1996 FORD WINDSTAR tow

Safety Restraints
11
[SR03830(ALL)05/95]
Shoulder Belt Adjustment (Driver and Right Front
Passenger)
[SR03840(ALL)05/95]
You can adjust the shoulder belt height to one of five (5)
positions. To adjust, pinch the release button and slide it up or
down until the belt rests on your shoulder near your neck.
Release the button and make sure the adjuster is firmly seated
in one of the five (5) positions.
[SR03850(ALL)05/95]
10-1/2 pica
art:0050166-A
The shoulder belt height adjuster
[SR03860(ALL)11/93]
Combination Lap and Shoulder Belt Ð Second Row
Bench Seat
[SR03901(ALL)11/93]
There is a unique safety restraint system for the outside seating
position of the second row bench seat. It is very important that
you read and understand this section before anyone rides in the
outside seating position (near the sliding door) of the
two-passenger bench seat.
[SR03910(ALL)05/95]
In addition to safety belt anchorages in the floor and roof
structures, the second row bench seat has a detachable safety
belt anchor mounted to the right window side of the seat. The
safety belt should always remain attached to this anchor except
when removing this seat.
[SR03915(ALL)12/93]
The second row passenger side outboard seating position uses a
hook above the sliding door to stow the shoulder safety belt when
entering or exiting the vehicle or when it is not being used.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

12
[SR03920(ALL)12/93]
NOTE: When the belt is stowed using the hook, DO NOT use
the hanging belt as an assist when entering the vehicle.
[SR03925(ALL)05/95]
27-1/2 pica
art:0050212-D
Proper stowage of second row shoulder safety belt
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
45
[SR31550(ALL)06/95]
17-1/2 pica
art:0050279-A
Setting the retractor to automatic locking mode
[SR31601(ALL)05/95]6.
Allow the belt to retract. A clicking sound will be heard as
the belt retracts. This indicates the retractor is in the
automatic locking mode. Pull on the lap belt portion across
the child seat towards the buckle and continue to pull up on
the shoulder belt portion while pushing down on the child
seat allowing the shoulder belt to retract, to remove any
slack in seat belt. See Figures 5 and 6.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
49
[SR31901(ALL)06/95]
17-1/2 pica
art:0050283-A
Checking the retractor
[SR31950(ALL)06/95]9.
Check to make sure that the seat is properly secured prior to
each use. If the retractor is not locked, repeat steps 6
through 8.
[SR32001(ALL)05/95]
NOTE: To remove retractor from the automatic lock mode,
allow seat belt to retract fully to its stowed position
and the retractor will automatically switch back to the
vehicle sensitive locking mode for normal adult usage.
[SR32050(ALL)05/95]
Installing a Child Safety Seat at the Rear Center
Seating Position with Locking Adjustable Lap Belt
[SR32101(ALL)05/95]1.
Lengthen the lap belt. To lengthen the belt, hold the tongue
so that its bottom is perpendicular to the direction of
webbing while sliding the tongue up the webbing.
[SR32150(ALL)05/95]2.
Place the child safety seat in the center seating position.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Starting Your Windstar
61
%*
[ST09900(ALL)02/95]
What To Do If The Engine Does Not Start
%*
[ST10000(ALL)02/95]
Fuel Pump Shut-Off Switch
*
[ST10100(ALL)03/95]
If the engine cranks but does not start or does not start after a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device intended to stop the
fuel pump when your vehicle has been involved in a substantial
jolt.
*
[ST10200(ALL)03/95]
Once the shut-off switch is triggered, you must reset the switch
by hand before you can start your vehicle.
[ST10300(ALL)06/94]
The fuel pump shut-off switch reset button is located behind the
jack access cover under the jack in the cargo compartment.
[ST10400(ALL)02/94]
10-1/2 pica
art:0050046-A
Fuel pump shut-off switch reset button location
*
[ST10500(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the switch or try to
start your vehicle. Have all the passengers get out of the
vehicle and call the local fire department or a towing
service.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Warning Lights and Gauges
71
*
[LG02420(ALL)05/95]
The light comes on briefly when you turn the ignition key to
ON, but it should turn off when the engine starts. If the light
does not come on when you turn the ignition toONor if it
comes on and stays on when you are driving, have your vehicle
serviced as soon as possible. This indicates a possible problem
with one of the vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG02430(ALL)05/95]
If the light turns on and off at one (1) second intervals while
you are driving the vehicle, it means that the engine is
misfiring. If this condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle serviced at the
first opportunity. You do not need to have your vehicle towed
in.
*
[LG02440(ALL)05/95]
If the light turns on and off on rare occasions while you are
driving, it means that a malfunction occurred and the condition
corrected itself.
*
[LG02460(ALL)05/95]
An example of a condition which corrects itself occurs when an
engine running out of fuel begins to misfire. In this case, the
Check Engine Warning Light may turn on and will then set a
Diagnostic Trouble Code indicating that the engine was
misfiring while the last of the fuel was being consumed. After
refueling, the Check Engine Warning Light will turn off after
the vehicle has completed three consecutive warm up cycles
without a misfire condition occurring. A warm up cycle consists
of engine start from a cold condition (engine at ambient
temperature) and running until the engine reaches normal
operating temperature.
*
[LG02470(ALL)05/95]
On the fourth engine start up, the Check Engine Warning Light
will turn off as soon as the engine begins to crank. It is not
necessary to have the engine serviced.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

