− AUTOMATIC TRANSMISSIONPARKING LOCK PAWL
AT−17
1358 Author: Date:
1996 TOYOTA T100 (RM449U)
PARKING LOCK PAWL
ON−VEHICLE REPAIR
1. REMOVE VALVE BODY (See page AT−12)
2. REMOVE PARKING LOCK PAWL BRACKET
3. REMOVE SPRING FROM PARKING LOCK PAWL
SHAFT
4. REMOVE PARKING LOCK PAWL AND SHAFT
5. INSTALL PARKING LOCK PAWL AND SHAFT
6. INSTALL SPRING TO PARKING LOCK PAWL SHAFT
7. INSTALL PARKING LOCK PAWL BRACKET
Torque: 7.4 N·m (75 kgf·cm, 65 in.·lbf)
HINT:
Push the lock rod fully forward.
Check that the parking lock pawl operates smoothly.
8. INSTALL VALVE BODY (See page AT−12)

Downloaded from www.Manualslib.com manuals search engine AT0ZK−01
AT6684
Q05731
200 mm
(7.87 in.)
0.8 − 1.5 mm (0.031 − 0.59 in) AT−18
− AUTOMATIC TRANSMISSIONTHROTTLE CABLE
1359 Author: Date:
1996 TOYOTA T100 (RM449U)
THROTTLE CABLE
ON−VEHICLE REPAIR
1. DISCONNECT THROTTLE CABLE
(a) Disconnect the cable from the throttle linkage.
(b) Disconnect the cable from the cable clamps in the engine
compartment.
(c) Remove the bolt and disconnect the cable clamp from the
torque converter clutch housing.
2. REMOVE VALVE BODY (See page AT−12)
3. REMOVE THROTTLE CABLE
Remove the retaining bolt and pull out the throttle cable.
4. INSTALL THROTTLE CABLE
(a) Make sure to push it in all the way.
(b) Install the bolt.
5. INSTALL VALVE BODY (See page AT−12)
6. IF THROTTLE CABLE IS NEW, STAKE STOPPER ON
INNER CABLE
HINT:
New cable does not have a staked cable stopper.
(a) Bend the cable so there is a radius of about 200 mm (7.87
in.).
(b) Pull the inner cable lightly until slight resistance is felt, and
hold it there.
(c) Stake the stopper, 0.8 − 1.5 mm (0.031 − 0.059 in.) from
the end of outer cable.
7. CONNECT THROTTLE CABLE
(a) Install the bolt and connect the cable clamp to the torque
converter clutch housing.
(b) Connect the cable to the cable clamps in the engine
compartment.
(c) Connect the cable to the throttle linkage.
8. ADJUST THROTTLE CABLE (See page DI−265)

Downloaded from www.Manualslib.com manuals search engine AT024−01
− AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
AT−19
1360 Author: Date:
1996 TOYOTA T100 (RM449U)
SHIFT LOCK SYSTEM
ON−VEHICLE INSPECTION
CHECK SHIFT LOCK SYSTEM
(a) With depressing the brake pedal, check that the tip of the parking lock cable protrudes from the pedal
bracket.
(b) Set the shift position to the P position. With the brake pedal depressed, check the select lock cancel.
(c) Check that the lock pin has no unusual operation sound.
(d) Remove the center cluster finish lower panel. (See page BO−36)
(1) Check that the sliding rod is protruded when the ignition key plate is turned from LOCK position
to ACC position.
(2) Check that the sliding rod is released when the ignition key plate is turned to LOCK position.
If the key interlock solenoid operation is defective, replace the key cylinder.

Downloaded from www.Manualslib.com manuals search engine AT025−01
Q06987
Shift Lever Sub−Assembly
Control Select Shaft
Control Shaft
Assembly
Shift Lock
Plate Stopper
Control Shaft
Support Sub−Assembly
Parking Lock
Cable Assembly Plate Washer
Snap Ring Shift Lever Plate
Sub−AssemblySlotted Spring PinBushing ClampClamp Boot
Spring
N·m (kgf·cm, ft·lbf) : Specified torque
19 (195, 14)
50 (510,37) BushingSpring
AT−20
− AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
1996 TOYOTA T100 (RM449U)
COMPONENTS

