(d) Connect the following hoses:(1) Vacuum hose from EGR vacuum modulator
(2) Pressure hose from EGR vacuum modulator(USA Spec.)
(e) Connect the EGR Gas Temp. Sensor connector.
EC±16
±
EMISSION CONTROL SYSTEMS Exhaust Gas Recirculation (EGR) System
WhereEverybodyKnowsYourName

(Rear Catalytic Converter)
1. (USA Spec.)REMOVE SUB±OXYGEN SENSOR
Remove the two nuts and sub±oxygen sensor from the front
exhaust pipe.
2. REMOVE REAR CATALYTIC CONVERTER (FRONT EXHAUST PIPE)
(a) Remove the two bolts and nuts holding the front exhaust
pipe to the center exhaust pipe.
(b) Remove the two bolts and nuts holding the front exhaust
pipe to the front catalytic converter, and remove the front
exhaust pipe and two gaskets.
3. REINSTALL REAR CATALYTIC CONVERTER (FRONT EXHAUST PIPE)
Install the two new gaskets, the front exhaust pipe with the
four bolts and new nuts.
Torque: 43 N Vm (440 kgf Vcm, 32 ft Vlbf)
4. (USA Spec.)
REINSTALL SUB±OXYGEN SENSOR
Install the new gasket, the sub±oxygen sensor to the front ex-
haust pipe with the two nuts.
Torque: 18 N Vm (180 kgf Vcm, 13 ft Vlbf)
±
EMISSION CONTROL SYSTEMS Three±way Catalyst (TWC) SystemEC±19
WhereEverybodyKnowsYourName


Front water bypass joint x Cylinder head  18 185 13
 Intake manifold x Cylinder head1818513
Delivery pipe x Intake manifold1818513
Fuel return pipe x Fuel pressure regulator

35

360

26 Fuel inlet hose x Delivery pipe  39 400 29  for SST 33 340 24 Cold start injector x Air intake chamber  7.8 80 69 in.Vlbf Air intake chamber x Intake manifold  18 185 13 EGR pipe x Air intake chamber  18 185 13
 EGR pipe x RH cylinder head  18 185 13
 Cold start injector tube x Air intake chamber  15 150 11
 Union (for brake booster) x Air intake chamber  29 300 22
 Throttle body x Air intake chamber  18 185 13
 IAC valve x Air intake chamber  18 185 13
 EGR valve adaptor x Air intake chamber  18 185 13
 EGR valve x EGR valve adaptor  18 185 13
Timing belt rear plate x Cylinder head7.88069 in. Vlbf
Water outlet housing x Water pump

18

185

13 Main bearing stud bolt x Cylinder block  15 150 11 Main bearing cap x Cylinder block for nut (1st) 27 275 20  (2nd) Turn 90 5
  for bolt 49 500 36 Connecting rod cap x Connecting rod 1st 25 250 18
  2nd Turn 905
 Rear oil seal retainer x Cylinder block  7.8 80 69 in.Vlbf
 Water seal plate x Cylinder block  14 145 10
 Generator bracket x Cylinder block  18 185 13
 Oil pump x Cylinder block 12 mm head 16 160 12
  14 mm head 30 310 22
 No.1 oil pan x Cylinder block 10 mm head 7.8 80 69 in. Vlbf
12 mm head1818513
No.1 oil pan x Oil pump

7.8

80

69 in. Vlbf No.1 oil pan x Rear oil seal retainer  7.8 80 69 in. Vlbf Oil strainer x Cylinder block  7.8 80 69 in. Vlbf Oil strainer x Oil pump  7.8 80 69 in. Vlbf Oil pan baffle plate x No.1 oil pan  7.8 80 69 in. Vlbf No.1 oil pan x No.2 oil pan  7.8 80 69 in. Vlbf
 Water pump x Cylinder block  18 185 13
 Water bypass pipe x Cylinder Block  18 185 13
 Knock sensor x Cylinder block  44 450 33
 Starter x Cylinder block  39 400 29
 Engine mounting bracket x Cylinder block  37 380 27
 Drive plate x Crankshaft  98 1,000 72
 Transmission x Cylinder block  57 580 42
 Transmission x No.1 oil pan  39 400 29
Drive plate x Torque converter3334025 Transmission oil cooler pipe x Transmission for union nut 34 350 25 Rear engine mounting member x Body  25 250 19\
 \
Rear engine mounting member x Rear engine mounting insulator1313510
EG±210±
1UZ ± FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

