1991 LEXUS SC400 rear view mirror

Fuel Pump ECUAuto Antenna Motor and Relay
Power Seat ECU
(For Passenger's Seat)
Power Seat ECU
(For Driver's Seat) CD Automatic Changer
Wireless Door Lock ECU
Moon Roof Control Relay
Locations of ECUs (Cont'd)
Many ECUs are mounted in this vehicle.
Take the following precautions during body repair to prevent damage to th\
e ECUs.


Before starting electric welding operations, disconnect the negative (-\
) terminal cable from the battery.
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the\
contents memorized by each
memory system. Then when work is finished, reset the clock and audio sys\
tems as before.
When the vehicle has tilt and telescopic steering, power seat and outsid\
e rear view mirror, which are all
equipped with memory function, it is not possible to make a record of th\
e memory contents.
So when the operation is finished, it will be necessary to explain this \
fact to the customer, and request
the customer to adjust the features and reset the memory.

Do not expose the ECUs to ambient temperatures above 80 °C (176 °F).
NOTICE: If it is possible the ambient temperature may reach 80°C (176°F) or, more, remove the ECUs
from the vehicle before starting work.

Be careful not to drop the ECUs and not to apply physical shocks to them\
.
5. COMPONENTS ADJACENT TO THE BODY PANELS
Various types of component parts are mounted directly on or adjacently to\
the body panels.
Strictly observe the following precautions to prevent damaging these com\
ponents and the body panels
during handling.

Before repairing the body panels, remove their adjacent components or ap\
ply protective covers over
the components.

Before prying components off using a screwdriver or a scraper, etc., attach protective tape to the tool
tip or blade to prevent damaging the components and the body paint.

Before removing components from the outer surface of the body, attach protective tape to the body to
ensure no damage to painted areas.
HINT: Apply touch-up paint to any damaged paint surfaces.

Before drilling or cutting sections, make sure that there are no wires, \
hoses, etc., on the reverse side.
INTRODUCTIONIN-9
WhereEverybodyKnowsYourName

GENERAL MAINTENANCE
MA00M±03
There are the maintenance and inspection
items which are considered to be the owner's
responsibility. They can be performed by the
owner or be can have them done at a service
shop. These items include those which should
be checked on a daily basis, those which, in
most cases, do not require (special) tools and
those which are considered to be reasonable
for the owner to perform. Items and procedures
for general maintanance are as follows:
MA00P±04
OUTSIDE VEHICLE
1. TIRES
(a) Check the pressure with a gauge. Adjust ifnecessary.
(b) Check for cuts, damage or excessive wear.
2. WHEEL NUTS Wheel checking the tires, check the nuts for
looseness or for missing nuts. If necessary,
tighten them.
3. TIRE ROTATION It is recommended that tires be rotated every
12,000 km (7,500 miles).
4. WINDSHIELD WIPER BLADES Check for wear or cracks whenever they do not
wipe clean. Replace if necessary.
5. FLUID LEAKS
(a) Check underneath for leaking fuel, oil, water or
other fluid.
(b) If you smell gasoline fumes or notice any leak, have the cause found and corrected.
6. DOORS AND ENGINE HOOD
(a) Check that all doors including the trunk lid operate smoothly, and that all latches lock
securely.
(b) Check that the engine hood secondary latch secures the hood from opening when the
primary latch is released.
MA00R±05
INSIDE VEHICLE
7. LIGHTS
(a) C h e c k t h a t t h e h eadlights, stop lights,
tail±lights, turn signal lights, and other lights
are all working. (b) Check the headlight aiming.
8. WARNING LIGHT AND BUZZERS
Check that all warning lights and buzzers func-
tion properly.
9. HORN Check that it is working.
10. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
11. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
12. WINDSHIELD DEFROSTER Check that the air comes out from the defroster
outlet when operating the heater air condition-
er at defroster mode.
13. REAR VIEW MIRROR
Check that it is mounted securely.
14. SUN VISORS Check that they move freely and are mounted
securely.
15. STEERING WHEEL Check that it has the specified freeplay. Be
alert for changes in steering condition, such as
hard steering, excessive freeplay or strange
noise.
16. SEATS
(a) Check that all front seat controls such as seat adjusters, seatback recliner, etc. operate
smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the locks hold securely in any latched position.
(d) Check that the head restraints move up and
down smoothly and that the locks hold securely
in ay latches position.
(e) For folding±down rear seat backs, check that the latches lock securely.
17. SEAT BELTS
(a) Ch e ck th a t th e se a t be lt syste m su ch as buckles, retractors and anchors operate
properly and smoothly.
(b) Check that the belt webbing is not cut, frayed,
worn or damaged.
18. ACCELERATOR PEDAL Check the pedal for smooth operation and un-
even pedal effort or catching.
±
MAINTENANCE (1UZ ± FE)MA±19
WhereEverybodyKnowsYourName

