Page 34 of 90 Report No. : 60404487 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
G.3.5 Safeguards components not mentioned in G.3.1 to
G.3.4 No such components N/A
G.3.5.1 Non - resettable devices suitably rated and marking
provided N/A
G.3.5.2 Single faults conditions ................................ .......... : N/A
G. 4 Connectors
N/A
G.4.1 Spacings N/A
G.4.2 Mains connector configuration .............................. : N/A
G.4.3 Plug is shaped that insertion into mains socket -
outlets or appliance coupler is unlikely N/A
G.5 Wound components
N/A
G.5.1 Wire insulation in wound components N/A
G.5.1.2 Protection against mechanical stress N/A
G.5.2 Endurance test N/A
G.5.2.1 General test requirements N/A
G.5.2.2 Heat run test N/A
Test time (days per cycle) ................................ ..... :


Test temperature (  C) ................................ ............ :

G.5.2.3 Wound components supplied from the m ains N/A
G.5.2.4 No insulation breakdown N/A
G.5.3 Transformers No transformers is used N/A
G.5.3.1 Compliance method ................................ ............... : N/A
Position ................................ ................................ .. : N/A
Method of protection ................................ .............. : N/A
G.5.3.2 Insulation N/A
Protection from displacement of windings ............. :

G.5. 3.3 Transformer overload tests N/A
G.5.3.3.1 Test conditions N/A
G.5.3.3.2 Winding temperatures N/A
G.5.3.3.3 Winding temperatures - alternative test method N/A
G.5.3.4 Transformers using FIW N/A
G.5.3.4.1 General N/A
FIW wire nominal diameter ................................ .... :

G.5.3.4.2 Transformers with basic insulation only N/A

Page 61 of 90 Report No. : 60404487 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
10.5.1 Add the following after the first paragraph:
For RS 1 compliance is checked by measurement
under the following conditions:
In addition to the normal operating condi tions, all
controls adjustable from the outside by hand, by any
object such as a tool or a coin, and those internal
adjustments or presets which are not locked in a reliable
manner, are adjusted so as to give maximum radiation
whilst maintaining an intelli gible picture for 1 h, at the
end of which the measurement is made.
NOTE Z1 Soldered joints and paint lockings are examples of
adequate locking.
The dose - rate is determined by means of a radiation
monitor with an effective area of 10 cm², at any point 10
cm from the outer surface of the apparatus.
Moreover, the measurement shall be made under fault
conditions causing an increase of the high - voltage,
provided an intelligible picture is maintained for 1 h, at
the end of which the measurement is made.
For RS 1, the dose - rate shall not exceed 1 μSv/h taking
account of the background level.
NOTE Z2 These values appear in Directive 96/29/Euratom of 13 May
1996. N/A
10.6.1 Add the following paragraph to the end of the
subclause:
EN 71 - 1:2011, 4.20 and the relat ed tests methods and
measurement distances apply. N/A
10.Z1 Add the following new subclause after 10.6.5.
10.Z1 Non - ionizing radiation from radio frequencies
in the range 0 to 300 GHz
The amount of non - ionizing radiation is regulated by
European Council Recommendation 1999/519/EC of 12
July 1999 on the limitation of exposure of the general
public to electromagnetic fields (0 Hz to 300 GHz).
For intentional radiators, ICNIRP guidelines should be
taken into account for Limiting Exposure to Time -
Varying Elec tric, Magnetic, and Electromagnetic Fields
(up to 300 GHz). For hand - held and body - mounted
devices, attention is drawn to EN 50360 and EN 50566 N/A
G.7.1 Add the following note:
NOTE Z1 The harmonized code designations corresponding to the
IEC cord type s are given in Annex ZD. P

Page 33 of 89 Report No. : 60404488 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
G.3.5 Safeguards components not mentioned in G.3.1 to
G.3.4 No such components N/A
G.3.5.1 Non - resettable devices suitably rated and marking
provided N/A
G.3.5.2 Single faults conditions ................................ .......... : N/A
G.4 Connectors
N/A
G.4.1 Spacings N/A
G.4.2 Mai ns connector configuration .............................. : N/A
G.4.3 Plug is shaped that insertion into mains socket -
outlets or appliance coupler is unlikely N/A
G.5 Wound components
N/A
G.5.1 Wire insulation in wound components N/A
G.5.1.2 Protection against mechanical stress N/A
G.5.2 Endurance test N/A
G.5.2.1 General test requirements N/A
G.5.2.2 Heat run test N/A
Test time (days per cycle) ................................ ..... :


Test temperature (  C) ................................ ............ :

G.5.2.3 Wound components supplied from the mains N/A
G.5.2.4 No insulation breakdown N/A
G.5.3 Transformers No transformers is used N/A
G.5.3.1 Compliance method ................................ ............... : N/A
Position ................................ ................................ .. : N/A
Method of protection ................................ .............. : N/A
G.5.3.2 Insulation N/A
Protection from displacement of windings ............. :

