2022 TOYOTA TUNDRA HYBRID USB port

4205-4. Using the other interior features
Owners Manual_USA_M0C031_en
5-4.Using the other interior features
The USB charging ports are
used to supply 2.5A (USB Type-
A) or 3.0A (USB Type-C) of
electricity at 5 V to external
devices.
Use the appropriate terminal for
each charging port type.
The USB charging ports are for
charging only. They are not
designed for data transfer or
other purposes.
Depending on the external
device, it may not charge prop-
erly. Refer to the manual
included with the device before
using a USB charging port.
■Using the USB charging
ports
In the console boxUSB Type-A
USB Type-C
Rear of console box
Open the lid. USB Type-A
USB Type-C
■The USB charging ports can be
used when
The power switch is in ACC or ON.
■Situations in which the USB
charging ports may not operate
correctly
●USB Type-A: If a device which
consumes more than 2.5 A at 5 V
is connected
USB Type-C: If a device which
consumes more than 3.0 A at 5 V
is connected
●If a device designed to communi-
cate with a personal computer,
such as a USB memory device, is
connected
●If the connected external device is
turned off (depend ing on device)
●If the temperature inside the vehi-
cle is high, such as after the vehi-
cle has been parked in the sun
■About connected external
devices
Depending on the connected exter-
nal device, charging may occasion-
ally be suspended and then start
again. This is not a malfunction.
Other interior features
USB charging ports

4215-4. Using the other interior features
Owners Manual_USA_M0C031_en
5
Interior features
A portable device can be
charged by just placing Qi stan-
dard wireless charge compatible
portable devices according to
the Wireless Power Consortium, such as smartphones and
mobile batteries, etc., on the
charge area.
This function cannot be used
with portable devices that are
larger than the charging area.
Also, depending on the portable
device, it may not operate as
normal. Please read the opera-
tion manual for portable devices
to be used.
■The “Qi” symbol
The “Qi” symbol is a trademark
of the Wireless Power Consor-
tium.
■Name for all parts
Charge area
Operation indicator light
NOTICE
■To prevent damage to the
USB charging ports
●Do not insert foreign objects into
the ports.
●Do not spill water or other liq-
uids into the ports.
●Rear of console box: When the
USB charging ports are not in
use, close the lids. If a foreign
object or liquid enters a port
may cause a short circuit.
●Do not apply excessive force to
or impact the USB charging
ports.
●Do not disassemble or modify
the USB charging ports.
■To prevent damage to exter-
nal devices
●Do not leave external devices in
the vehicle. The temperature
inside the vehicle may become
high, resulting in damage to an
external device.
●Do not push down on or apply
unnecessary force to an exter-
nal device or the cable of an
external device while it is con-
nected.
■To prevent 12-volt battery dis-
charge
Do not use the USB charging
ports for a long period of time with
the hybrid system is off.
Wireless charger (if
equipped)

608Alphabetical Index
Owners Manual_USA_M0C031_en
TRAC (Traction Control) ........ 375
Traction battery (hybrid battery) ................................................. 76Hybrid battery (traction battery) air intake vents ..................... 79
Location.................................. 76
Specification ......................... 543
Warning message .................. 79
Traction Control (TRAC) ........ 375
Traction motor (electric motor)73 Specification ......................... 543
Trailer Backup Guide ............. 383 Canceling the system ........... 386
Precautions .......................... 387
Procedure............................. 383
Setup (Calibration) ............... 384
Trailer hitch light ................... 386
Using Guidance mode.......... 385
Using Straight Path Assist .... 385
Trailer brake ............................ 380
Trailer brake controller .......... 380 Trailer settings ...................... 100
Trailer hitch light ............ 386, 410 Replacing light bulbs ............ 490
Trailer settings ........................ 100
Trailer Sway Control .............. 375
Trailer towing .......................... 181 Trailer Backup Guide............ 383
Trailer settings ...................... 100
Trailering light Replacing light bulbs ............ 490
Transfer ................................... 545
Transmission Automatic transmission ........ 200
Trip meters ................................ 93
Turn signal lights.................... 204 Replacing light bulbs ............ 490
Turn signal lever ................... 204
U
USB charging ports................ 420
V
Vanity lights ............................431
Vanity mirrors .........................431
Vehicle capacity weight .........541
Vehicle data recording ...............7
Vehicle identification number541
Vehicle information display .....98
Ventilators (seat ventilators) .407
Voltmeter ...................................91
W
Warning buzzersApproach warning ................263
Brake hold ............................506
Brake Override System ........505
Brake system ........................501
Charging system ..................502
Downshifting .........................203
Drive-Start Control ................505
Electric power steering .........503
Engine ..................................502
Hands off steering wheel warn- ing (LTA) .............................251
Hybrid system .......................502
Intuitive parking assist ..280, 504
Low engine oil pressure .......502
LTA (Lane Tracing Assist) ...242, 245, 504
Open door .................... 114, 116
Open window........................161
PCS (Pre-Collisio n System) .503
PKSB (Parking Support Brake) ...........................................504
Pre-collision braking .............230
Pre-collision warn ing ............230
RCTA (Rear Cross Traffic Alert) ...................................282, 505
Seat belt ...............................507
SRS airbag ...........................502
Vehicle sway warning function (LTA) ...................................251
