− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U)
(b) 2 position test.
Shift into the 2 position and, while drive with the accelerator pedal held constantly at the full throttle
valve opening position, check on the following points:
(1) Check up−shift operation.
Check that the 1 → 2 up−shift takes place and that the shift point conforms to the automatic shift
schedule (See page SS−32).
HINT:
There is no O/D up−shift and lock−up in the 2 position.
(2) Check engine braking.
While running in the 2nd gear of the 2 position, release the accelerator pedal and check the en-
gine braking effect.
(3) Check for abnormal noises during acceleration and deceleration, and for shock at up−shift and
down−shift.
(c) L position test.
Shift into the L position and while driving with the accelerator pedal held constantly at the full throttle
valve opening position, check the following points:
(1) Check no up−shift.
While running in the L position, check that there in no up−shift to 2nd gear.
(2) Check engine braking.
While running in the L position, release the accelerator pedal and check the engine braking ef-
fect.
(3) Check for abnormal noises during acceleration and deceleration.
(d) R position test.
Shift into the R position and while starting at full throttle, check for slipping.
CAUTION:
Before conducting this test ensure that the test area is free from personnel and obstructions.
(e) P position test.
Stop the vehicle on a gradient (more than 5°) and after shifting into the P position, release the parking
brake. Then check that the parking lock pawl holds the vehicle in place.
7. BASIC INSPECTION
(a) Check the fluid level.
HINT:
Drive the vehicle so that the engine and transaxle are at
normal operating temperature.
Fluid temperature: 70 − 80°C (158 − 176°F)
Only use the COOL range on the dipstick as a rough refer-
ence when the fluid is replaced or the engine does not
run.
(1) Park the vehicle on a level surface and set the park-
ing brake.
(2) With the engine idling and the brake pedal de-
pressed, shift the shift lever into all positions from
the P to L position and return to the P position.
(3) Pull out the oil level gauge and wipe it clean.
(4) Push it back fully into the pipe.
(5) Pull it out and check that the fluid level is in the HOT
range.
If the level is at the low side, add new fluid.

OR0028
Q06076
AT3417
OK if hot
Add if hot
AT4252
0 − 1 mm
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−133
1996 RAV4 (RM447U)
Fluid type: ATF DEXRON ®II
NOTICE:
Do not overfill.
(b) Check the fluid condition.
If the fluid smells burnt or is black, replace it.
(c) Replace the fluid.
(1) Remove the drain plug and drain the fluid.
(2) Reinstall the drain plug securely.
(3) With the engine OFF, add new fluid through the oil
filler pipe.
Fluid type: ATF DEXRON ®II
Capacity:
Drain and refill: 3.3 liters (3.5 US qts, 2.9 lmp. qts)
(4) Start the engine and shift the shift lever into all posi-
tions from P to L position and then shift into P posi-
tion.
(5) With the engine idling, check the fluid level. Add
fluid up to the COOL level on the dipstick.
(6) Check the fluid level at the normal operating tem-
perature 70 − 80°C (158 − 176°F) and add as nec-
essary.
NOTICE:
Do not overfill.
(d) Check the fluid leaks.
Check for leaks in the transaxle.
If there are leaks, it is necessary to replace O−rings, gaskets,
oil seals, plugs or other parts.
(e) Inspect and adjust throttle cable.
(1) Check that the throttle valve is fully closed.
(2) Check that the inner cable is not slack.
(3) Measure the distance between the outer cable end
and stopper on the cable.
Standard distance: 0 − 1 mm (0 − 0.04 in.)
If the distance is not within the standard, adjust the cable by the
adjusting nuts.

