2020 VOLVO S60 Warranty and Maintenance Records Information

15
SERVICE AND MAINTENANCE
Service operation Schedule of services
Hybrid Models miles x 1000 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
km x 1000 16 32 48 64 80 96 112 128 144 160 176 192 208 224 240
Steering/front suspension, check for wear
according to: Wheel angles checkXXX
Rear suspension, check for wear according
to: Wheel angles checkXXX
Transmission, Driveshaft and Differential
Automatic transmission fluid level, check/
adjust
D
XXX
Final drive/bevel gear, visual inspection
(AWD models only)
E
XXX
Driveshaft joints, check for wear/playXXX
Driveshafts, check rubber bootsXXX
Propeller shaft, pilot bearing and universal
joints, check wear (AWD models only))XXX
Controls and Lighting
Washer fluid level, check/adjustXXXXXXXXXXXXXXX
Check all wiper blades and washers for
headlights and windshields for function and
signs of wearXXXXXXXXXXXXXXX
External lighting, checkXXXXXXXXXXXXXXX
Headlights, fog lights, check and alignXXXXXXX
Horn, check functionXXXXXXXXXXXXXXX


16
SERVICE AND MAINTENANCEService operation Schedule of services
Hybrid Models miles x 1000 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
km x 1000 16 32 48 64 80 96 112 128 144 160 176 192 208 224 240
Body
Cabin air filter, replace
F
XXXXXXX
Clean inside of windshield in front of camera
(vehicles with camera for collision warning)XXXXXXXXXXXXXXX
Seatbelts
Seatbelts, check functionXXXXXXXXXXXXXXX
Brake System
Brake fluid level, check & adjustXXXXXXXXXXXXXXX
Brake fluid, replace
G
XXX
Parking brake, check/adjustXXXXXXXXXXXXXXX
Brake pads/discs, checkXXXXXXXXXXXXXXX
Brake hoses and lines, check for damage/
leaksXXX
Wheels and Tires
Wheels and tires, check wear and conditionXXXXXXXXXXXXXXX
Wheels and tires check inflation pressureXXXXXXX
Tire inflator kit
H


17
SERVICE AND MAINTENANCE
Service operation Schedule of services
Hybrid Models miles x 1000 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
km x 1000 16 32 48 64 80 96 112 128 144 160 176 192 208 224 240
Check and replace parts or software, as required by Volvo Car USA, LLC, that are covered under the terms of the Volvo New Car Warranty.A In the event of a leak from the transmission, check the oil level.
B May be necessary to change more frequently when driving in dusty/dirty areas.
C Replace at 150,000 miles/240,000 kilometers or 10 years, whichever comes first.
D Check automatic transmission fluid level only if an external leak is identified. Volvo recommends changing transmission fluid every 50,000 miles/80,000 kilometers, only on vehicles used for towing, or when
a message appears in the instrument panel text window.
E Only check the level if there is leakage.
F Recommended to replace at least once a year or more often in heavy traffic or dirty/dusty areas.
G Recommended to replace every 3 years or 40,000 miles (if driven in mountainous areas or humid climates – every one year) at owner’s request.
H Check expiration date label every four years for replacement date on vehicles with this equipment.

18
SERVICE AND MAINTENANCEMaintenance/Service recordsThe following pages contain the service interval
records section.A Word About Your Service Records After each service is performed, your authorized
Volvo retailer will validate the appropriate record
section by entering the date serviced, mileage,
representative signature, and the retailer stamp.
NOTE
It is your responsibility, and extremely
important for you to retain documentation of
all service or warranty repairs to your Volvo
(including work performed by you as well as by
non-authorized repair facility), in the event that
questions regarding warranty coverage arise.Volvo Genuine Parts... Keep Your Volvo a
VolvoRegardless of where you service your Volvo, make
sure Volvo Genuine Parts are used to assure the
safety and high quality of your vehicle.
From oil filters to replacement lamps, from
complete assemblies to useful accessories, all
Volvo Genuine Parts are rigorously tested to
ensure the reliability and durability you have come
to expect from Volvo products.
You won’t have to worry about compromising the
special safety features originally built into your
Volvo when you insist on using only Volvo Genuine
Parts for all service, maintenance, and repairs
performed on your vehicle.
Volvo Genuine Parts are available at authorized Volvo retailers located throughout North America.
Experienced and knowledgeable people will help
you be certain that your Volvo remains a Volvo.
Maintenance Service No. 1Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP

19
SERVICE AND MAINTENANCE
Maintenance Service No. 2Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 3Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 4Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP


20
SERVICE AND MAINTENANCEMaintenance Service No. 5Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 6Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 7Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP


21
Maintenance Service No. 8Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 9Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 10Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMPSERVICE AND MAINTENANCE


22
SERVICE AND MAINTENANCE

Maintenance Service No. 11Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 12Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
Maintenance Service No. 13Carried out
miles/km
Date
MileageRetailer Authorized Signature
SIGNATURE
Retailer Stamp
STAMP
