2020 MERCEDES-BENZ SL CLASS display

R
Use theresidua lheat function ifyou want to
heat orventilate thevehicle interior when
the ignition isswitched off.The residua l
heat function canonly beactivated ordeac-
tivated withtheignition switched off.
R Vehicles withCOMAND: ifyou change the
settings ofthe climate controlsystem, the
climate statusdisplayappea rsfor three sec-
onds atthe bottom ofthe screen inthe
COMAND display.You willsee thecurrent
settings ofthe various climate controlfunc-
tions.
ECO start /stop function During
automatic engineswitch-off, thecli-
mate controlsystem onlyoperates ata
reduced capacity. Ifyou require fullclimate
cont rolcapacity, theECO start/st opfunction
can bedeactivated bypressing theECO but-
ton (Ypage 130). Operating
theclimate controlsys-
tems Activating/
deactivating climatecon-
trol
General notes When
theclimate controlisswitched off,the
air suppl yand aircirculation arealso switched
off. The windows couldfogup.Therefore,
switch offclimate controlonly briefly
i Act
ivate climate controlprimarily usingthe
0058 button (Ypage 119). Activating/
deactivating X
Turn theSmartKey toposition 0048inthe igni-
tion lock (Ypage 126).
X To activate: pressthe0058 button.
The indicator lampinthe 0058 button lights
up. Airflow andairdistribution aresetto
automatic mode.
or
X Press the0078 button.
The indicator lampinthe 0078 button goes
out. Thepreviousl yselected settingsare
restored.
X To deactivate: pressthe0078 button.
The indicator lampinthe 0078 button lights
up. Switchin
gcoo ling with airdehumidi-
fication on/off
General notes If
you deactivate the"Cool ingwith air-dehu-
midification" function,theairinside thevehicle
will notbecooled. Theairinside thevehicle
will also notbedehumid ified.Thewindows can
fog upmore quickly. Therefore, deactivate the
cooling withair-dehumi dificationfunctiononly
briefly .
The "Cool ingwith airdehumid ification" func-
tion isonly available when theengine isrun-
ning. Theairinside thevehicle iscooled and
dehumid ifiedaccording tothe temperature
selected.
Condensation maydripfrom theunderside of
the vehicle whenitis in cooling mode.Thisis
normal andnotasign thatthere isamalfunc-
tion.
Activating/ deactivating X
To activate: pressthe005A button.
The indicator lampinthe 005A button lights
up.
X To deactivate: pressthe005A button.
The indicator lampinthe 005A or0056 but-
ton goes out.The"Cool ingwith airdehumid -
ification" functionhasadelay edswitch-off
feature.
The indicator lampinthe 005A button goes
out. The"Cool ingwith airdehumid ification"
function hasadelay edswitch-off feature. 118
Operat
ingthe climat econ trol systemsCli mat eco ntrol

Setting
theairdistr ibution
<002400460057004C005900440057004C0051004A001200470048004400460057
004C005900440057004C0051004A> X
Turn theSmartK eytoposition 0048inthe igni-
tion lock (Ypage 126).
X Press the008F button repeatedly untilthe
desired symbolappears inthe display .
Air distr ibution settings The
following airdistribution settingscan be
selected:
009C Directsair through thecent erand side
air vent s
009B Directsair through thefootwell air
vent s
009F Directsair through thecent er,side and
footwell vents
0061 Directsair through thedefroster vents
0087 Directsthe airflow through the
defroster, centerand side airvent s
(Canada only)
0086 Directsair through thedefroster and
footwell vents
008F Directsthe airflow through the
defroster vents,the cent erand side air
vent sas well asthe footwell airvent s
(Canada only)
i Regardle
ssofthe airdistribution setting,
airflow isalwa ysdirected throughtheside
air vent s.The side airvent scan only be
closed whentheadjuster inthe side airvent
is turned clockwise. Setting
theairflow
Setting theairflow X
Turn theSmartK eytoposition 0048inthe igni-
tion lock (Ypage 126).
X To increase: pressthe0097 button.
