2020 TOYOTA PRIUS C display

472
PRIUS c_U
8-2. Steps to take in an emergency
The following may indicate a problem with your transmission. Contact
your Toyota dealer or commercial towing service before towing.
● A warning message for the hybrid system is shown on the multi-
information display and the vehicle does not move.
● The vehicle makes an abnormal sound.
If your vehicle needs to be towed
If towing is necessary, we recommend having your vehicle
towed by your Toyota dealer o r commercial towing service,
using a wheel-lift type t ruck or flatbed truck.
Use a safety chain system for all towing, and abide by all stat e/
provincial and local laws.
Situations when it is necessary to contact dealers before towing

4798-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
●Fluid leaks un der the vehicle
(Water dripping from the air conditioning a fter use is normal.)
● Flat-looking tires or uneven tire wear
● is shown on the multi-information display
● Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the hybrid system
● Engine missing, stumb ling or running roughly
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one s ide when driving on a level road
● Loss of brake effectiveness, spongy feeling, pedal almost touch es
the floor
If you think something is wrong
If you notice any of the followi ng symptoms, your vehicle proba -
bly needs adjustment or repair. Contact your Toyota dealer as
soon as possible.
Visible symptoms
Audible symptoms
Operational symptoms

4888-2. Steps to take in an emergency
PRIUS c_U
Multi-information display
Warning message details and/or
correction procedures are shown
on the multi-information display.
Master warning light
The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the multi-
information display.
If any of the warning message or indicator comes on again after the
following actions have been per formed, contact your Toyota deal er.
If a warning message is displayed
If a warning is shown on the multi-information display, stay ca lm
and perform the following actions:
1
2

4898-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
Warning message and warning buzzer list
Warning messageDetails/Actions
Indicates a malfunction in the hybrid systemA buzzer sounds in accordance with the warn-
ing message that is displayed.
 Immediately stop the vehicle in a safe place
and contact your Toyota dealer.
Indicates that the high engine coolant tempera-
ture is too high
A buzzer also sounds.
 Immediately stop the vehicle in a safe
place. ( P. 529)
Indicates abnormal engine oil pressure
The warning message is shown if the engine oil
pressure is too low.
A buzzer also sounds.
 Immediately stop the vehicle in a safe place
and contact your Toyota dealer.
Indicates a malfunction in the LDA (Lane Depar-
ture Alert) system
A buzzer also sounds.
 Have the vehicle inspected by your Toyota
dealer.
Indicates a malfunction in the PCS (Pre-Collision
System)
A buzzer also sounds.
 Have the vehicle inspected by your Toyota
dealer.
(Flashes)

4938-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_UIndicates that the hybrid system has overheated
This message may be displayed when driving
under severe operating conditions. (For exam-
ple, when driving up a long steep hill.)
A buzzer also sounds.
 Stop and check. ( P. 529)
Indicates that the Automatic High Beam switch is
pressed while the headlights are in low beam.
Turn the high beam on.
Indicates that, since the VSC (Vehicle Stability
Control) system was turned off, the pre-collision
braking and pre-collision brake assist are dis-
abled (The pre-collision warning function will be
operational)
 Turn the VSC on. ( P. 240, 267)
Indicates that the pre-collision system is disabled.
 Have the vehicle inspected by your Toyota
dealer.
Indicates that the hybrid battery (traction battery)
is low A buzzer also sounds.
 When stopping the vehicle for a long
period of time, shift the shift lever to P. The
hybrid battery (traction battery) cannot be
charged with the shift position in N.
Warning messageDetails/Actions
(Flashes)

4958-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_UIndicates that the EV drive mode is not avail-
able
*2
The reason the EV drive mode is not available
(the vehicle is idling, battery charge is low,
speed is higher than the EV drive mode operat-
ing speed range, accelerator pedal is
depressed too much) may be displayed.
A buzzer also sounds.
 Use the EV drive mode when it becomes
available.
Warning messageDetails/Actions

4998-2. Steps to take in an emergency
8
When trouble arises
PRIUS c_U
Carrying out the corresponding action turns the message off.
After taking the specified steps to correct the suspected probl em,
check that the warning m essage and light go off.
Other displayed message
Displayed messageDetails/Actions
Maintenance of the hybrid battery (traction battery)
cooling component is required
The filter may be clogged, the air intake vent
may be blocked or there may be a gap in the
duct.
 If the air intake vent is dirty, refer to P. 404
for cleaning the air intake vent.
 If the message is being displayed and the air
intake vent is not dirty, have the vehicle
inspected at your Toyota dealer.
Have the malfunction repaired immediately. (vehicles with a
smart key system)
Interior
buzzerExterior buzzerWarning messageDetails/Actions
Once  The electronic key is not
detected when an attempt is
made to start the hybrid sys-
tem.

Start the hybrid system
with the electronic key
present.
(Flashes)

5008-2. Steps to take in an emergency
PRIUS c_U
Once3 times
The electronic key was carried
outside the vehicle and the
driver’s door was opened and
closed while the shift lever was
in P without turning off the
power switch.
Turn the power switch off
or bring the electronic key
back into the vehicle.
The electronic key was carried
outside the vehicle and a door
other than the driver's door was
opened and closed while the
power switch was in a mode
other than off.
Bring the electronic key
back into the vehicle.
Once
Contin-
uous
(For 5 sec-
onds)
An attempt was made to lock
the doors using the entry func-
tion after the electronic key was
carried outside the vehicle with-
out turning off the power switch.
 Turn the power switch off
and lock the doors again.
Interior
buzzerExterior buzzerWarning messageDetails/Actions
(Flashes)
(Displayed alternately)
(Flashes)
