1996 FORD WINDSTAR warning lights

Warning Lights and Gauges
99
[LG17000(ALL)11/93]
The Fuel Computer Functions
[LG17100(ALL)06/94]
The complete fuel computer menu is displayed for about five
seconds after the cluster self-test (when the ignition is turned to
ON) and after the SELECT button is pressed. After five seconds,
only the selected function is displayed.
% [LG17200(ALL)10/93]
TRIP DISTANCE
[LG17300(ALL)03/94]
Your trip distance is the distance you have traveled since the
last reset. To display your current trip distance, press the
SELECT button until the pointer is at TRIP DISTANCE. To reset
the trip distance to zero, press the RESET button while the
pointer is at TRIP DISTANCE. You may want to use this feature
to see how far you have traveled on a particular trip.
[LG17400(ALL)08/94]
If you do not reset your trip distance, the display will roll over
to zero when it passes 1999 miles or kilometers. If you switch
from miles to kilometers after you have passed 1242 miles
(1999 kilometers), you must add 2000 to the kilometers display
for actual distance traveled. The display will then roll over to
zero when it passes 1218 kilometers (3218 kilometers or 1999
miles traveled) whether you select English or metric units. If the
display is in metric units when you pass 1999 kilometers (1242
miles), both English and metric trip distances will roll over to
zero.
% [LG17500(ALL)10/93]
INSTANT ECONOMY
[LG17550(ALL)03/94]
Your instantaneous fuel economy is your vehicle's fuel economy
over the last one second of driving. To display your
instantaneous fuel economy, press SELECT until the pointer is
at INSTANT ECONOMY. Your instantaneous fuel economy
changes with your driving conditions. Factors affecting fuel
economy include braking, acceleration, and road terrain. You
may want to use this feature to see how your driving habits
affect your fuel economy. INSTANT ECONOMY is not
resettable.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
101
[LG18175(ALL)03/94]
Your distance to empty may change faster or slower than actual
distance traveled because your fuel economy varies with
changing driving conditions.
[LG18250(ALL)11/93]
The fuel computer will automatically warn you when your
distance to empty is low. When your distance to empty reaches
50 miles (80 km), 25 miles (40 km) and 10 miles (20 km), the
fuel computer will automatically select DISTANCE TO EMPTY,
flash the number for five seconds, and sound a one second
chime.
[LG18275(ALL)10/93]
If the Distance to Empty function displays CO or CS, you must
have the fuel indication system serviced.
[LG18300(ALL)03/94]
Turn your ignition to OFF while fueling to obtain an accurate
distance to empty reading. If you do not turn your ignition off,
the fuel computer will not display the new distance to empty
immediately, but will slowly increase to the correct value.
[LG18301(ALL)10/93]
AVERAGE SPEED
[LG18350(ALL)03/94]
Your average speed is the average speed your vehicle has
traveled while the ignition was ON since the last reset. To
display your average speed, press SELECT until the pointer is at
AVERAGE SPEED. Press the RESET button when AVERAGE
SPEED is selected to reset the average speed. You may want to
use this feature to see what your average speed is during daily
driving or on a long trip.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

102
% [LG18500(ALL)06/94]
Auxiliary Warning Module (If equipped)
[LG18600(ALL)06/94]
An additional bank of indicator and warning lights is located
above the driver's side vent, just to the right of the steering
wheel. The light(s) located in this module are described and
illustrated below.
[LG18700(ALL)04/95]
13-1/2 pica art:0050122-F
The auxiliary warning module
% [LG18710(ALL)05/95]
Traction Control Active Light
[LG18720(ALL)04/95]
This light comes on when the Traction Control system begins
applying and releasing the brakes and adjusting the engine
characteristics to limit a wheelspin condition. You may feel
some steering changes and hear some noise, but this is normal.
[LG18730(ALL)04/95]
one inch art:0050274-AFile:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
103
[LG18740(ALL)04/95]
The Traction Control light will stay on for a minimum of four
seconds.
[LG18750(ALL)06/95]
Check Traction Assist Light
[LG18760(ALL)04/95]
This light comes on when the Traction Control system is not
operating. In some conditions, you may want to turn Traction
Control off, such as when rocking your vehicle out of deep
snow or mud.
[LG18770(ALL)04/95]
one inch art:0050275-A[LG18780(ALL)04/95]
Traction Control will automatically turn off to prevent the
brakes from overheating. The system will turn back on once the
brakes have cooled down.
[LG18790(ALL)04/95]
NOTE: If the TRAC OFF light is flashing repeatedly, it means
that there is a Traction Control system malfunction
and the system is inoperative. Contact your dealer for
service as soon as possible.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