(d) Place the voltmeter positive (+) lead against the defoggerpositive (+) terminal.
(e) Place the voltmeter negative (±) lead with the foil strip against
the heat wire at the positive (+) terminal end and slide it
toward the negative (±) terminal end.
(f) The point where the voltmeter deflects from zero to several volts is the place where the heat wire is broken.
HINT: IF the heat wire is not broken, the voltmeter indicates 0 volts
at the positive (+) end of the heat wire but gradually increases to
about 12 volts as the meter probe is moved to the other end.
2. REPAIR DEFOGGER WIRES (a) Clean the broken wire tips with a grease, wax andsilicone remover.
(b) Place the masking tape along both sides of the wire to be repaired.
(c) Thoroughly mix the repair agent (Dupont paste No. 4817).
(d) Using a fine tip brush, apply a small amount to the wire.
(e) After a few minutes, remove the masking tape.
(f) Allow the repair to stand at least 24 hours.
(Mirror Defogger)
REMOVAL AND INSTALLATION OF
MIRROR ASSEMBLY
(See Outside Rear View Mirror on Pub. No. RM260U2, page
BO±42)
BE±54
±
BODY ELECTRICAL SYSTEM Defogger System
WhereEverybodyKnowsYourName

GENERAL DESCRIPTION
The LEXUS SC400/300 is equipped with an SRS (Supplemental Restraint System\
) such as the driver
airbag and front passenger airbag. Failure to carry out service operations in \
the correct sequence
could cause the SRS to unexpectedly deployed during servicing, possibly leadin\
g to a serious acci-
dent. Further, if a mistake is made in servicing the supplemental restraint system, i\
t is possible the
SRS may fail to operate when required. Before performing servicing (inc\
luding removal or installa-
tion of parts, inspection or replacement), be sure to read the followin\
g items carefully, then follow
the correct procedure described in the repair manual.
1. Malfunction symptoms of the supplemental restraint system are difficult to confirm, so the diagnostic trouble codes become the most important source of information when troubleshooting. When
troubleshooting the supplemental restraint system, always inspect the diagnostic trouble codes before
disconnecting the battery (See page RS±59).
2. Work must be started after 90 seconds from the time the ignition switch turn\
ed to the LOCK position
and the negative (±) terminal cable is disconnected from the battery. (The supplemental restraint
system is equipped with a back±up power source so that if work is sta\
rted within 90 seconds of
disconnecting the negative (±) terminal cable of the battery, the SRS may be deployed.)
When the negative (±) terminal cable is disconnected from the battery, memory of the clock and audio sys-
tems will be canceled. So before starting work, make a record of the contents memo\
rized by the audio
memory system. When work is finished, reset the audio systems as before and ad\
just the clock. When the
vehicle has power tilt and power telescopic steering, power seat, power outside rear view mirror and power
shoulder belt anchorage, which are all equipped with memory function, it is not \
possible to make a record
of the memory contents. So when the work is finished, it will be necessary\
to explain this fact to the custom-
er, and ask the customer to adjust the features and reset the memory.
To avoid erasing the memory of each memory system, never use a back±up\
power supply from outside
the vehicle.
3. Even in cases of a minor collision where the SRS does not deploy, the steering wheel pad, front passenger
airbag assembly, front airbag sensors and center airbag sensor assembly should be inspe\
cted (See pages
RS±16 , 28 , 41 and 44).
4. Never use SRS parts from another vehicle. When replacing parts, replace \
them with new parts.
5. Before repairs, remove the airbag sensor if shocks are likely to be applied to the sensors during r\
epairs.
6. Never disassemble and repair the steering wheel pad, front passenger airbag a\
ssembly, front airbag sensors or center airbag sensor assembly in order to reuse it.
7. If the steering wheel pad, front passenger airbag assembly, front airbag sensors or center airbag sensor assembly have been dropped, or if there are cracks, dents or dents or ot\
her defects in the case, bracket
or connector, replace them with new ones.
8. Do not expose the steering wheel pad, front passenger airbag assembly, front airbag sensors and center airbag sensor assembly directly to hot air or flames.
9. Use a volt/ohmmeter with high impedance (10 k
/V minimum) of troubleshooting of the system's electrical
circuit.
10. Information labels are attached to the periphery of the SRS components. \
Follow the instructions on the
notices.
11. After work on the supplemental restraint system is completed, perform the SRS\
warning light check (See page RS±59 ).
12. If the vehicle is equipped with a mobile communication system, refer to \
the precaution in the IN section. RS±2
±
SUPPLEMENTAL RESTRAINT SYSTEM GENERAL DESCRIPTION
WhereEverybodyKnowsYourName

