2020 MITSUBISHI OUTLANDER stop start

If this warning light comes on or flashes while you’re driving... 2-2 Quick index
2
or
Engine malfunction indicator (“SERVICE ENGINE SOON” or
“Check engine light”)
 Although your vehicle will usually be dr
ivable and not need towing, have the
engine system checked at an authorized Mi
tsubishi Motors dealer
or a repair facility
of your choice as soon as possible. If the
vehicle is not drivab
le, contact emergency
roadside assistance at 1-888-648-7820 (for
vehicles sold in U.S.A.) or 1-888-576-
4878 (for vehicles sold in Canada), an aut
horized Mitsubishi Moto
rs dealer, or local
towing company for assistance.
P. 5-197
Anti-lock braking system warning
light
 When this light comes on, the anti-lock
braking system is not functioning and only
the ordinary braking system is functioning.  Park your vehicle in a safe
place and stop the engine.
Test the system as described on page 5-98.  If the light does not go out after the test,
or if it comes on again, we recommend that
you have the system checked at an authoriz
ed Mitsubishi Motors dealer or a repair
facility of your choi
ce as soon as possible.
P. 5-98
SRS warning light
 Immediately have the airbag and the pre-te
nsioner seat belt sy
stem checked at an
authorized Mitsubishi Motors dealer.
P. 4-41
and
ASC indicator and ASC OFF indicator
 Park your vehicle in a safe
place and stop the engine.
Restart the engine and check wh
ether the indicator goes out.
 If the indicator does not go out, or if it
comes on again, have your vehicle inspected
by an authorized Mitsubishi Motors dealer or
a repair facility of
your choice as soon
as possible. When this indicator comes on, the active
stability control is
not functioning and
normal operation of the vehi
cle will not be affected.
P. 5-102
Warning lights
Do this
Ref. Page
BK0278200US.book 2 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this warning light comes on or
flashes while you’re driving...
Quick index 2-3
2
ASC indicator
 Park your vehicle in a safe
place and stop the engine.
Restart the engine and check
whether the indicator goes out.
 If the indicator does not go out, or if it co
mes on again, have your vehicle inspected
by an authorized Mitsubishi Motors dealer or
a repair facility of your choice as soon
as possible. When this indicator comes on, the hill start assist is not functioning. Start off carefully on a steep uphill slope.
P. 5-96
Tire pressure monitoring system warn-
ing light
 If the warning light comes on, you should st
op and adjust the tires to the proper
inflation pressure as
soon as possible.
(See “Tire inflation pr
essures” on page 9-20.)
Once adjustments have been
made, the warning light will go off after a few minutes
of driving.  If the warning light blinks for approxima
tely 1 minute and th
en remains continu-
ously illuminated, the system
is not operating properly. If
the system returns to nor-
mal, the warning light will
go off. If the warning light does not go off, have the
vehicle inspected at an author
ized Mitsubishi Motors dealer.
P. 5-140
LED headlight warning light
 If the warning light comes on, there may
be a malfunction in
the LED headlight
unit. Have the vehicle inspected at an authoriz
ed Mitsubishi Motors dealer or a repair
facility of your choice.
P. 5-202
Wa rn in g l ig h t s
Do this
Ref. Page
BK0278200US.book 3 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Seat belts
Seat and restraint systems 4-23
4
3. After the seat belt has retracted com- pletely, insert the latch plate (B) into theupper slit (F), and th
en insert the small
latch plate (A) into the lower slit (G). 4. Store the detachable anchor in the storage pocket on the seatback.
N00418401453
A tone and warning light are used to remindthe driver to fasten the seat belt.If the ignition switch is turned to the “ON” position or the operation mode is put in ON without the driver’s seat belt being fastened, awarning light will co
me on and a tone will
sound for approximately
6 seconds to remind
you to fasten your seat belt.If the vehicle is driven with the seat belt still unfastened, the warning light will blink and the tone will sound inte
rmittently until the
seat belt is fastened. At the same time, “FAS- TEN SEAT BELT” is displayed on the infor- mation screen in the multi informationdisplay.Driver’s seat belt reminder/warning light and display
WA R N I N G In order to reduce the risk of serious injury or death in an
accident, always fas-
ten your own seat belt. Do not allow any-one to ride in your ve
hicle unless he or she
is also seated and fastening a seat belt. Children should additi
onally be restrained
in a secure child restraint system.NOTE
 If the seat belt subs
equently remains unfas-
tened, the warning li
ght and the tone will
issue further warnings
each time the vehicle
starts moving from a stop.
BK0278200US.book 23 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-25
5
N00514301107
After pressing the engine switch and opera- tion mode in OFF, when driver’s door isopened, the steering wheel is locked.
The following methods can be used to unlock the steering wheel.  Put the operation mode in ACC.  Start the engine.
Steering wheel lock
(if so equipped)
To l o c k

NOTE
When the following operation is performed with the operation mode in OFF and theselector lever is in
the “P” (PARK) position,
the steering wheel is locked. • Open or close one of the doors. (except the liftgate) • Lock all the doors and the liftgate by using the F.A.S.T.-key operation or the remote control transmitter of the F.A.S.T.-key.
 When the driver’s door is opened while the steering wheel does not lock, warning dis-play will appear a
nd the buzzer sounds to
alert the steering
wheel is unlocked.
To unlock

