Page 52 of 88 Report No. : 60404489 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C

B.3, B.4 TABLE: Abnormal operatin g and fault condition tests
P
Ambient temperature T
amb (  C) ................................ ..................... : 2 0 - 2 2

Power source for EUT: Manufacturer, model/type, outputrating .. : -

Component No. Condition Supply
voltage
(V) Test
time Fuse no. Fuse
current
(A) Observation
Ventilation
openings Blo ck ed 14.4 2 h - - FI : 1. 6 9 A, NO,
CT (Monitor body : 3 6.6  C,
Power key knob body : 2 4.0
 C, Enclosure near media
button : 2 6 . 9  C, Ambient :
2 0 .6  C, NCD, NH
Speaker output Max. non -
clipped output 14.4 2 h - - FI : 2.96 A, NO,
CT ( Amp IC body (IC163) :
64. 0  C , Monitor body : 3 6.6
 C, Power key knob body :
2 4.3  C, Enclosure near
media button : 2 7.0  C,
Ambient : 2 0.6  C, NCD, NH
Speaker output SC 14.4 1 h - - FI : 0.5 - 1. 05 A , IP , NCD,
NH
IC101(3,8) SC 14.4 1 h - - FI : 0.5 A, CD(IC101), NH
IC902( 1,6) SC 14.4 1 h - - FI : 0.5 A, CD(IC902), NH
Supplementary information:
Abbreviation:
FI – Final Input Current; IP – Internal protection operated; NO – Normal Operated;
CD – Component Damaged (list damaged components); NCD – No Component Damaged;
NH – No Hazard ; CT – Constant temperatures were obtained (list components: temperature;);
NB – No indication of dielectric breakdown; YB – Dielectric breakdown (indicate time and location);
NC – Cheesecloth remained intact; YC – Cheesecloth charred or flamed;

Page 56 of 88 Report No. : 60404489 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C

4.1.2 TABLE: Critical components information
P
Object / part No. Manufacturer/
trademark Type / model Technical data Standard Mark(s) of
conformity 1)

Plastic
Enclosure LG CHEM LTD LUPOY GN -
5007F(#) V - 0 UL 94 UL ( E67171 )
Alternate Interchangeable Interchangeable Min. HB UL 94 UL
- Description: Interchangeability based on specified ratings
Metal Enclosure Interchangeable Interchangeable AL or EGI(SECC)
or GI(SGCC) or
NI or ALDC or
MG or SUS or
STS or NSP or
STEEL, Min. 0.4
thickness IEC 62368 - 1 Tested in
equipment
- Description: Interchangeability based on specified ratings and dimensions
PCB ZHEJIANG
HUABANG
ELECTRONICS
CO LTD H - 01 V - 0 UL 796 UL ( E251053 )
Alternate HYUN WOO
INDUST RIAL
CO LTD 3 V - 0 UL 796 UL (E131308)
Alternate Interchangeable Interchangeable Min. V - 1 UL 796 UL
- Description: Interchangeability based on specified ratings
LCD Panel LG Display Co.,
Ltd. LA065WV1 6.5 inch ,
( 800 x 480 ) IEC 62368 - 1 Tested in
equipm ent
Alternate LG Display
(Paju) Co., Ltd. LA065WV3 6.5 inch ,
( 800 x 480 ) IEC 60065 T Ü V - Rh
(JPTUV -
080511)
Alternate Giantplus
Technology Co.,
LTD. GPM1696A0 6.5 inch ,
( 800 x 480 ) IEC 60065 SGS F imko
(FI - 37636)
Mains connector
material KURARAY CO
LTD GN2330(#) V - 0 UL 94 UL (E90350)
Alternate Interchangeable Interchangeable Min. V - 1 UL 94 UL
- Description: Interchangeability based on specified ratings
Fuse ST VN5E010MHTR -
E 13A Sw itch off ISO/TS
16949:2009 9136.STM2
Supplementary information:
1)
Provided evidence ensures the agreed level of compliance. See OD - 2039.

Page 58 of 88 Report No. : 60404489 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C

