2021 VOLKSWAGEN EOS Owner´s Manual

In an emergency

Protecting yourself and the vehicle

Fig. 163 In the center of the instrument panel: Button for the emergency flashers.

If the emergency flashers are not working, a different method – as permitted by law – must be used to alert other motorists and cyclists to the breakdown.
WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
WARNING
The vehicle exhaust system and the catalytic converter get very hot. They can cause fires and serious personal injury.
x Never park where parts of the hot exhaust system or catalytic converter could ignite flammable materials, such as dry grass, brush, leaves, spilled fuel, etc.
The vehicle battery will be drained if the emergency flashers are on for a long time – even if the ignition is switched off.

Emergency closing and opening

WARNING
Careless opening and closing of the doors, the CSC roof, the luggage compartment lid, and the power sunroof is dangerous and can cause serious personal injury.
x Open or close the doors, the CSC roof, the luggage compartment lid, and the power sunroof only when no one is in the way.
WARNING
Before using the emergency procedure to close the CSC roof, park the vehicle as far away from moving traffic as possible. If necessary, switch on the emergency flashers and set up a warning triangle. Obey all applicable legal requirements.
NOTICE
If the vehicle's battery fails or the power windows won't work, the door windows are not lowered when the door is opened or closed. Always close and open the door carefully to help prevent damage to the window, the paint, or the rubber seal.
NOTICE
x Before using the emergency procedure to close the CSC roof and while doing it, check the area behind the vehicle for possible obstacles and make sure there is enough room to avoid damage. Rear lid assist does not work before and during the emergency closing procedure.
x Never close the CSC roof if the car is on a workshop hoist, parked with one side on a curb, or raised on a car jack or jackstands.
NOTICE
To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency locking or unlocking.

Manually unlocking and locking the driver door

Fig. 164 Door handle on driver door: Concealed lock cylinder.

Manually locking the passenger door

Fig. 165 On the front side of the passenger door: Emergency lock, covered by a rubber seal.

Fig. 166 On the front side of the passenger door: Manual vehicle locking with the key bit in the vehicle key.

Opening the luggage compartment lid from inside the luggage
compartment

Fig. 167 A: In the seat backrest: Opening the pass-through cover. B: In the luggage compartment: Release ring for luggage compartment lid.

Fig. 168 Inside the luggage compartment: Release lever for luggage compartment lid.