X To reduce: pressthe0095 button. Switching
theZONE function on/off
X To switch on:press the00D6 button.
The indicator lampinthe 00D6 button lights
up. The temperature settingfor the driver's side
isnot adopted forthe front -passenger
side.
X To switch off:press the00D6 button.
The indicator lampinthe 00D6 button goes
out. Thetemperature settingfor the driver's
side isadopted forthe front -passenger side. Defrosting
thewindshield
General notes You
canusethis funct iontodefrost thewind-
shield ortodefrost theinside ofthe wind-
shield andtheside windows.
Switch offthe "Windshield defrosting"function
as soon asthe windshield isclear again.
Switching the"windshield defrosting"
function onoroff X
Turn theSmartK eytoposition 0048inthe igni-
tion lock (Ypage 126).
X To switch on:press the0064 button.
The indicator lampinthe 0064 button lights
up.
The climate controlsystem switches tothe
following functions:
R high airflow
R high temperature
R air distribution tothe windshield andfront
side windows
R <0044004C00550010005500480046004C005500460058004F00440057004C0052
0051[ modeoff
X To switch off:press the0064 button.
The indicator lampinthe 0064 button goes
out. Thepreviously selectedsettingsare
restored. Air-recirculation moderemains
deactivated.
or X Press the0058 button.
The indicator lampinthe 0064 button goes
out. Airflow andairdistribution aresetto
automatic mode.
or X Turn temperature control0043 or006C counter -
clockwise orclockwise (Ypage 116).
or X Press the0097 or0095 button. 120
Operat
ingthe climate controlsystemsClimat econ trol

It
is only possib leto shift thetransmission
from positio n005D tothe desire dpositio nif you
depres sthe brake pedal.Only thenisthe shift
lock relea sed.
i Upshifts
takeplaceathigher engine
speed safter acold start. Thishelps thecat-
aly tic converter toreach itsopera tingtem-
peratu remore quickly.
Information onthe automa ticrelea seofthe
electric parking brake(Ypage 149).
Hill start assist Hill
start assisthelps youwhen pulling away
forward orinreverse onanuphi llgradi ent.It
holds thevehicle forashort timeafter you
have removed yourfoot from thebrake pedal.
This gives youenough timetomove yourfoot
from thebrake pedalto the accelera torpeda l
and todepres sit before thevehicle beginsto
roll. G
WARNING
After ashort time,hillstart assistwil lno lon-
ger brake yourvehicle anditcould rollawa y.
There isarisk ofan accident andinjury.
Therefore, quickly move yourfoot from the
brake pedalto the accelera torpeda l.Never
lea vethe vehicle whenitis held byhill start
assis t.
Hill start assistisnot active if:
R you arepulling awayon alevel roadoron a
downhi llgradi ent
R the transmission isin positio n005C
R the electric parking brakeisappl ied
R ESP ®
is malfu nctioning ECO
start/stop function
Introductio n The
ECO start/stop functionswitches the
engine offautoma ticallyifthe vehicle isstop-
ped under certain conditions.
The engine startsautoma ticallywhenthe
driver wants topul lawa yaga in.The ECO
start/stop functiontherebyhelpsyouto
reduce thefuel consumption andemissi onsof
you rvehicle . Important
safetynotes G
WARNING
If the engine isswitched offautoma tically
and youexit thevehicle ,the engine is
restarted automatically.The vehicle may
begi nmoving. Thereisarisk ofaccident and
injury.
If you wish toexit thevehicle ,alw ays turn
off the ignition andsecure thevehicle
aga inst rollingawa y.
Gene ralnotes 0043
ECO start/stop display
The ECO start/stop functionisactivated
whenever youswitch onthe engine usingthe
SmartKey orthe Start/St opbutton.
If the engine hasbeen switched offautoma ti-
cally bythe ECO start/stop function,the00D6
ECO symbo lis shown inthe multifu nctiondis-
pla y.
Mercede s-AMGvehicles:theECO start/stop
function isonly availablein drive program C.
Automatic engineswi tch-off If
the vehicle isbraked toastandstill withthe
transmission in005B or005C, theECO start/stop
function switches offthe engine automa tically.
