Acceleration
SideDeceleration
Side
Control
Plate (+)5
4
(−)
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−339
1996 RAV4 (RM447U)
INSPECTION PROCEDURE
1 Check actuator motor.
PREPARATION:
(a) Remove cruise control actuator.
(b) Disconnect actuator connector.
CHECK:
(a) Connect positive + lead to terminal 5 and negative − lead
to terminal 4 of actuator connector (Magnetic clutch ON).
NOTICE:
Do not connect the high tension cables to the wrong bat-
tery terminal.
You will damage the cruise control actuator.
(b) When battery positive voltage is applied to each terminal
of actuator connector, check that the control plate moves
smoothly without hesitating.
Moving directionTerminal No. to connect
Acceleration sidePositive + − 6Negative − − 7
Deceleration sidePositive + − 7Negative − − 6
(c) With the motor rotating as in 2., check that the motor is
stopped by limit switches when the control plate moves to
fully opened or fully closed position.
NG Replace actuator assembly.
OK
2 Check harness and connector between cruise control ECU and actuator motor
(See page IN−30).
NG Repair or replace harness or connector.
OK
Proceed to next circuit inspection shown on matrix chart (See page DI−336).
However, when DTC 11, 14 is displayed, check and replace cruise control ECU.

N21700
FL Block
MAIN Fuse
80 A
BatteryR/B No.2
DOME Fuse
225
7
1J1G
15BATT Cruise Control ECU
L−Y W
15 AL−Y
N17904
DOME Fuse R/B No.2
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−369
1996 RAV4 (RM447U)
Back−up Power Source Circuit
CIRCUIT DESCRIPTION
The ECU back−up power source provides power even when the ignition switch is off and is used for DTC
memory, etc.
WIRING DIAGRAM
INSPECTION PROCEDURE
1 Check DOME fuse.
PREPARATION:
Remove DOME fuse from R/B No.2.
CHECK:
Check continuity of DOME fuse.
OK:
Continuity
NG Check for short in all the harness and
components connected to the DOME fuse
(See attached wiring diagram).
OK
DI42Y−02

N14705BE6053I09124
LOCK
BATT
(−) (+)
DI−370
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 RAV4 (RM447U)
2 Check voltage between terminal BATT of ECU connector and body ground.
PREPARATION:
Remove ECU with connectors still connected.
CHECK:
Measure voltage between terminal BATT of ECU connector
and body ground.
OK:
Voltage: 10 − 16 V
OK Proceed to next circuit inspection shown on
matrix chart (See page DI−336).
NG
Check and repair harness and connector be-
tween battery and ECU.

EM0EH−03
S01361
Compression
Gauge
− ENGINE MECHANICALCOMPRESSION
EM−3
1996 RAV4 (RM447U)
COMPRESSION
INSPECTION
HINT:
If there is lack of power, excessive oil consumption or poor fuel
economy, measure the compression pressure.
1. WARM UP AND STOP ENGINE
Allow the engine to warm up to normal operating temperature.
2. DISCONNECT DISTRIBUTOR CONNECTOR
3. DISCONNECT HIGH−TENSION CORDS FROM SPARK
PLUGS AND IGNITION COIL
4. REMOVE SPARK PLUGS
5. CHECK CYLINDER COMPRESSION PRESSURE
(a) Insert a compression gauge into the spark plug hole.
(b) Fully open the throttle.
(c) While cranking the engine, measure the compression
pressure.
HINT:
Always use a fully charged battery to obtain engine speed of
250 rpm or more.
(d) Repeat steps (a) through (c) for each cylinder.
NOTICE:
This measurement must be done in as short a time as pos-
sible.
Compression pressure:
1,275 kPa (13.0 kgf/cm
2, 185 psi) or more
Minimum pressure: 932 kPa (9.5 kgf/cm
2, 135 psi)
Difference between each cylinder:
98 kPa (1.0 kgf/cm
2, 14 psi) or less
(e) If the cylinder compression in one or more cylinders is low,
pour a small amount of engine oil into the cylinder through
the spark plug hole and repeat steps (a) through (c) for
cylinders with low compression.
If adding oil helps the compression, it is likely that
the piston rings and/or cylinder bore are worn or
damaged.
If pressure stays low, a valve may be sticking or
seating is improper, or there may be leakage past
the gasket.
6. REINSTALL SPARK PLUGS
7. RECONNECT HIGH−TENSION CORDS TO SPARK
PLUGS AND IGNITION COIL

