2023 TOYOTA RAV4 PRIME display

RAV4 PRIME_OM_OM42E79U_(U)
1
2
3
4
5
6
7
8
9
10
Pictorial indexSearch by illustration
For safety
and securityMake sure to read through them
(Main topics: Child seat, theft deterrent system)
Plug-in hybrid
systemPlug-in hybrid system features, charging method,
etc.
(Main topics: Driving tips, charging methods)
Vehicle status
information and
indicatorsReading driving-related information
(Main topics: Meters, multi-information display)
Before driving
Opening and closing the doors and windows,
adjustment before driving
(Main topics: Keys, doors, seats, power windows)
Driving
Operations and advice which are necessary for
driving
(Main topics: Starting hybrid system, refueling)
Interior featuresUsage of the interior features
(Main topics: Air conditioner, storage features)
Maintenance
and careCaring for your vehicle and maintenance
procedures
(Main topics: Interior and exterior, light bulbs)
When trouble
arisesWhat to do in case of malfunction and emergency
(Main topics: 12-volt battery discharge, flat tire)
Vehicle
specificationsVehicle specifications, customizable features
(Main topics: Fuel, oil, tire inflation pressure)
For ownersReporting safety defects for U.S. owners, and seat
belt, SRS airbag and headlight aim instructions for
Canadian owners
IndexSearch by symptom
Search alphabetically

2TABLE OF CONTENTS
For your information...................6
Reading this manual ................ 11
How to search .......................... 12
Pictorial index .......................... 14
1-1. For safe use Before driving ................... 26
For safe driving ................ 27
Seat belts ......................... 29
SRS airbags ..................... 33
Front passenger occupant classification system ...... 43
Exhaust gas precautions.. 48
1-2. Child safety Riding with children .......... 49
Child restraint systems..... 50
1-3. Emergency assistance Safety Connect ................ 65
1-4. Theft deterrent system Immobilizer system .......... 70
Alarm................................ 71
2-1. Plug-in hybrid system Plug-in hybrid system fea-tures ............................... 74
Plug-in hybrid system pre- cautions .......................... 85
Plug-in Hybrid Electric Vehi- cle driving tips ................ 90
EV driving range .............. 93
2-2. Charging Charging equipment......... 97AC charging cable .........
100
Locking and unlocking the charging port lid and
charging connector ...... 105
Power sources that can be used............................. 110
Charging methods ......... 113
Charging tips ................. 115
Things to know before charging....................... 117
How to charge ............... 121
Using the charging schedule function ........................ 128
Using the “My Room Mode” .................................... 148
When charging cannot be carried out ................... 152
3-1. Instrument cluster Warning lights and indicators.................................... 166
Gauges and meters (with 7- inch display) ................ 173
Gauges and meters (with 12.3-inch display) ........ 178
Multi-information display (with 7-inch display)..... 185
Multi-information display (with 12.3-inch display) 196
Head-up display ............ 208
Energy monitor/consumption screen.......................... 212
1For safety and security
2Plug-in hybrid system
3
Vehicle status
information and
indicators

17Pictorial index
■Instrument panel
Power switch ................................................... ...................P.304
Starting the hybrid system/chan ging the modes ..........P.304, 307
Emergency stop of the hybrid system ............................ ......P.535
When the hybrid system will not start .......................... ........P.564
Warning messages ..............................................................P.552
Shift lever.................................................... ........................P.309
Changing the shift position.................................... ...............P.310
Precautions against towing ..................................................P.538
When the shift lever does not move............................. ........P.311
Meters ......................................................... ................P.173, 178
Reading the meters/adjusting the instrument panel light ............................................................... ......................P.177, 184
Warning lights/indicator lights ................................ ..............P.166
When the warning lights come on ................................ ........P.541
Multi-information display . .........................................P.185, 196
Display ........................................................ .................P.185, 196A
B
C
D

18Pictorial index
Energy monitor.....................................................................P.212
When the warning messages are displayed ........................ P.552
Turn signal lever ................................................................P.313
Headlight switch ................................................................P.321
Headlights/parking lights/tail lig hts/license plate lights/daytime
running lights/LED accessory lights
*1..................................P.321
Windshield wiper and washer switch ..............................P.327
Rear window wiper and washer switch ...........................P.330
Usage.......................................................... .................P.327, 330
Adding washer fluid ..............................................................P.494
Warning messages ..............................................................P.552
Emergency flasher switch ....................................... ..........P.534
Hood lock release lever ........................................ .............P.486
Tilt and telescopic steering lock release lever ................P.256
Adjustment ..................................................... ......................P.256
Air conditioning system ............................. .......................P.422
Usage.......................................................... .........................P.422
Rear window defogger ........................................... ..............P.424
Audio system
*2
Fuel filler door opener swi tch ...........................................P.333
*1: If equipped
*2: Refer to “MULTIMEDIA OWNER’S MANUAL”.
E
F
G
H
I
J
K
L

19Pictorial index
■Switches
Driving position memory switches*1................................P.250
Window lock switch ............................................. ..............P.272
Power window switches ....... .............................................P.270
Door lock switches ............................................................P.225
Outside rear view mirror swi tches ...................................P.268
“ODO TRIP” switch (vehicles with 7-inch multi-information dis-
play).......................................................... ...........................P.177
“ODO TRIP” switch (vehicles with 12.3-inch multi-information
display) ....................................................... ........................P.183
Instrument panel light control dial ...........................P .177, 184
Automatic High Beam switch ..................................... ......P.324
Windshield wiper de-icer switch
*1....................................P.429
Camera switch
*1, 2
Heated steering wheel switch*1........................................P.433
Power back door switch
*1.................................................P.231
*1: If equipped
*2: Refer to “MULTIMEDIA OWNER’S MANUAL”.
A
B
C
D
E
F
G
H
I
J
K
L
M

