1996 TOYOTA RAV4 stop start

Position
NORMALSHIFT SOLENOID NO. 1
MALFUNCTIONING
Solenoid valveNo. 1 No. 2GearSHIFT SOLENOID NO. 2
MALFUNCTIONINGBOTH SOLENOIDS MAL-
FUNCTIONINGSolenoid valve
No. 1 No. 2GearSolenoid valve
No. 1 No. 2GearGear when shift selector is
manually operated
D
2
LON
ONOFF
ON
ON OFF
OFF OFF
ON
ONOFF
ON
ON OFF
ON
ON ONOFF1st
2nd
3rd
O/D
1st
2nd
3rd
1st
2ndX
X
X
X
X
X
X
X
XON
ON
OFF
OFFON
ON
ON3rd 3rd
O/D
3rd
3rd
1st
2ndX
X
X
X
X
X
X
X
X OFF
OFFON
ON OFF OFF
OFF
ON
ON1st
O/D
1st O/D O/D
1st
1stO/D O/D O/D
O/D
1st
1st
X: MalfunctionsON
ON3rd
3rd
3rd
3rd3rd
3rd
3rd
DI−198
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A540H)
1996 RAV4 (RM447U)
DTC P0753, P0758 Shift Solenoid A/B Electrical Malfunc-
tion (Shift Solenoid Valve No. 1/No. 2)
CIRCUIT DESCRIPTION
Shifting from 1st to O/D is done in combination with ON and OFF of the shift solenoid valves No. 1 and No.
2 controlled by ECM. If an open or short circuit occurs in either of the shift solenoid valves, the ECM controls
the remaining normal shift solenoid valve to allow the vehicle to be operated smoothly (Fail safe function).
Fail Safe Function:
If either of the shift solenoid valve circuits develops an open or a short, the ECM turns the other shift solenoid
ON and OFF to shift to the gear positions shown in the table below. The ECM also turns the shift solenoid
valve SL OFF at the same time. If both solenoids are malfunction, hydraulic control cannot be done electroni-
cally so it must be done manually.
Manual shifting as shown in the following table must be done. (In the case of a short circuit, the ECM stops
sending current to the short circuited solenoid).
HINT:
Check the shift solenoid valve No. 1 when DTC P0753 is output and check the shift solenoid valve No. 2
when DTC P0758 is output.
DTC No.DTC Detecting ConditionTrouble Area
P0753
P0758
The ECM checks for an open or short circuit in the shift sole-
noid valves No.1 and No.2 circuit when it changes
The ECM records DTC P0753 or P0758 if condition (a) or (b) is
detected once, but it does not light up the MIL
After ECM detects condition (a) or (b) continuously 2 times or
more in one−trip, it causes the MIL light up until condition (a) or
(b) disappears
After that, if the ECM detects condition (a) or (b) once, it starts
lighting up the MIL
(d) Solenoid resistance is 8 Ω or less short circuit when sole-
noid is energized
(e) Solenoid resistance is 100 kΩ or more open circuit when
solenoid is not energized
Open or short in shift solenoid valve No. 1/No. 2 circuit
Shift solenoid valve No. 1/No. 2
ECM
DI410−01

