Page 750 of 1399
I00493
Cruise Control ECUIDL
C17 21
G−W
ECM
IDL IH1
E5 19
G−W
11
Threottle Position Sensor G−W
DI−316
−
DIAGNOSTICS CRUISE CONTROL SYSTEM
1996 LAND CRUISER (RM451U)
Idle Switch Circuit
CIRCUIT DESCRIPTION
When the idle switch in turned ON, a signal is sent to the ECU. The ECU uses\
this signal to correct the dis-
crepancy between the throttle valve position and the actuator position sensor val\
ue to enable accurate
cruise control at the set speed. If the idle switch is malfunctioning, problem\
symptoms also occur in the en-
gine, so also inspect the engine.
WIRING DIAGRAM
DI5OJ−02
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 751 of 1399
AB0119I00053 I00031
ON
IDL
(−) (+)
−
DIAGNOSTICS CRUISE CONTROL SYSTEM
DI−317
1996 LAND CRUISER (RM451U)
INSPECTION PROCEDURE
1 Check voltage between terminal IDL of cruise control ECU connector and body
ground.
PREPARATION:
(a) Remove the ECU with connector still connected.
(b) Disconnect the ECM and ABS ECU connectors.
(c) Turn ignition switch ON.
CHECK:
Measure voltage between terminal IDL of ECU connector and
body ground when the throttle valve is fully closed and fully
opened.
OK:
Throttle valve positionVoltage
Fully opened10 − 14 V
Fully closedBelow 2 V
OK Proceed to next circuit inspection shown on
problem symptoms table (See page DI−295 ).
NG
2 Check harness and connector between ECM and throttle position sensor (See page IN−28 ).
NG Repair or replace harness or connector.
OK
3 Check throttle position sensor circuit (See page DI−35).
NG Replace throttle position sensor.
OK
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 752 of 1399
I00052
Throttle Position Sensor
3
4
DI−318
−
DIAGNOSTICS CRUISE CONTROL SYSTEM
1996 LAND CRUISER (RM451U)
4 Check throttle position sensor.
PREPARATION:
Disconnect the throttle position sensor connector.
CHECK:
Measure resistance between terminals 3 and 4 of throttle posi-
tion sensor connector when the throttle valve is fully closed and
fully opened.
OK:
Throttle valve positionResistance
Fully opened1 MΩ or higher
Fully closedBelow 2.3 kΩ
NG Replace throttle position sensor.
OK
5 Check for open and short in harness and connector between cruise control\
ECU and throttle position sensor, throttle position sensor and body ground
(See page IN−28 ).
NG Repair or replace harness or connector.
OK
Check and replace cruise control ECU
(See page IN−28 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 759 of 1399
I00496
Cruise Control ECU
Fusible Link Fusible Link
Battery BR
BR
Instrument
Panel Fuse Block
ECU−IG
Ignition Switch BB
2
4 3
2
F6
1 JUNCTION
CONNECTOR J6
C17
C17B−W
I12
I12 4
2
2
2
2 B−W
F11
F11
B
B−Y
B
6EA2B
GND
13
14
AM1
FL AM1
1
ID
−
DIAGNOSTICS CRUISE CONTROL SYSTEM
DI−325
1996 LAND CRUISER (RM451U)
ECU Power Source Circuit
CIRCUIT DESCRIPTION
The ECU power source supplies power to the actuator and sensors, etc.. When\
terminal GND and the cruise
control ECU case are grounded.
WIRING DIAGRAM
DI5OM−02
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 787 of 1399

