2022 TESLA MODEL X Owner´s Manual

Parts and Accessories
Parts, Accessories, and
Modifications
Use only genuine Tesla parts and accessories.
Tesla performs rigorous testing on parts to
ensure their suitability, safety, and reliability.
Purchase these parts from Tesla, where they
are professionally installed and where you can receive expert advice about modifications to
Model X. Accessories are available for
purchase from Tesla stores or online at www.tesla.com/shop .
Tesla is unable to assess parts manufactured
by other distributors and therefore accepts no
responsibility if you use non-Tesla parts onModel X.
Warning: Installing non-approved parts
and accessories, or performing non- approved modifications, can affect the
performance of Model X and the safety of
its occupants. Any damage caused by
using or installing non-approved parts, or by performing non-approved
modifications, is not covered by the
warranty.Warning: Tesla does not accept liability
for death, personal injury or damage that
occurs if you use or install non-approved
accessories or make non-approved
modifications.Body Repairs
If Model X is in a collision, contact Tesla toensure that it is repaired with genuine Tesla
parts. Tesla has selected and approved body
shops that meet strict requirements for
training, equipment, quality, and customer
satisfaction.
Some repair shops and insurance companies
might suggest using non-original equipment
or salvaged parts to save money. However,
these parts do not meet Tesla

Specifications
Identification
Labels
Vehicle Identification Number
You can find the VIN at the following
locations:

Vehicle Loading
Load Capacity Labeling It is important to understand how much
weight your Model X can safely carry. This
weight is called the vehicle capacity weight
and includes the weight of all occupants, cargo and any additional equipment added toyour Model X since it was manufactured.
One or more labels attached to the center
door pillar indicate how much weight Model X
can safely carry. Labels are visible when the front door is open.
1. Towing label (if equipped)
2. Tire and Loading Information label
3. Statutory Plate
Note: Towing capability is available only if
Model X is equipped with the Towing Package.
Warning: Overloading Model X has an
adverse effect on braking and handling,
which can compromise your safety or cause damage.Caution: Never load more than 175 lbs (80
kg) on the rear load

Tire and Loading Information Label
The Tire and Loading Information label
provides:

DescriptionTotalSubtract occupant weight (5 x
150 lbs/68 kg)750 lbs
(340 kg)Available cargo weight204 lbs
(93 kg)
The cargo weight should be distributed
between the front and rear trunks.
Caution: Never load more than 175 lbs (80
kg) on the rear load

Dimensions and Weights
Exterior Dimensions
AOverall Length198.3 in5,036 mm
B
Overall Width (including mirrors) Overall Width (including folded
mirrors)
Overall Width (excluding mirrors)89.4 in 81.6 in
78.7 in2,271 mm
2,072 mm 1,999 mmCOverall Height66 in*1,684 mm*DWheel Base116.7 in2,965 mmEOverhang - Front38.3 in974 mmFOverhang - Rear43.2 in1,097 mm
G
Ground Clearance:
Standard, with skis
Standard, without skis
Very high, with skis
Very high, without skis7 in
7 in
8 in
9 in171 mm
183 mm 211 mm
223 mmHTrack - Front
Track - Rear67.1 in
67.3 in1,705 mm 1,710 mm*Values are approximate. Dimensions can vary depending on a vehicle

Shoulder RoomFrontRear
Third60.7 in 56.8 in 40 in1542 mm
1442 mm 1016 mmHip RoomFront Rear
Third55.6 in 59 in
38.5 in1412 mm
1498 mm 978 mm
Cargo Volume
Front TrunkRear*TotalSeven Seat Vehicles6.6 cu ft (187 L)76.5 cu ft (2166 L)**83.1 cu ft (2353 L)Six Seat Vehicles6.6 cu ft (187 L)70.7 cu ft (2002 L)**77.3 cu ft (2189 L)Five Seat Vehicles6.6 cu ft (187 L)81.2 cu ft (2299.5 L)**87.8 cu ft (2486.5 L)* Maximum cargo volume behind the front row seats. Includes the 12.6 cu ft (357 L) cargo area
in the rear trunk (area behind the third row seats, if equipped).** Second row seats fully forward and/or folded.
Weights
Curb Weight* - 60D/75D5,185 lbs2,352 kgCurb Weight* - 90D5,267 lbs2,389 kgCurb Weight* - P90D5,377 lbs2,439 kgCurb Weight* - 100D5,421 lbs2,459 kgCurb Weight* - P100D5,483 lbs2,487 kgGVWR** - 60D/75D6,581 lbs2,985 kgGVWR** - 90D6,658 lbs3,020 kgGVWR** - P90D6,768 lbs3,070 kgGVWR** - 100D6,788 lbs3,079 kgGVWR** - P100D6,878 lbs3,120 kgGross Vehicle Weight Distribution -
60D/75DFront: 2,890 lbs Rear: 3,690 lbsFront: 1,311 kg
Rear: 1,674 kgGross Vehicle Weight Distribution - 90DFront: 2,977 lbs Rear: 3,681 lbsFront: 1,350 kgRear: 1,670 kgGross Vehicle Weight Distribution -P90DFront: 2,976 lbs Rear: 3,792 lbsFront: 1,350 kgRear: 1,720 kgGross Vehicle Weight Distribution -100DFront: 3,097 lbs Rear: 3,690 lbsFront: 1,405 kg Rear: 1,674 kg
Dimensions and Weights
Specifications183

Gross Vehicle Weight Distribution -
P100DFront: 3,027 lbs Rear: 3,851 lbsFront: 1,373 kgRear: 1,747 kgGross Axle Weight Rating- Front3,241 lbs1,470 kgGross Axle Weight Rating - Rear (at
nominal tire pressure of 42 psi)3,968 lbs1,800 kgTowing Capacity (if equipped)See Towing and Accessories on page 78.*Curb Weight = weight of the vehicle with correct