86
%*
[LG10921(ALL)03/95]
Check Engine Warning Light
[LG10932(ALL)02/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation of the powetrain. The OBD II system is designed to
check the function of the vehicle's powertrain control system
during normal operation. If an emission problem is detected, the
Check Engine Warning Light (in the cluster) is turned on.
[LG10941(ALL)11/93]
6 pica art:0050065-B
The check engine warning light
*
[LG10949(ALL)05/95]
Modification or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
[LG10955(ALL)02/95]
The light comes on briefly when you turn the ignition key to
ON, but it should turn off when the engine starts. If the light
does not come on when you turn the ignition to ON or if it
comes on and stays on when you are driving, have your vehicle
serviced as soon as possible. This indicates a possible problem
with one of the vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG10960(ALL)05/95]
If the light turns on and off at one (1) second intervals while
you are driving the vehicle, it means that the engine is
misfiring. If this condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle serviced at the
first opportunity. You do not need to have your vehicle towed
in.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

106
*
[IP01200(ALL)01/93]
The instrument panel (dashboard) on your vehicle is divided
into several different sections. Illustrations are provided for the
major parts of the instrument panel that are explained in this
chapter. Some items shown may not be on all vehicles.
[IP01400(ALL)04/95]
The controls for the climate control systems, headlamps, dim
switch, rear window defogger, fog lamps, power rear quarter
windows, Traction Control, clock/radio and the rear window
washer and wiper are all on the instrument panel.
% [IP01425(ALL)04/95]
NOTE: Any cleaner or polish that increases the gloss (shine)
of the upper part of te instrument panel should be
avoided. The dull finish in this area us to help protect
the driver from undesirable windshield reflection.
%*
[IP01450(ALL)04/95]
Cleaning the Instrument Panel Lens
*
[IP01475(ALL)04/95]
Clean the instrument panel lens with a soft cloth and a glass
cleaner, such as Ford Ultra-Clear Spray Glass Cleaner, or
equivalent. Do not use paper towel or any abrasive cleaner to
clean the lens as these may cause scratches.
%*
[IP01500(ALL)01/93]
Climate Control Systems
[IP01550(ALL)04/95]
Your vehicle is equipped with a control assembly designed to
handle either a combination A/C-Heater System or a
Heater-Only System. Main Heater-Only Systems are standard
equipment. Main and Rear Heater-Only Systems, Main
A/C-Heater Systems, and Main and Rear A/C-Heater Systems
are optional.
[IP01630(ALL)04/95]
If your vehicle has a rear system, the front control will be
equipped with a rear fan control knob plus another fan speed
control knob which is installed in the rear.
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996