For special national conditions, see Annex ZB.
1 Add the following note:
NOTE Z1 The use of certain substances in electrical and electronic
equipment is restricted within the EU: see Directive 2011/65/EU. P
4.Z1 Add the following ne w subclause after 4.9:
To protect against excessive current, short - circuits and
earth faults in circuits connected to an a.c. mains ,
protective devices shall be included either as integral
parts of the equipment or as parts of the building
installation, su bject to the following, a), b) and c):
a) except as detailed in b) and c), protective devices
necessary to comply with the requirements of B.3.1 and
B.4 shall be included as parts of the equipment;
b) for components in series with the mains input to the
eq uipment such as the supply cord, appliance coupler,
r.f.i. filter and switch, short - circuit and earth fault
protection may be provided by protective devices in the
building installation;
c) it is permitted for pluggable equipment type B or
permanently conn ected equipment , to rely on
dedicated overcurrent and short - circuit protection in the
building installation, provided that the means of
protection, e.g. fuses or circuit breakers, is fully
specified in the installation instructions.
If reliance is placed o n protection in the building
installation, the installation instructions shall so state,
except that for pluggable equipment type A the
building installation shall be regarded as providing
protection in accordance with the rating of the wall
socket outlet. N/A
5.4.2.3.2.4 Add the following to the end of this subclause:
The requirement for interconnection with external
circuit is in addition given in EN 50491 - 3:2009. N/A
10.2.1 Add the following to c)
and d)
in table 39:
For additional requirements, see 10.5.1. N/A

Page 63 of 88 Report No. : 60404489 001

IEC 62368 - 1 – ATTACHMENT 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
5.5.6 Finland, Norway and Sweden
To the end of the subclause the following is added:
Resistors used as basic safeguard or bridging basic
insulation in class I pluggable equipment type A
shall comply with G.10.1 and the test of G.10.2. N/A
5.6.1 Denmark
Add to the end of the subclause
Due to many existing installations where the socket -
outlets can be protected with fuses with higher rating
than the rating of the socket - outlets the protection for
pluggable equipment type A shall be an integral part of
the equipment.
Justification:
In Denmark an existing 13 A socket outlet can be
protected by a 20 A fuse. N/A
5.6.4.2.1 Ireland and United Kingdom
After the indent for pluggable equipment type A , the
following is added:
– t he protective current rating is taken to be 13 A, this
being the largest rating of fuse used in the mains plug. N/A
5.6.5.1 To the second paragraph the following is added:
The range of conductor sizes of flexible cords to be
accepted by terminals for equ ipment with a rated
current over 10 A and up to and including 13 A is:
1,25 mm 2
to 1,5 mm 2
in cross - sectional area. N/A
5.7.5 Denmark
To the end of the subclause the following is added:
The installation instruction shall be affixed to the
equipment if th e protective conductor current
exceeds the limits of 3,5 mA a.c. or 10 mA d.c. N/A

Page 78 of 88 Report No. : 60404489 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C

5
Modification to 4.Z1
N /A
4.Z1 Add the following new subclause after 4.9:

To protect against excessive current, short - circuits
and earth faults in circuits connected to an a.c.
mains , protective devices shall be included either as
integral parts of the equipment or as parts of the
building installation, subject to the following, a), b)
and c):
a) except as detailed in b) and c), protective devices
necessary to comply with the requirements of B.3.1
and B.4 shall be included as parts of the equipment;
b) for components in series with the mains input to
the equipment such as the supply cord, appliance
coupler, r.f.i. filter and switch, short - circuit and earth
fault protection may be provided by protective
devices in the building installation;
c) it is permitted for pluggable equipm ent type B or
permanently connected equipment , to rely on
dedicated overcurrent and short - circuit protection in
the building installation, provided that the means of
protection, e.g. fuses or circuit breakers, is fully
specified in the installation instruc tions.

If reliance is placed on protection in the building
installation, the installation instructions shall so state,
except that for pluggable equipment type A the
building installation shall be regarded as providing
protection in accordance with the ra ting of the wall
socket outlet. N/A
6
Modification to 5.4.2.3.2.4
N/A
5.4.2.3.2.4 Add the following to the end of this subclause:

The requirement for interconnection with external
circuit is in addition given in EN 50491 - 3:2009. N/A
7
Modification to 10.2.1
N/A
10.2.1
Add the following to c)
and d)
in table 39:

For additional requirements, see 10.5.1. N/A

Page 82 of 88 Report No. : 60404489 001

IEC 62368 - 1_ATTACHMENT 2
Clause Requirement + Test Result - Remark Verdict


TRF No. IEC62368_1 C

A capacitor classified Y3 according to EN 60384 -
14:2005, may bridge this insulation under
the following conditions:

• the insulation requirements are satisfied by
having a capacitor classified Y3 as defined by EN
60384 - 14, which in addition to the Y3 tes ting, is
tested with an impulse test of 2,5 kV defined in
5.4.11;

• the additional testing shall be performed on all the
test specimens as described in EN 60384 - 14;

the impulse test of 2,5 kV is to be performed before
the endurance test in EN 60384 - 14, in the sequence
of tests as described in EN 60384 - 14.
5.5.2.1 Norway

After the 3rd paragraph the following is added:

Due to the IT power system used, capacitors are
required to be rated for the applicable line - to - line
voltage (230 V). N/A
5.5.6 Finland, Norway and Sweden