QTY
PART NUMBER
PART NAME
CHANGE IN SUPPLY PARTS FOR INNER REAR VIEW MIRROR Page 1 of 3
Supply parts for the inner rear view mirror have been changed from an assembly to the com-
ponents listed below.
PART NUMBER INFORMATION:
BODY
BO92±008
DECEMBER 4, 1992
SC 300/400
87825±24010 1Spring, Inner Rear View Mirror Body Setting
DESCRIPTION
87808±24010 2Holder Subassembly,
Inner Rear View Mirror
87817±24010 1Spacer, Inner Rear View Mirror
N/A N/A Not available as a
separate supply part
This part is attached to windshield. Use original part or replace windshield\
and mirror base
as an assembly, if necessary.
WhereEverybodyKnowsYourName

CHANGE IN SUPPLY PARTS FOR INNER REAR VIEW MIRROR (CONT'D)Page 2 of 3
1) Remove Center Visor
a) Remove the visor arm set clip (Figure 1).
b) Remove the two attachment screws.
Figure 1
Figure 2
Figure 3
Figure 4 2) Remove Inner Rear View Mirror
a) Remove mirror set screw (Figure 2).
b) Disconnect the mirror wire harness.
INNER REAR VIEW MIRROR REMOVAL:
Note: To prevent damage to plastic parts,
tape the screwdriver tip before use.
COMPONENT DISASSEMBLY:
a) Using snap ring pliers, remove the spring.
b) Remove the two holders and the spacer (Figure 3).
NOTE: Do not remove the mirror base from the windshield.
COMPONENT ASSEMBLY:
a) Reinstall components by installing the spacer, two holders and spring.
b) Install the spring using snap ring pliers (Figure 4).
WhereEverybodyKnowsYourName

CHANGE IN SUPPLY PARTS FOR INNER REAR VIEW MIRROR (CONT'D)Page 3 of 3
a) Install inner rear view mirror by re±installing
attachment set screw (Figure 5).
INNER REAR VIEW MIRROR & CENTER
VISOR INSTALLATION:
PARTS LOCATION:
Note: Use thread locking compound on
set screw to ensure screw reten-
tion.
b) Re±connect wire harness.
Note: Check review mirror dimming operation before re±installation of
center visor.
c) Install center visor by re±installing two attachment screws.
d) Re±install visor arm set clip.
WhereEverybodyKnowsYourName

1
2
X
X X
910
D4 I15
BLACK
107
LIQUID CRYSTAL INNER REAR VIEW MIRROR
2
1F
8 1B
5 B212
RY
R
R
R
W± B
10A
DOME
FROM POWER SOURCE
SYSTEM(
SEE PAGE 56 )
INNER MIRROR UNLOCK
WARNING SW
[IGNITION SW]
D4 I15
TO FRONT PERSONAL
LIGHT
DAY/NIGHT
SHIFT SW 1F
9
1I
15
9
10
1H
13
1J
1
1F
YW±B
1 2
D 4 DAY/NIGHT SHIFT SW
1 ± GROUND: ALWAYS APPROX.
12 VOLTS
I15 UNLOCK WARNING SW [IGNITION SW]
10±9: CLOSED WITH IGNITION KEY IN CYLINDER
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
D 430I1529
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
219ENGINE COMPARTMENT LEFT
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B20ENGINE ROOM MAIN WIRE
1F20ROOF WIRE
1H
1I20COWL WIRE
1J
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
IF36LEFT KICK PANEL
: SPLICE POINTS
CODESEE PAGEWIRE HARNESS WITH SPLICE POINTSCODESEE PAGEWIRE HARNESS WITH SPLICE POINTS
B 240ROOF WIRE
SERVICE HINTS
WhereEverybodyKnowsYourName