F15316
E1
TsTc DLC1
BR3904
0.13 sec. 0.13 sec.
ON
OFF
BR3893
72 67
ON
OFF
0.5 sec. 0.5 sec. 0.5 sec. 0.5 sec.1.5 sec.
2.5 sec.4 sec.
Repeat Malfunction Code (Example Code 72, 76) DI−236
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
1996 RAV4 (RM447U)
2. SPEED SENSOR SIGNAL CHECK
(a) Check the speed sensor signal.
(1) Turn the ignition switch OFF.
(2) Using SST, connect terminals Ts and E1 of the
DLC1.
SST 09843−18020
(3) Start the engine.
(4) Check that the ABS warning light blinks.
HINT:
If the ABS warning light does not blink, inspect the ABS warning
light circuit (See page DI−275).
(5) Drive vehicle straight forward.
HINT:
Drive vehicle faster than 45 km/h (28 mph) for several seconds.
(6) Stop the vehicle.
(7) Using SST, connect terminals Tc and E1 of the
DLC1.
SST 09843−18020
(8) Read the number of blinks of the ABS warning light.
HINT:
See the list of DTC shown on the next page.
If every sensor is normal, a normal code is output (A cycle
of 0.25 sec. ON and 0.25 sec. OFF is repeated).
If 2 or more malfunctions are indicated at the same time,
the lowest numbered code will be displayed 1st.
(9) After doing the check, disconnect terminals Ts and
E1, and Tc and E1 of the DLC1, and turn the ignition
switch OFF.

BE6443
(1)
(2)
(1)
No.Operation MethodCRUISE MAIN Indicator Light
Blinking PatternDiagnosis
1 Turn SET/COAST switch ON
2Turn RES/ACC switch ON
3Turn CANCEL switch ON
Turn stop light switch ON
Depress brake pedal
Turn PNP switch OFF
(Shift to except D position)
4Drive at about 40 km/h
(25 mph)or higher
Drive at about 40 km/h
(25 mph) or below
LightON
OFF
LightON
OFF
LightON
OFFSwitch ON
Switch OFF
LightON
OFFSwitch OFF
Switch ONSET/COAST switch circuit
is normal
RES/ACC switch circuit
is normal
CANCEL switch circuit
is normal
Stop light switch circuit
is normal
PNP switch circuit is
normal
Vehicle Speed Sensor is
normal
LightON
OFF LightON
OFF
1sec.
0.25 sec.0.25 sec.
Turn clutch switch OFF
(Depress clutch pedal)Clutch switch circuit
is normal
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−331
1996 RAV4 (RM447U)
4. INPUT SIGNAL CHECK
HINT:
(1) For check No.1 − No.2.
Turn the ignition switch ON.
(2) For check No.3.
Turn ignition switch ON.
Shift to D position. (A/T Vehicle)
(3) For check No.4.
Jack up the vehicle.
Start the engine.
Shift to D position. (A/T Vehicle)
(a) Press the control switch to the SET/COAST or RES/ACC
position and hold it down or hold it up (1).
(b) Push the main switch ON (2).
(c) Check that the CRUISE MAIN indicator light blinks twice
or 3 times repeatedly after 3 seconds.
(d) Turn the SET/COAST or RES/ACC switch OFF.
(e) Operate each switch as listed in the table below.
(f) Read the blinking pattern of the CRUISE MAIN indicator
light.
(g) After performing the check, turn the main switch OFF.
HINT:
When 2 or more signals are input to the ECU, the lowest num-
bered code will be displayed first.

S01590
Disconnect
S01562
Engine Stopped
Air
S01561
Engine
2,500 rpmAir
P02553
− EMISSION CONTROLEXHAUST GAS RECIRCULATION (EGR) SYSTEM
EC−9
1996 RAV4 (RM447U)
HINT:
As a large amount of exhaust gas enters, the engine will misfire
slightly.
7. REMOVE VACUUM GAUGE
Remove the vacuum gauge, and reconnect the vacuum hoses
to the proper locations.
8. INSPECT EGR VALVE
(a) Apply vacuum directly to the EGR valve with the engine
idling.
(b) Check that the engine runs rough or dies.
(c) Reconnect the vacuum hoses to the proper locations.
HINT:
As exhaust gas is increasingly recirculated, the engine will start
to misfire.
9. REMOVE SST FROM DLC1 (See page SF−1)
SST 09843−18020
10. INSPECT EGR VACUUM MODULATOR OPERATION
(a) Disconnect the vacuum hoses from ports P, Q and R of
the EGR vacuum modulator.
(b) Block ports P and R with your finger.
(c) Blow air into port Q, and check that the air passes through
to the air filter side freely.
(d) Start the engine, and maintain speed at 2,500 rpm.
(e) Repeat the above test. Check that there is a strong resis-
tance to air flow.
(f) Reconnect the vacuum hoses to the proper locations.
11. REMOVE THROTTLE BODY (See page SF−30)
12. REMOVE EGR VALVE
13. INSPECT EGR VALVE
Check for sticking and heavy carbon deposits.
If a problem is found, replace the valve.