EM−2
−
ENGINE MECHANICAL CO/HC
505
Author: Date:
1996 LAND CRUISER (RM451U)
6. TROUBLESHOOTING
If the CO/HC concentration does not comply with regulations,
troubleshoot in the order given below.
See the table below for possible causes, and then inspect and
correct the applicable causes if necessary.
COHCProblemsCauses
NormalHighRough idle
3. Faulty ignitions:
Incorrect timing
Fouled, shorted or improperly gapped plugs
Open or crossed high −tension cords
Cracked distributor cap
4. Incorrect valve clearance
5. Leaky EGR valve
6. Leaky intake and exhaust valves
7. Leaky cylinders
LowHighRough idle
(Fluctuating HC reading)
1. Vacuum leaks:
PCV hose
EGR valve
Intake manifold
Air intake chamber
Throttle body
IAC valve
Brake booster line
2. Lean mixture causing misfire
HighHighRough idle
(Black smoke from exhaust)
1. Restricted air filter
2. Faulty SFI systems:
Faulty pressure regulator
Clogged fuel return line
Defective ECT sensor
Faulty ECM
Faulty injector
Faulty throttle position sensor
Faulty MAF meter
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 799 of 1399
EM−14
−
ENGINE MECHANICAL TIMING CHAIN
1996 LAND CRUISER (RM451U)
9. DISCONNECT OIL COOLER PIPE BRACKET FROM
NO. 1 OIL PAN
10. REMOVE OIL LEVEL SENSOR
(a) Remove the 4 bolts and level sensor.
(b) Remove the gasket from the level sensor.
11. REMOVE BOLTS HOLDING NO.1 OIL PAN TO TRANS-
MISSION HOUSING
Remove the 6 bolts.
12. REMOVE NO. 2 OIL PAN (See page LU−5)
13. REMOVE NO. 1 OIL PAN (See page LU−5)
14. REMOVE CRANKSHAFT PULLEY
(a) Using SST, remove the pulley bolt. SST 09213−58012, 09330 −00021
(b) Remove the crankshaft pulley.
HINT:
If necessary, remove the pulley with SST. SST 09950−50010 (09951 −05010, 09952−05010,
09953 −05010, 09953 −05020, 09954−05020)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 808 of 1399

−
ENGINE MECHANICAL TIMING CHAIN
EM−23
1996 LAND CRUISER (RM451U)
15. INSTALL OIL LEVEL SENSOR
(a) Install a new gasket to the level sensor.
(b) Install the level sensor with the 4 bolts.
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
16. CONNECT OIL COOLER PIPE BRACKET TO NO. 1 OIL
PA N
17. INSTALL CYLINDER HEAD (See page EM−54 )
NOTICE:
However, for the installation of the camshaft timing gear
and timing chain, follow the below procedure. Align the
blight link of the timing chain and camshaft timing gear
mark, and install them to the camshaft.
18. INSTALL WATER PUMP
Install a new gasket and water pump with the 4 bolts and 2 nuts.
Torque: 21 N·m (210 kgf·cm, 15 ft·lbf)
19. INSTALL RADIATOR PIPE
(a) Connect the No.2 radiator hose to the water inlet.
(b) Install the 2 nuts holding the radiator pipe to the No.1 oil
pan.
Torque: 21 N·m (210 kgf·cm, 15 ft·lbf)
20. INSTALL A/C COMPRESSOR AND BRACKET
(a) Install the A/C compressor bracket with the 5 bolts.
Torque: 37 N·m (375 kgf·cm, 27 ft·lbf)
(b) Install the A/C compressor with the 4 bolts. Torque: 25 N·m (250 kgf·cm, 18 ft·lbf)
(c) Install and adjust the drive belt (See page CH−2).
21. INSTALL RADIATOR (See page CO−16 )
22. FILL ENGINE WITH OIL
23. INSTALL ENGINE UNDER COVER
24. START ENGINE AND CHECK FOR LEAKS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 814 of 1399

−
ENGINE MECHANICAL CYLINDER HEAD
EM−29
1996 LAND CRUISER (RM451U)
16. DISCONNECT PS RESERVOIR TANK
Remove the 3 bolts and disconnect the reservoir tank.
17. DISCONNECT RADIATOR INLET HOSE
18. DISCONNECT NO. 3 WATER BYPASS HOSE
19. REMOVE GENERATOR (See page CH−8 )
20. REMOVE THROTTLE BODY (See page SF−45)
21. REMOVE OIL DIPSTICKS AND GUIDES FOR ENGINE AND TRANSMISSION
(a) Remove the 2 mounting bolts.
(b) Pull out the dipstick together with dipstick guide.
(c) Remove the O−ring from the dipstick guide.
22. REMOVE INTAKE MANIFOLD STAY
Remove the 2 bolts and intake manifold stay.
23. DISCONNECT FUEL INLET HOSE
Remove the union bolt and 2 gaskets, and disconnect the fuel
inlet hose from the fuel filter.
24. DISCONNECT ENGINE WIRE
(a) Disconnect the connectors. (1) Disconnect the ECT sender gauge connector.
(2) Disconnect the ECT cut switch connector.
(3) Disconnect the ECT sensor connector.
(4) Disconnect the knock sensor connector.
(5) Disconnect the crankshaft position sensor connec-tor.
(6) Remove the bolt and disconnect the engine wire from the cylinder block.