752-1. Plug-in hybrid system
2
Plug-in hybrid system
The plug-in hybrid system oper-
ates in the following modes.
The multi-information display can
be used to check which mode the
plug-in hybrid system is currently
being driven in. (P.185, 196)
■EV mode
When a sufficient amount of
electricity is remaining after
charging
*1, EV driving is per-
formed using electricity stored in
the hybrid battery (traction bat-
tery).
*2
When in EV mode, the EV drive
mode indicator illuminates.
*1: The amount of remaining charge can be checked on the SOC
(State of Charge) gauge.
( P.173)
*2: Depending on the situation, EV
driving may be canceled and
both gasoline engine and electric
motor are used. ( P.80)
■AUTO EV/HV mode
Normally, the electricity stored
in the hybrid battery (traction
battery) is used for EV driving.
However, when more power is
required, such as for driving
uphill or accelerating suddenly,
the gasoline engine starts and
provides powerful acceleration
by strongly depressing the
accelerator pedal.
When the vehicle is in a condi-
tion where EV driving is possi-
ble, EV mode and AUTO EV/HV
mode can be switched by oper-
ating the switch. ( P.76)
When in AUTO EV/HV mode, the
AUTO EV/HV mode indicator illumi-
nates.
■HV mode
When in HV mode, the vehicle is
driven using both the gasoline
Plug-in hybrid system
operation mode

782-1. Plug-in hybrid system
from an external power source.
■If the plug-in hybrid system
operation mode cannot be
changed
In the following si tuations, the plug-
in hybrid system operation mode
cannot be changed even if the
AUTO EV/HV mode switch or
EV/HV mode selection switch is
pressed. (In this case, the warning
message is displaye d on the multi-
information displa y when the switch
is pressed.)
●When electricity needed for EV
driving is not remaining (when in
EV mode or AUTO EV/HV mode)
●When the traction battery is
almost completely charged (hybrid
battery [traction battery] charge
mode)
■When switching from EV mode
to another mode using the
switch
When the power switch is turned off,
operation mode switching is can-
celed and the system returns to EV
mode the next time the vehicle is
started.
*
*
: If there is not enough charge remaining in the hybrid battery
(traction battery) to allow EV driv-
ing, the system s witches to HV
mode.
■Hybrid battery (traction battery)
charge mode
●The following may occur to protect the system, etc.
• Cannot switch to hybrid battery (traction battery) charge mode or
cannot cancel it
• Gasoline engine does not start or stops even after switching to
hybrid battery (traction battery)
charge mode
●If a load to the system is large,
such as when the power con-
sumption of the air conditioning
system is large or when the tem-
perature of the engine coolant is
high, it may take longer time than
usual to charge using the hybrid
battery (traction battery) charge
mode, or charging to the hybrid
battery (traction battery) may not
be performed.
■When in EV mode
In EV mode, EV driving (driving
WARNING
■When using the hybrid bat-
tery (traction battery) charge
mode
Observe the following precautions
when using the hybrid battery
(traction battery) charge mode
while parking.
Failure to do so may lead to death
or serious health hazard, as the
gasoline engine operates when in
the hybrid battery (traction bat-
tery) charge mode.
●Do not stop the vehicle near
flammable materials.
●Do not use the hybrid battery
(traction battery) charge mode
in a closed area where ventila-
tion is insufficien t, such as in a
garage or area with snow
buildup.
Control when driving in
each mode

792-1. Plug-in hybrid system
2
Plug-in hybrid system
using only the electric motor)* is
possible. However, depending
on the situation, EV driving may
be canceled and both gasoline
engine and electric motor are
used ( P.80). Also, if a little
electricity is remaining in the
hybrid battery (traction battery),
HV mode is automatically
selected. To drive in EV mode
long, observe the followings.
 Avoid sudden acceleration
and sudden deceleration, and
be sure to drive smoothly. If
you repeatedly accelerate,
the hybrid battery (traction
battery) charge will deplete
quickly. Also, EV driving may
be canceled by rapid acceler-
ation or vehicle speed.
 Restrain your speed as much
as possible. The distance that
can be driven in EV mode will
reduce considerably at high
speeds.
*: The EV driving range can be
checked using the multi-informa-
tion display. ( P.173, 178)
■When in AUTO EV/HV mode
Only the electric motor is used
for EV driving
* during normal
driving, but when the accelera-
tor pedal is strongly depressed,
the gasoline engine starts.
( P.80)
Also, when the hybrid battery
(traction battery) level is low, the
mode switches to HV mode automatically the same as in EV
mode.
AUTO EV/HV mode is suitable
for driving conditions when more
power is required, such as for
driving uphill or accelerating
suddenly. However, because
the gasoline engine will start
more easily, it is recommended
to drive in EV mode usually.
*: The EV driving range can be
checked using th e multi-informa-
tion display. ( P.173, 178)
■When in HV mode
The vehicle can be used in the
same way as a standard Plug-in
Hybrid Electric Vehicle
In HV mode, controls are pri-
marily carried out as follows in
accordance with the driving con-
ditions.
 The gasoline engine stops
*
when the vehicle is stopped.
 During start off, the electric
motor (traction motor) drives
the vehicle.
 During normal driving, the
gasoline engine and electric
motor (traction motor) are
controlled effectively, and the
vehicle is driven with optimum
fuel efficiency. Also, when
necessary, the electric motor
(traction motor) operates as
an electrical generator to
charge the hybrid battery
(traction battery).
