- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-8
1862 Author
: Date
:
VALVE BODY ASSEMBLY
ON-VEHICLE REPAIR
1. REMOVE ENGINE NO.2 UNDER COVER
2. DRAIN ATF
3. REMOVE OIL PAN
NOTICE:
Some fluid will remain in the oil pan.
(a) Remove the 20 bolts.
(b) Remove the oil pan gasket.
4. EXAMINE PARTICLES IN PAN
Remove the magnets and use them to collect steel particles.
Carefully look at the foreign matter and particles in the pan and
on the magnets to anticipate the type of wear you will find in the
transmission.
Steel (magnetic)...bearing, gear and clutch plate wear
Brass (non-magnetic)...bushing wear
5. REMOVE OIL STRAINER
Remove the 4 bolts, the oil strainer and the O-ring.
NOTICE:
Be careful as some fluid will come out with the oil strainer.
6. DISCONNECT TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid connectors.
(b) Remove 2 bolts and the 2 temperature sensors clamp
from the valve body.
(c) Disconnect the 2 temperature sensor from the valve body.
7. DISCONNECT 7 CONNECTORS FROM SHIFT SOLE-
NOID VALVES

D12705
D12706
Shift
Solenoid
Valve SL2Shift
Solenoid
Valve SLUShift
Solenoid
Valve SR
Shift
Solenoid
Valve S2 Shift
Solenoid
Valve S1 Shift
Solenoid
Valve SL1 Shift
Solenoid
Valve SLT
D12707
Pin
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-9
1863 Author
: Date
:
8. REMOVE VALVE BODY
(a) Remove the 19 bolts and the valve body.
(b) Remove the 3 drum seal gaskets.
9. REMOVE SOLENOID VALVE
(a) Remove the 2 bolts and the shift solenoid valve SR.
(b) Remove the 3 bolts and the shift solenoid valve S1 and
S2.
(c) Remove the 2 bolts, 2 solenoid lock plates and the 4
straight pins.
(d) Remove the shift solenoid SL2 and the shift solenoid
valve SLU.
(e) Remove the shift solenoid SL1 and the shift solenoid
valve SLT.
(f) Remove the O-ring from the solenoid valve S2.
10. INSTALL SOLENOID VALVE
(a) Install a new O-ring to shift solenoid valve S2.
(b) Install the shift solenoid SL1 and the shift solenoid valve
SLT.
(c) Install the shift solenoid SL2 and the shift solenoid valve
SLU.
(d) Install the 4 straight pins and the 2 solenoid lock plates
with the 2 bolts.
Torque:6.4 N´m (65 kgf´cm,57 in´lbf)
(e) Install the shift solenoid valve S1and S2 with the 2 bolts.
Torque:10 N´m (102 kgf´cm,7 ft´lbf)
(f) Install the shift solenoid valve SR with the 2 bolts.
Torque:6.4 N´m (65 kgf´cm,5.7 ft´lbf)
11. INSTALL VALVE BODY
HINT:
Align the groove of the manual valve with the pin of the lever.
(a) Install the 3 new drum seal gaskets to the transmission
case.

D12705
A
A
AAAA A B
D12704
A B
OrangeBlue
D12703
D13663
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-10
1864 Author
: Date
:
(b) Install the 19 bolts and the valve body.
Torque:
BoltA.B: 11 N´m (110 kgf´cm, 8 ft´lbf)
Bolt length:
Bolt A: 25 mm (0.98 in.)
Bolt B: 36 mm (1.42 in.)
12. CONNECT TEMPERATURE SENSOR
(a) Connect the 2 temperature sensors to the valve body, and
install the 2 temperature sensors clamp with the 2 bolts.
Torque:
A: 11 N´m (112 kgf´cm, 8 ft´lbf)
B: 10 N´m (100 kgf´cm, 7 ft´lbf)
Bolt length:
Bolt A: 36 mm (1.42 in.)
Bolt B: 12 mm (0.47 in.)
Sensor wire harness:
Wire harnessColor
for linear controlOrange
for oil temp warning lampBlue
13. CONNECT 7 CONNECTORS TO SHIFT SOLENOID
VA LV E S
14. INSTALL OIL STRAINER
(a) Install a new O-ring.
(b) Install the oil strainer with the 4 bolts.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
15. INSTALL OIL PAN
HINT:
Remove any packing material, and be careful not to spill oil on
the contacting surfaces of the transmission case and the oil
pan.
(a) Install a new gasket and oil pan.
(b) Install the 20 bolts and oil pan.
Torque: 4.4 N´m (45 kgf´cm, 39 in´lbf)

- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-1 1
1865 Author
: Date
:
16. FILL ATF AND CHECK ATF LEVEL
(a) Install a new gasket and a drain plug.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(b) Remove the refill plug.
(c) Fill new fluid through the refill hole (See page AT-3-1).
17. INSTALL ENGINE NO.2 UNDER COVER

D12734
AT07Y-02
D12736
D12734
AT-4
- AUTOMATIC TRANSMISSIONVEHICLE SPEED SENSOR
1858 Author
: Date
:
2004 LAND CRUISER (RM1071U)
VEHICLE SPEED SENSOR
ON-VEHICLE REPAIR
1. DISCONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR
2. REMOVE NO. 1 VEHICLE SPEED SENSOR
Remove the bolt and the No. 1 vehicle speed sensor.
3. DISASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Remove the O-ring from the speedometer driven gear
assembly.
(b) Remove the clip and the speedometer driven gear from
the speedometer driven gear sleeve.
4. ASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Install the speedometer driven gear and the clip to the
speedometer driven gear sleeve.
(b) Coat a new O-ring with ATF.
(c) Install the O-ring to the speedometer driven gear assem-
bly.
5. INSTALL NO. 1 VEHICLE SPEED SENSOR
Install the No. 1 vehicle speed sensor with the bolt.
Torque: 16 N´m (160 kgf´cm, 12 ft´lbf)
6. CONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR

D12737
Speed Sensor NT
Speed Sensor SP2
D02395
D12737
Speed Sensor NT
Speed Sensor SP2
- AUTOMATIC TRANSMISSIONVEHICLE SPEED SENSOR
AT-5
1859 Author
: Date
:
2004 LAND CRUISER (RM1071U)
7. DISCONNECT SPEED SENSOR NT AND SP2 CON-
NECTORS
8. REMOVE SPEED SENSOR NT AND SP2
(a) Remove the 2 bolts, speed sensor NT and SP2.
(b) Remove 2 O-rings from the speed sensor NT and SP2.
9. INSTALL SPEED SENSOR NT AND SP2
(a) Coat 2 new O-rings with ATF and install them to the
speed sensor NT and SP2.
(b) Install the speed sensor NT and SP2 with 2 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
10. CONNECT SPEED SENSOR NT AND SP2 CONNEC-
TORS

- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-497
690 Author
: Date
:
2004 LAND CRUISER (RM1071U)
Pattern Select Switch Circuit (2nd Start Switch)
CIRCUIT DESCRIPTION
When 2nd start mode is selected with the pattern select switch, the ECM controls the solenoid valves and
the transmission starts from 2nd gear.
In D position, the transmission automatically shifts up through 3rd to 5th as usual.
In 2nd position, the transmission is held in 2nd gear.
DIB3N-02

D12771
ECM
PWR E829 J/B No.4
E4
(*) Electronically Controlled
Transmission Pattern Select SW
5
W-B
IF IU19
SB Combination Meter
C1519
Cowl Side J/B LH
L-R
1
2
3 C1520
SB312
4F 4C
W-BB
B
E8
E8
E818
28 2nd
PWR
5L-W 10
3M
3PCowl Side J/B RH
18
2E66 24
2E 2QP-B
SNWI MPX1 MPX2
(*) Pattern Select Switch (2nd Start Switch)
When the 2nd start switch is pushed, the switch contact is made and the 2nd mode is selected.
To cancel the 2nd start, push the 2nd start switch once again. The 2nd start is automatically cancelled
out when the ignition switch is turned OFF. DI-498
- DIAGNOSTICSAUTOMATIC TRANSMISSION
691 Author
: Date
:
2004 LAND CRUISER (RM1071U)
WIRING DIAGRAM