WA R N I N GIf the engine is stopped while driving, do not open a door or
press the LOCK switch
on the remote control switch until the vehicle stops in a safe
place. This could
cause the steering wheel to lock, making it impossible to operate the vehicle.CAUTION Carry the F.A.S.T.-key with you when leav- ing the vehicle.If your vehicle needs to be towed, put the operation mode in ACC to unlock the steer- ing wheel.
NOTE
 When the steering wheel does not unlock, the warning display wi
ll appear. Press the
engine switch again
while moving the steer-
ing wheel slightly
right and left.
 When the steering wheel lock is abnormal, the warning display will
appear and the inner
buzzer will sound. Put
the operation mode in
OFF and then press the lock switch of the F.A.S.T.-key. If the warning will appear again, contact an authorized MitsubishiMotors dealer.  If there is a fault in the steering wheel lock, the warning display will
appear. Immediately
stop the vehicle in a sa
fe place and contact
an authorized Mitsubishi Motors dealer.
BK0278200US.book 25 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-26 Features and controls
5
N00514601432
 The operation mode ca
n be in any mode
to start the engine.  The starter motor will be turning for up to approximately 15 seconds if the engine switch is released at once. Pressing the engine switch again while the starter motor is still turning will stop the starter motor.The starter motor will be turning for up to approximately 30 se
conds while the
engine switch is pressed.If the engine does not start, wait for a while and then attempt to start the engine again. Trying repeatedly with the engineor starter motor still turning will damage the starter mechanism.  If the engine will not start because the bat- tery is weak or discharged, refer to “Jump-starting the engine” on page 8-2 for instructions. A longer warm up period will only con- sume extra fuel.
The engine is warmed up enough for driv- ing when the bar graph of engine coolanttemperature display star
ts to move or the
low coolant temperature indicator goes out. Refer to “Engine coolant temperaturedisplay” on page 5-163.
Your vehicle is equipped with an electroni- cally controlled fuel injection system. This system automatically controls fuel injection. There is usually no need to depress the accel-erator pedal when starting the engine. To prevent battery drai
n, wait a few seconds
between attempts to restart the engine.
1. Make sure all occupants are properly seated with seat belts fastened.2. Make sure the parking brake is applied. 3. Press and hold the brake pedal down firmly with your right foot. 4. Make sure the selector
lever is in the “P”
(PARK) position. 5. Press the engine switch. 6. Confirm that all warning lights and warn- ing displays are functioning properly.
Starting and stopping the engine

Tips for starting

WA R N I N G Never run the engine in
a closed or poorly
ventilated area any longer than is neededto move your vehicle out of the area. Car- bon monoxide gas, which is odorless and extremely poisonous, could build up andcause serious injury or death.CAUTION Do not push-start the vehicle.Do not run the engine at high rpms or drive at high speeds until the engine has had a chance to warm up.
Starting the engine

NOTE
 After the engine has not
started for a while,
the brake pedal effort needed to start the engine may become grea
ter. If this occurs,
depress the brake pedal more firmly than usual.NOTE
 The engine can only be started when the selector lever is in the “P” (PARK) or “N” (NEUTRAL) position. For safety reasons,
the engine should be
started when the selector lever is in the “P” (PARK) position in which the driving wheels lock.
BK0278200US.book 26 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced Securi
ty Transmitter (F.A.S.T.-key) (if so equipped)
Features and controls 5-27
5
After several attempts, you may experience that the engine still does not start. 1. Make sure that all electric devices, such as lights, air conditio
ning blower and rear
window defogger, are turned off.2. While depressing the brake pedal, press the accelerator peda
l halfway and hold it
there, then crank th
e engine. Release the
accelerator pedal, immediately after the engine starts.
3. If the engine still will not start, the engine could be flooded with too much gasoline.While depressing the brake pedal, push the accelerator pedal all the way down and hold it there, then press the engineswitch to crank the engine. If the engine does not start after 5 to 6 seconds, push the engine switch
to stop cranking the
engine, and release th
e accelerator pedal.
Put the operation mode in OFF. Wait a few seconds, and then press the engine switch to crank the engine again while depressing the brake pedal, but do notpush the accelerator
pedal. If the engine
fails to start, repeat
these procedures. If
the engine still will
not start, contact your
local Mitsubishi Motors dealer or a repair facility of your choi
ce for assistance.
Startability of the engine with an ambient temperature of -22 °F (-30 °C) or lowerWhen the ambient temperature is -22 °F (-30 °C) or lower, it may not be possible to start from a standstill even with the selector leverin the “D” (DRIVE) or “R” (REVERSE) position. This phenomenon occurs because the trans-axle has not warmed up sufficiently; it does not indicate a problem.
If this occurs, place
the selector lever in the “P” (PARK) positionand let the engine idle for at least 10 minutes.
The transaxle will wa
rm up, and you will be
able to start normally.Do not leave the vehicle during warm-up operation. The MIVEC engine automatically switches its intake-valve control between a low-speed mode and a high-speed mode in accordance with driving conditions for maximum engine performance.
N00568201024
NOTE
 Minor noises may be heard on engine start- up. These will disappear as the engine warmsup.
When the engine is hard to start
Using the MIVEC engine
NOTE
 To protect the engine
, the high-speed mode
may not be selected wh
ile the engine coolant
temperature is low. In such a case, the engine revolutions do not rise to over 5,000 rpm even if the accelerato
r pedal is depressed.
Stopping the engine

