2022 TOYOTA 4RUNNER headlight bulb

17Pictorial index
4RUNNER (U)
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 435
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 540
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 342
Checking/rotation/tire pressur e warning system . . . . . . . . .P. 435
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 502
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 420
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 420
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 535
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 527
Headlights/daytime running lights . . . . . . . . . . . . . . . . . . . . P. 223
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
Front turn signal/parking lights . . . . . . . . . . . . . . . . . . . . . . P. 223
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 232
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Stop/tail lights/rear side marker lights . . . . . . . . . . . . . . . . P. 223
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 462, Wattages: P. 541)
*: Vehicles with a smart key system
8
9
10
11
12
13
14
15

4636-3. Do-it-yourself maintenance
6
Maintenance and care
4RUNNER (U)■
Front
■Rear
Bulb locations
Headlight high beam (if
equipped)/daytime running
light
Front turn signal/parking
light
Front side marker light1
2
3
Rear turn signal light
Back-up light
License plate light1
2
3

4646-3. Do-it-yourself maintenance
4RUNNER (U)■
Headlight high beam (if equi
pped)/daytime running lights
Turn the bulb base counter-
clockwise.
Pull the bulb out while press-
ing the lock release of the
connector.
Replace the light bulb, and
install the bulb base.
Align the 3 tabs on the light bulb
with the mounting and insert.
Turn and secure the bulb
base.
Shake the bulb base gently to
check that it is not loose, turn
the headlights on once and visu-
ally confirm that no light is leak-
ing through the mounting.
Replacing light bulbs
1
2
3
4

4726-3. Do-it-yourself maintenance
4RUNNER (U)■
Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
●
Headlight low beams (if equipped)
● Headlight low/high beams (if equipped)
● Fog lights
● Side turn signal lights
● Stop/tail lights
● Rear side marker lights
● High mounted stoplight
● Outer foot lights (if equipped)
■LED light bulbs
The headlight low beams (if equipped), headlight low/high beams (if
equipped), fog lights, side turn signal lights, stop/tail lights, rear side marker
lights, high mounted stoplight and outer foot lights consist of a number of
LEDs. If any LEDs burn out, take your vehicle to your Toyota dealer to have
the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the lens does not indicate a
malfunction. Contact your Toyota dealer for more information in the following
situations:
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the lens.
WARNING
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hand s. When it is
unavoidable to hold the glass portion, use and hold with a clea n dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headligh t unit. This
may damage the headlights or cause condensation to build up on the lens.
■ To prevent damage or fire
● Make sure bulbs are fully seated and locked.
● Check the wattage of the bulb before installing to prevent heat damage.

5418-1. Specifications
8
Vehicle specifications
4RUNNER (U)
Light bulbs
Light bulbsBulb No.WTy p e
Exterior
Headlight high beam (if
equipped) /daytime running
lights
900560A
Front turn signal and parking
lights7444NA28/8C
Front side marker lights5B
Rear turn signal lights21C
Back-up lights16B
License plate lights5B
Interior
Front personal/ front interior
lights5B
Rear interior light8D
Vanity lights8B
Door courtesy lights1685B
Luggage compartment lights8D
A: HB3 halogen bulbs
B: Wedge base bulbs (clear)C: Wedge base bulbs (amber)
D: Double end bulbs

595Alphabetical index
4RUNNER (U)
Fog lights ................................. 232Replacing light bulbs............. 462
Switch ................................... 232
Wattage ................................ 541
Four-wheel drive
system ............................ 305, 309
Front passenger occupant classification system .............. 48
Front personal lights ............... 370
Front seats ............................... 135 Adjustment ............................ 135
Cleaning................................ 408
Correct driving posture ........... 30
Driving position memory ....... 148
Head restraints ..................... 152
Seat heaters ......................... 367
Seat position memory ........... 148
Seat ventilators ..................... 367
Front side marker lights.......... 223 Light switch ........................... 223
Replacing light bulbs............. 467
Wattage ................................ 541
Front turn signal lights ........... 221
Replacing light bulbs............. 465
Turn signal lever ................... 221
Wattage ................................ 541
Fuel ........................................... 240
Capacity ................................ 534
Fuel gauge .............................. 90
Fuel pump shut off system.... 485
Information ............................ 542
Refueling............................... 240
Type .............................. 240, 534
Warning light ......................... 489
Fuel filler door.......................... 240 Refueling............................... 240
Fuel pump shut off system ..... 485
Fuses ........................................ 459 Garage door opener ................ 396
Gauges ....................................... 90
Glove box ................................. 373
Grocery bag hooks.................. 382
Head restraints ........................ 152
Headlights ................................ 223
Automatic High Beam
system .......... ...................... 228
Light switch ........................... 223
Replacing light bulbs .... 464, 472
Wattage ................................ 541
Heaters Air conditioning
system ....... ................. 352, 359
Outside rear view mirrors ....................... 354, 361
Seat heaters ......................... 367
Hill-start assist control ........... 334
Hood ......................................... 420
Hooks Cargo hooks ......................... 379
Cargo net hooks ................... 380
Grocery bag hooks ............... 382
Retaining hooks (floor mat) .... 28
Horn .......................................... 155G
H