EM0EV−02
A04063
N·m (kgf·cm, ft·lbf) : Specified torque
 Non−reusable part
29 (300, 22)
Hold Down ClampHold Down Clamp
BatteryEngine Hood
Battery Tray
Lower Radiator
HosePS Pump
w/ BracketCharcoal Canister
Battery Tray
IAT Sensor ConnectorAir Cleaner Cap
 Gasket
 Gasket
Fuel Inlet Hose
Fuel Filter
Water Inlet
Upper Radiator
Hose
Heater Hose
PS Pump Drive Belt
Generator Drive
Belt
Accelerator Cable
Generator
Generator Drive Belt
Adjusting Bar
Air Filter
EVAP VSV Connector
Air Cleaner Case
Radiator
Reservoir
Relay Block No. 2
Upper Cover
Relay Block No. 2
Wire Harness
A/C Compressor
Type B Type A
Type B Type A
− ENGINE MECHANICALENGINE UNIT
EM−65
1996 RAV4 (RM447U)
ENGINE UNIT
COMPONENTS

METER, ANALOG
Current flow activates a magnetic
coil which causes a needle to
move, thereby providing a relative
display against a background
calibration. LED (LIGHT EMITTING DIODE)
Upon current flow, these diodes
emit light without producing the
heat of a comparable light. IGNITION COIL
Convert low-voltage DC current
into high-voltage ingition current
for firing the spark plugs. 1. SINGLE
FILAMENT
GROUND
The point at which wiring attaches
to the Body, thereby providing a
return path for an electrical circuit;
without a ground, current cannot
flow.
Current flow causes a headlight
filament to heat up and emit light.
A headlight may have either a
single (1) filament or a double (2)
filament. BATTERY
Stores chemical energy and
converts it into electrical energy.
Provides DC current for the auto's
various electrical circuits.
CAPACITOR (Condenser)
A small holding unit for temporary
storage of electrical voltage.
CIRCUIT BREAKER
Basically a reusable fuse, a circuit
breaker will heat and open if too
much current flows through it. Some
units automatically reset when cool,
others must be manually reset.
DIODE
A semiconductor which allows
current flow in only one direction.
DIODE, ZENER
A diode which allows current flow
in one direction but blocks reverse
flow only up to a specific voltage.
Above that potential, it passes the
excess voltage. This acts as a
simple voltage regulator.
PHOTODIODE
The photodiode is a semiconductor
which controls the current flow
according to the amount of light.
FUSE
A thin metal strip which burns
through when too much current
flows through it, thereby stopping
current flow and protecting a
circuit from damage.
FUSIBLE LINK
A heavy-gauge wire placed in
high amperage circuits which
burns through on overloads,
thereby protecting the circuit.
The numbers indicate the cross-
section surface area of the wires.HORN
An electric device which sounds a
loud audible signal.
LIGHT
Current flow through a filament
causes the filament to heat up
and emit light.
METER, DIGITAL
Current flow activates one or
many LED's, LCD's, or fluorescent
displays, which provide a relative
or digital display.
MOTOR
A power unit which converts
electrical energy into mechanical
energy, especially rotary motion. CIGARETTE LIGHTER
An electric resistance heating
element.
DISTRIBUTOR, IIA
Channels high-voltage current
from the ignition coil to the
individual spark plugs.2. DOUBLE
FILAMENT HEADLIGHTS
FUEL
(for High Current Fuse or
Fusible Link.)
(for Medium Current Fuse)
M
16
E GLOSSARY OF TERMS AND SYMBOLS

11 5
SRS
NOTICE: When inspecting or repairing the SRS, perform the operation in accordance with the following
precautionary instructions and the procedure and precautions in the Repair Manual for the applicable model
year.