To the end of the subclause the following is added:

Resistors used as basic safeguard or bridging
basic insulation in class I pluggable equipment
type A shall comply with G.10.1 and the test of
G.10.2. N/A
5.6.1 Denmark

Add to the end of the subclause
Due to many existing installations where the socket -
outlets can be protected with fuses
with higher rating than the rating of the socket -
outlets the protection for pluggable
equipment type A shall be an integral part of the
equi pment.
Justification:
In Denmark an existing 13 A socket outlet can be
protected by a 20 A fuse. N/A
5.6.4.2.1 Ireland and United Kingdom

After the indent for pluggable equipment type A ,
the following is added:
– the protective current rating is taken t o be 13 A,
this being the largest rating of fuse used in the
mains plug. N/A

Page 21 of 88 Report No. : 60404490 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
6.4.3 Reduction of the likelihood of ignition under single
fault conditions in PS2 and PS3 circuits N/A
6.4.3.1 Supplementary safeguards N/A
6.4.3.2 Single Fault Conditions ................................ .......... : N/A
Special conditions for temperature limited by fuse N/A
6.4.4 Control of fire spread in PS1 circuits P
6.4.5 Control of fire spread in PS2 circuits P
6.4.5.2 Supplementa ry safeguards For conductor and devices are
mounted on printed board
made of Min. V - 1.
Other components in PS2 are
mounted on printed board
made of Min. V - 1 and PVC
wire used .
Not ignite during single fault
condition . P
6.4.6 Control of fire spread in PS3 circuits Provided Metallic enclosure P
6.4.7 Separation of combustible materials from a PIS P
6.4.7.2 Separation by distance N/A
6.4.7.3 Separation by a fire barrier P
6.4.8 Fire enclosures and fire barriers P
6.4.8.2 Fire enclosure and fire bar rier material properties P
6.4.8.2.1 Requirements for a fire barrier V - 0 class material or metal,
Printed board made of V - 0 P
6.4.8.2.2 Requirements for a fire enclosure Metallic enclosure provided P
6.4.8.3 Constructional requirements fo r a fire enclosure
and a fire barrier P
6.4.8.3.1 Fire enclosure and fire barrier openings P
6.4.8.3.2 Fire barrier dimensions P
6.4.8.3.3 Top openings and properties E quipment for building - in ,
e valuation shall be considered
in the end product N/A
Openings dimensions (mm) ................................ ... : N/A
6.4.8.3.4 Bottom openings and properties E quipment for building - in ,
e valuation shall be considered
in the end product N/A
Openings dimensions (mm) ................................ ... : N/A
Flammability tests for the bottom of a fire enclosure N/A

Page 30 of 88 Report No. : 60404490 001

IEC 62368 - 1
Clause Requirement + Test Result - Remark Verdict


TR F No. IEC62368_1 C
F.3.3.6 Rated current or rated power ................................ : See copy of marking plate P
F.3.3.7 Equipment with multiple supply connections N/A
F.3.4 Voltage setting device N/A
F.3.5 Terminals and operating devices N/A
F.3.5.1 Mains appliance outlet and socket - outlet markings
................................ ................................ ............... : No such component N/A
F.3.5.2 Switch position identification marking .................... : No such component N/A
F.3.5.3 Replacement fuse identification and rating
markings ................................ ................................ : No replaceable fuse N/A
Instructional safeguards for neutral fuse ............... : No such component N/A
F.3.5.4 Replacement battery identifi cation marking .......... : No replaceable battery N/A
F.3.5.5 Neutral conductor terminal N/A
F.3.5.6 Terminal marking location N/A
F.3.6 Equipment markings related to equipment
classification N/A
F.3.6.1 Class I equipment N/A
F.3.6.1.1 Protective earthing c onductor terminal .................. : N/A
F.3.6.1.2 Protective bonding conductor terminals ............... : N/A
F.3.6.2 Equipment class marking ................................ ...... : N/A
F.3.6.3 Functional earthing terminal marking .................... : N/A
F.3.7 Equipment IP rating marking ................................ . : N/A
F.3.8 External power supply output ma rking .................. : N/A
F.3.9 Durability, legibility and permanence of marking P
F.3.10 Test for permanence of markings P
F.4 Instructions
N/A
a) Information prior to installation and initial use It shall be evaluated in the
end - equipment N/A
b) Equipment fo r use in locations where children not
likely to be present N/A
c) Instructions for installation and interconnection N/A
d) Equipment intended for use only in restricted
access area N/A
e) Equipment intended to be fastened in place N/A
f) Instr uctions for audio equipment terminals N/A
g) Protective earthing used as a safeguard N/A
