2021 VOLKSWAGEN EOS Owner´s Manual

Description Possible solution
CSC roof stops while opening or closing.
– Check the instrument cluster display (where applicable) for
information on what to do ⇒ table .If the CSC roof stops exactly in the middle, give the roof a gentle “nudge” forward so that it will close.
– Push and hold the lever shown in ⇒ fig. 32 to close the CSC roof completely and to lock it into place. – If the CSC roof does not completely close and latch, try to close and latch it using the emergency procedure. – Get professional help if necessary and have the system checked by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop.
Automatic Rollover Support System

WARNING
The Automatic Rollover Support System can cause serious injuries if persons or objects are in the way when it deploys.
x Never use accessory seat covers or protective covers that block the rollover protection deployment area.
x Every rear seat passenger must be properly seated on a seat of his or her own and must stay in a proper seating position at all times.
x Always keep the area around the supports free of anything that could interfere with their deployment or fly about and injure occupants when the supports deploy.
x Never take the covers off the Automatic Rollover Support System.
x Never attach a child seat, child restraints, straps, or anything else to the rollover protec-tion supports.
WARNING
If there is a system malfunction, the Automatic Rollover Support System may cause serious injuries by not deploying properly, by not deploying at all, or by deploying unexpectedly.
x If a malfunction exists in the system, have it checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. A malfunction exists in the system if the indicator light:
– does not come on when the ignition is turned on;
– does not go out about 5 seconds after you start the engine;
– goes out after switching on the ignition and then comes back on again;
– comes on or flickers when you are driving.
NOTICE
If deployed, the Automatic Rollover Support System can damage the CSC roof when opening or closing the top.
x Do not open or close the CSC roof if the Automatic Rollover Support System has deployed.

Power sunroof

Opening or closing the power sunroof

Fig. 35 In the center console: Switch for the power sunroof.

Wind deflector

Fig. 36 Wind deflector in the windshield frame.

Pinch protection can help reduce the risk of pinching injuries when closing the power sunroof ⇒ . If the power sunroof closing meets resistance or there is something in the way, the power sunroof opens again immediately.
x Check why the power sunroof did not close.
x Try to close the power sunroof again by pulling the  switch briefly.
x If the power sunroof still cannot close, the power sunroof will stop where the resistance is located. The power sunroof will close the next time without pinch protection.
Closing the power sunroof without pinch protection
x Pull and hold the  switch ⇒ fig. 35.
x The power sunroof will now close without pinch protection!
x If the power sunroof still will not close, please see an authorized Volkswagen dealer or an author-ized Volkswagen Service Facility.
WARNING
Without pinch protection, the power sunroof will close with enough force to cause serious personal injury.
x Always be careful when closing the power sunroof.
x Always make sure that no one is in the way when overriding the pinch protection to close the power sunroof!
x Pinch protection cannot prevent fingers or other parts of the body from being pressed against the edge of the roof; injuries may result.
x Pinch protection does not work if the power sunroof is closed by pulling and holding the switch.
Pinch protection is also active during convenience closing of the windows and the power sunroof, Power locking and closing system.
If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Initializing the power sunroof

Fig. 37 In the center console: Switch for the power sunroof.

WARNING
Closing the sunroof without pinch protection can cause severe injuries.
x Always be careful when closing the sunroof.
x Always make sure that no one is in the way when overriding pinch protection to close the sunroof.
x Pinch protection does not prevent fingers or other body parts from being pressed against the roof frame, thereby causing injury.
If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