MX0C0−02
Q06152
− MANUAL TRANSAXLEDIFFERENTIAL LOCKING SYSTEM (4WD)
MX−73
1996 RAV4 (RM447U)
INSPECTION
1. INSPECT CENTER DIFFERENTIAL LOCK SYSTEM
(a) Inspect the differential lock operation.
(1) Use a lift or jack stand to lift up the vehicle so that
all 4 tires can rotate.
(2) Apply the parking brake and start the engine.
(3) Set the center differential lock switch to ON.
(4) Depress the clutch pedal and shift into the 2nd gear.
(5) With the engine idling, gradually engage the clutch
and check that the engine stops.
(6) With the parking brake and engine ON, turn the cen-
ter differential lock switch OFF.
(7) Depress the clutch pedal and shift into the 2nd gear.
(8) With the engine idling, gradually engage the clutch
and check that the front wheels rotate.
HINT:
This inspection must be done when the engine is idling.
(b) Inspect the center differential lock indicator operation.
(1) Turn the ignition switch ON.
(2) Check that when the differential lock switch is
turned ON and OFF, the differential lock indicator
lamp lights up and goes off, respectively.
(c) Inspect the center differential lock warning buzzer opera-
tion.
(1) Start the engine and check that the differential lock
warning buzzer does not sound when the center dif-
ferential lock switch is turned ON.
(2) Interchange the solenoid hose No.1 and solenoid
hose No.2 between the differential lock control sole-
noid No.1 and No.2 and the differential lock actua-
tor. And check that the differential lock warning
buzzer sounds when the differential lock switch is
turned OFF.
(3) Return the solenoid hose No.1 and solenoid hose
No.2 to their original location, and check that the dif-
ferential lock warning buzzer stops.
HINT:
Do the inspection with the vehicle stopped.
After finishing the inspection, inspect the differential lock
control solenoid hoses.

FI2553
SST
S01837
Fuel
Pump
Connector
S01832
Plug SF−2
− SFISFI SYSTEM
1996 RAV4 (RM447U)
(b) When installing the battery, be especially careful not to in-
correctly connect the positive (+) and negative (−) cables.
(c) Do not permit parts to receive a severe impact during re-
moval or installation. Handle all SFI parts carefully, espe-
cially the ECM.
(d) Do not be careless during troubleshooting as there are
numerous transistor circuits and even slight terminal con-
tact can cause further troubles.
(e) Do not open the ECM cover.
(f) When inspecting during rainy weather, take care to pre-
vent entry of water. Also, when washing the engine
compartment, prevent water from getting on the SFI parts
and wiring connectors.
(g) Parts should be replaced as an assembly.
(h) Care is required when pulling out and inserting wiring con-
nectors.
(i) Release the lock and pull out the connector, pulling on the
connectors.
(j) Fully insert the connector and check that it is locked.
(k) Use SST for inspection or test of the injector or its wiring
connector.
SST 09842−30070
8. FUEL SYSTEM
(a) When disconnecting the high fuel pressure line, a large
amount of gasoline will spill out, so observe the following
procedures:
(1) Disconnect the fuel pump connector.
(2) Start the engine. After the engine has stopped on
its own, turn the ignition switch to LOCK.
(3) Put a container under the connection.
(4) Slowly loosen the connection.
(5) Disconnect the connection.
(6) Plug the connection with a rubber plug.