Q08832
Q08831N
RP
Q07907
Neutral
Basic
Line
Groove
DI−134
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U)
(f) Inspect and adjust shift lever position.
When shifting the shift lever from the N position to other
positions, check that the lever can be shifted smoothly
and accurately to each position and that the position indi-
cator correctly indicates the position.
If the indicator is not aligned with the correct position, carry out
the following adjustment procedures:
(1) Loosen the nut on the control shaft lever.
(2) Push the control shaft lever fully downward.
(3) Return the control shaft lever 2 notches to the N
position.
(4) Set the shift lever to the N position.
(5) While holding the shift lever lightly toward the R
position side, tighten the shift lever nut.
Torque: 6.9 N·m (70 kgf·cm, 61 in·lbf)
(6) Start the engine and make sure that the vehicle
moves forward when shifting the lever from the N to
D position and reverses when shifting it to the R
position.
(g) Inspect and adjust park/neutral position switch.
Check that the engine can be started with the shift lever
only in the N or P position, but not in other positions.
If not as stated above, carry out the following adjustment proce-
dure:
(1) Loosen the park/neutral position switch bolt and set
the shift lever to the N position.
(2) Align the groove and neutral basic line.
(3) Hold in position and tighten the bolt.
Torque: 5.4 N·m (55 kgf·cm, 48 in·lbf)
HINT:
For continuity inspection of the park/neutral position switch, see
page DI−156.
(h) Inspect the idle speed.
Idle speed: 700 ± 50 rpm (In N position and A/C OFF)
8. MECHANICAL SYSTEM TESTS
(a) Measure the stall test
The object of this test is to check the overall performance of the transaxle and engine by measuring
the stall speeds in the D and R positions.
NOTICE:
Do the test at normal operation ATF temperature 50 − 80°C (122 − 176°F).
Do not continuously run this test longer than 5 seconds.
To ensure safety, conduct this test in a wide, clear, level area which provides good traction.
The stall test should be always carried out in pairs. One technician should observe the condi-
tions of wheels or wheel stoppers outside the vehicle while the other is doing the test.
(1) Chock the 4 wheels.
(2) Fully apply the parking brake.
(3) Connect OBD II scan tool or TOYOTA hand−held tester to the DLC3.

− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−135
1996 RAV4 (RM447U)
(4) Start the engine and check idle speed.
(5) Keep your left foot pressed firmly on the brake pedal.
(6) Shift into the D position. Fully depress the accelerator pedal. Quickly read the stall speed at this
time.
Stall speed: 2,370 ± 150 rpm
(7) Do the same test in R position.
Stall speed: 2,370 ± 150 rpm
Evaluation:
ProblemPossible cause
Stall speed low in D and R positions
Engine output may be insufficient
Stator one−way clutch is operating properly
HINT:
If more than 600 rpm below the specified value, the torque converter clutch could
be faulty
Stall speed high in D position
Line pressure too low
Forward clutch slipping
No. 2 one−way clutch not operating properly
U/D one−way clutch not operating properly
Stall speed high in R position
Line pressure too low
Direct clutch slipping
1st and reverse brake slipping
U/D brake slipping
Stall speed high in D and R positions
Line pressure too low
Improper fluid level
U/D one−way clutch not operating properly
(b) Measure the time lag.
When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag before
the shock can be felt. This is used for checking the condition of the U/D direct clutch, forward clutch,
direct clutch, and 1st and reverse brake.
NOTICE:
Do the test at normal operating ATF temperature 50 − 80°C (122 − 176°F).
Make sure to allow 1 minute interval between tests.
Take 3 measurements and take the average value.
(1) Fully apply the parking brake
(2) Start the engine and check idle speed.
Idle speed: 700 ± 50 rpm (In N position and A/C OFF)
(3) Shift the shift lever from the N to D position. Using a stop watch, measure the time it takes from
shifting the lever until the shock is felt.
Time lag: N → D Less than 1.2 seconds
In the same way, measure the time lag for N → R.
Time lag: N → R Less than 1.5 seconds
Evaluation:
ProblemPossible cause
N → D time lag is longer
Line pressure too low
Forward clutch worn
U/D one−way clutch not operating properly
N → R time lag is longer
Line pressure too low
Direct clutch worn
1st and reverse brake worn
U/D brake worn