G.5.3.3 Transformer overload tests N/A
G.5.3.3.1 T est conditions N/A
G.5.3.3.2 Winding temperatures N/A
G.5.3.3.3 Winding temperatures - alternative test method N/A
G.5.3.4 Transformers using FIW N/A
G.5.3.4.1 General N/A
FIW wire nominal diameter ................................ .... :

G.5.3.4.2 Transformers with basic insulat ion only N/A

Page 60 of 89 Report No. : 60404488 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
10.5.1 Add the following after the first paragraph:
For RS 1 compliance is checked by measurement
under the following conditions:
In addition to the normal operating conditions, all
controls adjustable from the outside by hand , by any
object such as a tool or a coin, and those internal
adjustments or presets which are not locked in a reliable
manner, are adjusted so as to give maximum radiation
whilst maintaining an intelligible picture for 1 h, at the
end of which the measurem ent is made.
NOTE Z1 Soldered joints and paint lockings are examples of
adequate locking.
The dose - rate is determined by means of a radiation
monitor with an effective area of 10 cm², at any point 10
cm from the outer surface of the apparatus.
Moreover, the measurement shall be made under fault
conditions causing an increase of the high - voltage,
provided an intelligible picture is maintained for 1 h, at
the end of which the measurement is made.
For RS1, the do se - rate shall not exceed 1 μSv/h taking
account of the background level.
NOTE Z2 These values appear in Directive 96/29/Euratom of 13 May
1996. N/A
10.6.1 Add the following paragraph to the end of the
subclause:
EN 71 - 1:2011, 4.20 and the related tests methods and
measurement distances apply. N/A
10.Z1 Add the following new subclause after 10.6.5.
10.Z1 Non - ionizing radiation from radio frequencies
in the range 0 to 300 GHz
The amount of non - ionizing radiation is regulated by
European Council Recommend ation 1999/519/EC of 12
July 1999 on the limitation of exposure of the general
public to electromagnetic fields (0 Hz to 300 GHz).
For intentional radiators, ICNIRP guidelines should be
taken into account for Limiting Exposure to Time -
Varying Electric, Mag netic, and Electromagnetic Fields
(up to 300 GHz). For hand - held and body - mounted
devices, attention is drawn to EN 50360 and EN 50566 N/A
G.7.1 Add the following note:
NOTE Z1 The harmonized code designations corresponding to the
IEC cord types are giv en in Annex ZD. P

Page 32 of 88 Report No. : 60404489 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
G. 3.5 Safeguards components not mentioned in G.3.1 to
G.3.4 No such components N/A
G.3.5.1 Non - resettable devices suitably rated and marking
provided N/A
G.3.5.2 Single faults conditions ................................ .......... : N/A
G.4 Connectors
N/A
G.4.1 Spacings N/A
G.4.2 Mains connect or configuration .............................. : N/A
G.4.3 Plug is shaped that insertion into mains socket -
outlets or appliance coupler is unlikely N/A
G.5 Wound components
N/A
G.5.1 Wire insulation in wound components N/A
G.5.1.2 Protection against mechanical stress N/A
G.5.2 Endurance test N/A
G.5.2.1 General test requirements N/A
G.5.2.2 Heat run test N/A
Test time (days per cycle) ................................ ..... :


Test temperature (  C) ................................ ............ :

G.5.2.3 Wound components supplied from the mains N/A
G.5.2.4 No insulation breakdown N/A
G.5.3 Tra nsformers No transformers is used N/A
G.5.3.1 Compliance method ................................ ............... : N/A
Position ................................ ................................ .. : N/A
Method of protection ................................ .............. : N/A
G.5.3.2 Insulation N/A
Protection from displacement of windings ............. :

G.5.3.3 Transformer overload tests N/A
G.5.3.3.1 Test condit ions N/A
G.5.3.3.2 Winding temperatures N/A
G.5.3.3.3 Winding temperatures - alternative test method N/A
G.5.3.4 Transformers using FIW N/A
G.5.3.4.1 General N/A
FIW wire nominal diameter ................................ .... :