S01834
Gasket
SST (Union)
SST
Fuel Inlet Hose Gasket
SST (Union)
S01835
301 − 347 kPa
S01836
For 5 Minutes After Engine has Stopped
147 kPa
or More SF−6
− SFIFUEL PUMP
1996 RAV4 (RM447U)
(f) Install the fuel inlet hose and SST (pressure gauge) to the
fuel filter outlet with the 3 gaskets and SST (union bolt).
SST 09268−45012
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(g) Wipe off any splattered gasoline.
(h) Connect the TOYOTA hand−held tester to the DLC3.
(i) Reconnect the negative (−) terminal cable to the battery.
(j) Turn the ignition switch ON.
(k) Measure the fuel pressure.
Fuel pressure:
301 − 347 kPa (3.1 − 3.5 kgf/cm
2, 44 − 50 psi)
If pressure is high, replace the fuel pressure regulator.
If pressure is low, check these parts:
Fuel hoses and connections
Fuel pump
Fuel filter
Fuel pressure regulator
(l) Remove the TOYOTA hand−held tester from the DLC3.
(m) Start the engine.
(n) Measure the fuel pressure at idle.
Fuel pressure:
301 − 347 kPa (3.1 − 3.5 kgf/cm
2, 44 − 50 psi)
(o) Stop the engine.
(p) Check that the fuel pressure remains as specified for 5
minutes after the engine has stopped.
Fuel pressure:
147 kPa (1.5 kgf/cm
2, 21 psi) or more
If pressure is not as specified, check the fuel pump, pressure
regulator and/or injectors.
(q) After checking fuel pressure, disconnect the negative (−)
terminal cable from the battery and carefully remove the
SST to prevent gasoline from splashing.
SST 09268−45012
(r) Reconnect the fuel inlet hose with 2 new gaskets and the
union bolt.
Torque: 29 N·m (300 kgf·cm, 21 ft·lbf)
(s) Reconnect the negative (−) terminal cable to the battery.
(t) Check for fuel leakage (See page SF−1).
(u) Reinstall the engine comportment R/B No.2 and air clean-
er assembly.
3. CHECK FUEL PUMP
(a) Remove the LH rear seat assembly.
(b) Remove the floor service hole cover.

S01898
SF0QO−03
S01946
P
E
R
S00037
Ohmmeter
Throttle Position Sensor
VC
VTA
E2
S01901
Disconnect
Plug
− SFITHROTTLE BODY
SF−27
1996 RAV4 (RM447U)
THROTTLE BODY
ON−VEHICLE INSPECTION
1. INSPECT THROTTLE BODY
(a) Check that the throttle linkage moves smoothly.
(b) Check the vacuum at each port.
Start the engine.
Check the vacuum with your finger.
Port nameAt idleOther than idle
PNo vacuumVacuum
ENo vacuumVacuum
RNo vacuumNo vacuum
2. INSPECT THROTTLE POSITION SENSOR
(a) Apply vacuum to the throttle opener.
(b) Disconnect the sensor connector.
(c) Using an ohmmeter, measure the resistance between
each terminal.
Clearance between
lever and stop screwBetween
terminalsResistance
0 mm (0 in.)VTA − E20.2 − 5.7 kΩ
Throttle valve fully
openVTA − E22.0 − 10.2 kΩ
−VC − E22.5 − 5.9 kΩ
(d) Reconnect the sensor connector.
3. INSPECT AND ADJUST THROTTLE OPENER
4. WARM UP ENGINE
Allow the engine to warm up to normal operating temperature.
5. CHECK IDLE SPEED
Idle speed: 700 ± 50 rpm
6. CHECK AND ADJUST THROTTLE OPENER SETTING
SPEED
(a) Disconnect the vacuum hose from the throttle opener,
and plug the hose end.
(b) Maintain the engine at 2,500 rpm.
(c) Release the throttle valve.
(d) Check that the throttle opener is set.
Throttle opener setting speed:
1,300 − 1,500 rpm (w/ cooling fan OFF)
