AreaLocationMeasurement (in)Measurement (mm)Leg RoomFront42.41,077Rear35.5901Shoulder RoomFront58.41,484Rear55.11,399Hip RoomFront54.81,393Rear50.31,278
Cargo Volume
AreaVolume (liters)Volume (cubic feet)Front trunk893.1Behind first row, second row folded flat1,73961.4Behind second row70925.0Maximum total cargo volume with driver and front
passenger1,82864.6Maximum total cargo volume with driver and 4
passengers79828.2
Weights
Refer to the certification label for mass data (see Identification Labels on page 203).
Dimensions and Weights
207Specifications

Motor Type
Motor TypeLong RangePlaidFront and rear
motorAC permanent magnet
synchronous motor, liquid-
cooled, with variable frequency
driveAC permanent magnet synchronous motor, carbon-fiber-wrapped rotor, liquid-cooled,
with variable frequency drive (2x motors in
the rear)
Transmission
TypeLong RangePlaidFront transmissionSingle speed fixed gear,
7.5:1Single speed fixed gear, 7.5:1. Enhanced
lubricationRear transmissionSingle speed fixed gear,
9.0:1Independent single speed fixed gear, 7.5:1.
Dry sump lubrication
Steering
SteeringSpecificationsTypeVariable ratio rack and pinion with electronic power steering,
speed sensitiveNumber of turns lock to lock2.33Turning Circle (curb to curb)40.3 ft/12.3 m
Brakes
BrakesSpecifications
Type
4-wheel anti-lock braking system (ABS) with
Electronic Brake Force Distribution, Integrated
Advanced Stability Control and Electronic Accelerator
pedal actuated regenerative braking systemCalipersFront: Four piston, fixedRear: Single piston, floatingRotor Diameters (ventilated)Front: 14.96”/380 mmRear: 14.37”/365 mmFront Rotor thicknessNew: 1.26”/32 mmService limit: 1.18”/30 mmRear Rotor thicknessNew: 1.10”/28 mm
Subsystems
208MODEL S Owner

BrakesSpecificationsService limit: 1.02”/26 mmFront Brake Pad Thickness (excluding
back plate)New: 0.41”/10.5 mm (MIN)Service limit: 0.09”/ 2.3 mmRear Brake Pad Thickness (excluding
back plate)New: 0.33”/8.5 mm (MIN)Service limit: 0.11”/ 2.7 mmParking brakeElectrically actuated parking brake calipers
Suspension
SuspensionSpecificationsFrontIndependent, double wishbone, air spring with adaptive damper, stabilizer barRearIndependent, multi-link, air spring with adaptive damper, stabilizer bar
Battery - Low Voltage
Battery - Low VoltageSpecificationsRating6.9 amp hourVoltage15.5V
Battery - High Voltage
Battery - High VoltageSpecificationsTypeLiquid-cooled lithium ion (Li-ion)Nominal Voltage407 V DCTemperature RangeDo not expose Model S to ambient temperatures above 149

Wheel Specifications (Factory)
Wheel TypeLocationSizeOffset19" CardenioFront9.5J x 1940 mmRear10.5J x 1945 mm21" ArachnidFront9.5J x 2140 mmRear10.5J x 2145 mmLug Nut Torque129 lb. ft (175 Nm)Lug Nut Socket Size21 mm
NOTE: For instructions on how to jack/lift Model S, see Jacking and Lifting on page 201.
Tire Specifications (Factory)
Tire TypeLocationSize19" All-SeasonFrontRear255/45R19 104W XL
285/40R19 107W XL19” SummerFront Rear255/45R19 104Y XL
285/40R19 107Y XL21" SummerFront Rear265/35ZR21 101(Y) XL
295/30ZR21 102(Y) XLTire pressures vary depending on the type of tires fitted. Refer to the tire pressures printed on
the Tire and Loading Information label. This label is located on the center door pillar and is
visible when the
driver

Understanding Tire Markings
Laws require tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire. It also provides the tire identification number (TIN) for certification of safety standards, and in case of a recall.
1Tire category. P indicates that the tire is for passenger vehicles.2Tire width. This 3-digit number is the width (in millimeters) of the tire from sidewall edge to sidewall edge.3Aspect ratio. This 2-digit number is the sidewall height as a percentage of the tread
width. So, if the tread width is 205 mm, and the aspect ratio is 50, the sidewall height is
102 mm.4Tire construction. R indicates that the tire is of Radial ply construction.5Wheel diameter. This 2-digit number is the diameter of the wheel rim in inches.6Load index. This 2 or 3-digit number is the weight each tire can support. This number is not always shown.
Wheels and Tires
211Specifications

7Speed rating. When stated, indicates the maximum speed (in mph) at which the tire can
be used for extended periods. Q=99 mph (160 km/h), R=106 mph (170 km/h), S=112 mph (180 km/h), T=118 mph (190 km/h), U=124 mph (200 km/h), H=130 mph (210 km/h), V=149 mph (240 km/h), W=168 mph (270 km/h), Y=186 mph (300 km/h), (Y)=vehicle

Uniform Tire Quality Grading
The following information relates to the tire grading system developed by the National Highway Traffic Safety Administration (NHTSA), which grades tires by tread wear, traction and
temperature performance. Tires that have deep tread, and winter tires, are exempt from these marking requirements.
Where applicable, quality grades are found on the tire