The ECO start/stop functionisopera tional
when:
R the indicator lampinthe ECO button islit
green
R the outsid etemperature iswithin therange
that issuita bleforthe system
R the engine isat normal operatingtempera-
ture
R the settemperature forthe vehicle interior
has been reached
R the battery issufficie ntlycharged Drivi
ng
129Drivi ngand parking Z

Problem
Possible
causes/co nsequences and0050 0050
Solutions The
engine isnot run-
ning smoothly andis
misfiring. There
isamalfunction inthe engine electron icsorinamechanical
componen tof the engine management system.
X Only depress theaccelerator pedalslightly.
Otherwise, non-combusted fuelmay getinto thecatalytic con-
verter anddamage it.
X Have thecause rectified immediately ataqual ified specialist
workshop. The
coolant tempera-
ture display showsa
value above 248‡
(120 †).The coolant
warning lampmayalso
be on and awarning
tone maysound. The
coolant levelistoo low. Thecoolant istoo hotand theengine is
no longer beingcooled sufficiently.
X Stop assoon aspossible andallow theengine andthecoolant to
cool down.
X Check thecoolant level(Ypage 270). Observe thewarning notes
as you dosoand add coolant ifnecessary. If
the coolant leveliscorrect ,the engine radiator fanmay befaulty.
The coolant istoo hotand theengine isno longer beingcooled suf-
ficiently.
X At coolant temperatures below248‡(120 †),drive tothe near-
est quali fiedspecialist workshop.
X Avoid heavy loadsonthe engine asyou doso, e.g. driving in
mountainous terrainandstop-and- gotraffic. Notes
ontowing vehicles
The vehicle isnot suitable forattaching tow
bar systems, suchasthose usedforflat tow-
ing ordinghy towing.
Att aching orusing towbarsystems mayresult
in damage tothe vehicle.
When towing avehicle withtowbarsystems,
safe driving characterist icscannot beguaran-
teed forthe towing vehicle orthe towed vehi-
cle.
The vehicle/vehicle combinationmayswerve.
Observe thepermissible towingmethods
(Y page 292)andthenotes ontowing with
both axles onthe ground (Ypage 292). DYNAMIC
SELECTcontroller General
informat ion
Select thedrive program usingtheDYNAMIC
SELE CTcont roller. Available
driveprogra ms: I
Individual Individual
settings C
Comfort Comfort-
oriented, opti-
mum-econ omyengine and
transmission settings S
Sport Sporty
engine andtrans-
mission settings S+
Sport Plus Particularly
sportytrans-
mission settings Race
Maximum
sportiness and
engine andtransmission
settin gssuitable forthe
racetrack Depending
onthe drive program selected the
following vehiclecharacterist icswill change:
R the drive (engine management)
R the transmission management
R ESP ®
R the suspension
R the steering 132
DY
NAMIC SELECTcontrolle rDrivingandparking

inf
ormat ionabout startingthe engin e
(Y page 127). X
Press DYNAMICSE LECT butt on0043 asmany
tim esasnec essary untilthe desire ddrive
progr amisselec ted.
The selec teddrive programappears inthe
multif unction display. After ashor tperiod of
tim e,the display goesoutand thesymbol
for the selec teddrive programappears.
In addition ,the curr entdrive programset-
tin gs are displayed brieflyin the multim edia
syst emdisplay.
i In
afew coun tries, theECO start/sto p
func tion isdeact ivatedat the factorydue to
the available fuelgrade. Inthis case, the
ECO start/sto pfunc tion isnot available in
any drive program,regar dless ofthe display
in the multim ediasystemdisplay.
