Fuel Inlet Hose
ON
DI−120
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
OBDII scan tool (exculding TOYOTA hand−held tester)
1 Check fuel pump operation.
PREPARATION:
(a) Remove side trim cover (See page SF−61).
(b) Turn ignition switch ON.
CHECK:
(a) Connect between terminal FC of ECM and body ground.
(b) Check for fuel pressure in the inlet hose when it is pinched
off.
OK:
There is pressure in the inlet hose.
HINT:
At this time, you will hear a fuel flowing noise.
OK Check for starter signal circuit (See page
DI−105).
NG
2 Check for ECM power source circuit (See page DI−11 3).
NG Repair or replace.
OK
3 Check circuit opening relay (See page SF−40).
NG Replace circuit opening relay.
OK

− DIAGNOSTICSENGINE
DI−121
1996 RAV4 (RM447U)
4 Check voltage between terminal FC of ECM and body ground (See page DI−11 6,
step 4).
NG Check for open in harness and connector be-
tween EFI main relay (Marking: EFI) and circuit
opening relay, circuit opening relay and ECM.
OK
5 Check fuel pump (See page SF−5).
NG Repair or replace fuel pump.
OK
6 Check for open in harness and connector between circuit opening relay and fuel
pump, fuel pump and body ground (See page IN−30).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN−30).

S02412
A/C Amplifier
B+
R−Y
E621
ACTECM
E1 7 DI−122
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
A/C Cut Control Circuit
CIRCUIT DESCRIPTION
This circuit cuts air conditioning operation during vehicle acceleration in order to increase acceleration per-
formance. During acceleration with the vehicle speed at 25 km/h (16 mph) or less, engine speed at 1,200
rpm or less and throttle valve opening angle at 60° or more, the A/C magnet switch is turned OFF for several
seconds.
WIRING DIAGRAM
DI408−01

− DIAGNOSTICSENGINE
DI−123
1996 RAV4 (RM447U)
INSPECTION PROCEDURE
TOYOTA hand−held tester:
1 Connect the TOYOTA hand−held tester and check operation of air conditioning
cut control.
PREPARATION:
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Turn ignition switch ON and TOYOTA hand−held tester main switch ON.
(c) Starter the engine and air conditioning switch ON.
HINT:
A/C magnet clutch is turned ON.
(d) Select the ACTIVE TEST mode on the TOYOTA hand−held tester.
CHECK:
Check operation of A/C magnet clutch cut when air conditioning cut control is operated by the TOYOTA
hand−held tester.
OK:
A/C magnet clutch is turned OFF.
OK Proceed to next circuit inspection shown on
matrix chart (See page DI−20).
NG
2 Check for open and short in harness and connector between ECM and A/C am-
plifier (See page IN−30).
NG Repair or replace harness or connector.
OK

P23738
ACT
(+)
DI−124
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
3 Check voltage between terminal ACT of ECM and body ground.
PREPARATION:
(a) Remove side trim cover (See page SF−61).
(b) Start the engine.
CHECK:
Measure voltage between terminal ACT of ECM connector and
body ground when A/C switch is turned to ON and OFF.
OK:
A/C switch conditionVoltage
ON9 − 14 V
OFFBelow 2.0 V
NG Check and replace A/C amplifier.
OK
Check and replace ECM (See page IN−30).
OBDII scan tool (excluding TOYOTA hand−held tester)
1 Check voltage between terminal ACT of ECM and body ground (See same page,
step 3).
OK Check and replace ECM (See page IN−30).
NG
2 Check for open and short in harness connector between ECM and A/C amplifier
(See page IN−30).
NG Repair or replace harness or connector.
OK
Check and replace A/C amplifier.

Q08848
DI−128
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U)
The diagnosis system operates in normal mode
during normal vehicle use, and also has a check
mode for technicians to simulate malfunction symp-
toms and perform troubleshooting. Most DTCs use
2 trip detection logic (*) to prevent erroneous detec-
tion. By switching the ECM to check mode when
troubleshooting, the technician can cause the MIL
to light up for a malfunction that is only detected
once or momentarily (TOYOTA hand−held tester)
(See page DI−127).
*2 trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the second test
drive, this second detection causes the MIL to light up.
2. Normal Mode:
INSPECT DIAGNOSIS
(a) Check the MIL.
(1) The MIL lights up when the ignition switch is turned
ON and the engine is not running.
HINT:
If the MIL does not light up, troubleshoot the combination meter
(See page BE−2).
(2) When the engine starts, the MIL should go off. If the
lamp remains on, the diagnosis system has de-
tected a malfunction or abnormality in the system.
(b) Check the DTC.
NOTICE:
TOYOTA hand−held tester only:
When the diagnostic system is switched from the normal
mode to the check mode, it erases all DTCs and freezed
frame data recorded in the normal mode. So before switch-
ing modes, always check the DTCs and freezed frame data,
and note them down.
(1) Prepare the OBD II scan tool (complying with SAE
J1978) or TOYOTA hand−held tester.
(2) Connect the OBD II scan tool or TOYOTA hand−
held tester to the DLC3.
(3) Turn the ignition switch ON and turn the OBD II scan
tool or TOYOTA hand−held tester switch ON.
(4) Use the OBD II scan tool or TOYOTA hand−held
tester to check the DTCs and freezed frame data.
Note them down (For operating instructions, see
the OBDII scan tool’s instruction book.).

