1996 FORD CONTOUR Owners Manual

212
*
[SV15000(ALL)03/95]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
*
[SV15200(O )05/95]
Nearly all engines will consume engine oil. As a result, it may
be necessary to add some oil between oil changes.
*
[SV16300(ALL)06/95]
Changing the Engine Oil and the Oil Filter
[SV16400(ALL)03/95]
Change the engine oil and oil filter per the following, whichever
occurs first.
[SV16500(ALL)05/95]
twelve pica
chart:0001472-A*
[SV16600(ALL)04/95]
Refer to the Maintenance Schedule and Record Booklet for
additional information.
%*
[SV16700(ALL)04/95]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

Servicing Your Contour
213
*
[SV17275(ALL)06/95]
RWARNING
Continuous contact with USED motor oil has caused
cancer in laboratory mice.
*
[SV17290(ALL)05/95]
Protect your skin by washing with soap and water.
*
[SV17300(ALL)03/95]
Engine Coolant
%*
[SV17320(ALL)03/95]
Checking the Engine Coolant
*
[SV17350(ALL)01/95]
NOTE: Be sure to read and understandPrecautions When
Servicing Your Vehicleat the beginning of this chapter.
*
[SV17400(ALL)05/95]
RWARNING
The cooling fan is automatic and may come on at any
time. Always disconnect the negative terminal of the
battery before working near the fan.
[SV17720(ALL)05/95]
13-1/2 pica
art:0000336-D
The engine coolant recovery reservoir (2.5L shown Ð 2.0L similar)
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

214
%*
[SV17825(ALL)05/94]
Your vehicle's coolant protects your engine from overheating in
the summer and from freezing in the winter. Check the level of
the coolant at least once a month. Simply look at the engine
coolant reservoir located in the engine compartment. To locate
the reservoir, see the diagram of your vehicle's engine under
Engine Type, in this chapter.
*
[SV17850(ALL)01/95]
Check the engine coolant level in the engine coolant reservoir at
least once a month using the following guidelines.
[SV17900(ALL)01/95]
When your vehicle's engine is cool, the coolant level in the
engine coolant recovery reservoir should be at or above the
MIN mark. When the engine is hot, the coolant level should be
at the MAX mark. If the level is below the indicator mark in
either condition, coolant may need to be added.
*
[SV18000(ALL)05/95]
The coolant additives also protect the entire cooling system from
internal passageway corrosion and these additives lubricate the
water pump. The coolant should be serviced as noted in the
Maintenance Schedule and Recordbooklet.
*
[SV18100(ALL)01/95]
Adding engine coolant
*
[SV18200(ALL)05/95]
RWARNING
Do not put engine coolant in the container for the
windshield washer fluid.
*
[SV18300(ALL)05/95]
RWARNING
Never remove the coolant recovery cap while the engine
is running or hot.
[SV18500(ALL)01/95]1.
Before you remove the cap, turn the engine off and let it
cool. Even when the engine is cool, be careful when you
remove the coolant recovery cap.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

Servicing Your Contour
215
[SV18600(ALL)05/95]2.
When the engine is cool, wrap a thick cloth around the cap
and turn it slowly counterclockwise to relieve the pressure.
*
[SV18700(ALL)03/95]3.
Step back while the pressure releases.
[SV18800(ALL)05/95]4.
When you are sure that all the pressure has been released,
use the cloth to turn and remove cap.
*
[SV18900(ALL)02/95]5.
Stand away from the reservoir opening. Hot steam may blow
out or hot engine coolant may even splash out.
*
[SV19000(ALL)01/95]
RWARNING
Failure to follow these instructions could result in serious
personal injury from hot engine coolant or steam
blowout and/or damage to the engine cooling system or
engine.
*
[SV19025(ALL)03/95]
To find out how much engine coolant mixture your vehicle's
coolant system can hold, seeRefill capacities for fluidsin the
Index.
*
[SV19100(ALL)01/95]
Have your dealer check the engine cooling system for leaks if
you have to add a quart (liter) of engine coolant more than
once a month.
*
[SV19102(ALL)06/95]
Add engine coolant only to the recovery reservoir.If the
coolant level is low, add to the reservoir a 50/50 mixture of
water and the type of engine coolant that Ford specifies. You
may add water by itself only in an emergency, but you should
replace it with a 50/50 mixture as soon as possible. Check the
engine coolant again the next few times you drive your vehicle.
*
[SV19104(ALL)02/95]
Ford Premium Cooling System Fluid is an optimized formula
that will protect all metals and rubber elastomers used in Ford
engines for four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use supplemental coolant
additives in your vehicle. These additives may harm your
engine cooling system. Follow the recommended service interval
for changing your engine coolant.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

