- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-499
692 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Check pattern select switch (2nd start switch).
PREPARATION:
Disconnect the pattern select switch connector.
CHECK:
Check continuity between terminals 2 and 3 of pattern select
switch connector when pattern select switch is set to 2nd start
switch ON and OFF.
OK:
2nd start switchSpecified condition
Press continuously º2ndº switchContinuity
Release º2ndº switchNo continuity
NG Replace the pattern select switch.
OK
2 Check harness and connector between terminal SNWI of ECM and body ground.
PREPARATION:
(a) Connect the pattern select switch connector.
(b) Disconnect the connector of ECM.
CHECK:
Check continuity between terminal SNWI of ECM and body
ground when the pattern select switch is set to 2nd start switch
ON and OFF.
OK:
2nd start switchSpecified condition
Press contnuously º2ndº switchContinuity
Release º2ndº switchNo Continuity
OK Proceed to next circuit inspection shown on
matrix chart (See page DI-396).
NG
Repair or replace harness or connector
(See page IN-36).
Page 921 of 3115
D12773D13182
ECM
TFN E8
IU1 Combination Meter
19
SB
8Cowl Side J/B LH
EB1
D6
Detection SW
(Transfer Neutral Position)
W-B Y-G
1 2SBBJ/B No.4
B29
12 3
4F 4C 9
C15
C1520
5
EB1 W-B Y-GY-G1118
E8
E7 P-B 24 66
2Q2E
38 39
6D
6D J/B No. 6MPX1 MPX2
EC Y-G 10
If1 DI-500
- DIAGNOSTICSAUTOMATIC TRANSMISSION
693 Author: Date:
2004 LAND CRUISER (RM1071U)
A/T. P. (Automatic Transmission Parking) Indicator Circuit
CIRCUIT DESCRIPTION
The propeller shaft and wheels are free even when the transmission shift lever is set to P as long as the
transfer shift lever is in Neutral position. The A/T.P. indicator light lights up to warn the driver that the propeller
shaft and wheels are not locked.
If the A/T.P. indicator light goes on, the transfer shift lever should be shifted to the positions other than N
position.
WIRING DIAGRAM
DI3C7-07
Page 922 of 3115
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-501
694 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Check park/neutral position switch (See page DI-402).
NG Replace the park/neutral position switch.
OK
2 Check transfer neutral position switch (See page DI-457).
NG Replace the transfer neutral position switch.
OK
3 Check harness and connector between ECM and transfer neutral position
switch, transfer neutral position switch and body ground (See page IN-36).
NG Repair or replace the harness or connector.
OK
Proceed to next circuit inspection shown on
matrix chart (See page DI-396).
Page 923 of 3115
DIC2Y-01
DI-402
- DIAGNOSTICSAUTOMATIC TRANSMISSION
595 Author: Date:
2004 LAND CRUISER (RM1071U)
CIRCUIT INSPECTION
DTC P0705 Transmission Range Sensor Circuit Mal-
function (PRNDL Input)
DTC P0850 Park/Neutral Switch Input Circuit
CIRCUIT DESCRIPTION
The park/neutral position switch detects the shift lever position and sends signals to the ECM.
DTC No.DTC Detection ConditionTrouble Area
P0705
(2-trip detection logic)
All switches are OFF simultaneously for P, R, N, D, 3 and 2
positions.
2 or more switches are ON simultaneously for P, R, N, (D 4),
3 and (2 L) positions.
Short in park/neutral position switch circuit
P k/ t l iti it h
P0850
Park/neutral position switch remaines ON (P, N position) during
driving under conditions (a) and (b) for 30 sec. (2-trip detection
logic)
(a) Vehicle speed: 70 km/h (44 mph) or more
(b) Engine speed: 1,500 - 2,500 rpmPark/neutral position switch
ECM
MONITOR DESCRIPTION
The park/neutral position switch detects the shift lever position and sends a signal to the ECM.
For security, the park/neutral position switch detects the shift lever position so that engine can be started
only when the vehicle is in P or N shift position.
When the park/neutral position switch sends more than one signal at a time from switch positions P, R, N
or D, the ECM interprets this as a fault in the switch. The ECM will turn on the MIL and store the DTC.