Availa bledrive progra ms: C
Comfo rt Comfo
rtable andecon omi-
cal drivin gchar acterist ics S
Spor t Spor
tydrivin gchar acteris-
tic s S+
Spor tPlus Part
icularly sportydrivin g
char acterist ics I
Ind ividual Ind
ividual settings E
Ec ono my
(vehic leswith
adjust able
dampin g) Part
icularly economical
drivin gchar acterist ics CV
CURVE
(vehic leswith
Ac tiveBody
Cont rol) Part
icularly economical
drivin gchar acterist icswith
cor ner ing func tion Addit
ional informat ionfordrive programs
(Y page 139). DYNAMIC
SELECTcontroller
(Mer cedes-AM Gvehicles) Gener
alinfor mation
Selec tthe drive programusing theDYN AMIC
SE LECT con troller.
Availa bledrive progra ms: I
Ind ividual Ind
ividual settings C
Comfo rt Comfo
rt-or ient ed,opti-
mum- economyengin eand
tr ansm ission settings S
Spor t Spor
tyengin eand trans-
missio nset tings S+
Spor tPlus Part
icularly sportytrans-
missio nset tings Ra
ce Maxim
umsport inessand
engin eand transm ission
set tings suitable forthe
racet rack Depe
ndingon the drive programselec tedthe
followin gvehic lechar acterist icswill chan ge:
R the drive (enginemanag ement)
R the transm ission manag ement
R ES P®
R the suspen sion
R the steerin g
R the availability ofthe ECO start/sto pfunc -
tion
R the drive rassist ancesyst ems
R the availability ofgliding mode
Furt herinformat ionforautom aticdrive pro-
gram characterist ics(Ypage 139).
Addit ionally, indrive programIyou can config-
ure therespe ctive vehic lechar acterist ics
using themultim ediasystem. You canfind
inf ormat ionabout thisinthe Digit alOperat or's
Manual.
Eac htim eyou startthe engin ewith theSmar t-
Key orthe Start/ Stop butt on,drive programC
is act ivate d.For further informat ionabout
star tingthe engin e,see (Ypage 127). 134
DYNAMIC
SELECTcontroller(Merced es-AMGvehicles)Driving andparking

Selec
tingthedrive progra m X
Turn DYNAMI CSEL ECT controller 0043as
many times asnecessary untilthedesired
drive program isselected.
The symbol ofthe selected driveprogram is
shown inthe multifunct iondisplay .
In addition, thecurrent driveprogram set-
tings aredisplay edbriefly inthe multimedia
system display.
The drive program indicator onDYNAMIC
SEL ECT controller 0043lights upinred.
Additional information fordrive programs
(Y page 139). Additional
settings 0043
ECO start/ stopfunct ion(Ypage 129)
0044 ESP ®
(Y page 65)
0087 Suspension (Ypage 173)
0085 Permanent activationofmanual gearshift-
ing (Ypage 142)
When youpress buttons 0043-0085 the corre-
sponding settingis selected. TheDYNAMIC
SEL ECT controller settingis overwritten .These
settingswill also bemaintained ifyou
switch todrive program RACE,S+,Sor Cwith
the DYNAMI CSEL ECT controller.
If you switch todrive program I,all stored
characterist icswill beaccepted. Thisisalso
the case ifyou have previously pressedbut-
tons 0043-0085. Automat
ictransmission Import
antsafety notes G
WARNING
If the engine speedisabove theidling speed
and youengage transmissionposition 003A
or 0046, thevehicle couldpullaway sud-
denly. Thereisarisk ofan accident.
When engaging transmissionposition 003A
or 0046, alwaysfirmly depress thebrake
pedal anddonot simultaneously accelerate. G
WARNING
The automatic transmissionswitches toneu-
tral position Nwhen youswitch offthe
engine. Thevehicle mayrollaway .There isa
risk ofan accident.
Aft erswitching offthe engine, alwaysswitch
to parking position P.Prevent theparked
vehicle fromrolling awaybyapply ingthe
parking brake. Selec
torlever
Overview oftransmission positions All
vehicles (exceptMercedes-AMG vehi-
cles)
! If
the engine speedistoo high orthe vehi-
cle isin motion, donot shift theautomatic
transm issiondirectly from005Bto005E, from
005E to005B ordirectly to005D.
Do not open thedriver's doorwhile thevehi-
cle isin motion. Atlow speeds intransm is-
sion position 005Bor005E, otherwise parkposi-
tion 005Disengaged automatically.
