1996 FORD THUNDERBIRD Owners Manual

134
*
[AS02800(MBC )04/95]
q
Using the ªSCAN/TUNEº button to scan
radio stations
*
[AS02900(MBC )04/95]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the top
ahalf of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately five
seconds. Pushing the bottom
bhalf of the
ªSEEKº button will begin the scan mode
down the frequency band, again stopping on
each listenable station for approximately five
seconds.
*
[AS03000(MBC )04/95]
To stop the scan mode on the presently
sampled station press the ªSCAN/TUNEº
button again.
*
[AS03200(MBC )04/95]
q
Setting the Station Memory Preset buttons
*
[AS03300(MBC )02/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
[AS03350(MBC )05/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS03400(MBC )04/95]
1. Select a band, then select a frequency.
*
[AS03600(MBC )04/95]
2. Press one of the memory buttons and hold
the button until the sound returns. That
station is now held in memory on that
button.
*
[AS03700(MBC )04/95]
3. Follow the two steps above for each station
memory preset button you want to set.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

135
*
[AS03950(MBC )04/95]
q
Using the Automatic Memory Load feature
*
[AS04050(MBC )03/95]
If no stations are in memory preset, you can
activate theAuto Memory Loadfeature by
pressing and holding the ªAUTO PRESETº
buttonfor approximately three seconds.
Auto Memory Load sets all memory buttons
in AM, FM1 and FM2 sequentially by seeking
out the first six strong stations for the
respective band and storing them in memory
buttons 1-5. (FM2 will store the second set of
strong stations from the FM band.)
*
[AS04150(MBC )04/95]
With Auto Memory Store, you can
continually set strong stations into your
memory buttons without losing your existing
memory presets, which is especially handy
while traveling. Your radio will automatically
set your memory buttons to the strong local
stations so you don't have to continually
manually tune to existing stations.
*
[AS04250(MBC )02/95]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio
will set the first five strong stations of the
band you are in (AM, FM1 or FM2) into the
memory buttons. The display will show
ªAUTOº, then run through the frequencies,
stopping momentarily on the stations being
set into the memory buttons. The radio is
now in the ªAUTOº mode and this display
will show ªAUTOº each time a preset is
activated.
*
[AS04350(MBC )04/95]
NOTE: If there are fewer than five strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

136
*
[AS04450(MBC )04/95]
After all stations have been filled, the radio
will begin playing the station stored on
memory button 1.
*
[AS04550(MBC )04/95]
To deactivate the Auto Memory Store mode
and return to the manually-set memory
button stations (or those stations set using
Auto Memory Load), simply push the
ªAUTO PRESETº button. Display will show
ªAUTOº then ªOFFº. The next time Auto
Memory Store is activated on that band, the
radio will store the next set of five strong
stations.
*
[AS04600(MBC )02/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS04700(MBC )04/95]
q
Increasing or decreasing bass response
[AS04750(MBC )05/94]
Push the ªAUDIOº button repeatedly until
the display reads ªBASSº. Push the top (+)
side of the ªVOLUMEº button to increase
bass (more ªlowsº), and push the bottom (±)
side to decrease bass (less ªlowsº).
*
[AS04800(MBC )04/95]
q
Increasing or decreasing treble response
[AS04900(MBC )05/94]
Push the ªAUDIOº button repeatedly until
the display reads ªTREBº. Push the top (+)
side of the ªVOLUMEº button to increase
treble (more ªhighsº), and push the bottom
(±) side to decrease treble (less ªhighsº).
*
[AS04950(MBC )04/95]
q
Adjusting speaker balance
[AS05000(MBC )05/94]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBALº.
Push the top (+) side of the ªVOLUMEº
button to shift the sound to the right
speakers, and push the bottom (±) side to
shift the sound to the left speakers.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

137
*
[AS05100(MBC )04/95]
q
Adjusting speaker fader
[AS05200(MBC )05/94]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADEº.
Push the top (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the bottom (±) side to
shift the sound to the rear speakers.
*
[AS05300(MBC )04/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble, and
positions of speaker balance and fader
functions (left to right, front to rear).
*
[AS06800(MBC )04/95]
Using the Controls on Your New Compact
Disc Player
*
[AS07000(MBC )04/95]
Your new Ford Compact Disc Player is capable
of playing 12 cmor8 cm discs, without an
adapter! The Player operates when the power is
on and a disc is inserted (label side up). Handle
the disc by its edge only. (Be sure to read and
follow all of the care and cleaning instructions
underHow To Take Care of and Clean Your CD
Player and Discs.
*
[AS07100(MBC )04/95]
NOTE: If after you insert a disc, the disc is
ejected and ªERRORº begins scrolling
in the display, remove the disc and
reinsert it right side up (label side up).
[AS07200(MBC )03/95]
The digital display on your CD player will
either show the track (selection) number or the
elapsed time. (The display mode can be selected
by pressing the memory preset button #6.)
Indicators for play
b, stop
Xand compression
on (ªCº) are also in the display. (These features
are described later.)
*
[AS07300(MBC )04/95]
Once a disc is inserted, operation of the CD
player will override that of the radio.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

