2424-4. Refueling
4RUNNER (U)
Open the fuel filler door.
Turn the fuel tank cap slowly to
open. Hang the fuel tank cap on
the back of the fuel filler door.
After refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.
Opening the fuel tank cap
1
2
Closing the fuel tank cap
WARNING
■ When replacing the fuel tank cap
Do not use anything but a genuine Toyota fuel tank cap designed for your
vehicle. Doing so may cause a fire or other incident which may result in
death or serious injury.
616
4RUNNER (U)
GAS STATION INFORMATION
Auxiliary catch leverFuel filler door
P. 420 P. 242
Hood lock release
leverTire inflation
pressure
P. 420P. 540
Fuel tank capacity
(Reference) 23.0 gal. (87.0 L, 19.1 Imp. gal.)
Fuel type
Unleaded gasoline only P. 240, 534
Cold tire inflation
pressure P. 5 4 0
Engine oil capacity
(Drain and refill —
reference)
P. 5 3 5
Engine oil type
P. 535
