372 Vehicle Care
2. Go to the front of thevehicle and locate the
secondary release lever
under the front center of
the hood. Push the
secondary hood release
lever to the right to
release.
3. After you have partially lifted the hood, the gas
strut system will
automatically lift the hood
and hold it in the fully open
position. To close the hood:
1. Before closing the hood, be sure all filler caps are on
properly, and all tools are
removed.
2. Pull the hood down until the strut system is no
longer holding up the hood.
3. Lower the hood 20 cm (8 in) above the vehicle.
Allow the hood to fall.
Check to make sure the
hood is latched completely.
Repeat this process with
additional force if
necessary.
{Warning
Do not drive the vehicle if
the hood is not latched
completely. The hood could
open fully, block your vision,
and cause a crash. You or
others could be injured.
Always close the hood
completely before driving. The Driver Information Center
(DIC) will display a message if
the hood is not fully closed.
Stop and turn off the vehicle,
check the hood for
obstructions, and close the
hood again. Check to see if the
message still appears on
the DIC.

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
378 Vehicle Care
1. Windshield Washer FluidReservoir. See Washer
Fluid 0393.
2. Engine Coolant Surge Tank and Pressure Cap. See
Cooling System 0386.
3. Engine Air Cleaner/Filter 0384.
4. Engine Cooling Fan (Out of View). See Cooling System
0386.
5. Engine Oil Fill Cap. See Engine Oil 0378.
6. Engine Oil Dipstick. See Engine Oil 0378.
7. Remote Positive (+) Battery Terminal. See
Jump Starting - North
America 0447.
8. Brake/Clutch Fluid Reservoir. See Brake Fluid
0398.
9. Remote Negative (-) Battery Terminal. See
Jump Starting - North
America 0447. 10. Engine Compartment Fuse
Block. See Engine
Compartment Fuse Block
0407.
Engine Oil
To ensure proper engine
performance and long life,
careful attention must be paid
to engine oil. Following these
simple, but important steps
will help protect your
investment:
.Use engine oil approved to
the proper specification and
of the proper viscosity
grade. See “Selecting the
Right Engine Oil” in this
section.
.Check the engine oil level
regularly and maintain the
proper oil level. See
“Checking Engine Oil” and
“When to Add Engine Oil” in
this section.
.Change the engine oil at the
appropriate time. See Engine
Oil Life System 0381.
.Always dispose of engine oil
properly. See “What to Do
with Used Oil” in this section.
Checking Engine Oil
Check the engine oil level
regularly, every 650 km
(400 mi), especially prior to a
long trip. The engine oil
dipstick handle is a loop. See
Engine Compartment
Overview0373 for the
location.
{Warning
The engine oil dipstick
handle may be hot; it could
burn you. Use a towel or
glove to touch the dipstick
handle.
If a low oil Driver Information
Center (DIC) message displays,
check the oil level.

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
Vehicle Care 381
manufacturer's warnings
about the use and disposal of
oil products.
Used oil can be a threat to the
environment. If you change
your own oil, be sure to drain
all the oil from the filter before
disposal. Never dispose of oil
by putting it in the trash or
pouring it on the ground, into
sewers, or into streams or
bodies of water. Recycle it by
taking it to a place that
collects used oil.
Engine Oil Life
System
When to Change
Engine Oil
This vehicle has a computer
system that indicates when to
change the engine oil and
filter. This is based on a
combination of factors which
include engine revolutions,
engine temperature, and miles
driven. Based on driving
conditions, the mileage atwhich an oil change is
indicated can vary
considerably. For the oil life
system to work properly, the
system must be reset every
time the oil is changed.
When the system has
calculated that oil life has been
diminished, it indicates that an
oil change is necessary.
A CHANGE ENGINE OIL
SOON message comes on.
Change the oil as soon as
possible within the next
1 000 km (600 mi). It is
possible that, if driving under
the best conditions, the oil life
system might indicate that an
oil change is not necessary for
up to a year. The engine oil
and filter must be changed at
least once a year and at this
time the system must be
reset. Your dealer has trained
service people who will
perform this work and reset
the system. It is also important
to check the oil regularly over
the course of an oil drain
interval and keep it at the
proper level.
If the system is ever reset
accidentally, the oil must be
changed at 5 000 km
(3,000 mi) since the last oil
change. Remember to reset
the oil life system whenever
the oil is changed.
How to Reset the Engine
Oil Life System
Reset the system whenever
the engine oil is changed so
that the system can calculate
the next engine oil change. To
reset the system:
1. Using the DIC buttons, display REMAINING OIL
LIFE on the DIC. See Driver
Information Center (DIC)
(Base Level) 0129 or
Driver Information Center
(DIC) (Uplevel) 0132.
2. Press and hold the thumbwheel on the
steering wheel. When the