261
Roadside Emergencies
%*
[RE00700(ALL)03/95]
Jump-Starting Your Vehicle
*
[RE00800(ALL)01/93]
Your vehicle's battery may discharge if you leave the lights or
any electrical equipment on after you turn the engine off. If this
happens, you may be able to jump-start from a booster battery
to start your vehicle.
*
[RE00900(ALL)02/95]
RWARNING
The gases around the battery can explode if exposed to
flames, sparks, or lit cigarettes. An explosion could result
in injury or vehicle damage.
*
[RE01000(ALL)02/95]
RWARNING
To protect yourself when charging a battery, always
shield your face and eyes. Make sure that you can
breathe fresh air.
%*
[RE01100(ALL)05/95]
RWARNING
Applying too much pressure on the ends when lifting a
battery could cause acid to spill. Lift the battery with a
carrier or with your hands on the opposite corners.
%*
[RE01200(ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns skin, eyes,
and clothing.
*
[RE01220(ALL)05/95]
If the acid touches someone's skin, eyes, or clothing,
immediately flush the area with water for at least 15 minutes. If
someone swallows the acid, have him or her drink lots of milk
or water first, then Milk of Magnesia, a beaten egg, or vegetable
oil. Call a doctor immediately.
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

Servicing Your Windstar
337
%*
[SV32300(ALL)01/95]
Adding Automatic Transaxle Fluid
*
[SV32400(ALL)04/95]
The fluid type is stamped on the dipstick. Before adding any
fluid, be sure that the correct type will be used.
*
[SV32500(ALL)05/95]
Add fluid in 1/2 pint (0.25 liter) increments through the filler
tube to bring the level to the correct area on the dipstick. If an
overfill occurs, excess fluid should be removed by a qualified
technician.
%*
[SV32600(ALL)01/93]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
*
[SV32700(ALL)06/94]
NOTE: Always use Motorcraft MERCONHor equivalent
MERCONHautomatic transaxle fluid when you refill
your automatic transaxle fluid.
%*
[SV32800(ALL)02/95]
Brake Fluid
*
[SV32900(ALL)05/90]
Your vehicle is equipped with a brake fluid level indicator in
the master cylinder which lights the BRAKE warning light on
the instrument panel when the brake fluid level is low.
*
[SV33000(ALL)01/93]
Under normal circumstances, your vehicle should not use up
brake fluid rapidly. However, expect the level of the brake fluid
to slowly fall as you put more mileage on your vehicle and the
brake pads wear.
*
[SV33100(ALL)10/89]
Check the brake fluid at least once a year. You can do this by
looking at the fluid level in the plastic reservoir on the master
cylinder. The fluid level should be at or near the MAX mark.
*
[SV33200(ALL)05/95]
RWARNING
Brake fluid is toxic.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

387
Index
Engine oil (continued)
disposal...................... 318
engine oil pressure warning light.......... 73,89
filter, specifications................. 364
refill capacities................... 363
synthetic oil.................... 317
ªbreak-inº oils.................... 5
viscosity...................... 317
Entry system
illuminated..................... 154
keyless....................... 147
remote....................... 151
Exhaust fumes...................... 62
Extended Service Plan, Ford............... 4
F
Federal Communications Commission.......... 233
Flashers, hazard.................... 135
Flashing the lights................... 130
Flat tire........................ 267
Fluid refill capacities.................. 363
Foglamps....................... 121
Ford Dispute Settlement Board............. 286
Ford Extended Service Plan................ 4
Ford Motor Company of Canada............ 292
Ford of Canada Customer Assistance Centre....... 292
Foreign registration.................. 290
French owner guides, how to obtain............ 3
Fuel
calculating fuel economy............... 314
capacity...................... 363
choosing the right fuel................ 310
filling your vehicle with fuel............. 308
fuel gauge.................... 77,94
improving fuel economy............... 315
low fuel warning light................. 76
octane rating.................... 310
File:wnixs.ex
Update:Tue Mar 19 08:12:49 1996

389
Index
GVWR (Gross Vehicle Weight Rating)
calculating..................... 253
definition...................... 251
H
Hazard flashers.................... 135
Headlamps
autolamp system.................. 123
checking alignment................. 352
cleaning...................... 125
daytime running lights................ 122
flashing...................... 130
high beam..................... 130
replacing bulbs................... 352
turning on and off................. 120
warning chime................... 122
Head restraints.................... 171
Heated mirrors.................... 190
Heating
manual heating and air conditioning system...... 106
rear seat controls.................. 116
High beams, indicator light.............. 75,90
Hitch......................... 255
Hood
latch location.................... 303
lubrication specifications............... 365
release lever.................... 303
Horn......................... 134
Hoses, checking.................... 323
I
Identification Number, Vehicle (VIN).......... 285
Idle, relearning.................... 266
Ignition
positions of the ignition................ 55
removing the key................... 56
Indicator lamp module................. 102
File:wnixs.ex
Update:Tue Mar 19 08:12:49 1996
