2020 TOYOTA HIGHLANDER Accessories, Audio & Navigation (in English)

1774-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
1 Insert the disc into the slot
with the label side up.
 The “DISC” indicator light
turns on while the disc is
loaded.
 The player will start to play
the disc automatically.
1 Press the button and
remove the disc.
●If a disc cannot be ejected, do not
forcibly take out the disc. Keep
pressing the button for
approximately 10 seconds and
release it.
●If the ejected disc remains in the slot for 15 seconds, the player will
automatically reload the disc.
1
Insert the SD card with the
label side up, positioning the
cut off corner to the right.
 To eject the SD card, push on
the center of the SD card.
When it ejects slightly, pull it
straight out.
Disc slot
Loading a disc
Ejecting a discSD card slot

1784-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Open the cover and connect
audio-video equipment to the
HDMI input port.
2 Press the “INPUT” button to
turn on the HDMI mode.
●The volume can be adjusted using
the vehicle’s audio controls. All
other operations must be made on
the audio-visual equipment itself.
For details about operation of
audio-visual equipment, refer to
the manufacturer’ s instructions.
The rear seat entertainment
system can be operated with the
remote controller. The system
cannot be operated by touching
the switches on the screen
directly.
Turning on/off the rear seat
entertainment system
Selecting a control icon
Inputting the selected control
icon
Turning on/off the speaker
output
Changing the screen size
Turning on the DLNA/Mira-
cast
®/HDMI mode
Adjusting the volume
Turning on the SD mode
Turning on the DISC mode
HDMI input port
NOTICE
●When the HDMI input port is not
i n u s e , k e e p t h e H D M I i n p u t p o r t
cover closed. Inserting any-
thing other than an appropriate
plug may cause electrical fail-
ure.
Remote controller
A
B
C
D
E
F
G
H
I

1794-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Adjusting the screen settings
1 Press the button to turn
on the rear seat entertain-
ment system.
 Press the button once
again to turn off the system.
1 Press “+” or “-” on the “VOL”
button to adjust the volume.
 When the speaker output is
off, the volume cannot be
adjusted.
1 Press the button to
turn on/off the speaker out-
put.
On: The sound is available from
both vehicle speakers and
headphones.
Off: The sound is available from
the headphones only. 1
Press the “DISC”, “SD” or
“INPUT” button to change the
audio/visual source.
 Every time “INPUT” button is
pressed, the DLNA/Mira-
cast
®/HDMI mode will be
changed.
1 Press the , , or
button to select the control
icon on the screen.
2 Press the “ENT” button to
enter.
Turning on/off the rear
seat entertainment system
Adjusting the volume
Turning on/off the speaker
output
J&KDQJLQJWKHDXGLRYLVXDO
VRXUFH
6HOHFWLQJDFRQWUROLFRQ

1804-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Press the “SIZE” button to
change the screen size.
DISC/SD/DLNA/Miracast®
mode
“Normal”: Displays the screen at
the original ratio (16:9)
“Full”: Displays the screen in full
screen mode
HDMI mode
“Normal 1”: Displays the screen
at the original ratio (4:3)
“Normal 2”: Displays the screen
in wide screen aspect (16:9)
“Full”: Displays the screen in full
screen mode
●The screen size can be changed
for each media mode individually.
You can adjust the contrast and
brightness of the screen. The
screen setting levels can be
adjusted for day mode and night
mode individually.
1 Press the “SETTING” button.
2 The screen settings can be
adjusted.
Turning on/off the speaker
output
Select to turn the over scan
function on/off.
*
When turned on, this function
hides image distortion at the
edge of the screen. (Part of
the image may be cut off.)
Turning on/off the “LCD AI”.
The “LCD AI” is automatically
determines the tone of the
video image and sets the
contrast to an optimum level,
displaying a sharp image.
Select to turn the screen off.
Weakens the contrast of the
screen
Strengthens the contrast of
the screen
Changing the screen size
Adjusting the screen set-
tings
A
B
C
D
E
F

1814-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Darkens the screen
Brightens the screen
*: This function is not available depending on the screen.
1 Remove the insulating sheet.
●An insulating sheet is set to pre-
vent the batteries from being dis-
charged.
1Remove the cover. 2
Remove the depleted batter-
ies and install 2 new AA bat-
teries.
●If the remote contr oller batteries
are discharged, the following
symptoms may occur.
• The rear seat entertainment sys-
tem control will no t function prop-
erly.
• The operational range is reduced.
●When replacing the AA batteries
• Batteries can be purchased at
your Toyota dealer, electric appli-
ance shop, or camera stores.
• Replace only with the same or
equivalent type recommended by
a Toyota dealer.
• Dispose of used batteries accord-
ing to local laws.
Before using the remote
controller (for new vehicle
owners)
When the remote control-
ler batteries are fully
depleted
G
H
:$ 5 1 , 1 *
●To prevent acci dents and elec-
tric shock
• Do not disassemble or modify the remote controller.
●When the remote controller is
not used
• Stow the remote c ontroller. Inju-
ries may result i n the event of
an accident or sudden braking.

1824-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
For the rear seat entertainment
system, aftermarket head-
phones can be used to listen to
audio.
Wireless headphones can be
used.
When using wireless head-
phones, use headphones that
comply with the following condi-
tions.
■Communication system
Infrared rays
●With some wireless headphones
generally available in the market,
it may be difficult to catch signals
properly.
Toyota recommends the use of
Toyota genuine wireless head-
phones. Please contact your Toy-
ota dealer for further details.
●When the sound volume needs to
be changed while a wireless
headphone is used, adjust the vol-
ume using the wireless head-
phone’s volume switch.
WA R N I N G
●Removed batteries and other
parts
• Keep away from children. These parts are small and if
swallowed by a child, they can
cause choking.
NOTICE
●To prevent damage to the
remote controller
• Keep the remote controller away from direct sunlight, heat
and high humidity.
• Do not drop or strike the remote controller against hard objects.
• Do not sit on or place heavy objects on the remote controller.
●For normal operation after
replacing the batteries, observe
the following precautions to pre-
vent accidents.
• Always work with dry hands. Moisture may cau se the battery
to rust.
• Do not touch or move any other components inside the remote
controller.
• Do not bend any of the battery terminals.
Using headphones
Using wireless head-
phones (sold separately)

1834-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
The rear seat entertainment
system can be operated from
the front seats.
1 Press the “AUDIO” button.
8-inch display model
12.3-inch display model
2 Select “Source” on the
screen or press “AUDIO” but-
ton again.
3 Select “Rear”. 4
The rear seat entertainment
system can be operated from
this screen.
Adjusting the sound settings
Turning on/off the rear sys-
tem lock
• The operation lock on the rear
seat entertainment system can be
turned on or off.
Selecting the rear seat enter-
tainment system’s media
mode
Audio/visual operation but-
tons
Turning on/off the rear seat
entertainment system
Operating from the front
seats
A
B
C
D
E

1844-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing a Blu-ray
Disc™ (BD) and DVD
discs
This system can play
Blu-ray Disc™ (BD) videos
with digital sound. In addi-
tion to commercial BD and
DVD titles, AVCHD, BDAV
videos and Video CD can be
played on this system, so
digital TV recorded by home
digital video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K
