1996 FORD WINDSTAR tow

112
[IP01992(ALL)06/94]2.
Turn the Temperature Control Knob toward the WARM
(red) area.
[IP02002(ALL)06/94]3.
Turn the Fan Speed Knob to the speed of your choice. When
your vehicle warms up, you may want to set the Fan Speed
Knob to a lower speed, or adjust the Temperature Control
Knob to a lower setting to maintain a comfortable
temperature.
*
[IP02012(ALL)10/93]
To defrost the windshield and side windows:
[IP02016(ALL)08/94]
n
Turn the Function Selector Knob toV(DEFROST), turn the
Temperature Control Knob to the WARM (red) area and turn
the Fan Speed Knob to the position of your choice.
*
[IP02021(ALL)10/93]
To heat and defrost at the same time:
[IP02031(ALL)04/95]
n
Turn the Function Selector Knob toP
(DEFROST/FLOOR),turn the Temperature Control Knob and
the Fan Speed Knob to provide the temperature and fan
speed you prefer.
[IP02050(ALL)06/94]
Do not place objects under the front seats unless your vehicle is
equipped with an under seat storage tray. Improperly stored
objects will interfere with the flow of air to the back seats.
[IP02060(ALL)06/94]
Remove any snow, ice, or leaves from the area below the
windshield on the outside of your vehicle. They could block the
air intake.
[IP02070(ALL)06/94]
Heating and Air Conditioning System
*
[IP02075(ALL)06/94]
Turning On the Heat
[IP02080(ALL)06/94]
You can heat the inside of your vehicle and defrost the
windshield using the Function Selector Knob located in the
control assembly in the instrument panel.
[IP02085(ALL)05/95]
The seven function selector modes are: MAX A/C, AC,Q
(PANEL),S(PANEL/FLOOR),R(FLOOR),P
(DEFROST/FLOOR), andV(DEFROST). If your vehicle is
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996

Instrument Panel Controls
115
[IP02252(ALL)06/94]3.
Turn the Fan Speed Knob to the position of your choice.
[IP02262(ALL)10/93]4.
Make sure that the registers in the instrument panel are open
and adjusted to the positions of your choice.
[IP02272(ALL)06/94]
During periods of high humidity, vapor may be emitted from
the air outlets when using the A/C with outside air. Correct
this by switching the Function Control Knob to MAX A/C.
*
[IP02282(ALL)06/94]
Improving fuel economy
[IP02292(ALL)06/94]
Whenever you turn on the air conditioning, your vehicle uses
more fuel because the air conditioning compressor is running.
To get better fuel economy while cooling your vehicle, do not
use the air conditioner on mild days. Instead, set the function
control knob toQ(PANEL) and turn the temperature control
knob to COOL.
*
[IP02302(ALL)04/95]
Operating tips
[IP02307(ALL)08/94]
To vary the temperature inside your vehicle, move the
Temperature Control Knob toward WARM (red) for warmer
temperatures and toward COOL (blue) for cooler temperatures.
The Temperature Control Knob setting determines the
temperature of the air being discharged from the system in all
operating modes (heating or A/C).
[IP02312(ALL)08/94]
When stopped in traffic for long periods of time in hot weather,
place the automatic transaxle gearshift selector lever in Park (P)
or in Neutral (N). This aids in engine cooling and air
conditioner efficiency. (If the engine overheats, turn the
Function Selector Knob toQ(PANEL) and turn the
Temperature Control Knob to WARM.)
*
[IP02316(ALL)10/93]
When your vehicle's engine is operated at full throttle, the air
conditioner compressor will automatically be turned off to allow
maximum engine power. This may occur during passing or
when climbing steep grades. The compressor will return to
normal operation within a few seconds after full throttle is no
longer needed.
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996

Instrument Panel Controls
125
*
[IP13460(ALL)01/95]
To keep the lamps on after you leave your vehicle:
*
[IP13470(ALL)10/94]
n
Move the slider knob to the right. Once the slider knob is to
the right, it controls how long the lamps stay on.
*
[IP13480(ALL)12/93]
n
The further you move the slide knob toward the right, the
longer the headlamps stay on after you leave your vehicle.
Similarly, if you move the slide knob only slightly toward
the left, the headlamps stay on for only a moment after you
turn your vehicle off.
%*
[IP13485(ALL)05/95]
Cleaning the Exterior Lamps
*
[IP13490(ALL)05/95]
Do not use dry paper towel, chemical solvents or abrasive
cleaners to clean the lamps, as these may cause scratches or
crack the lamps.
% [IP13501(ALL)11/93]
Interior Lamps
%*
[IP13550(ALL)01/93]
Lighting Up the Instrument Panel
[IP13560(ALL)03/94]
The instrument panel lights can be turned on by turning the
headlamp control knob to either the first or second position.
You can brighten or dim the instrument panel lights by rotating
the dim switch up or down to the desired brightness. The dim
switch is located to the right of the steering column next to the
radio.
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996

