Page  59   of  89   Report No. :  60404488 001

IEC 62368 - 1  –   ATTACHMENT 1
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C

  For special national conditions, see Annex ZB.
1   Add   the following note:
NOTE Z1  The use of certain substances in electrical and electronic
equipment is restricted within the EU: see Directive 2011/65/EU.     P
4.Z1   Add   the following new subclause after 4.9:
To protect against excessive current, short - circuits and
earth faults in circuits connected to an a.c.  mains ,
protective devices shall be included either as integral
parts of the equipment or as parts of the building
installation, subject to the following, a), b) and c):
a) except as detailed in b) and c), protective devices
necessary to comply with the requirements of B.3.1 and
B.4 shall be included as parts of the equipment;
b) for components in series with the mains   input to the
equipment such as the supply cord, appliance coupler,
r.f.i. filter and switch, short - circuit and earth fault
protection may be provided by protective devices in the
building installation;
c) it is permitted for  pluggable equipment type B   or
permanently connected equipment , to rely on
dedicated overcurrent and short - circuit protection in the
building installation, provided that the means of
protection, e.g. fuses or circuit breakers, is fully
specified in the installation instructions.
If reli ance is placed on protection in the building
installation, the installation instructions shall so state,
except that for  pluggable equipment type A   the
building installation shall be regarded as providing
protection in accordance with the rating of the wal l
socket outlet.     N/A
5.4.2.3.2.4   Add   the following to the end of this subclause:
The requirement for interconnection with  external
circuit   is in addition given in EN 50491 - 3:2009.     N/A
10.2.1   Add the following to  c)
  and  d)
  in table 39:
For additional re quirements, see 10.5.1.     N/A



Page  64   of  89   Report No. :  60404488 001

IEC 62368 - 1  –   ATTACHMENT 1
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C
 5.5.6   Finland, Norway  and   Sweden
To the end of the subclause the following is added:
Resistors used as  basic safeguard   or bridging  basic
insulation   in  class I pluggable equipment   type A
shall comply with G.10. 1 and the test of G.10.2.     N/A
5.6.1   Denmark
Add   to the end of the subclause
Due to many existing installations where the socket -
outlets can be protected with fuses with higher rating
than the rating of the socket - outlets the protection for
pluggable equi pment type A shall be an integral part of
the equipment.
Justification:
In Denmark an existing 13 A socket outlet can be
protected by a 20 A fuse.     N/A
5.6.4.2.1   Ireland and United Kingdom
After the indent for  pluggable equipment type A , the
following is  added:
–   the  protective current rating   is taken to be 13 A, this
being the largest rating of fuse used in the  mains   plug.     N/A
5.6.5.1   To the second paragraph the following is added:
The range of conductor sizes of flexible cords to be
accepted by termina ls for equipment with a rated
current over 10 A and up to and including 13 A is:
1,25 mm 2
  to 1,5 mm 2
  in cross - sectional area.     N/A
5.7.5   Denmark
To the end of the subclause the following is added:
The installation instruction shall be affixed to the
equip ment if the  protective conductor current
exceeds the limits of 3,5 mA a.c. or 10 mA d.c.     N/A



Page  79   of  89   Report No. :  60404488 001

IEC 62368 - 1_ATTACHMENT 2
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C

5
Modification to 4.Z1
N /A
4.Z1   Add  the following new subclause after 4.9:

To protect against excessive current, short - circuits
and earth faults in circuits connected to an a.c.
mains , protective devices shall be included either as
integral parts of the equipment or as parts of   the
building installation, subject to the following, a), b)
and c):
a) except as detailed in b) and c), protective devices
necessary to comply with the requirements of B.3.1
and B.4 shall be included as parts of the equipment;
b) for components in series  with the mains input to
the equipment such as the supply cord, appliance
coupler, r.f.i. filter and switch, short - circuit and earth
fault protection may be provided by protective
devices in the building installation;
c) it is permitted for  pluggable equipm ent type B  or
permanently connected equipment , to rely on
dedicated overcurrent and short - circuit protection in
the building installation, provided that the means of
protection, e.g. fuses or circuit breakers, is fully
specified in the installation instruc tions.