The transm issioncouldbedamaged. Automat
ictransmission
135Drivingandparking Z

005D
Park position
005E Reverse gear
005C Neutral
005B Drive
The selector leveralway sreturn sto its original
position. Thecurren ttrans mission position 005D,
005E, 005Cor005B isshown inthe trans mission
position displayinthe multifunc tiondisplay.
Mercedes-AMG vehicles
! If
the engine speedistoo high orthe vehi-
cle isin motion ,do not shift theautomatic
tran smission directlyfrom005Bto005E, from
005E to005B ordirectly to005D.
Do not open thedriver's doorwhile thevehi-
cle isin motion .At low speeds intrans mis-
sion position 005Bor005E, otherwise parkposi-
tion 005Disengaged automatically.
The transmission couldbedamaged. 005D
Park position
005E Reverse gear
005C Neutral
005B Drive
The selector leveralway sreturn sto its original
position. Thecurren ttrans mission position 005D,
005E, 005Cor005B isshown inthe trans mission
position displayinthe multifunc tiondisplay. Tr
ansmission positionanddrive pro-
gram display All
vehicles (exceptMercedes-AMG vehi-
cles) 0043
Transmission position
0044 Gear
0087 Drive program
The curren ttran smission positionanddrive
program appearinthe multifunc tiondisplay.
Mercedes-AMG vehicles 0043
Transmission position
0044 Drive program
The curren ttran smission positionanddrive
program appearinthe multifunc tiondisplay.
In addition todrive program 0044being shown in
the multifunc tiondisplay, thecurren tlyselec-
ted drive program isindicated inred onthe
DYNA MICSELECT controller (Ypage 132). 136
Automa
tictransmissionDriving andparking

R
optimal fuelconsumpt ionresulting fromthe
automatic transmissionshifting upsooner.
The vehicle isdriven inthe low engine speed
range andthewheels areless likely tospin.
R gliding modeisavaila ble.
R the ECO start/stop functionisavaila ble.
R ESP ®
provides theoptimum compromise
between tractionand stability. Furtherinfor-
mation aboutESP®
(Y page 66).
Drive programI(Individual)
In drive program Ithe following properties of
the drive program canbeselected:
R the drive (engine management )
R the transm issionmanagement
R ESP ®
R the suspension
Infor mation aboutconfiguring driveprogram I
with themultimedia systemcanbefound in
the Digital Operator's Manual.
i To
permanent lyselect thegears indrive
program Iusing thesteering wheelpaddle
shifters, selecttheM(manual) settingfor
the transm ission. Manua
lgearshift ing
General notes You
canchange gearyourself usingthesteer-
ing wheel paddle shifters. Thetransm ission
must beinposition 005Btodo this.
Depending onwhich steering wheelpaddle
shifter ispulled, theautomatic transmission
immediately shiftsintothenext gear down or
up, ifpermitt ed.
To use manual shifting, youhave twooptions:
R temporary setting
R permanent setting
If you activate manualgearshifting, themulti-
funct iondisplay willshow thecurrent gear
instead oftransm issionposition 005B.
If manual gearshifting isdeactivated, thegears
will beselected automatically. Temp
orarysetting X
To activat e:shift theselector leverto005B.
X Pull steering wheelpaddle shifter0043or0044.
The temporary settingisactive foracert ain
amount oftime. Under certaincondit ions,the
minimum amountoftime isexten ded,e.g.in
the case oflateral acceleration, duringoverrun
mode orwhen driving onsteep terrain.
X To deactivat e:pull steering wheelpaddle
shifter 0044and hold itin place.
or
X Use thelever toswitch thetransm ission
position.
or X All
vehicles (exceptMercedes-AMG vehi-
cles): usetheDYNAMI CSEL ECT button to
change thedrive program.
X Mercedes-AMG vehicles:usethe
DYNAMI CSEL ECT controller tochange the
drive program.
Perma nentsetting All
vehicles (exceptMercedes-AMG vehi-
cles) 142
Automa
tictransmissionDriving andparking
