2022 CITROEN C3 AIRCROSS Owners Manual

207
Characteristics of engines
and towed loads
Engines
The engine specifications (capacity, max.
power, max. speed, energy, CO
2 emissions,
etc.) associated with your vehicle are given in
the registration document, as well as in sales
brochures.
These characteristics correspond to the
values type-approved on a test bed, under
conditions defined in European legislation
(Directive
1

999/99/EC).
For more information, contact a CITROËN
dealer or a qualified workshop.
Weights and towed loads
The maximum weights and towed loads for
your vehicle are given in the registration
document, as well as in sales brochures.
These values are also shown on the
manufacturer's nameplate or label.
For more information, contact a CITROËN
dealer or a qualified workshop. The GTW values and the towable loads
listed are valid for a maximum altitude of
1,000
metres. The towable load must be
reduced by steps of 10% for each additional
1,000

metres.
The maximum authorised nose weight
corresponds to the weight permitted on the
towbar.
GT W: Gross train weight.
High exterior temperatures may result
in a reduction in the per formance of the
vehicle to protect the engine. When the
exterior temperature is higher than 37°C,
limit the towed weight.
Towing using a lightly loaded vehicle can
adversely affect roadholding.
Braking distances are increased when
towing a trailer.
When using a vehicle to tow, never exceed
a speed of 60 mph (100 km/h) (obser ve
the local legislation in force). If the exterior temperature is high, it is
recommended that the engine be allowed
to idle for 1 to 2
minutes after the vehicle
comes to a stop, to facilitate its cooling.
9
Technical data

208
Engines and towed loads – PETROL
EnginePureTech 82 PureTech 110 S&S PureTech 110PureTech 130
S&S
Gearboxes Manual 5-speed
(BVM5) Manual 5-speed
(BVM5) Automatic
6-speed( E AT 6 ) Automatic
6-speed( E AT 6 ) Manual 6-speed
(BVM6)
Code EB2FEB2DTEB2DTM EB2DTS
Model codes HMZB/R1BHNZB/R1B HNZ W/R1B HNV W/R1HNYH/R1B
Capacity (cm
3) 1,1 9 91,1 9 91,1 9 91,1 9 91,1 9 9
Max power: EEC standard (kW) 6081818195
Fuel Unleaded Unleaded Unleaded Unleaded Unleaded
Braked trailer (within the GTW limit) on a 10 or
12% slope (kg) 650
840 840840840
Unbraked trailer (kg) 560600 600600 620
Maximum authorised nose weight (kg) 5050505050
Technical data

209
Engines and towed loads – DIESEL
EngineHDi 92 BlueHDi 100BlueHDi 100
S&S BlueHDi 120/115 S&S
Gearboxes Manual 5-speed
(BVM5) Manual 5-speed
(BVM5) Manual 5-speed
(BVM5) Manual 6-speed
(BVM6)
Code DV6DDV6FD DV6FD DV6FC
Model codes 9HPA/R2A BHYB/R2A BHYB/R2B BHZH/R2BBHXH/R2B*
Capacity (cm
3) 1,5 6 01,5 6 01,5 6 01,5 6 01,5 6 0
Max power: EEC standard (kW) 68737388 85
Fuel DieselDieselDieselDieselDiesel
Braked trailer (within the GTW limit) on a 10 or
12% slope (kg) 840
840840 870870
Unbraked trailer (kg) 610620 620640 640
Maximum authorised nose weight (kg) 5050505050
*

F

or Belgium.
9
Technical data

210
Dimensions (in mm)
These dimensions have been measured on an
unladen vehicle.
* Mirrors folded.
** Version with longitudinal bars.
Technical data

211
Checking tyre pressures
The tyre pressures should be checked when
cold at least monthly.
The pressures given on the label are valid for
cold tyres. If you have driven for more than
10 minutes or more than 6 miles (10 kilometres)
at more than 30
mph (50 km/h), the tyres will be
warm; in this case 0.3
bar (30 kPa) should be
added to the pressures given on the label.
Never reduce the pressure of a warm tyre.
Low tyre pressures increase fuel
consumption.Identification markings
Different visible markings for the identification
of your vehicle.
A. Vehicle identification number (VIN) on
the front right seat floor
The number is engraved on the body structure.B. Vehicle identification number (VIN) on
the dashboard
The number is on a label, visible through the
windscreen.
C. Manufacturer's label
This tamperproof label is affixed to the driver’s
door aperture. D. Tyres label
This label is affixed to the driver's door
aperture.
It bears the following information about the
tyres:
-

t
he tyre pressures, unloaded and loaded,
-

t
he tyre specification, made up of the
dimensions and type as well as the load and
speed indices,
-

t
he spare tyre pressure.The vehicle may be originally equipped
with tyres with higher load and speed
indices than those indicated on the label,
without affecting inflation pressure.
It bears the following information:
-
t he name of the manufacturer,
- t he European Whole Vehicle Type Approval
number,
-

t
he vehicle identification number (VIN),
-

t
he gross vehicle weight (GV W),
-

t
he maximum authorised train weight
(GT W),
-

t
he maximum weight on the front axle,
-

t
he maximum weight on the rear axle.
9
Technical data

212

1
CITROËN Connect Nav
GPS satellite navigation –
Applications – Multimedia
audio system – Bluetooth
®
telephone
Contents
First steps

2
S

teering mounted controls
3
M

enus
3
V

oice commands
5
N

avigation

11
Connected navigation
1

3
Applications


16
Radio


21
DAB radio (Digital Audio Broadcasting)

2
2
Media


23
Telephone


25
Settings


29
Frequently asked questions

3
2The different functions and settings
described vary according to the version
and configuration of your vehicle.
As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary
and the
ignition on.
The system is protected in such a way that
it will only operate in your vehicle.
The display of the message Energy
Economy Mode signals that a change to
standby is imminent.
The link below gives access to OSS (Open
Source Software) codes for the system.
https://www.groupe-psa.com/fr/oss/
https://www.groupe-psa.com/en/oss/
.
CITROËN Connect Nav

2
12:13
18,5 21,5
23 °CFirst steps
With the engine running, a press
mutes the sound.
With the ignition off, a press turns
the system on.
Adjustment of the volume.
Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen.
Depending on the model, use the "Source" or
"Menu" buttons either side of the touch screen
for access to the menus, then press the virtual
buttons in the touch screen.
You can display the menu at any time by
pressing the screen briefly with three fingers.
All of the touch areas of the screen are white.
Press the cross to go back a level.
Press "OK" to confirm. The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (e.g. spectacles cloth) with
no additional product.
Do not use sharp objects on the screen.
Do not touch the screen with wet hands.
*
D

epending on equipment
Certain information is displayed permanently in
the upper band of the touch screen:
-

R
eminder of the air conditioning information
(depending on version), and direct access to
the corresponding menu.
-

G
o directly to the selection of the audio
source, to the list of radio stations (or list of
titles depending on the source).
-

G
o to the message notifications, emails,
map updates and, depending on the
services, the navigation notifications.
-

G
o to the settings for the touch screen and
the digital instrument panel.
Selecting the audio source (depending on version):
- F M/DAB*/AM* radio stations.
-

U
SB memory stick.
-

C
D player (depending on model).
-

M
edia player connected via the auxiliary socket
(depending on model).
-

T
elephone connected via Bluetooth* and
Bluetooth multimedia broadcast (streaming).
CITROËN Connect Nav