If reliance is placed on protection in the building
installation, the installation instructions shall so state,
except that for  pluggable equipment type A  the
building installation shall be regarded as providing
protection in accordance with the ra ting of the wall
socket outlet.     N/A
6
Modification to 5.4.2.3.2.4
N/A
5.4.2.3.2.4   Add  the following to the end of this subclause:

The requirement for interconnection with  external
circuit   is in addition given in EN 50491 - 3:2009.     N/A
7
Modification to   10.2.1
N/A
10.2.1
Add the following to  c)
  and  d)
  in table 39:

For additional requirements, see 10.5.1.     N/A



Page  83   of  89   Report No. :  60404488 001

IEC 62368 - 1_ATTACHMENT 2
Clause   Requirement + Test   Result  -   Remark   Verdict


TRF No.  IEC62368_1 C

A   capacitor classified Y3 according to EN 60384 -
14:2005, may bridge this insulation under
the following conditions:

•    the insulation requirements are satisfied by
having a capacitor classified Y3 as defined by EN
60384 - 14, which in addition to the Y3 tes ting, is
tested with an impulse test of 2,5 kV defined in
5.4.11;

•   the additional testing shall be performed on all the
test specimens as described in EN 60384 - 14;

the impulse test of 2,5 kV is to be performed before
the endurance test in EN 60384 - 14,   in the sequence
of tests as described in EN 60384 - 14.
5.5.2.1   Norway

After the 3rd paragraph the following is added:

Due to the IT power system used, capacitors are
required to be rated for the applicable line - to - line
voltage (230 V).     N/A
5.5.6   Finland, Norway  and  Sweden

To the end of the subclause the following is added:

Resistors used as  basic safeguard  or bridging
basic insulation  in  class I pluggable equipment
type A  shall comply with G.10.1 and the test of
G.10.2.     N/A
5.6.1   Denmark

Add  to the end of the subclause
Due to many existing installations where the socket -
outlets can be protected with fuses
with higher rating than the rating of the socket -
outlets the protection for pluggable
equipment type A shall be an integral part of the
equi pment.
Justification:
In Denmark an existing 13 A socket outlet can be
protected by a 20 A fuse.     N/A
5.6.4.2.1   Ireland and United Kingdom

After the indent for  pluggable equipment type A ,
the following is added:
–   the  protective current rating  is taken t o be 13 A,
this being the largest rating of fuse used in the
mains  plug.     N/A



Page  21   of  88   Report No. :  60404489 001

IEC 62368 - 1
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C
  6.4.3   Reduction of the likelihood of ignition under single
fault conditions in PS2 and PS3 circuits     N/A
6.4.3.1    Supplementary safeguards     N/A
6.4.3.2   Single Fault Conditions   ................................ ..........   :     N/A
  Special conditions for temperature limited by fuse     N/A
6.4.4   Control of fire spread in PS1 circuits     P
6.4.5   Control of fire spread in PS2 circuits     P
6.4.5.2   Supplementa ry safeguards   For conductor and devices are
mounted   on  printed board
made of  Min. V - 1.
Other components in PS2   are
mounted on printed board
made of   Min.   V - 1   and PVC
wire used .
Not ignite during single fault
condition .   P
6.4.6   Control of fire spread in PS3   circuits   Provided  Metallic   enclosure   P
6.4.7   Separation of combustible materials from a PIS     P
6.4.7.2   Separation by distance     N/A
6.4.7.3   Separation by a fire barrier     P
6.4.8   Fire enclosures and fire barriers     P
6.4.8.2   Fire enclosure and fire bar rier material properties     P
6.4.8.2.1   Requirements for a fire barrier   V - 0 class material or metal,
Printed board made of V - 0   P
6.4.8.2.2   Requirements for a fire enclosure   Metallic   enclosure provided   P
6.4.8.3   Constructional requirements fo r a fire enclosure
and a fire barrier     P
6.4.8.3.1   Fire enclosure and fire barrier openings     P
6.4.8.3.2   Fire barrier dimensions     P
6.4.8.3.3   Top openings and properties   E quipment for building - in ,
e valuation shall be considered
in the end product   N/A
  Openings dimensions (mm)   ................................ ...   :     N/A
6.4.8.3.4   Bottom openings and properties   E quipment for building - in ,
e valuation shall be considered
in the end product   N/A
  Openings dimensions (mm)   ................................ ...   :     N/A
  Flammability tests for the bottom of a fire enclosure     N/A