138
*
[AS07400(MBC )04/95]
NOTE: The volume, bass, treble, balance and
fader controls on the radio are also
used with the CD player. Refer to
earlier operating instructions on these
controls.
*
[AS07500(MBC )04/95]
How to insert a disc and begin play
*
[AS07550(MBC )04/95]
Insert one disc,label side upinto the disc
opening. When inserted, the disc automatically
loads into the unit and play starts at the
beginning of the first track (selection).
*
[AS07600(MBC )04/95]
When the disc reaches the end, the disc player
automatically returns to the beginning of the
disc and resumes playing.
*
[AS07610(MBC )02/95]
How to change the track being played
[AS07620(MBC )03/95]
Press the top
aside of the ªSEEKº button to
seek forward to the next track of the disc. If the
button is held and the last track is reached, the
disc player will automatically begin playing the
last track of the disc.
[AS07630(MBC )03/95]
Press the bottom
bside of the ªSEEKº button
to seek the previous track on the disc.
*
[AS07650(MBC )04/95]
NOTE: Once a disc is inserted, the disc
opening is secured to prevent the
accidental insertion of a second disc.
*
[AS07700(MBC )04/95]
NOTE: The CD player has heat protection
circuitry to protect the laser diode. If
the temperature of the player reaches
167ÊF (75ÊC), theheat detection circuit
will shut off the player and ªTOO
HOTº will scroll in the display for
approximately five seconds (radio will
resume playing). When the temperature
returns to normal operating range, the
CD player will again be operational.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

139
*
[AS07750(MBC )04/95]
How to stop and restart the CD player
*
[AS07800(MBC )04/95]
When a disc is loaded, the unit automatically
enters the play mode and the play indicator
a
illuminates. To stop temporarily, press the
ªPLAY/STOPº button or the ªAM/FMº button.
The stop indicator
Xin the display illuminates
and operation returns to the radio mode. To
resume CD play, press the ªPLAY/STOPº
button once again.
*
[AS07850(MBC )04/95]
NOTE: If the ignition key is turned OFF
during play and then is set to the ON
or ACCESSORY position, the CD
player will resume playing in the mode
it was in when ignition was turned off.
*
[AS07900(MBC )05/95]
How to fast forward or reverse your CD
player
*
[AS07950(MBC )05/95]
To quickly search for a particular point in a
selection, press the ªFFº button (to fast forward)
or the ªREVº button (to reverse). While either
button is pressed, the disc goes forward or
backward at two different speeds depending on
how long the button is held down. (Pressing
either button for more than approximately three
seconds will speed up the process.) Release the
button at the desired point (found by watching
the elapsed playing time in the display or by
listening to the sound during fast forward or
reverse). When you have reached the beginning
of track 1, the CD player will begin playing.
*
[AS08000(MBC )04/95]
When you have reached the end of the disc by
keeping the fast forward button pressed, the
display will show ªENDº and the player will go
into pause mode. Push the ªPLAY/STOPº
button to begin playing the first track of the
disc, press the ªREVº button to back up from
the end of the disc, or use the ªSEEKº function
to locate a desired track.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

140
*
[AS08020(MBC )04/95]
Using the ªSCANº function
[AS08030(MBC )03/95]
Press the ªSCAN/TUNEº button to enter the
scan mode. Once in the scan mode, press the top
aor bottom
bhalf of the ªSEEKº button to
scan forward or reverse, respectively. The CD
player will begin scanning the disc, stopping on
each listenable track for approximately eight
seconds. This continues until you press the
ªSCAN/TUNEº button a second time. While in
the scan mode, the display shows the current
sampled track number.
*
[AS08040(MBC )04/95]
Special features of your CD player
*
[AS08050(MBC )04/95]
q
Compression
*
[AS08060(MBC )04/95]
The compression feature will bring soft and
loud passages closer together for a more
consistent listening level.
*
[AS08070(MBC )04/95]
To turn the compression on, press the
ªCOMPº button. When on, the compression
indicator (ªCº) will appear in the display.
Press the button again to turn off.
*
[AS08080(MBC )04/95]
q
Automatic Disc Storage
*
[AS08090(MBC )04/95]
If the disc is ejected from the CD player but
is not removed from the disc opening within
approximately 10 seconds, the player will
automatically reload the disc for storage,
unless the disc is automatically ejected due to
a ªfocus errorº (disc inserted upside down).
In this case, the disc will not be automatically
reloaded.
*
[AS08095(MBC )04/95]
How to eject the disc
*
[AS08096(MBC )04/95]
Push the ªEJECTº button to stop play, eject the
disc and resume radio operation of your audio
system.
*
[AS08097(MBC )04/95]
NOTE: You can eject the disc while the radio
power and/or ignition is on or off.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

141 % [AS21350(MBC )02/95]
full page art:0060641-B
Electronic Stereo Radio with Cassette
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996