DI−136
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U)
9. HYDRAULIC TEST
Measure the line pressure.
NOTICE:
Do the test at normal operating ATF temperature 50 − 80°C (122 − 176°F).
The line pressure test should always carried out in pairs. One technician should observe the
conditions of wheels or wheel stoppers outside the vehicle while the other is doing the test.
Be careful to prevent SST’s hose from interfering with the exhaust pipe.
(1) Warm up the ATF.
(2) Remove the teat plug on the transaxle case left side and connect SST (See page AX−14. for the
location to connect SST).
SST SST 09992−00094 (09992−00230, 09992−00270)
(3) Chock the 4 wheels.
(4) Fully apply the parking brake.
(5) Start the engine and check idling speed.
(6) Keep your left foot pressed firmly on the brake pedal and shift into the D position.
(7) Measure the line pressure when the engine is idling.
(8) Fully depress the accelerator pedal. Quickly read the highest line pressure when engine speed
reaches stall speed.
NOTICE:
Release the accelerator pedal and stop test if the wheels being to rotate before the engine speed
reaches specified stall speed.
(9) In the same way, do the teat in R position.
Specified line pressure:
ConditionD position kPa (kgf/cm2, psi)R position kPa (kgf/cm2, psi)
Idling353 − 422 (3.6 − 4.3, 51 − 61)598 − 804 (6.1 − 8.2, 87 − 117)
Stall824 − 971 (8.4 − 9.9, 119 − 141)1,530 − 1,780 (15.6 − 18.1, 222 − 257)
If the measured pressures are not up to specified values, recheck the throttle cable adjustment and do a
retest.
Evaluation:
ProblemPossible cause
If the measured value in all positions are higher.
Throttle cable out of adjustment
Throttle valve defective
Regulator valve defective
If the measured values in all positions are lower.
Throttle cable out of adjustment
Throttle valve defective
Regulator valve defective
Oil pump defective
U/D direct clutch defective
If pressure is low in the D position only.D position circuit fluid leakage
Forward clutch defective
If pressure is low in the R position only.
R position circuit fluid leakage
Direct clutch defective
1st and reverse brake defective

DI40F−02
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−141
1996 RAV4 (RM447U)
PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the diagnostic trouble code check but the trouble still occurs, check the
circuits for each symptom in the order given in the charts on the following pages and proceed to the page
given for troubleshooting.
The Matrix Chart is divided into 3 chapters.
Chapter 1: Electronic Circuit Matrix Chart
Chapter 2: On−Vehicle repair Matrix Chart
Chapter 3: Off−Vehicle repair Matrix Chart
When troubleshooting, check Chapter 1 first. If instructions are given in Chapter 1 to proceed to chapter 2
or 3, proceed as instructed.
(1) If the instruction ”Proceed to next circuit inspection shown on matrix chart” is given in the flow
chart for each circuit, proceed to the circuit with the next highest number in the table to continue
the check.
(2) If the trouble still occurs even though there are no abnormalities in any of the other circuits, then
check and replace the ECM.
Chapter 1: Electronic Circuit Matrix Chart
SymptomSuspect AreaSee page
No up−shift (A particular gear, from 1st to 3rd gear, is not up−
shifted)7. ECMDI−140
No up−shift (3rd → O/D)
1. O/D main switch & O/D OFF indicator light circuit
2. O/D cancel signal circuit
3. ECMDI−161
DI−166
DI−140
No down−shift (O/D → 3rd)
1. O/D main switch & O/D OFF indicator light circuit
2. O/D cancel signal circuit
3. ECMDI−161
DI−166
DI−140
No down−shift (A particular gear, from 1st to 3rd gear, is not
down−shifted)1. ECMDI−140
No lock−up1. Stop light switch circuit
2. ECMDI−159
DI−140
No lock−up off1. Pattern select switch circuit
2. ECMDI−168
DI−140
Shift point too high or too low1. ECMDI−140
Up−shift to O/D from 3rd while O/D main switch is OFF1. O/D main switch & O/D OFF indicator light circuit
2. ECMDI−161
DI−140
Up−shift to O/D from 3rd while engine is cold1. ECMDI−140
No kick−down1. ECMDI−140
Engine stalls when starting off or stopping1. ECMDI−140
Chapter 2: On−Vehicle Repair
(: A241E, A244E, A245E, A246E Automatic Transaxle Repair Manual Pub. No. RM390U)
SymptomSuspect AreaSee page
Does not move in any forward position1. Off−vehicle matrix chart−
Does not move in reverse position1. Off−vehicle matrix chart−
Does not move in any position
1. Primary regulator valve
2. Manual valve
3. Throttle valve
4. Off−vehicle matrix chart