216
*
[SV19106(ALL)04/94]
NOTE: When you change or add engine coolant, it is
important to maintain your engine coolant
concentration between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local climate
conditions. Below 40% you will lose freeze protection
and above 60% your engine may overheat on a warm
day.
*
[SV19108(ALL)03/95]
NOTE: The use of an improper coolant may void your
warranty for the engine cooling system. Use only a
premium, nationally recognized brand name engine
coolant. Do not use alcohol, methanol antifreeze or
engine coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant, the
aluminum engine on your vehicle will corrode.
*
[SV19110(ALL)05/95]
Ford Motor Company expressly authorizes the Ford Rotunda
engine coolant recycling process and chemicals. Use only Ford
Rotunda recycled engine coolant or an equivalent recycled
engine coolant that is certified by the supplier to meet Ford
specification ESE-M97B44-A.
%*
[SV19112(ALL)04/95]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
[SV19115(ALL)02/95]
Use Ford Premium Cooling System Fluid or an equivalent
engine coolant that meets Ford Specification ESE-M97B44-A.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

Servicing Your Contour
217
*
[SV20050(ALL)03/95]
Battery
*
[SV20100(ALL)02/95]
Your vehicle may have a Motorcraft maintenance-free battery.
The Motorcraft maintenance-free battery does not require
additional water during its life of service. The vents are part of
the cover and cannot be removed. For longer, trouble-free
operation, keep the top of the battery clean and dry. Also, make
certain the battery cables are tightly fastened to the battery
terminals.
*
[SV20150(ALL)02/95]
If you see any corrosion on the battery cables or terminals,
remove the cables from the terminal and clean them both with a
wire brush. You can neutralize the acid with a solution of
baking soda and water. Reinstall the cables when you are done
cleaning them, and apply a small quantity of grease to the top
of each battery terminal to help prevent corrosion.
[SV20200(ALL)02/95]
Battery Replacement
*
[SV20250(ALL)02/95]
If your original equipment battery requires replacement (under
warranty), it may in some cases be replaced by a Motorcraft
low-maintenance battery. The low-maintenance battery has
removable vent caps for checking the electrolyte level and for
adding water, if needed.
*
[SV20300(ALL)05/95]
Check your battery's electrolyte level, at least every 12 months
or 12,000 miles (20,000 km), in temperatures above90ÊF (32ÊC)
and more often in temperatures above90ÊF (32ÊC).Keep the
electrolyte in each cell up to the ªlevelº indicator. Do not
overfill the battery cell.
*
[SV20350(ALL)02/95]
If the electrolyte level in your battery gets low, you can add
plain tap water to the battery, as long as you don't use hard
water, or water with a high mineral or alkali content. If
possible, however, try to only fill the battery cell with distilled
water. If the battery needs water often, have the charging
system checked.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

218
*
[SV20400(ALL)01/95]
RWARNING
Batteries normally produce explosive gases which can
cause personal injury. Therefore, do not allow flames,
sparks or lit tobacco to come near the battery. When
charging or working near a battery, always cover your
face and protect your eyes, and also provide ventilation.
%*
[SV20450(ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns skin, eyes,
and clothing.
*
[SV20475(ALL)06/95]
If the acid touches someone's skin, eyes, or clothing,
immediately flush the area with water for at least 15 minutes. If
someone swallows the acid, have him or her drink lots of milk
or water first, then Milk of Magnesia, a beaten egg, or vegetable
oil. Call a doctor immediately.
%*
[SV20500(ALL)05/95]
RWARNING
Applying too much pressure on the ends when lifting a
battery could cause acid to spill. Lift the battery with a
carrier or with your hands on the opposite corners.
*
[SV20550(ALL)03/95]
Help Us Protect Our Environment
*
[SV20600(ALL)04/95]
Ford Motor Company strongly recommends that used lead-acid
batteries be returned to an authorized recycling facility for
disposal.
[SV20650(ALL)01/95]
6 pica art:0001223-A
Battery recycling symbol
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996

Servicing Your Contour
219
[SV20660(ALL)06/95]
Disconnecting the Battery
[SV20675(ALL)02/95]
Because your vehicle engine is electronically controlled by a
computer, some control conditions are maintained by power
from the battery. If you ever disconnect the battery or install a
new battery, you must allow the computer to ªrelearnº its idle
conditions before your vehicle will drive properly. To begin this
process, put the gearshift in P (Park) (automatic transaxle) or
Neutral (manual transaxle), set the emergency brake, turn off all
the accessories, and start the vehicle. Bring the engine to normal
operating temperature. Allow the manual transaxle to idle for
one minute in Neutral. Allow the automatic transaxle engine to
idle for one minute in N (Neutral) and one minute in D (Drive).
Perform the previous procedure with the air conditioning (if
equipped) on and off (conditions permitting). The relearning
process will complete automatically as you drive the vehicle.
*
[SV20700(ALL)03/95]
If you do not let the engine relearn its idle, the idle quality of
your vehicle may be adversely affected until the idle is
relearned. Your vehicle will eventually relearn its idle while you
drive it, but it takes much longer than if you use the previous
procedure.
*
[SV21700(ALL)03/95]
Windshield Washer Fluid and Wipers
*
[SV21800(ALL)03/95]
Washer Fluid
*
[SV22100(ALL)01/95]
Check the level of the windshield washer fluid every time you
stop for fuel. The reservoir for washer fluid is located on the
passenger's side of the engine compartment. Visual inspection
can determine if the washer fluid is adequate. Do not operate
the washer when the reservoir is empty.
File:cdsvo.ex
Update:Thu Jan 25 12:09:28 1996