597Alphabetical index
4RUNNER (U)
LATCH anchors ......................... 61
LeverAuxiliary catch lever .............. 420
Hood lock release lever ........ 420
Shift lever .............................. 216
Turn signal lever ................... 221
Wiper lever.................... 234, 237
License plate lights ................. 223 Light switch ........................... 223
Replacing light bulbs............. 471
Wattage ................................ 541
Light bulbs Replacing .............................. 464
Wattage ................................ 541
Lights Automatic High Beam
system ......... ....................... 228
Fog light switch ..................... 232
Front Interior light.................. 370
Headlight switch.................... 223
Interior lights list .................... 369
Luggage compartment lights ................................... 132
Personal lights ...................... 370
Rear interior light .................. 370
Replacing light bulbs............. 464
Turn signal lever ................... 221
Vanity lights .......................... 384
Wattage ................................ 541
Limited slip differential ........... 334
Load capacity........................... 189
Lock steering column ............. 208
Luggage compartment features .................................. 379 Maintenance
Do-it-yourself maintenance... 417
General maintenance ........... 413
Maintenance data ................. 532
Maintenance requirements ... 411
Resetting the message indicating maintenance is
required .............................. 412
Malfunction indicator lamp..... 487
Manual air conditioning system.................................... 352
Master warning light ....... 490, 497
Meter ........................................... 90 Indicators ................................ 87
Instrument panel light control .................................. 91
Meters..................................... 90
Multi-information display ......... 92
Warning lights ......................... 85
Mirrors Inside rear view mirror .......... 157
Outside rear view mirror defoggers ................... 354, 361
Outside rear view mirrors ..... 159
Vanity mirrors ....................... 384
Moon roof ................................. 169
Door lock linked moon roof operation ........... 171
Jam protection function ........ 170
Operation .............................. 169
LM

600Alphabetical index
4RUNNER (U)
Seats ................................. 135, 138Adjustment .................... 135, 138
Adjustment
precautions ................. 137, 147
Child seats/child restraint
system installation . ............... 59
Cleaning................................ 408
Driving position memory ....... 148
Head restraints ..................... 152
Properly sitting in the seat ...... 30
Seat heaters ......................... 367
Seat position memory ........... 148
Seat ventilators ..................... 367
Sensor
Automatic headlight system ......... ....................... 226
Inside rear view mirror .......... 158
Intuitive parking assist .......... 288
Service reminder indicators ..... 84
Shift lever ................................. 216 Automatic transmission......... 216
If the shift lever cannot be shifted from P .... 219 Shift lock system ..................... 218
Side airbags ............................... 37
Side marker lights ................... 223
Light switch ........................... 223
Replacing light bulbs ............ 467
Wattage ................................ 541
Side mirrors ............................. 159 Adjusting and folding ............ 159
Side turn signal lights ............. 221
Slide deck................................. 382
Smart key system .................... 119 Antenna location ................... 119
Entry functions ...................... 110
Starting the engine ............... 210
Snow tires ................................ 345
Spare tire .................................. 502 Inflation pressure .................. 540
Storage location.................... 503
Spark plug ................................ 536
Specifications .......................... 532
Speedometer.............................. 90
Steering lock ............................ 208 Column lock release ............. 208
Steering wheel ......................... 155 Adjustment............................ 155
Storage feature ........................ 372
Storage precautions................ 187
Stuck If the vehicle becomes stuck ................................... 530
Sun visors ................................ 384