\
 \

Front suspension crossmember x Engine mounting insulator  59 600 43
\
 \
PS pump x Cylinder head for bolt 39 400 29
\
 \
 for nut 43 440 32
\
 \
Propeller shaft x Transmission  79 805 58\
 \

Propeller shaft x Differential

79

805

58\
 \

Propeller shaft x Body

37

375

27\
 \
Center floor crossmember brace x Body  13 130 9\
 \
Fuel inlet hose x Fuel tube  30 310 22\
 \
TWC (Front) x Exhaust manifold  62 530 46\
 \
Front exhaust pipe x TWC (Front)  43 440 32\
 \
Front exhaust pipe support bracket x Transmission  43 440 32\
 \
Front exhaust pipe x Center Exhaust pipe  43 440 32\
 \
Center exhaust pipe x Tailpipe  44 195 14
\
 \
Main heated oxygen Exhaust manifold  44 450 33
\
 \
Sub heated oxygen sensor x Front exhaust pipe  44 450 33
±
1UZ ± FE ENGINE ENGINE MECHANICALEG±211
WhereEverybodyKnowsYourName

The 1 UZ±FE engine has 8±cylinders in a V±arrangement at a bank an\
gle of 905. From the front of the RH
bank cylinders are numbered 2 ± 4 ± 6 ± 8, and from the front of t\
he LH bank cylinders are 1 ± 3 ± 5 ± 7.
The crankshaft is supported by 5 bearings inside the crankcase. These beari\
ngs are made of a copper and
lead alloy.
The crankshaft is integrated with 8 weights for balance. Oil holes are plac\
ed in the center of the crankshaft
to supply oil to the connecting rods, bearing, pistons and other component\
s.
The ignition order is 1 ± 8 ± 4 ± 3 ± 6 ± 5 ± 7 ± 2. T\
he cylinder head is made of alminum alloy, with a cross
flow type intake and exhaust layout and with pent±roof type combustion chambers. The spark plugs are
located in the center of the combustion chambers.
At the front and rear of the intake manifold, a water passage has been p\
rovided which connects the RH
and LH cylinder heads.
Exhaust and intake valves are equipped with irregular pitch springs made\
of special valve spring carbon
steel which are capable of functioning at all engine speeds.
The RH and LH intake camshaft are driven by a timing belt, and a gear on\
the intake camshaft engages
with a gear on the exhaust camshaft to drive it. The cam journal is supp\
orted at 5 (intake) or 4 (exhaust)
places between the valve lifters of each cylinder and on the front end o\
f the cylinder head. Lubrication of
the cam journals and gears is accomplished by oil being supplied through th\
e oiler port in the center of the
camshaft.
Adjustment of the valve clearance is done by means of an outer shim type\
system, in which valve adjusting
shims are located above the valve lifters. This permits replacement of the sh\
ims without removal of the
camshafts.
Pistons are made of high temperature±resistant aluminum alloy, and a depression is built into the piston
head to prevent interference with the valves.
Piston pins are the full±floating type, with the pins fastened to neither the piston boss nor the connecting
rods. Instead, snap rings are fitted on both ends of the pins, preventing the\
pins from falling out.
The No.1 compression ring is made of steel and the No.2 compression ring\
is made of cast iron. The oil
ring is made of a combination of steel and stainless steel. The outer diamet\
er of each piston ring is slightly
larger than the diameter of the piston and the flexibility of the rings allows them to hug the cylinder walls
when they are mounted on the piston. Compression rings No.1 and No.2 work to\
prevent gas leakage from
the cylinder and the oil ring works to scrape oil off the cylinder walls to prevent it from entering the combus-
tion chambers.
The cylinder block is made of aluminum alloy with a bank of 90 5. Cast iron cylinders are installed inside
the cylinder block. It has 8 cylinders which are approximately twice the le\
ngth of the piston stroke. The top
of each cylinder is closed off by the cylinder head and the lower end of the cylinders becomes the crank-
case, in which the crankshaft is installed. In addition, the cylinder block c\
ontains a water jacket, through
which coolant is pumped to cool the cylinders.
The No.1 and No.2 oil pans are bolted onto the bottom of the cylinder bl\
ock. The No.1 oil pan is made of
aluminum alloy. The No.2 oil pan is an oil reservoir made of pressed steel sheet. An o\
il level sensor is
installed in the No.1 oil pan (If oil level drops below a set level, a warning light\
s up.). And oil pan baffle plate
keeps sufficient oil in the bottom of the No.2 oil pan even when the vehicle is t\
ilted. This dividing plate also
prevents the oil from marking waves when the vehicle is stopped suddenly\
and the oil shifts away from the
oil pump suction pipe.
Plastic region tighten bolts are used for the cylinder head, main bearin\
g cap and connecting rod.
EG±4
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