Downloaded from www.Manualslib.com manuals search engine AT026−01
− AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
AT−21
1996 TOYOTA T100 (RM449U)
REMOVAL
(See page SR−13)

Downloaded from www.Manualslib.com manuals search engine AT027−02
Q06988
Q02712
Casing Cap
Q02711
D10995
AT−22
− AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
1996 TOYOTA T100 (RM449U)
DISASSEMBLY
1. REMOVE 3 CLAMPS
2. REMOVE SHIFT LEVER SUB−ASSEMBLY
Remove the nut, bolt and shift lever sub−assembly.
3. REMOVE PARKING LOCK CABLE ASSEMBLY
Loosen the casing cap and remove the parking lock cable as-
sembly and spring.
4. REMOVE SHIFT LEVER PLATE SUB−ASSEMBLY,
CONTROL SELECT SHAFT AND SPRING
(a) Using a pin punch and hammer, tap out the slotted spring
pin and control select shaft.
CAUTION:
Be careful when tapping out the slotted spring pin so that
the spring and control select shaft do not fly out.
(b) Remove the shift lever plate sub−assembly.
5. REMOVE CONTROL SHAFT SUPPORT SUB−
ASSEMBLY
(a) Using a snap ring expander, remove the snap ring.
(b) Remove the plate washer, bushings and control shaft
support sub−assembly.
(c) Remove the shift lock plate stopper.

Downloaded from www.Manualslib.com manuals search engine AT028−02
D10995
Q06989
Q02711
Q02708
Spring
Casing
Cap
Control Select
ShaftControl Shaft
Support Sub−Assembly
Q02712
Casing Cap
− AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
AT−23
1996 TOYOTA T100 (RM449U)
REASSEMBLY
1. INSTALL CONTROL SHAFT SUPPORT
(a) Install the bushings, control shaft support sub−assembly
and plate washer.
(b) Using a snap ring expander, install the snap ring.
2. INSTALL SHIFT LEVER SUB−ASSEMBLY, CONTROL
SELECT SHAFT AND SPRING
(a) Insert the spring and control select shaft.
(b) Install the shift lever sub−assembly with the bolt and nut.
Torque: 19 N·m (195 kgf·cm, 14 ft·lbf)
3. INSTALL SHIFT LEVER PLATE SUB−ASSEMBLY
(a) Install the shift lever plate sub−assembly.
(b) Align the hole of the shift lever plate assembly and hole
of the control select shaft.
(c) Using a pin punch, tap in the slotted spring pin.
4. INSTALL PARKING LOCK CABLE ASSEMBLY
(a) Apply MP grease to the inside sliding surface of the con-
trol shaft support sub−assembly.
(b) Install the parking lock cable assembly to the control shaft
support sub−assembly, as shown.
(c) Tighten the casing cap.
Torque: 50 N·m (510 kgf·cm, 37 ft·lbf)

Downloaded from www.Manualslib.com manuals search engine Q02705
”R” direction
P position
L position
Q06988
AT−24
− AUTOMATIC TRANSMISSIONSHIFT LOCK SYSTEM
1996 TOYOTA T100 (RM449U)
5. CHECK PARKING LOCK CABLE OPERATION
(a) Push the parking lock cable to check that there is no
scraping noise and stopper knocking due to lack of
grease.
(b) Shift the shift lever in P position and check that the lever
is locked when you push the parking lock cable 7 mm
(0.28 in.).
(c) Check that the select lever is released when the parking
lock cable is free.
(d) Measure the freeplay of the tip of the control lever when
the control shaft is in play.
Freeplay: 6 mm (0.24 in.)
(e) Release the select lock and measure the freeplay of the
tip of the control lever when the shift lock plate and stop-
per lock in the shift direction.
Freeplay: 10 mm (0.39 in.)
(f) Shift the shift in P position and check that the shift lock
plate does not contact with the stopper when the control
shaft is rotated towards R position.
(g) With the stopper in operation, release shift lock and check
that shifting from P to R position is prevented when select-
ing a position.
(h) For each shift position from R to L position, check that the
ignition key plate turning from ACC position to LOCK posi-
tion is prevented.
6. INSTALL 3 CLAMPS
7. CHECK SHIFT LOCK SYSTEM