G.5.3.4.2 Transformers with basic insulation only N/A

Page 59 of 88 Report No. : 60404489 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
10.5.1 Add the following after the first paragraph:
For RS 1 compliance is checked by measurement
under the following conditions:
In addition to the normal operating conditions, all
controls adjustable from the outside by hand, by any
object such as a tool or a coin, and those internal
adjustments or presets which are not locked in a reliable
manner, are adjusted so as to give maximum radiation
whilst maintaining an intelligible picture for 1 h, at the
end of which the measurement is made.
NOT E Z1 Soldered joints and paint lockings are examples of
adequate locking.
The dose - rate is determined by means of a radiation
monitor with an effective area of 10 cm², at any point 10
cm from the outer surface of the apparatus.
Moreover, the measurement shall be made under fault
conditions causing an increase of the high - voltage,
provided an intelligible picture is maintained for 1 h, at
the end of which the measurement is made.
For RS1, the dose - rate sh all not exceed 1 μSv/h taking
account of the background level.
NOTE Z2 These values appear in Directive 96/29/Euratom of 13 May
1996. N/A
10.6.1 Add the following paragraph to the end of the
subclause:
EN 71 - 1:2011, 4.20 and the related tests methods an d
measurement distances apply. N/A
10.Z1 Add the following new subclause after 10.6.5.
10.Z1 Non - ionizing radiation from radio frequencies
in the range 0 to 300 GHz
The amount of non - ionizing radiation is regulated by
European Council Recommendation 1999 /519/EC of 12
July 1999 on the limitation of exposure of the general
public to electromagnetic fields (0 Hz to 300 GHz).
For intentional radiators, ICNIRP guidelines should be
taken into account for Limiting Exposure to Time -
Varying Electric, Magnetic, and Electromagnetic Fields
(up to 300 GHz). For hand - held and body - mounted
devices, attention is drawn to EN 50360 and EN 50566 N/A
G.7.1 Add the following note:
NOTE Z1 The harmonized code designations corresponding to the
IEC cord types are given in Anne x ZD. P

Page 32 of 88 Report No. : 60404490 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
G. 3.5 Safeguards components not mentioned in G.3.1 to
G.3.4 No such components N/A
G.3.5.1 Non - resettable devices suitably rated and marking
provided N/A
G.3.5.2 Single faults conditions ................................ .......... : N/A
G.4 Connectors
N/A
G.4.1 Spacings N/A
G.4.2 Mains connect or configuration .............................. : N/A
G.4.3 Plug is shaped that insertion into mains socket -
outlets or appliance coupler is unlikely N/A
G.5 Wound components
N/A
G.5.1 Wire insulation in wound components N/A
G.5.1.2 Protection against mechanical stress N/A
G.5.2 Endurance test N/A
G.5.2.1 General test requirements N/A
G.5.2.2 Heat run test N/A
Test time (days per cycle) ................................ ..... :


Test temperature (  C) ................................ ............ :

G.5.2.3 Wound components supplied from the mains N/A
G.5.2.4 No insulation breakdown N/A
G.5.3 Tra nsformers No transformers is used N/A
G.5.3.1 Compliance method ................................ ............... : N/A
Position ................................ ................................ .. : N/A
Method of protection ................................ .............. : N/A
G.5.3.2 Insulation N/A
Protection from displacement of windings ............. :

G.5.3.3 Transformer overload tests N/A
G.5.3.3.1 Test condit ions N/A
G.5.3.3.2 Winding temperatures N/A
G.5.3.3.3 Winding temperatures - alternative test method N/A
G.5.3.4 Transformers using FIW N/A
G.5.3.4.1 General N/A
FIW wire nominal diameter ................................ .... :

G.5.3.4.2 Transformers with basic insulation only N/A

Page 59 of 88 Report No. : 60404490 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
10.5.1 Add the following after the first paragraph:
For RS 1 compliance is checked by measurement
under the following conditions:
In addition to the normal operating conditions, all
controls adjustable from the outside by hand, by any
objec t such as a tool or a coin, and those internal
adjustments or presets which are not locked in a reliable
manner, are adjusted so as to give maximum radiation
whilst maintaining an intelligible picture for 1 h, at the
end of which the measurement is made.
N OTE Z1 Soldered joints and paint lockings are examples of
adequate locking.
The dose - rate is determined by means of a radiation
monitor with an effective area of 10 cm², at any point 10
cm from the outer surface of the apparatus.
Moreover, the measuremen t shall be made under fault
conditions causing an increase of the high - voltage,
provided an intelligible picture is maintained for 1 h, at
the end of which the measurement is made.
For RS1, the dose - rate sh all not exceed 1 μSv/h taking
account of the background level.
NOTE Z2 These values appear in Directive 96/29/Euratom of 13 May
1996. N/A
10.6.1 Add the following paragraph to the end of the
subclause:
EN 71 - 1:2011, 4.20 and the related tests methods an d
measurement distances apply. N/A
10.Z1 Add the following new subclause after 10.6.5.
10.Z1 Non - ionizing radiation from radio frequencies
in the range 0 to 300 GHz
The amount of non - ionizing radiation is regulated by
European Council Recommendation 1999 /519/EC of 12
July 1999 on the limitation of exposure of the general
public to electromagnetic fields (0 Hz to 300 GHz).
For intentional radiators, ICNIRP guidelines should be
taken into account for Limiting Exposure to Time -
Varying Electric, Magnetic, and Electromagnetic Fields
(up to 300 GHz). For hand - held and body - mounted
devices, attention is drawn to EN 50360 and EN 50566 N/A
G.7.1 Add the following note:
NOTE Z1 The harmonized code designations corresponding to the
IEC cord types are given in Anne x ZD. P