MONITOR STRATEGY
P0705:
Related DTCsP0705Park/neutral position switch/Verify switch input
Required sensors/ComponentsPark/neutral position switch
Frequency of operationContinuous
DtiCondition (A), (B) and (D)2 sec.DurationCondition (C)60 sec.
MIL operation2 driving cycle
Sequence of operationNone
Page 924 of 3115
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-403
596 Author: Date:
2004 LAND CRUISER (RM1071U)
P0850:
Related DTCsP0850Park/neutral position switch/Verify switch cycling
Rid /C tMainPark/neutral position switchRequired sensors/ComponentsSubCrankshaft position sensor (NE), MAF meter
Frequency of operationContinuous
Duration30 sec.
MIL operation2 driving cycles
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
P0705:
ItSpecificationItemMinimumMaximum
The monitor will run whenever the follow-
ing DTCs are not present.See page DI-361
Ignition switchON
Battery voltage10.5 V or more
P0850:
ItSpecificationItemMinimumMaximum
The monitor will run whenever the follow-
ing DTCs are not present.See page DI-361
Vehicle speed70 km/h (43 mph) or more-
Engine speed1,500 rpm or more2,500 rpm or less
Intake air amount per revolution0.9 g/rev. or more-
Page 925 of 3115
DI-404
- DIAGNOSTICSAUTOMATIC TRANSMISSION
597 Author: Date:
2004 LAND CRUISER (RM1071U)
TYPICAL MALFUNCTION THRESHOLDS
P0705:
Detection criteriaThreshold
One of the following conditions is met: Condition (A), (B), (C) or (D)
Condition (A)
Number of the following signal input at the same time2 or more
P switch
N switch
R switchON D switchON
3 switch
2 switch
Condition (B)
Number of the following signal input at the same time2 or more
NSW switch
R switch
D switchON
3 switch
ON
2 switch
Condition (C)
All of following conditions are met
P switch
N switch
NSW switch
R switchOFF
D switch
OFF
3 switch
2 switch
Condition (D)
Both (i) and (ii) are met
(i) One of followings is met
NSW switch
P switchON N switchON
R switch
(ii) One of followings is met
4 switchON L switchON
P0850:
Detection criteriaThreshold
NSW signalON
Page 926 of 3115
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-405
598 Author: Date:
2004 LAND CRUISER (RM1071U)
COMPONENT OPERATING RANGE
P0705:
ParameterStandard value
Park/neutral position switchThe park/neutral position switch sends only one signal to the ECM.
P0850:
ParameterStandard value
Park/neutral position switchThe park/neutral position switch is OFF when avobe condition.
Page 927 of 3115
D12758
B-RB-W
B-W
2 391
IG1 No. 3 Relay
STAR To Starter Relay
A
7
39 SB LL2L DL7
R-LG-W
GAUGE2If1
ALT
Battery1
2C2EI18
Ignition SW
B-R 12 IN2
IG1 1310
J/B No. 6
3P
3QSB
3C6D
3M4
4 5
2 4
2Q6
Ib2185C
GPECM
E6
E5
E9
E8R
D
2 N NSW
Shift Lock Control ECU
6
B-G5D
2
6C 8
6
II 109
R-B
AM111
20
9 16
17 J17
J/C
33M
3M
3M 3P
3P
3P
3E
2E6C6D 6D
AM137 77
1Cowl Side J/B LH
L-B
2 J/B No. 2J/B No. 3 FL Block
1
1
F16 F17B-G141
3 Cowl Side J/B RH
G-R R-L G-B G-Y
A48A48 A48 A48 R-L 14R-L
3
RBNL RL PL
1
G-BE8 E8E8 E9
3 1913
5
6 11
12
13
34
17
27
28
30
20
16 6D6D6D 6D
6C 6C 6C6C 6C 6C 6CA A
B-W
69 P1
Park/Neutral Position SW
G-Y G-R To Body ECUG-W
1
G-W
IX1
1
R-B R-BG-W
G
G-B G-Y G-R
R-L
G-R8
23
1 3
5L
4 E8E8 G-W J/B No. 5
NSSD
NSSL
AT L
AT 41
6
12
8G-B G-Y NP
To ABS & BA &
TRAC & VSC ECU
DI-406
- DIAGNOSTICSAUTOMATIC TRANSMISSION
599 Author: Date:
2004 LAND CRUISER (RM1071U)
WIRING DIAGRAM