Page  30   of  88   Report No. :  60404489 001

IEC 62368 - 1
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C
  F.3.3.6   Rated current or rated power   ................................   :   See copy of marking plate   P
F.3.3.7   Equipment with multiple supply connections     N/A
F.3.4   Voltage setting device     N/A
F.3.5   Terminals and operating devices     N/A
F.3.5.1   Mains appliance outlet and socket - outlet markings
  ................................ ................................ ...............   :   No such component   N/A
F.3.5.2   Switch position identification marking ....................   :    No such component   N/A
F.3.5.3   Replacement fuse identification and rating
markings   ................................ ................................   :   No  replaceable   fuse   N/A
  Instructional safeguards for neutral fuse   ...............   :   No such component   N/A
F.3.5.4   Replacement battery identifi cation marking   ..........   :   No replaceable battery   N/A
F.3.5.5   Neutral conductor terminal     N/A
F.3.5.6   Terminal marking location     N/A
F.3.6   Equipment markings related to equipment
classification     N/A
F.3.6.1   Class I equipment     N/A
F.3.6.1.1   Protective earthing c onductor terminal   ..................   :     N/A
F.3.6.1.2   Protective bonding conductor terminals    ...............   :     N/A
F.3.6.2   Equipment class marking   ................................ ......   :     N/A
F.3.6.3   Functional earthing terminal marking   ....................   :     N/A
F.3.7   Equipment IP rating marking   ................................ .   :     N/A
F.3.8   External power supply output ma rking   ..................   :     N/A
F.3.9   Durability, legibility and permanence of marking     P
F.3.10   Test for permanence of markings     P
F.4   Instructions
N/A
  a) Information prior to installation and initial use   It shall be evaluated in the
end - equipment   N/A
  b) Equipment fo r use in locations where children not
likely to be present     N/A
  c) Instructions for installation and interconnection     N/A
  d) Equipment intended for use only in restricted
access area      N/A
  e) Equipment intended to be fastened in place     N/A
  f) Instr uctions for audio equipment terminals      N/A
  g) Protective earthing used as a safeguard     N/A



Page  47   of  88   Report No. :  60404489 001

IEC 62368 - 1
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C

5.5.2.2   TABLE: Stored discharg e on capacitors
N/A
Location   Supply voltage (V)   Operating and fault
condition   1)
  Switch
position   Measured
voltage
(Vpk)   ES Class

Supplementary information:
X - capacitors installed for testing:
  bleeding resistor rating:
  ICX:
1)   Normal operating condition (e.g., normal operation, or open fuse), SC= short circuit, OC= open circuit

5.6.6   TABLE: Resistance of protective conductors and terminations
N/A
Location   Test current
(A)   Duration
(min)   Voltage drop
(V)   Resi stance
( Ω )

Supplementary information:

5.7.4   TABLE: Unearthed accessible parts
N/A
Location    Operating and
fault conditions   Supply
Voltage (V)   Parameters   ES
class
Voltage
(V
rms   or V
pk )   Current
(A
rms   or A
pk )   Freq.
(Hz)

S upplementary information:
Abbreviation: SC= short circuit; OC= open circuit

5.7.5   TABLE: Earthed accessible conductive part
N/A
Supply voltage (V)   ...........................   :

Phase(s)    ................................ .........   :   []   Single Phase;  [ ]   Three Phase : [   ] Delta  [ ] W ye
Power Distribution System    .............   :     TN              TT              IT


Location   Fault Condition No   in IEC
60990 clause 6.2.2   Touch current
(mA)   Comment

Supplementary Information:





Page  51   of  88   Report No. :  60404489 001

IEC 62368 - 1
Clause   Requirement + Test   Result  -   Remark   Verdict


TR F No.  IEC62368_1 C
  16. Power key knob body   24.5   28.6   -     60
17. Enclosure near media button   26.9   31.0   -     77
18. Frame body (Not accessib le)   31.4   -   80.5     -
19. Metal enclosure body (Not accessible)   42.0   -   91.1     -
Ambient temperature   See
above   See
above   See
above     -
Temperature T of winding:   t
1   (°C)
R
1   (  )   t
2   (°C)
R
2   (  )   T (  C)   Allowed
T
max   (  C)   Insulation
class

Supplementary in formation:
Note 1. The temperatures for accessible parts are adjusted to reflect a value of 25 °C .
Note 2. Maximum operating Temperature pe rmitted by the Manufacturer(Tma) is  70    C .



B.2.5   TABLE: Input test
P
U (V)   Hz   I (A)   I rated (A)   P (W)   P rated (W )   Fuse No   I fuse (A)   Condition/status
10.2   -   1.73   -   17.65   -   -   -
Max. normal
load condition.
12.0   -   1.67   3.5   20.04   -   -   -
Max. normal
load condition.
14.4   -   1.69   -   24.34   -   -   -
Max. normal
load condition.
Supplementary information:
Max. normal load condit ion :  The  equipment   is operated in such a way as to deliver one - eighth of the NON -
CLIPPED   OUTPUT POWER to the RATED LOAD IMPEDANCE ( 4Ω )   using the standard signal described
in  Annex E and  Max. brightness for LCD module.