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
382 Vehicle Care
confirmation message
displays, select YES. The
oil life will change to 100%.
Be careful not to reset the
oil life display accidentally
at any time other than
after the oil is changed.
It cannot be reset
accurately until the next oil
change.
The oil life system can also be
reset as follows: 1. Using the DIC buttons, display REMAINING OIL
LIFE on the DIC. See Driver
Information Center (DIC)
(Base Level) 0129 or
Driver Information Center
(DIC) (Uplevel) 0132.
2. Fully press and release the accelerator pedal three
times within five seconds.
If the CHANGE ENGINE
OIL SOON message is not
on, the system is reset.
The system is reset when the
CHANGE ENGINE OIL SOON
message is off. If the CHANGE ENGINE OIL
SOON message comes back
on when the vehicle is started,
the engine oil life system has
not been reset. Repeat the
procedure.
Automatic
Transmission Fluid
How to Check Automatic
Transmission Fluid
It is not necessary to check
the transmission fluid level.
A transmission fluid leak is the
only reason for fluid loss. If a
leak occurs, take the vehicle to
your dealer and have it
repaired as soon as possible.
The vehicle is not equipped
with a transmission fluid level
dipstick. There is a special
procedure for checking and
changing the transmission
fluid. Because this procedure
is difficult, this should be done
at the dealer. Contact your
dealer for additional
information.
Caution
Use of the incorrect
automatic transmission fluid
may damage the vehicle, and
the damage may not be
covered by the vehicle
warranty. Always use the
correct automatic
transmission fluid. See
Recommended Fluids and
Lubricants
0474.
Change the fluid and filter at
the intervals listed in
Maintenance Schedule 0469,
and be sure to use the fluid
listed in Recommended Fluids
and Lubricants 0474.
Manual Transmission
Fluid
It is not necessary to check
the manual transmission fluid
level. A transmission fluid leak
is the only reason for fluid
loss. If a leak occurs, take the
vehicle to your dealer and
have it repaired as soon as

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
Vehicle Care 383
possible. See Recommended
Fluids and Lubricants0474
for the proper fluid to use.
Hydraulic Clutch
For vehicles with a manual
transmission, it is not
necessary to regularly check
brake/clutch fluid unless there
is a leak suspected. Adding
fluid will not correct a leak.
A fluid loss in this system
could indicate a problem. Have
the system inspected and
repaired.
When to Check and What
to Use
The brake/hydraulic clutch
fluid reservoir cap has this
symbol on it. See Engine
Compartment Overview 0373
for reservoir location. The common hydraulic clutch
and brake master cylinder fluid
reservoir is filled with brake
fluid as indicated on the
reservoir cap. See Brake Fluid
0
398 for brake fluid to use.
How to Check and Add
Fluid
Visually check the brake/
clutch fluid reservoir to make
sure the fluid level is at the
MIN (minimum) line on the side
of the reservoir. The brake/
hydraulic clutch fluid system
should be closed and sealed.
Do not remove the cap to
check the fluid level or to
top-off the fluid level. Remove
the cap only when necessary
to add the proper fluid until
the level reaches the MIN line.
Engine Air Filter Life
System
This feature provides the
engine air filter’s remaining life
and best timing for a change.
The timing to change an engine air filter depends on
driving and environmental
conditions.
When to Change the
Engine Air Filter
When the Driver Information
Center (DIC) displays a
message to replace the engine
air filter at the next oil change,
follow this timing.
When the DIC displays a
message to replace the engine
air filter soon, replace the
engine air filter at the earliest
convenience.
The system must be reset
after the engine air filter is
changed.
If the DIC displays a message
to check the engine air filter
system, see your dealer.
How to Reset the Engine
Air Filter Life System
To reset:
1. Place the vehicle in P (Park).

