2021 Lexus GX460 Owner's Manual / LEXUS 2021 GX460 OWNER'S MANUAL QUICK GUIDE (OM60T24U)

33
GX460_QG_OM60T24U_(U)
■Turning the Blind Spot Monitor system on/off
Press or of the meter control switches and select on the multi-informa-
tion display.
Press or of the meter control swit ches and select , and then press .
Each pressing of the sw itch turns the Blind Spot Monitor on and off.1
2

34
GX460_QG_OM60T24U_(U)
Headlights
■Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
U.S.A.
Canada
The side marker, parking, tail,
license plate, instrument panel
lights, and daytime running lights
turn on.
The headlights and all the lights
listed above (except daytime
running lights) turn on.
The headlights, daytime run-
ning lights and all the lights
listed above turn on and off
automatically.
Off.1
2
3
4
(U.S.A. only)
1
2

35
GX460_QG_OM60T24U_(U)
Automatic High Beam
■Activating the Automatic High Beam system
Press the Automatic High Beam
switch.
Turn the headlight switch to the
or position.
The Automatic High Beam indicator
will come on when the system is oper-
ating.
The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of
streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or
off as necessary.
1
2

36
GX460_QG_OM60T24U_(U)
■Turning the high beam on/off manually
● Switching to the high beam
Push the lever away from you.The Automatic High Beam indicator
will turn off and the high beam indica-
tor will turn on.
Pull the lever to its original position to
activate the Automatic High Beam sys-
tem again.
● Switching to the low beam
Press the Automatic High Beam switch.The Automatic High Beam indicator
will turn off.
Press the switch to activate the Auto-
matic High Beam system again.
■Temporarily switching to the low beams
Pull the lever toward you and then re turn it to its original position.
The high beams are on while the lever is pull ed toward you, however, after the lever is
returned to its original position, the low beams remain on for a certain amount of time. After-
wards, the Automatic High Be am will be activated again.

37
GX460_QG_OM60T24U_(U)
Windshield Wipers and Washers
■Intermittent windshield wipers with interval adjuster
Off
Intermittent operation
Low speed operation
High speed operation
Temporary operation
Wiper intervals can be adjusted when inter-
mittent operation is selected. Increases the interm ittent windshield
wiper frequency
Decreases the intermittent windshield
wiper frequency
Washer/wiper dual operation
Pulling the lever op erates the wipers
and washer.
The wipers will automatically operate a
couple of times after the washer
squirts.
Vehicles with headlight cleaners: If the
headlights are on, the headlight clean-
ers will operate once.1
2
3
4
5
6
7
8

38
GX460_QG_OM60T24U_(U)
■Rain-sensing windshield wipers
*1 or *2 Off
Rain-sensing operation
*1 or *2
Low speed operation
*1 or *2
High speed operation
*1 or *2
High speed operation
*1: For the U.S.A.
*2:For Canada
When “AUTO” is se lected, the wipers
will operate automatically when the sen-
sor detects falling rain. The system auto-
matically adjusts wiper timing in
accordance with rain volume and vehi-
cle speed.
The sensor sensitivity can be adjusted when
“AUTO” is selected.
Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
Pulling the lever operates the wipers
and washer.
The wipers operate automatically.
(After operating seve ral times, the wip-
ers operate one more time after a short
delay to prevent dripping.)
Vehicles with headlight cleaners: If the
headlights are on, the headlight clean-
ers will operate once.
1
2
3
4
5
6
7
8

39
GX460_QG_OM60T24U_(U)
Rear Window Wiper and Washer
*1 or *2
Off
*1 or *2
Intermittent operation
*1 or *2
Normal operation
*1: For the U.S.A.
*2:For Canada
Washer/wiper dual operation
Pushing the lever operates the wiper
and washer.
The wipers will automatically operate a
couple of times after the washer
squirts.
1
2
3
4

40
GX460_QG_OM60T24U_(U)
Touch Screen (with navigation system)
■Basic operation
Press to display the hand s-free operation screen.
Press to display the “Information” screen.
Press to display th e “Setup” screen.
Press to display the home screen.
Press to display the air co nditioning control screen.
Press to display the map screen.
Press to display the audio/visual screen.
This system is operated mainly by selectin g the buttons on the screen. (Referred to as
screen buttons in this manual.)
For details, see the “NAVIGA TION SYSTEM OWNER’S MANUAL”.
1
2
3
4
5
6
7
