2022 TOYOTA 4RUNNER differential

3384-5. Using the driving support systems
4RUNNER (U)
■When the “TRAC OFF” indicator light comes on even if has not
been pressed
TRAC, hill-start assist control, downhill assist control and cr awl control are
temporary deactivated. If the indicator light continues to rema in on, contact
your Toyota dealer.
■ When the VSC or TRAC system is turned off by pressing the VSC o ff
switch
On vehicles with pre-collision system, pre-collision brake assi st and pre-colli-
sion braking will also be disabled. The PCS warning light will come on and
the message will be shown on the multi-information display. ( P. 259)
■ Operating conditions of hill-start assist control
When the following conditions are met, the hill-start assist co ntrol will operate:
2WD models
● The shift lever is in a position other than P or N (when starting off forward/
backward on an upward incline)
● The vehicle is stopped
● The accelerator pedal is not depressed
● The parking brake is not engaged
4WD models
● The system has detected that the vehicle is moving backward
● The shift lever is in a position other than P or N (when starting off forward/
backward on an upward incline)
● The brake pedal is not depressed.
● The rear differential is not locked.(if equipped)
■ Automatic system cancelation of hill-start assist control (2WD models)
The hill-start assist control will turn off in any of the following situations:
● The shift lever is shifted to P or N
● The accelerator pedal is depressed
● The parking brake is engaged
● 2 seconds at maximum elapsed after the brake pedal is released
■ When the brake system o perates continuously
The brake actuator may overheat. In this case, the TRAC and hil l-start assist
control systems will stop operating, a buzzer will sound and th e “TRAC OFF”
indicator will come on. Refrain from using the system until the “TRAC OFF”
indicator turns off. (There is no problem with continuing norma l driving.)

3504-6. Driving tips
4RUNNER (U)
NOTICE
■To prevent water damage
Take all necessary safety measures to ensure that water damage to the
engine or other components does not occur.
● Water entering the engine air intake will cause severe engine damage.
● Water entering the automatic transmission will cause deterioration in shift
quality, locking up of your transmission accompanied by vibration, and ulti-
mately damage.
● Water can wash the grease from wheel bearings, causing rusting and pre-
mature failure, and may also enter the differentials, transmission and
transfer case, reducing the gear oil’s lubricating qualities.
■ When you drive through water
If driving through water, such as when crossing shallow streams , first check
the depth of the water and the bottom of the riverbed for firmn ess. Drive
slowly and avoid deep water.
■ Inspection after off-road driving
● Sand and mud that has accumulated in brake drums and around bra ke
discs may affect braking efficiency and may damage brake system compo-
nents.
● Always perform a maintenance inspection after each day of off-r oad driv-
ing that has taken you through rough terrain, sand, mud, or wat er. For
scheduled maintenance information, refer to the “Scheduled Maintenance
Guide” or “Owner’s Manual Supplement”.

4877-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)(U.S.A.)
(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control sys-
tem
 Have the vehicle inspected by your Toyota dealer
immediately.
SRS warning light
Indicates a malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system;or
• The seat belt pretensioner system
 Have the vehicle inspected by your Toyota dealer
immediately.
(U.S.A.)
(Canada) ABS warning light
Indicates a malfunction in:
• The ABS; or
• The brake assist system
 Have the vehicle inspected by your Toyota dealer
immediately.
Slip indicator
Indicates a malfunction in:
• The VSC system;
• Trailer Sway Control system;
• The TRAC system;
• The active traction control system;
• The AUTO LSD system;
• The downhill assist control system;
• The hill-start assist control system; or
• The Crawl Control system
 Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes rapidly)
Rear differential lock indi cator light (if equipped)
Indicates a malfunction in the rear differential lock sys-
tem
 Have the vehicle inspected by your Toyota dealer
immediately.
Warning lightWarning light/Details/Actions

4887-2. Steps to take in an emergency
4RUNNER (U)
(Flashes rapidly)
Four-wheel drive indicator light (if equipped)
Indicates a malfunction in the four-wheel drive system
 Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes rapidly)
Low speed four-wheel dri ve indicator light (if
equipped) Indicates a malfunction in the four-wheel drive system
 Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes rapidly)
Center differential lock indicator light (if equipped)
Indicates a malfunction in the four-wheel drive system
 Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes contin-
uously)
Multi-terrain Select ind icator light (if equipped)*4
Indicates a malfunction in the Multi-terrain Select sys-
tem
 Have the vehicle inspected by your Toyota dealer
immediately.
Power steering warning light
Indicates a malfunction in the power steering system
 Have the vehicle inspected by your Toyota dealer
immediately.
Unengaged “Park” warning light (if equipped)
Indicates a malfunction in the transmission “Park”
mechanism.
 Have the vehicle inspected by your Toyota dealer
immediately.
KDSS warning light (if equipped)
Indicates a malfunction in KDSS
 Have the vehicle inspected by your Toyota dealer
immediately.
(Flashes)
Automatic running boards indicator light (if
equipped)
Indicates a malfunction in Automatic running boards
 Have the vehicle inspected by your Toyota dealer
immediately.
Open door warning light (warning buzzer)*2
Indicates that a door is not fully closed
 Check that all the doors are closed.
Warning lightWarning light/Details/Actions

