1
Introductory Information
*
[IN00400(ALL)04/95]
Ford's Commitment to You
*
[IN00500(ALL)04/95]
At Ford Motor Company, excellence is the continuous
commitment to achieve the best result possible. It is dedication
to learning what you want, determination to develop the right
concept, and execution of that concept with care, precision, and
attention to detail. In short, excellence means being the standard
by which others are judged.
*
[IN00600(ALL)04/95]
Our Guiding Principles
*
[IN00700(ALL)04/95]
n
Quality comes first.For your satisfaction, the quality of our
products and services must be our number one priority.
*
[IN00800(ALL)04/95]
n
You are the focus of everything we do.Our work must be
done with you in mind, providing better products and
services than our competition.
*
[IN00900(ALL)04/95]
n
Continuous improvement is essential to our success.We
must strive for excellence in everything we do: in our
products Ð in their safety and value Ð and in our services,
our human relations, our competitiveness, and our
profitability.
*
[IN01000(ALL)04/95]
n
Employee involvement is our way of life. We are a team.
We must treat one another with trust and respect.
*
[IN01100(ALL)04/95]
n
Dealers and suppliers are our partners.We must maintain
mutually beneficial relationships with dealers, suppliers, and
our other business associates.
*
[IN01200(ALL)04/95]
n
Integrity is never compromised.Our conduct worldwide
must be pursued in a manner that is socially responsible and
commands respect for its integrity and for its positive
contributions to society.
File:wnins.ex
Update:Tue Mar 19 08:27:16 1996

8
*
[SR01700(ALL)05/95]
RWARNING
Passengers should not be allowed to ride in the cargo
area. Persons not riding in a seat with a fastened seat
belt are much more likely to suffer serious injury in a
collision. Cargo should always be secured to prevent it
from shifting and causing damage to the vehicle or harm
to passengers.
*
[SR01800(ALL)05/95]
RWARNING
Failure to follow these precautions could increase the risk
and/or severity of injury in a collision. 1) Use the
shoulder belt on the outside shoulder only. Never wear
the shoulder belt under the arm. 2) Never swing it
around your neck over the inside shoulder. 3) Never use
a single belt for more than one person.
*
[SR01900(ALL)05/95]
RWARNING
To reduce the risk of serious injury in a collision, always
drive and ride with your seatback upright and the lap
belt snug and low across the hips.
*
[SR02000(ALL)05/95]
RWARNING
To reduce the risk of serious injury in a collision,
children should always ride with the seatback upright.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
15
[SR03960(ALL)06/94]
24 pica art:0050170-D
Figure 2: Securing the detachable shoulder belt
[SR03970(ALL)02/94]
Refer to the ªSeatsº section in theFeatureschapter of this
Owner Guide for information on removing and installing seats.
[SR03980(ALL)12/93]
After re-installing the second row bench seat, make sure that the
safety belt is not twisted before you insert it into the detachable
anchor. A twisted safety belt may cause the retractor to work
improperly. Then insert the detachable anchor tongue into the
detachable anchor until you hear a ªsnapº and feel the latch
engage.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