130
[SC02100(ALL)02/95]
To indicate a lane change to the right, push the turn signal
lever up slightly (without latching) and hold it in position. To
indicate a lane change to the left, pull the turn signal lever
down slightly (without latching) and hold it in position. The
lever will return to the OFF position when you release it.
*
[SC02200(ALL)05/94]
If the turn indicator light in the instrument panel does not
illuminate or remains on (does not flash) when you signal a
turn, the turn signaling system is malfunctioning. Have this
condition corrected as soon as possible, and use the accepted
hand signals until the turn signal system is repaired.
%*
[SC02220(ALL)03/95]
High Beams
*
[SC02226(ALL)01/93]
To turn on the high beams, turn the headlamps on and push
the turn signal lever away from you until it latches. When the
high beams are on, the high beam indicator light on the
instrument panel is illuminated.
*
[SC02230(ALL)01/93]
To return to the low beam setting, pull the turn signal lever
toward you until it latches back into the neutral position. The
high beam indicator light turns off.
*
[SC02235(ALL)11/93]
7-1/2 pica art:0040086-D
High beam and flash-to-pass operation
%*
[SC02700(ALL)05/95]
Flashing the Lights
*
[SC02800(ALL)01/93]
To flash the headlamps, pull the turn signal lever toward you
for a moment and then release it. The high beam headlamps
will flash whether the headlamps are on or off.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Steering Column Controls
137
*
[SC05000(ALL)03/95]
To change the position of the steering column:
[SC05100(ALL)02/95]1.
Make sure your vehicle is stopped.
*
[SC05200(ALL)03/95]2.
Pull the tilt release lever on the column toward you.
[SC05300(ALL)02/95]3.
Tilt the steering wheel up or down until you find the best
position for you.
[SC05400(ALL)02/95]4.
Release the lever to lock the wheel in place.
[SC05500(ALL)02/95]
Be sure the steering wheel is locked in place. It can only be
adjusted to specific positions. Do not adjust the steering wheel
while the vehicle is in motion.
%*
[SC05600(ALL)03/91]
Speed Control (If equipped)
*
[SC07500(ALL)03/95]
If your vehicle has speed control, you can automatically
maintain a constant speed at or above 30 mph (50 km/h).
[SC07515(ALL)05/95]
When driving in hilly terrain, at high elevations, or when
pulling a trailer, it may be desirable to drive in the Overdrive
Lockout mode. This can be done by depressing the O/D button
on the end of the gearshift lever. Driving in this mode helps
prevent excessive transaxle shifting and helps speed control to
maintain speed when going down steep hills.
*
[SC07530(ALL)05/95]
Use of radio transmitting equipment that is not Federal
Communications Commission (FCC) or in Canada the Canadian
Radio and Telecommunications Commission (CRTC) approved
may cause the speed control to malfunction. Therefore, use only
properly installed FCC (CRTC in Canada) approved radio
transmitting equipment in your vehicle.
[SC07560(ALL)04/95]
NOTE: Do not shift to N (Neutral) when using the speed
control. This will cause the engine to overspeed.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

143
Features
*
[FV00300(ALL)03/95]
Your vehicle is designed with innovative and state-of-the-art
features. Understanding how these features work can make
driving your vehicle more comfortable.
%*
[FV01400(ALL)01/95]
Doors
*
[FV01500(ALL)01/93]
For information on the liftgate refer to theLiftgatesection later
in this chapter.
*
[FV02400(ALL)01/93]
Sliding Door
*
[FV02500(ALL)01/93]
The sliding door allows rear seat passengers to enter and exit
easily.
[FV02900(ALL)03/94]
To open the sliding door from inside of the vehicle, pull the
handle toward the rear of the vehicle. The door will stay open if
you slide it all the way back until the detent at the bottom of
the door engages.
[FV02920(ALL)10/93]
13-1/2 pica
art:0050119-A
The inside sliding door handle
[FV03000(ALL)10/93]
To close the door, pull the handle toward the front of the
vehicle and slide the door. Be sure it is fully closed.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
153
[FV09371(ALL)04/95]
When you use the remote entry UNLOCK, or PANIC buttons,
the illuminated entry system turns on the interior lights for 25
seconds. You can turn these lights off with the LOCK button or
by turning the ignition to the RUN position.
%*
[FV09381(ALL)02/95]
Replacing the batteries
*
[FV09392(ALL)02/95]
The remote entry transmitter is powered by two coin type
three-volt lithium 2016 batteries (included) that should last for
several years of normal use. If you notice a significant decrease
in operating range, the batteries should be replaced.
Replacement batteries can be purchased at most pharmacies,
watch stores or at your Ford or Lincoln-Mercury dealer.
*
[FV09401(ALL)11/93]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
[FV09411(ALL)11/93]
7-1/2 pica art:0050159-A
Replacing the batteries
*
[FV09421(ALL)02/95]
The transmitter can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the transmitter.
DO NOT TAKE THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two halves back
together.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

162
*
[FV11200(ALL)01/93]
Manual Flip-Open Quarter Windows
[FV11300(ALL)06/94]
To open the flip-open quarter windows in the third row,
squeeze the upper and lower pads and pull the rear portion of
the latch toward you. Swing the latch forward and out, then
lock it into the open position by pushing rearward until you
hear a click. To close the windows, squeeze the upper and
lower pads and pull the handle inward. Release pads and push
the handle inward until you hear a click.
[FV11400(ALL)10/93]
13-1/2 pica
art:0050083-A
Manual flip-open quarter window latch location
*
[FV11600(ALL)09/93]
Power Quarter Windows (If equipped)
[FV11701(ALL)03/94]
The power rear quarter vent windows operate with the ignition
in the ON or ACC positions. The vent windows are controlled
by the right and left switches located in the center of the
instrument panel, just to the right of the rear defogger. Press the
indented side of the switch to open the windows; press the
raised side of the switch to close the windows.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996