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
384 Vehicle Care
2. Display the Air Filter Lifeon the DIC. See Driver
Information Center (DIC)
(Base Level) 0129 or
Driver Information Center
(DIC) (Uplevel) 0132.
3. Press
Ton the steering
wheel, or press the trip
odometer reset stem if the
vehicle does not have DIC
controls, to move to the
Reset/Disable display area.
Select Reset, then press
the thumbwheel or press
the reset stem for several
seconds.
4. Press the thumbwheel or the reset stem to confirm
the reset.
Engine Air
Cleaner/Filter
The engine air cleaner/filter is
in the engine compartment on
the passenger side of the
vehicle for the 2.0L L4 and
2.7L L4 engines, and in the
center of the engine compartment for the 3.6L
V6 engine. See Engine
Compartment Overview
0373.
When to Inspect the
Engine Air Cleaner/Filter
.For intervals on changing
and inspecting the engine air
filter, see Maintenance
Schedule 0469.
.If equipped with Engine Air
Filter Life System, see
Engine Air Filter Life System
0383.
.If driving in very dusty areas,
follow the engine air filter
inspecting and changing
intervals, see Maintenance
Schedule 0469.
How to Inspect/Replace
the Engine Air
Cleaner/Filter
Do not start the engine or
have the engine running with
the engine air cleaner/filter
housing open. Before
removing the engine air
cleaner/filter, make sure that
the engine air cleaner/filter housing and nearby
components are free of dirt
and debris.
Do not clean the engine air
cleaner/filter or components
with water or compressed air.
{Warning
Operating the engine with
the air cleaner/filter off can
cause you or others to be
burned. Use caution when
working on the engine. Do
not start the engine or drive
the vehicle with the air
cleaner/filter off, as flames
may be present if the engine
backfires.
Caution
If the air cleaner/filter is off,
dirt can easily get into the
engine, which could damage
it. Always have the air
cleaner/filter in place when
driving.

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
392 Vehicle Care
Caution
Do not run the engine if
there is a leak in the engine
cooling system. This can
cause a loss of all coolant
and can damage the system
and vehicle. Have any leaks
fixed right away.
If Steam Is Coming from
the Engine Compartment
{Warning
Steam and scalding liquids
from a hot cooling system
are under pressure. Turning
the pressure cap, even a
little, can cause them to
come out at high speed and
you could be burned. Never
turn the cap when the
cooling system, including the
pressure cap, is hot. Wait for
the cooling system and
pressure cap to cool.
If No Steam Is Coming
from the Engine
Compartment
If an engine overheat warning
is displayed but no steam can
be seen or heard, the problem
may not be too serious.
Sometimes the engine can get
a little too hot when the
vehicle:
.Climbs a long hill on a
hot day.
.Stops after high-speed
driving.
.Idles for long periods in
traffic.
If the overheat warning is
displayed with no sign of
steam: 1. Turn the air conditioning off.
2. Turn the heater on to the highest temperature and
to the highest fan speed.
Open the windows as
necessary. 3. When it is safe to do so,
pull off the road, shift to
P (Park) or N (Neutral) and
let the engine idle.
If the overheat warning no
longer displays, the vehicle
can be driven. Continue to
drive the vehicle slowly for
about 10 minutes. Keep a safe
vehicle distance from the
vehicle in front. If the warning
does not come back on,
continue to drive normally and
have the cooling system
checked for proper fill and
function.
If the warning continues, pull
over, stop, and park the
vehicle right away.
If there is no sign of steam,
idle the engine for
three minutes while parked.
If the warning is still displayed,
turn off the engine until it
cools down.

Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-16500442) -
2023 - CRC - 5/4/22
396 Vehicle Care
with all local and state
ordinances/laws regarding
motor vehicle operation.
Caution
The new vehicle break-in
period should be completed
before performing the brake
burnishing procedure or
damage may occur to the
powertrain/engine. See New
Vehicle Break-In0259.
Caution
Brake fade can occur during
this burnish procedure and
can cause brake pedal travel
and force to increase. This
could extend stopping
distance until the brakes are
fully burnished.
Completing the following
procedure as instructed will
not damage the brakes. The
brake pads may smoke and
produce an odor. The braking
force and pedal travel may increase. After the procedure,
the brake pads may appear
white at the rotor contact.
1. Using the G-Force Gauge in the HUD display, apply
the brakes 10 times
starting at 100 km/h
(60 mph) to 50 km/h
(30 mph) while
decelerating at 0.4g.
SeeHead-Up Display (HUD)
0136. This is a medium
brake application. Drive for
at least 0.5 km (0.3 mi)
between applying the
brakes.
2. If further cleanup of the brake discs is needed,
repeat this procedure with
0.7g applications.
As with all high performance
brake systems, some amount
of brake squeal is normal.
Brake Pad Life
System (If Equipped)
When to Change
Brake Pads
If equipped, this system
estimates the remaining life of
the front and rear brake pads.
Brake Pad Life is displayed in
the Driver Information Center
(DIC), along with a percentage
for each axle. The system
must be reset every time the
brake pads are changed.
When the system has
determined that the brake
pads need to be replaced, a
message displays, which may
include mileage remaining.
Brake pads should always be
replaced as complete
axle sets.
How to Reset the Brake
Pad Life System
The system will automatically
detect when significantly worn
brake pads are replaced.
