
OFF ON
64
I02283
OFF ON
6 4
3
Z07777
1
3 4 65
− AIR CONDITIONINGAIR CONDITIONING SWITCH
AC−83
1996 TOYOTA T100 (RM449U)
INSPECTION
1. INSPECT A/C INDICATOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
6 and negative (−) lead to terminal 4 and check that the
indicator lights up, when A/C switch ON.
(b) Connect the positive (+) lead from the battery to terminal
3 and check that the indicator dims
If operations are not as specified, replace the A/C switch.
2. INSPECT A/C SWITCH CONTINUITY
Condition/ CircuitTester connectionSpecified condition
OFF−No continuity
ON4 − 5
4 − 6Continuity
Illumination circuit3 − 1Continuity
If continuity is not as specified, replace the A/C switch

Downloaded from www.Manualslib.com manuals search engine AC0GV−02
N05735
FRESH Clamp
RECIRC
N05736
Clamp
DEF
FACE
N05734
Clamp
COOL
WARM
− AIR CONDITIONINGHEATER CONTROL ASSEMBLY
AC−91
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page
AC−87).
1. AFTER INSTALLATION, INSPECT HEATER CONTROL
LEVER OPERATION
Move the control lever and dials left and right check for stiffness
and binding the full range of the lever.
If there is stiffness and binding, proceed next step.
2. ADJUST HEATER CONTROL CABLES
(a) Set heater control assembly in these conditions:
(1) Air inlet control lever in ”FRESH” position
(2) Mode control lever in ”FACE” position
(3) Temperature control lever in ”Max. WARM” position
(b) Adjust the air inlet control cable.
Set the air inlet damper control damper on ”FRESH” posi-
tion, install the control cable and lock the clamp.
HINT:
Lock the clamp during lightly pushing the outer cable in the
direction shown by arrow.
(c) Adjust mode control cable.
Set the air inlet damper control damper on ”FACE” posi-
tion, install the control cable and lock the clamp.
HINT:
Lock the clamp during lightly pulling the outer cable in the direc-
tion shown by arrow.
(d) Adjust air mix control cable.
Set the air inlet damper control damper on ”WARM” posi-
tion, install the control cable and lock the clamp.
HINT:
Lock the clamp during lightly pulling the outer cable in the direc-
tion shown by arrow.