−
No up−shift (1st → 2nd)1. 1−2 shift valve
2. Off−vehicle matrix chart
−

DI−142
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U) No up−shift (2nd → 3rd)
1. 2−3 shift valve
2. Off−vehicle matrix chart
−
No up−shift (3rd → O/D)1. 3−4 shift valve
2. Off−vehicle matrix chart
−
No down−shift (O/D → 3rd)1. 3−4 shift valve
2. Off−vehicle matrix chart
−
No down−shift (3rd → 2nd)1. 2−3 shift valve
2. Off−vehicle matrix chart
−
No down−shift (2nd → 1st)1. 1−2 shift valve
2. Off−vehicle matrix chart
−
Harsh engagement (N → R)1. C2 accumulator
2. Off−vehicle matrix chart
−
Harsh engagement (N → D)1. C1 accumulator
2. Off−vehicle matrix chart
−
Harsh engagement (N → L)
1. 1. C1 accumulator
2. Low coast modulator valve
3. Off−vehicle matrix chart

−
Harsh engagement (1st → 2nd (D position) )
1. Accumulator control valve
2. B
2 Accumulator
3. Off−vehicle matrix chart


−
Harsh engagement (1st → 2nd (2 position) )
1. B2 accumulator
2. Accumulator control valve
3. 2nd coast modulator valve
4. Off−vehicle matrix chart


−
Harsh engagement (1st → 2nd → 3rd → O/D)1. Throttle valve
2. Primary regulator valve

Harsh engagement (2nd → 3rd)
1. C2 accumulator
2. Accumulator control valve
3. Off−vehicle matrix chart

−
Harsh engagement (3rd → O/D)
1. B2 accumulator
2. C
3 accumulator
3. Off−vehicle matrix chart


−
Harsh engagement (O/D → 3rd)1. B4 accumulator
2. Off−vehicle matrix chart
−
Harsh engagement (3rd → 2nd)1. C2 Accumulator
2. Off−vehicle matrix chart
−
Slip (Forward & Reverse)1. Primary regulator valve
2. Off−vehicle matrix chart
−
Slip (R position)1. Off−vehicle matrix chart−
Slip (1st)1. Off−vehicle matrix chart−
Slip (2nd)1. Off−vehicle matrix chart−
Slip (3rd)1. Off−vehicle matrix chart−
Slip (O/D)1. Off−vehicle matrix chart−
No engine braking (1st (L position))1. Low coast modulator valve
2. Off−vehicle matrix chart
−
No engine braking (2nd (2 position))1. 2nd coast modulator valve
2. Off−vehicle matrix chart
−
No kick−down
1. 1−2 shift valve
2. 2−3 shift valve
3. 3−4 shift valve



DI−144
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U) Harsh engagement (O/D → 3rd)
1. U/D brake (B4)
2. On−vehicle matrix chart
−
Harsh engagement (3rd → 2nd)1. Direct clutch (C2)
2. On−vehicle matrix chart
−
Harsh engagement (Lock−up)1. Torque converter clutchAX−20
Slip (Forward & reverse)
1. Torque converter clutch
2. Oil pump
3. On−vehicle matrix chartAX−20

−
Slip (R position)1. Direct clutch (C2)
2. 1st and reverse brake (B
3)


Slip (1st)
1. Forward clutch (C1)
2. No. 2 one−way clutch (F
2)
3. U/D one−way clutch (F
3)



Slip (2nd)
1. Forward clutch (C1)
2. 2nd brake (B
2)
3. No. 1 one−way clutch (F
1)
4. U/D one−way clutch (F
3)

Slip (3rd)
1. Forward clutch (C1)
2. Direct clutch (C
2)
3. U/D one−way clutch (F
3)



Slip (O/D)
1. Forward clutch (C1)
2. Direct clutch (C
2)
3. U/D clutch (C
3)



No engine braking (1st (L position))1. 1st and reverse brake (B3)
2. On−vehicle matrix chart
−
No engine braking (2nd (2 position))1. 2nd coast brake (B1)
2. On−vehicle matrix chart
−
No kick−down1. On−vehicle matrix chart−
Poor acceleration
1. Torque converter clutch
2. Forward clutch (C
1)
3. On−vehicle matrix chart
AX−20

−
No lock−up1. Torque converter clutch
2. On−vehicle matrix chartAX−20
−
Engine stalls when staring off or stopping1. Torque converter clutchAX−20