20
*
[SR09100(ALL)01/95]
n
reduce the risk of harm in frontal collisions that are not
severe enough to activate the supplemental air bag
*
[SR09200(ALL)01/95]
n
reduce the risk of being thrown from your vehicle
%*
[SR09300(ALL)01/95]
The Importance of Being Properly Seated
*
[SR09400(ALL)05/95]
In a collision, the air bag must inflate extremely fast to help
provide additional protection for you. In order to do this, the
air bag must inflate with considerable force. If you are not
seated in a normal riding position with your back against the
seatback, the air bag may not protect you properly and could
possibly hurt you as it inflates.
*
[SR09800(ALL)05/95]
RWARNING
If a passenger is not properly seated and restrained, an
inflating air bag could cause serious injury.
*
[SR09890(ALL)05/95]
Your vehicle is equipped with a right front passenger air bag.
Air bags deploy with great force, faster than the blink of an eye.
Front passengers, especially children and small adults, must
never sit on the front edge of the seat, stand near the glove
compartment of the instrument panel, or lean over near the air
bag cover when the vehicle is moving. All occupants should sit
with their backs against the seatback, move the seat to the most
rearward position if possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should use child or
infant seats.
*
[SR09900(ALL)05/95]
RWARNING
When using forward-facing child seats move the
passenger seat as far back from the instrument panel as
possible. NEVER SECURE REAR-FACING INFANT
SEATS IN THE FRONT SEAT.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
21
*
[SR09920(ALL)05/95]
THE FORCE OF THE RAPIDLY INFLATING PASSENGER AIR
BAG COULD PUSH THE TOP OF THE REAR-FACING SEAT
AGAINST THE VEHICLE SEATBACK, ARMRESTS OR
CONSOLE. REAR-FACING INFANT SEATS MUST ALWAYS
BE SECURED IN THE REAR SEAT.
*
[SR10100(ALL)05/95]
RWARNING
Do not place objects or mount equipment on or near the
air bag cover on the steering wheel or in front seat areas
that may come in contact with a deploying air bag.
Failure to follow this instruction may increase the risk of
personal injury in the event of a collision.
*
[SR10200(ALL)06/95]
For further information about the proper mounting of
equipment in the front seat of this vehicle, please refer to Ford's
brochure entitledSome Important Information About Air Bag
Supplemental Restraint Systemwhich can be obtained by calling
Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.
*
[SR10300(ALL)06/95]
For additional important safety information on the proper use of
seat belts, child seats, and infant seats, please read the other
sections of this part of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats for Children.
*
[SR10400(ALL)01/95]
How the Air Bag Supplemental Restraint System
Operates
*
[SR10500(ALL)06/95]
The Air Bag Supplemental Restraint System consists of the
driver and passenger air bags, impact sensors, a system
diagnostic module, a readiness light and tone, and the electrical
wiring which connects the components.
*
[SR10600(ALL)05/95]
The driver air bag is in the center of the steering wheel and is
indicated by the letters ªSRS.º The right front passenger seat air
bag is in the upper right-hand section of the instrument panel
ledge above the glove compartment. The letters ªSRSº appear
there. Both air bags are designed to stay out of sight until they
are activated.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

26
*
[SR13900(ALL)05/95]
RWARNING
Never let a passenger hold a child on his or her lap
while the vehicle is moving. The passenger cannot
protect the child from injury in a collision.
*
[SR14000(ALL)05/95]
RWARNING
Passengers should not be allowed to ride in the cargo
area. Persons not riding in a seat with a fastened seat
belt are much more likely to suffer serious injury in a
collision. Cargo should always be secured to prevent it
from shifting and causing damage to the vehicle or harm
to passengers.
*
[SR14100(ALL)05/95]
RWARNING
Carefully follow all of the manufacturer's instructions
included with the safety seat you put in your vehicle. If
you do not install and use the safety seat properly, the
child may be injured in a sudden stop or collision.
*
[SR14200(ALL)05/95]
RWARNING
Never leave a child unattended in your vehicle.
*
[SR14300(ALL)05/95]
RWARNING
Safety belts and seats can become hot in a vehicle that
has been closed up in sunny weather; they could burn a
small child. Check seat covers and buckles before you
place a child anywhere near them.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

32
[SR17300(ALL)04/95]5.
Place the child on the child seat and position the shoulder
belts over each shoulder. Refer to Figure 4.
[SR17400(ALL)04/95]
10-1/2 pica
art:0050139-B
Figure 4: Shoulder safety belt placement on the child
[SR17550(ALL)03/95]
NOTE: Read the following steps carefully to become familiar
with the indicator windows located on each safety belt
tongue and the chest clip. When either of the tongues
or the chest clip is unbuckled, the color red appears in
the window. When the tongues or chest clip are
securely buckled, the color green appears.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
35
[SR18025(ALL)04/95]
27-1/2 pica
art:0050141-B
Figure 6: Securing the chest clip
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996