Malfunction symptoms of the supplemental restraint system are difficult to confirm, so the diagnostic trouble
codes become the most important source of information when troubleshooting.
When troubleshooting the supplemental restraint system, always inspect the diagnostic trouble codes before
disconnecting the battery.

Work must be started after 90 seconds from the time the ignition SW is turned to the LOCKº position and the
negative (-) terminal cable is disconnected from the battery.
(The supplemental restraint system is equipped with a back-up power source so that if work is started within
90 seconds of disconnecting the negative (-) terminal cable of the battery, the SRS may be activated.)
When the negative (-) terminal cable is disconnected from the battery, the memory of the clock and audio
systems will be canceled. So before starting work, make a record of the contents memorized by each memory
system. When work is finished, reset the clock and audio system as before and adjust the clock.
To avoid erasing the memory of each memory system, never use a back-up power supply from outside the
vehicle.

When removing the steering wheel pad or handling a new steering wheel pad, keep the pad upper surface
facing upward. Also, lock the lock lever of the twin lock type connector at the rear of the pad and take care
not to damage the connector.
(Storing the pad with its metallic surface up may lead to a serious accident if the SRS inflates for some reason.)

Always store a removed or new front passenger airbag assembly with the airbag door facing up. Storing the
airbag assembly with the airbag door facing down could cause a serious accident if the airbag inflates.

Store the steering wheel pad where the ambient temperature remains below 935C (2005F), without high
humidity and away from electrical noise.

Never use SRS parts from another vehicle. When replacing parts, replace them with new parts.

Never disassemble and repair the steering wheel pad, front passenger airbag assembly, airbag sensor
assembly.

Before repairing the body, remove the airbag sensor if during repair shocks are likely to be applied to the
sensors due to vibration of the body or direct tapping with tools or other parts.

Do not reuse a steering wheel pad or front airbag sensors.
After evaluating whether the center airbag sensor assembly is damaged or not, decide whether or not to reuse
it. (See the Repair Manual for the method for evaluating the center airbag sensor assembly.)

When troubleshooting the supplemental restraint system, use a high-impedance (Min. 10kW/V) tester.

The wire harness of the supplemental restraint system is integrated with the instrument panel wire harness
assembly.
The vehicle wiring harness exclusively for the airbag system is distinguished by corrugated yellow tubing, as
are the connectors.

Do not measure the resistance of the airbag squibs.
(It is possible this will deploy the airbag and is very dangerous.)

If the wire harness used in the supplemental restraint system is damaged, replace the whole wire harness
assembly.

INFORMATION LABELS (NOTICES) are attached to the periphery of the SRS components. Follow the
instructions on the notices.

Z13341
Q06243
Q06242
BE2682
MX−74
− MANUAL TRANSAXLEDIFFERENTIAL LOCKING SYSTEM (4WD)
1996 RAV4 (RM447U)
2. INSPECT DIFFERENTIAL LOCK CONTROL COM-
PONENTS
(a) Inspect the differential lock control switch continuity.
Switch PositionTester ConnectionSpecified Condition
OFF (Free)7−10Continuity
ON (Lock)7−8Continuity
Illumination circuit2−3Continuity
If continuity is not as specified, check the bulb or replace the
switch.
(b) Inspect the differential lock warning buzzer.
(1) Remove the combination meter, then remove the
differential lock warning buzzer.
(2) Taking care to match the polarity of the buzzer, ap-
ply battery positive voltage to the terminals of the
buzzer and check that the buzzer sounds.
(c) Inspect the differential lock indicator switch continuity.
Switch PositionTester ConnectionSpecified Condition
Free1 − 2No continuity
Push1 − 2Continuity
If continuity is not as specified, replace the switch.
