2020 TOYOTA LAND CRUISER Owners Manual (in English)

401
LC200_OM_OM60R53U_(U)
5-1. Using the air conditioning system and defogger
5
Interior features
Rear air conditioning system
■Adjusting the temperature setting
Press “” to increase the temperature and “ ” to decrease the tem-
perature on .
The temperature for the right-hand and left-hand seats can be set sepa-
rately.
■
Adjusting the fan speed setting
Press “ ” (increase) or “ ” (decrease) on .
The fan speed is shown on the display. (7 levels)
Press to turn the fan off.
Air outlets and fan speed are automatically adjusted according
to the temperature setting.

4025-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)■
Changing the air flow mode
Press .
The air flow mode switches
each time the button is pressed.
Air flows to the upper body
Air flows to the upper body
and feet
Air flows to the feet
1
2
3

LC200_OM_OM60R53U_(U)
4035-1. Using the air conditioning system and defogger
5
Interior features
■Using the automatic mode
Press .
Adjust the temperature setting.
To stop the operation, press .
■If the system is operated manually in automatic mode
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
■Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
■Adjusting the position of and opening and closing the air out-
lets Direct air flow to the left or
right, up or down.
Turn the knob fully to the
back of the vehicle to close
the vent.
Air conditioning controls
Air outlets
1
2
3
1
2

4045-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
engine is not running.

405
LC200_OM_OM60R53U_(U)
5-1. Using the air conditioning system and defogger
5
Interior features
Heated steering wheel/seat heaters/seat
ventilator s
: If equipped
Heated steering wheel and seat heaters heat the side grips of t he
steering wheel and seats. Seat ventilators maintain good airflo w
by blowing air from the seats.
WARNING
● Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the hea ter is on:
• Babies, small children, the elderly, the sick and the physical ly chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sle eping
drugs, cold remedies, etc.)
● Observe the following precautions to prevent the minor burns or overheat-
ing:
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the sea t and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent battery discharge, do not use the functions when the engine is
not running.

4065-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
Turns the heated steering wheel
on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
●The heated steering wheel can be used when the engine switch is in IGNI-
TION ON mode.
● The heated steering wheel will automatically turn off after about 30 minutes.
● If the indicator light flashes, press the switch to turn the heated steering
wheel off and then press the switch again. If the indicator light still flashes, a
malfunction may be occurring. Turn the heated steering wheel of f and have
the vehicle inspected by your Toyota dealer.
Seat heater switches
The indicator light (yellow) on the
switch comes on when the seat
heater is operating.
Seat ventilator switches
The indicator light (green) on the
switch comes on when the seat
ventilator is operating.
Level indicator lights
The seat heater temperature level
or the seat ventilator fan speed
level (for front seats only) is dis-
played.
“AUTO” indicator lights
Heated steering wheel (if equipped)
Front seat heaters and ventilators
1
2
3
4

LC200_OM_OM60R53U_(U)
4075-1. Using the air conditioning system and defogger
5
Interior features
■Modes and indicators
The mode can be changed by pressing the switch.
*: When automatic mode is selected, the level automatically chang es
depending on the air conditioning settings.
■ The seat heaters and venti lators can be used when
The engine switch is in IGNITION ON mode.
■ Replacing the air filters
Filters are installed in the seat ventilators. For replacement of the filters, con-
tact your Toyota dealer.
■ Customization
The automatic mode settings for the seat heaters and ventilators can be
changed. ( P. 590)
Mode“AUTO” indicator lightLevel indicator lights
OffOffOff
Automatic*On3 to 1, or off
HiOff3
MidOff2
LoOff1

4085-1. Using the air conditioning system and defogger
LC200_OM_OM60R53U_(U)
For left-hand second seat
For right-hand second seat
High heating temperature
Low heating temperature
To turn on the seat heater, press
“HI” or “LO”.
Off
■The seat heaters can be used when
The engine switch is in IGNITION ON mode.
Second outboard seat heaters (if equipped)
1
2
3
4
45
