5137-2. Steps to take in an emergency
Owners Manual_USA_M0C031_en
7
When trouble arises
on P.481 to clean them.
• If the warning message is shown when the air intake vent and filter
of the hybrid battery (traction bat-
tery) are not dirty, have the vehicle
inspected at you r Toyota dealer.
■If “Shift to P Before Exiting
Vehicle” or “Shift to P when
Parked” is displayed
Message is displayed when the
driver’s door is opened without turn-
ing the power switch to OFF with the
shift lever in any position other than
P.
Shift the shift lever to P.
■If “Shift is in N Release Acceler-
ator Before Shif ting” is shown
Message is displayed when the
accelerator pedal has been
depressed and the shift lever is in N.
Release the accelerator pedal and
shift the shift lever to D, S or R.
■If “Auto Power OFF to Conserve
Battery” is displayed
Power was turned off due to the
automatic power off function.
Next time when starting the hybrid
system, increase the hybrid system
speed slightly and maintain that
level for approximately 5 minutes to
recharge the 12-volt battery.
■If “Headlight System Malfunc-
tion Visit Your Dealer” is dis-
played
The following systems may be mal-
functioning. Have the vehicle
inspected by your Toyota dealer
immediately.
●The LED headlight system
●The automatic headlight leveling
system (if equipped)
●Automatic High Beam
■If “Engine Oil Level Low Add or
Replace” is displayed
The engine oil le vel may be low.
Check the level of the engine oil,
and add engine oil if necessary. This message may be displayed if the
vehicle is stopped on a slope. Move
the vehicle to a l
evel surface and
check if the message disappears.
■If “Hybrid System Stopped
Steering Power Low” is dis-
played
This message is displayed if the
hybrid system is stopped while driv-
ing.
When steering wheel operations are
heavier than usual, grip the steering
wheel firmly and operate it using
more force than usual.
■If “Maintenance Required
Soon” is displayed
Indicates that all maintenance
according to the driven distance on
the maintenance schedule
* should
be performed soon.
Comes on approximately 4500
miles (7200 km) after the message
has been reset.
If necessary, perform maintenance.
Please reset the m essage after the
maintenance is performed.
(  P.449)
*: Refer to the separate “Scheduled
Maintenance Guide” or “Owner’s
Manual Supplement” for the main-
tenance interval applicable to your
vehicle.
■If “Maintenance Required Visit
Your Dealer” is displayed
Indicates that all maintenance is
required to correspond to the driven
distance on the maintenance sched-
ule
*.
Comes on approximately 5000
miles (8000 km) after the message
has been reset. (The indicator will
not work properly unless the mes-
sage has been reset.)
Perform the necessary mainte-
nance. Please reset the message
after the maintenance is performed.
(  P.449)

5227-2. Steps to take in an emergency
Owners Manual_USA_M0C031_en
4While raising, secure the tire,
taking care that the tire goes
straight up without catching
on any surrounding part, to
prevent it from flying forward
during a collision or sudden
braking.
Tightening torque:
34.7 ft•lbf (46.6 N•m, 4.8 kgf•m)
5Confirm it is not loose after
tightening:
1 Push and pull the tire
2 Try rotating
Visually check to ensure tire is not
hung on surrounding parts.
If looseness or misassembly exists,
repeat step 2 and step 4.
6 Repeat step5, any time the
tire is lowered or disturbed.
7 Stow the tools and jack
securely.
■The temporary spare tire
●The temporary spare tire is identi-
fied by the “TEMPORARY USE
ONLY” marking on the disc wheel
and/or tire sidewall.
Use the temporary spare tire tem-
porarily, and only in an emer-
gency.
●Make sure to check the tire infla-
tion pressure of the temporary spare tire. (
P.547)
■When using the temporary
spare tire
As the temporary spare tire is not
equipped with the tire pressure
warning valve and transmitter, low
inflation pressure of the spare tire
will not be indicated by the tire pres-
sure warning system. Also, if you
replace the temporary spare tire
after the tire pressure warning light
comes on, the light remains on.
■If you have a flat rear tire on a
road covered with snow or ice
Install the temporary spare tire on
one of the front w heels of the vehi-
cle. Perform the following steps and
fit tire chains to the rear tires:
1 Replace a front tire with the tem-
porary spare tire.
2 Replace the flat rear tire with the
tire removed from the front of the
vehicle.
3 Fit tire chains to the rear tires.
WARNING
■When using the temporary
spare tire
●Remember that t he temporary
spare tire provided is specifi-
cally designed for use with your
vehicle. Do not use your tempo-
rary spare tire on another vehi-
cle.
●Do not use more than one tem-
porary spare tires simultane-
ously.
●Replace the temporary spare
tire with a standa rd tire as soon
as possible.
●Avoid sudden acceleration,
abrupt steering, sudden brak-
ing and shifting operations that
cause sudden engine braking.

