Remote Entry System
(If equipped)
*
[FV08036( ALL)03/94]
If your vehicle has the remote entry system, you
can lock and unlock the vehicle doors and open
the trunk without using a key. The remote also
has a personal alarm feature. The buttons for the
system are located on the hand held
transmitter(s) that came with your vehicle.
*
[FV08040( ALL)02/95]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
*
[FV08045(MBC )02/95]
The remote entry features only operate with the
ignition in the OFF position.
[FV08050(MBC )02/95]
one third page art:0001000-A
Remote entry transmitter
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

111 %
*
[FV08055( ALL)02/95]
Unlocking the doors and opening the trunk
*
[FV08060( ALL)02/95]
To unlock the driver's door, press the UNLOCK
button.
*
[FV08065( ALL)02/95]
To unlock the other doors, press the UNLOCK
button a second time within five seconds of
unlocking the driver's door.
[FV08070(MBC )05/95]
To open the trunk, press the TRUNK button.
*
[FV08080( ALL)02/95]
Locking the doors
*
[FV08085( ALL)02/95]
To lock all the doors, press the LOCK button.
*
[FV08090(MBC )01/95]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. The doors will lock again,
the horn will beep and the low beam headlamps
and tail lamps will flash.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

112
*
[FV08114( ALL)02/95]
Activating the remote personal alarm
*
[FV08120( ALL)02/95]
If you wish to activate the remote personal
alarm, press the PANIC button. This will honk
the horn and flash the low beam headlamps and
tail lamps for approximately two minutes and
forty-five seconds. You can turn it OFF by
pressing the PANIC button again or by turning
the ignition key to the RUN position.
[FV08125( ALL)05/94]
When you use the remote entry UNLOCK,
TRUNK or PANIC buttons, the illuminated entry
system turns on the interior lights for 25
seconds. You can turn these lights off with the
LOCK button or by turning the ignition to the
RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[FV08725( ALL)02/95]
Replacing the batteries
*
[FV08750(MBC )02/95]
The remote entry transmitter is powered by two
coin type three-volt lithium 2016
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

113
*
[FV08775( ALL)02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV08800(MBC )02/95]
quarter page art:0020790-A
Replacing the batteries
*
[FV08825(MBC )02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
%*
[FV08850( ALL)02/95]
Replacement/additional transmitters
*
[FV08875(MBC )02/95]
In the event a transmitter is lost, return the
remaining transmitters to your dealer for
reprogramming of your remote entry system.
This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[FV08900(MBC )02/95]
Additional transmitters may be purchased from
your dealer (remote entry system will work with
up to four transmitters). Return your existing
transmitters to your dealer so the remote entry
system can be reprogrammed with your new
and existing transmitters.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

114
*
[FV08925( ALL)02/95]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
%
*
[FV08950( ALL)02/95]
Windows
%*
[FV08980( BCGV)02/95]
Using the Power Windows
[FV08990(MBC )03/03]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates the
windows.
*
[FV09050( ALL)01/95]
Power windows can only be opened or closed
when the ignition switch is in the ON or ACC
position.
*
[FV09075(MBCG )05/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

115 [FV09200( BC )05/95]
half page art:0010233-G
The master controls on the driver's door
%*
[FV13100( BC )02/95]
Moon Roof (If equipped)
[FV13200( BC )05/95]
You can move the moon roof back to open the
glass panel, or you can tilt it up to ventilate the
vehicle. There is also an intermediate position
between closed and open which can reduce wind
noise at speeds between 30 and 45 miles per
hour (50 and 70 km/h).
*
[FV13300( BC )01/95]
The rocker type switch is used to open and close
the moon roof. You must press and hold the
switch until the desired position is reached. At
fully open, closed and intermediate positions, the
motor will automatically turn off. Release the
switch at this time to avoid motor damage.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

116 [FV13400( BC )05/92]
two third page art:0010248-CThe switch for the moon roof
[FV13600( BC )07/93]
To open the moon roof, press and hold the rear
portion of the switch. The glass panel will move
to the intermediate position and stop. If the rear
of the switch is pressed again the glass panel
will move to the full open position and stop.
[FV13700( BC )07/93]
To close the moon roof, press and hold the front
portion of the switch. The glass panel will move
to the intermediate position and stop. Press and
hold the front of the switch again and the panel
will move to the fully closed position and stop.
File:rcfvb.ex
Update:Mon Feb 19 10:50:02 1996

117
*
[FV13800( BC )01/95]
To tilt the moon roof into vent position when
the glass panel is closed, press the front portion
of the switch.
*
[FV13900( BC )04/95]
To close from vent position, press and hold the
rear portion of the switch.
*
[FV14100( BC )01/95]
Occasionally wiping the outside guide rail covers
of the moon roof with a clean cloth will help
keep the moon roof working properly.
[FV14200( BC )05/89]
one third page art:0010250-B
The moon roof
*
[FV14300( BC )01/95]
RWARNING
Do not let children play with the moon
roof. They may seriously hurt themselves.
*
[FV14400( BC )01/95]
Sliding Shade
*
[FV14500( BC )01/95]
The moon roof has a sliding shade that you can
manually open or close to block the sun when
the glass panel is shut.
*
[FV14600( BC )01/95]
To close the sliding shade, pull the shade toward
the front of the vehicle. The shade automatically
opens and locks when the moon roof is opened.