10. REMOVE RH NO.3 TIMING BELT COVERRemove the 3 bolts, timing belt cover and 3 gaskets.
11. DISCONNECT FUEL INLET HOSE FROM LH DELIVERY PIPE
Remove the pulsation damper and 2 gaskets, and discon-
nect the fuel inlet hose from the delivery pipe.
CAUTION:
w Put a shop towel under the delivery pipe.
w Slowly loosen the union bolt.
12. D I S C O N N E C T F U E L R E T U R N H O S E F R O M F U E L
RETURN PIPE
13. DISCONNECT PCV HOSE FROM LH CYLINDER HEAD
14. REMOVE LH NO.3 TIMING BELT COVER
(a) Remove the 4 bolts.
(b) Disconnect the cord grommet from the timing belt cover, and remove the timing belt cover and 3 gaskets.
(c) Remove the cord grommet from the high±tension cord.
15. DISCONNECT HEATER WATER VALVE FROM BODY
(a) Disconnect the VSV connector.
(b) Remove the bolt holding the engine wire clamp to the water valve bracket.
(c) Remove the 2 bolts, and disconnect the water valve and bracket assembly.
16. REMOVE THROTTLE BODY
(a) Disconnect the following connectors: (1) Throttle position sensor connector
(2) w/ TRAC:
Sub±throttle position sensor connector
(3) w/ TRAC:
Sub±throttle actuator connector
EG±16
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

(e) Connect the following connectors:(1) Throttle position sensor connector
(2) w/ TRAC:Sub±throttle position sensor connector
(3) w/ TRAC: Sub±throttle actuator connector
27. REINSTALL HEATER WATER VALVE
(a) Install the water valve and bracket assembly with the 2 bolts.
(b) Install the engine wire clamp with the bolt.
(c) Connect the VSV connector.
28. REINSTALL RH NO.3 TIMING BELT COVER
(a) Install the 3 gaskets to the timing belt cover.
(b) Fit the portion A of the timing belt cover, matching it with the lower high±tension cord cover.
(c) Install the timing belt cover with the 3 bolts.
29. REINSTALL VSV FOR EVAP SYSTEM Install the VSV with the 2 bolts.
30. REINSTALL LH NO.3 TIMING BELT COVER
(a) Install the 3 gaskets to the timing belt cover.
(b) Install the cord grommet to the high±tension cord (from the LH ignition coil).
(c) Install the cord grommet to the timing belt cover.
(d) Fit the portion A of the timing belt cover, matching it with the lower high±tension cord cover.
(e) Install the timing belt cover with the 4 bolts.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±29
WhereEverybodyKnowsYourName

(b) Connect the tester probe of a timing light to the high ±tension
cord for No.6 cylinder.
(c) Using a timing light, check the ignition timing.
Ignition timing: 8 ± 12 5 BTDC @ idle
(Transmission in neutral position)
If the ignition timing is not as specified, check that following
conditions are normal:
w Throttle valve fully closed
w Continuity between terminals IDL1 and E2 of the throttle
position sensor
w Valve timing
(d) Remove the SST from the DLC1. SST 09843±18020
5. DISCONNECT TACHOMETER AND TIMING LIGHT FROM ENGINE
6. REINSTALL UPPER HIGH±TENSION CORD COVER
(a) Fit portion A of the upper high±tension cord cover matching the top of the lower high±tension cord cover.
(b) Push the front side of the upper high±tension cord cover, and
fit the front side claw groove of the upper high±tension cord
cover to the claw of the lower high ±tension cord cover.
(c) Install the upper high±tension cord cover with the 2 bolts.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±33