FI3605
013 sec. ON
OFF
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−129
1996 RAV4 (RM447U)
(5) See page DI−138 to confirm the details of the
DTCs.
NOTICE:
When simulating symptoms with an OBD II scan tool (ex-
cluding TOYOTA hand−held tester) to check the DTCs, use
the normal mode. For codes on the DTC chart subject to ”2
trip detection logic”, turn the ignition switch off after the
symptoms have been simulated for the first time. Then re-
peat the simulation process again. When the program has
been simulated twice, the MIL lights up and the DTCs are
recorded in the ECM.
3. Check Mode:
INSPECT DIAGNOSIS
HINT:
TOYOTA hand−held tester only:
Compared to the normal mode, the check mode has high sens-
ing ability to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check mode.
(a) Check the DTC.
(1) Initial conditions.
Battery positive voltage 11 V or more
Throttle valve fully closed
Transaxle in the PARK position
Air conditioning switched off
(2) Prepare the TOYOTA hand−held tester.
(3) Connect the TOYOTA hand−held tester to the
DLC3.
(4) Turn the ignition switch ON and switch the TOYOTA
hand−held tester ON.
(5) Switch the TOYOTA hand−held tester from the nor-
mal mode to the check mode (Check that the MIL
flashes.).
(6) Start the engine (The MIL goes off after the engine
start.).
(7) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTCs, etc.
(8) After simulating the malfunction conditions, use the
TOYOTA hand−held tester diagnosis selector to
check the DTCs and freezed frame data, etc.
HINT:
Take care not to turn the ignition switch OFF.
Turning the ignition switch off switches the diagnosis system
from check mode to normal mode, so all DTCs, etc. are erased.
(9) After checking the DTC, inspect the applicable cir-
cuit.

− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−131
1996 RAV4 (RM447U)
4. CHECK FOR INTERMITTENT PROBLEMS
TOYOTA hand−held tester only:
By putting the vehicle’s ECM in check mode, 1 trip detection logic is possible instead of 2 trip detection logic
and sensitivity to detect open circuits is increased. This makes it easier to detect intermittent problems.
(1) Clear the DTCs (See step 3).
(2) Set the check mode (See step 3).
(3) Do simulation test (See page IN−20).
(4) Check the connector connection and terminal (See page IN−30).
(5) Visual check and contact pressure (See page IN−20).
(6) Handle the connector (See page IN−20).
5. PROBLEM SYMPTOM CONFIRMATION
Taking into consideration the results of the customer problem analysis, try to reproduce the symptoms of the
trouble. If the problem is that the transaxle does not up−shift, down−shift, or the shift point is too high or too
low, conduct the following road test to confirm the automatic shift schedule and simulate the problem symp-
toms.
6. ROAD TEST
NOTICE:
Do the test at normal operating ATF temperature 50 − 80°C (122 − 176°F).
(a) D position test.
Shift into the D position, keep the accelerator pedal constant at the full throttle valve opening position
and check the following points:
(1) Check up− shift operation.
Check that 1 → 2, 2 → 3 and 3 → O/D up−shift takes place, at the shift point shown in the automat-
ic shift schedule (See page SS−32).
HINT:
O/D Gear Up−shift Prohibition Control:
Engine coolant temperature is 50°C (122°F) or less.
If there is a 10km/h (6 mph) difference between the set cruise control speed and vehicle speed.
O/D main switch is pushed ON (During the O/D OFF indicator light lights up.).
O/D Gear Lock−up Prohibition Control:
Brake pedal is depressed.
Engine coolant temperature is 50°C (122°F) or less.
(2) Check for shift shock and slip.
Check for shock and slip at the 1 → 2, 2 → 3 and 3 → O/D up−shifts.
(3) Check for abnormal noise and vibration.
Run at the D position lock−up or O/D gear and check for abnormal noise and vibration.
HINT:
The check for the cause of abnormal noise and vibration must be performed very thoroughly as it could also
be due to loss of balance in the torque converter clutch, etc.
(4) Check kick−down operation.
While running in the D position, 2nd, 3rd and O/D gears, check that the possible kick−down ve-
hicle speed limits for 2 → 1, 3 → 2 and O/D → 3 kick−downs conform to those indicated on the
automatic shift schedule (See page SS−32).
(5) Check abnormal shock and slip at kick−down.
(6) Check the lock−up mechanism.
Drive in the D position, O/D gear, at a steady speed (lock−up ON) of about 75 km/h (47
mph).
Lightly depress the accelerator pedal and check that the RPM does not change abruptly.
If there is a big jump in RPM, there is no lock−up.