5388-1. Specifications
4RUNNER (U)
*: Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at
the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or
an equivalent of matching quality to satisfy the above specific ation. Please
contact your Toyota dealer for further details.
*: Your Toyota vehicle is filled with “Toyota Genuine Differentia l Gear Oil” at
the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or
an equivalent of matching quality to satisfy the above specific ation. Please
contact your Toyota dealer for further details.
Front differential (4WD models)
Oil capacity
Part-time 4WD models
1.6 qt. (1.55 L, 1.4 Imp. qt.)
Full-time 4WD models
1.5 qt. (1.40 L, 1.2 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Rear differential
Oil capacity
Vehicles without a rear differential lock
2.9 qt. (2.70 L, 2.4 Imp. qt.)
Vehicles with a rear differential lock
2.8 qt. (2.65 L, 2.3 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent

592Alphabetical index
4RUNNER (U)
Back doorBack door.............................. 130
Back window ......................... 165
Smart key system ................. 119
Wireless remote control ........ 110
Back window ............................ 165
Back-up lights Replacing light bulbs............. 470
Wattage ................................ 541
Battery ...................................... 430
Battery checking ................... 430
If the vehicle battery is discharged ...................... 523
Preparing and checking before winter....................... 342
Warning light ......................... 486
Bottle holders .......................... 378
Brake Fluid ...................................... 427
Parking brake........................ 222
Warning light ......................... 486
Brake assist ............................. 333
Brake override system ............ 175
Break-in tips ............................. 176
Brightness control Instrument panel light
control................................... 91 Care .................................. 404, 408
Exterior ................................. 404
Interior .................................. 408
Seat belts.............................. 409
Wheels and wheel ornaments .......................... 405
Cargo capacity......................... 189
Cargo hooks ............................ 379
Cargo net hooks ...................... 380
Center differential lock ........... 309
Chains ...................................... 344
Child restraint system............... 55 Booster seats, definition ......... 56
Booster seats, installation....... 67
Convertible seats, definition ... 56
Convertible seats,
installation ............................ 64
Front passenger occupant classification syst em ............ 48
Infant seats, definition............. 56
Infant seats, installation .......... 64
Installing CRS with LATCH anchors ............ 61
Installing CRS with seat belts...................................... 64
Installing CRS
with top tether strap.............. 68
BC

597Alphabetical index
4RUNNER (U)
LATCH anchors ......................... 61
LeverAuxiliary catch lever .............. 420
Hood lock release lever ........ 420
Shift lever .............................. 216
Turn signal lever ................... 221
Wiper lever.................... 234, 237
License plate lights ................. 223 Light switch ........................... 223
Replacing light bulbs............. 471
Wattage ................................ 541
Light bulbs Replacing .............................. 464
Wattage ................................ 541
Lights Automatic High Beam
system ......... ....................... 228
Fog light switch ..................... 232
Front Interior light.................. 370
Headlight switch.................... 223
Interior lights list .................... 369
Luggage compartment lights ................................... 132
Personal lights ...................... 370
Rear interior light .................. 370
Replacing light bulbs............. 464
Turn signal lever ................... 221
Vanity lights .......................... 384
Wattage ................................ 541
Limited slip differential ........... 334
Load capacity........................... 189
Lock steering column ............. 208
Luggage compartment features .................................. 379 Maintenance
Do-it-yourself maintenance... 417
General maintenance ........... 413
Maintenance data ................. 532
Maintenance requirements ... 411
Resetting the message indicating maintenance is
required .............................. 412
Malfunction indicator lamp..... 487
Manual air conditioning system.................................... 352
Master warning light ....... 490, 497
Meter ........................................... 90 Indicators ................................ 87
Instrument panel light control .................................. 91
Meters..................................... 90
Multi-information display ......... 92
Warning lights ......................... 85
Mirrors Inside rear view mirror .......... 157
Outside rear view mirror defoggers ................... 354, 361
Outside rear view mirrors ..... 159
Vanity mirrors ....................... 384
Moon roof ................................. 169
Door lock linked moon roof operation ........... 171
Jam protection function ........ 170
Operation .............................. 169
LM

599Alphabetical index
4RUNNER (U)
Radiator .................................... 427
Rear differential lock system .................................... 317
Rear seats
Adjustment ............................ 138
Folding down ........ 140, 142, 144
Rear step bumper .................... 131
Rear turn signal lights............. 221
Replacing light bulbs............. 469
Turn signal lever ................... 221
Wattage ................................ 541
Rear view mirror Inside rear view mirror .......... 157
Outside rear view mirrors...... 159
Rear view monitor system
*
Rear window ............................ 165
Rear window defoggers ....................... 354, 361
Rear window wiper .................. 237
Refueling .................................. 240
Capacity ................................ 534
Fuel types ............................. 534
Opening the fuel tank cap ..... 242
Replacing Fuses .................................... 459
Key battery............................ 455
Light bulbs ............................ 462
Tires ...................................... 502
Reporting safety defects
for U.S. owners ...................... 572
Resetting the message indicating maintenance
is required .............................. 412
Roof luggage carrier ............... 184 Safety Connect .......................... 72
Seat belt reminder light .......... 489
Seat belts ................................... 32
Adjusting the seat belt ............ 32
Automatic Locking
Retractor (ALR) .................... 33
Child restra int system
installation ............................ 64
Cleaning and maintaining the seat belt........................ 409
Emergency Locking Retractor (ELR) .................... 33
How to wear your seat belt ..... 32
How your child should wear
the seat belt.......................... 33
Pregnant women, proper
seat belt use ......................... 34
Reminder light and buzzer.... 489
Seat belt extender .................. 33
Seat belt pretensioners........... 33
SRS warning light ................. 487
Seat heaters ............................. 367
Seat position memory ............. 148
Seat ventilators........................ 367
Seating capacity ...................... 189
RS
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