Owners Manual_USA_M0C031_en
Alphabetical Index597
Seat belt extender precautions............................................. 30
Seat belt precautions ............. 52
Child-protectors .. ................... 116
Cleaning .......................... 442, 445 Aluminum wheel ornaments . 442
Aluminum wheels ................. 442
Exterior ................................. 442
Interior .................................. 445
Radar sensor........................ 226
Seat belts ............................. 445
Clock ......................................... 91
Coat hooks .............................. 426
Condenser .............................. 461
Console box ............................ 415
Console box light ................... 410
Consumption screen.............. 106
Coolant .................................... 460 Checking .............................. 460
Cooling system ...................... 460 Engine overheating .............. 535
Coussins gonflables Modification et é limination en fin
de vie des coussins gonflables ........................................... 583
Crawl Control .......................... 365
Cruise control Dynamic radar cruise control with full-speed range .......... 255
Cup holders ............................ 414
Current fuel consumption ....... 97
Curtain shield airbags ............. 36
Customizable features ........... 561
D
DAC ......................................... 372
Daytime running light system211
Daytime running lights Replacing light bulbs ............ 490
Deck divider ............................ 417 Defogger
Outside rear view mirrors .....401
Rear window.........................401
Windshield ............................401
Differential ...............................546
Digital Rear-view Mirror .........146
Dimension ...............................540
Dinghy towing .........................194
Display Dynamic radar cruise control with full-speed range ..........255
Head-up display ...................102
Intuitive parking assist ..........274
LTA (Lane Tracing Assist) .....248
Multi-information display.........95
Warning messages ............... 511
Display change button .............93
Distance until next engine oil change .....................................93
Do-it-yourself maintenance ...449
Door courtesy lights...............410
Door lock Side doors ............................ 113
Smart key system .................128
Wireless remote control........ 111
Doors Automatic door locking and unlocking system ................ 116
Door glasses ........................160
Door lock .............................. 113
Open door warning buzzer . 114, 11 6
Outside rear view mirrors .....156
Rear door child-protectors .... 116
Side doors ............................ 113
Downhill assist control system ...............................................372
Drive distance ...........................98
Drive information ......................98
Drive-start control ..................177

598Alphabetical Index
Owners Manual_USA_M0C031_en
Driving ..................................... 171 Break-in tips ......................... 172
Correct driving posture ........... 27
Hybrid Electric Vehicle driving tips...................................... 390
Procedures ........................... 171
Winter drive tips ................... 395
Driving information display ..... 97
Driving mode sel ect switch ... 358
Driving position memory ....... 137 Memory recall function ......... 139
Power easy access system .. 137
Driving range ............................ 97
Dynamic radar cruise control with full-speed range ........... 255Approach warning ................ 263
Warning message ................ 265
E
ECB (Electronically Controlled Brake System) ...................... 374Warning light ........................ 501
EDR (Event data recorder)......... 8
Elapsed time ............................. 98
Electric motor (traction motor)73
Electric Power Steering (EPS) ............................................... 375Warning light ........................ 503
Electronic key ......................... 110 Battery-saving function......... 129
If the electronic key does not operate properly ................. 527
Replacing the battery ........... 485
Electronic sunshade .............. 164
Electronically Controlled Brake System (ECB) ....................... 374Warning light ........................ 501
Electronically modulated air sus- pension ................................. 355
Emergency flashers ............... 494
Emergency tire puncture ....... 515 Emergency, in case of
If a warning buzzer sounds ..501
If a warning light turns on .....501
If a warning message is dis-played ................................. 511
If the 12-volt battery is dis- charged ..............................529
If the electronic key does not operate properly .................527
If the fuel door cannot be opened ...........................................526
If the hybrid sys tem will not start
...........................................524
If the vehicle is submerged or water on the road is rising ..495
If you have a flat tire .............515
If you lose your keys.............526
If you think something is wrong ...........................................499
If your vehicle becomes stuck ...........................................538
If your vehicle has to be stopped in an emergency .................494
If your vehicle needs to be towed ...........................................497
If your vehicle ove rheats ......535
Engine......................................542 ACC ......................................198
Compartment........................457
How to start the hybrid system...........................................195
If the hybrid sys tem will not start
...........................................524
If your vehicle has to be stopped in an emergency .................494
Overheating ..........................535
Power switch ........................195
Engine coolant ........................460 Capacity ...............................544
Checking ..............................460
Preparing and checking before winter ..................................395

Owners Manual_USA_M0C031_en
Alphabetical Index599
Engine coolant temperature gauge....................................... 91
Engine oil Capacity ............................... 543
Checking .............................. 458
Warning light ........................ 502
Engine oil pressure gauge ...... 91
Engine switch (power switch)195 Auto power off function ........ 198
Changing the power switch modes ................................ 198
If your vehicle has to be stopped in an emergency................. 494
Starting the hybrid system.... 195
Enhanced Vehicle Stability Con- trol (Enhanced VSC) ............ 375
Enhanced VSC (Enhanced Vehi- cle Stability Control) ............ 375
EPS (Electric Power Steering) ............................................... 375Warning light ........................ 503
Event data recorder (EDR)......... 8
F
Flat tire .................................... 515 Tire pressure warning system........................................... 468
Floor mats ................................. 26
Fluid Automatic transmission ........ 545
Brake .................................... 546
Washer ................................. 462
Fog light Replacing light bulbs ............ 490
Switch................................... 214
Footwell lights ..... ................... 410
Four-wheel drive system ....... 361
Front fog light Replacing light bulbs ............ 490
Front passenger occupant clas- sification system .................... 46 Front seats ..............................133
Adjustment ...........................133
Cleaning ...............................445
Correct driving posture ...........27
Driving position memory .......137
Head restraints .....................140
Memory recall function .........139
Power easy access system ..137
Seat heaters ....... ..................407
Seat position memory...........137
Seat ventilators.....................407
Front tray light ........................410
Front turn signal lights ..........204 Turn signal lever ...................204
Front turn signal/parking lights Replacing light bulbs ....490, 491
Wattage ................................548
Fuel Capacity ...............................542
Fuel gauge .............................91
Information ......... ..................549
Opening the fuel tank cap ....222
Type......................................542
Warning light.........................507
Fuel consumption Average fuel economy ............97
Current fuel consumption .......97
Fuel door When the fuel door cannot be opened ...............................526
Fuel economy ...........................97
Fuel gauge.................................91
Fuses .......................................487
G
Garage door opene r ...............433
Gauges ......................................91
Glove box ................................413
Glove box light........................410