WA R N I N GDo not operate the en
gine switch while
driving except in an emergency. If theengine is stopped while driving, the brake servomechanism will ce
ase to function and
braking efficiency will deteriorate. Also,the power steering system will not func- tion and it will require greater manual effort to operate the steering. This couldresult in a serious accident.
BK0278200US.book 27 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Free-hand Advanced
Security Transmitter (F.A.S
.T.-key) (if so equipped)
5-28 Features and controls
5
1. Stop the vehicle. 2. Fully engage the parking brake while depressing the brake pedal. 3. Move the selector
lever to the “P”
(PARK) position, and then press the engine switch to stop the engine.
N00568301142
Insert the F.A.S.T.-key into the key slot in the instrument panel. St
arting the engine and
changing the operation mode should be now possible. Remove the F.A.S.T.-key from the key slotafter starting the engine
or changing the oper-
ation mode.
If the operation mode is in OFF and the driver’s door is opened with the F.A.S.T.-key in the key slot, a warni
ng is issued with the
warning display and
the buzzer buzzing for
approximately 3 seconds to remind you to remove the key.
NOTE
 If you have to bring the engine to an emer- gency stop while driving, press and hold theengine switch for 3 seconds or more, or pressit quickly 3 times or
more. The engine will
stop and the operation m
ode will go to ACC.
 Do not stop the engine wi
th the selector lever
in any position other than the “P” (PARK) position. If the engine is stopped with theselector lever in any
position other than the
“P” (PARK) position, the operation mode will go to ACC rather than OFF.Put the operation mode
in OFF after placing
the selector lever in the “P” (PARK) posi- tion.
If the F.A.S.T.-key is not operat- ing properly

NOTE
 Do not insert into the
key slot anything other
than the F.A.S.T.-key. This could cause dam-age or a malfunction.
 Remove the object or
additional key from the
F.A.S.T.-key before inserting the key into thekey slot. The vehicle may not be able toreceive the registered ID code from the regis- tered key. Therefore, th
e engine may not start
and the operation mode
may not change.
 The F.A.S.T.-key is fixed in the key slot when inserted in the illustrated direction.Simply pull out the key to
remove it from the
key slot.
F.A.S.T.-key reminder

NOTE
BK0278200US.book 28 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Power liftgate (if so equipped) Features and controls 5-43
5
N00576500045
When the power liftgate main switch (A) is on, the power liftgate
can be operated using
either the power liftgate switch on theF.A.S.T.-key, the driver’s side power liftgate switch or the open/close switches on the power liftgate.Refer to “Operating conditions” on page 5-43.
N00576100038
The power liftgate can be opened automati-cally when all of the following conditions are met.  The operation mode is in OFF.  The power liftgate is completely closed.  The power liftgate is unlocked.
 The operation mode is in ON with the selector lever in the “P” (PARK) position.
Automatic operation

WA R N I N G To avoid accidental or
unintended opera-
tion of the power liftgate, turn off thepower liftgate main switch when not oper- ating the power liftgate. Do not turn off the power liftgate main switch while the power liftgate is opening or closing.
CAUTION Do not apply excessive force to the power liftgate when opening
or closing it. Doing so
could damage to th
e power liftgate.
NOTE
Do not start the engine while the power lift- gate is operating. Th
e sudden operation pre-
vention mechanism c
ould operate, making
the power liftgate stop
intermittently while it
moves.  The power liftgate
cannot be opened when
the battery is discharged or disconnected. The liftgate must be then opened using the inside liftgate release.Refer to “Inside lift
gate release” on page
5-48.  If the keyless entry syst
em or close switch is
operated when the power liftgate main switch is off, the warning buzzer sounds 4times to notify the driver that the power lift- gate cannot be operated.  The power liftgate does
not operate normally
under the following conditions: • When parked on an incline • In strong winds • When the power liftg
ate is covered with
snow
 Repeated continuous opening and closing operation of the power li
ftgate will activate a
built-in protec
tion circuit and switch the
power liftgate to manual operation.
 If one of the power liftgate switches is oper- ated while the power lift
gate is operating, the
power liftgate will reverse and return to thefull open or close position.  If the selector lever is moved from “P” (PARK) position to a
nother position while
the power liftgate is
operating or completely
open, a warning buzzer will sound forapproximately 10 sec
onds to notify the
driver that the power liftgate is open.  If the battery or fuse is replaced while the power liftgate is open,
it cannot be closed
automatically.In this case close th
e power liftgate manu-
ally.
Operating conditions

NOTE
BK0278200US.book 43 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
