2020 Lancia Ypsilon Owner handbook (in English)

Warning light What it means
LOW BRAKE FLUID/HANDBRAKE ENGAGED
The warning light switches on when the ignition key is turned to MAR, but it should switch off after a few
seconds.
Low brake fluid level
The warning light turns on when the level of the brake fluid in the reservoir falls below the minimum level,
possibly due to a leak in the circuit. On some versions the display shows the dedicated message.
36)
Handbrake engaged
The warning light (or symbol on the display) comes on when the handbrake is on.
IMPORTANT If the warning light comes on when the vehicle is in motion, check that the handbrake is not
engaged.
WARNING
36)If the warning light switches on when travelling, stop the car immediately and contact a Lancia Dealership.
47

Warning light What it means
INSUFFICIENT ENGINE OIL PRESSURE/ENGINE OIL DETERIORATED
When the ignition key is turned to MAR, the warning light switches on, but it should go out as soon as the
engine is started.
Low engine oil pressure
The warning light turns on and stays on constantly along with a dedicated message on the display (for
versions/markets where provided) when the system detects that engine oil pressure is low.
37)
WARNING
37)If thewarning light switches on when driving (on certain versions together with a dedicated message on the display) stop the engine
immediately and contact a Lancia Dealership.
48
KNOWING THE INSTRUMENT PANEL

Warning light What it means
Degraded engine oil(only Diesel versions with DPF)
The warning light switches on flashing and, for versions/markets where provided, a dedicated message is
shown on the display. Depending on the versions, the warning light can flash in the following modes: for 1
minute every two hours or for 3-minute cycles with the warning light off for 5 seconds until the oil is
changed. After the initial warning, each time the engine is started up, the warning light will continue to flash
in the same mode, until the oil is changed. On some versions, the display shows a dedicated message
together with the warning light. The flashing of the warning light should not be considered as a fault, it
simply informs the customer that the oil needs to be changed following normal car use. Remember that the
deterioration of the engine oil is accelerated by:
mainly town use of the vehicle which makes the DPF regeneration process more frequent;
use of the vehicle for short drives, in which the engine does not have time to reach its regular operating
temperature;
repeated interruptions to the regeneration process signalled by the DPF warning light coming on.
38)29)
WARNING
38)If the warning light switches on, the degraded engine oil must be changed as soon as possible, and never more than 500 km from the
first time that the warning light switches on. Failure to observe the above may result in severe damage to the engine and invalidate the
warranty. The activation of this warning light is not related to the amount of oil in the engine. Therefore, never top up with oil when the warning
light starts flashing.
49

WARNING
29)To avoid damaging the engine it is advisable to change the engine oil when thewarning light flashes. In this case, go to a Lancia
Dealership.
Warning light What it means
ENGINE COOLANT TEMPERATURE TOO HIGH
The warning light switches on when the ignition key is turned to MAR, but it should switch off after a few
seconds.
The warning light switches on (on some versions, with a dedicated message on the display and a symbol
on the display) when the engine is overheated.
in normal driving conditions:stop the car, switch off the engine and check that the water level in the
reservoir is not below the MIN mark. In this case, wait for the engine to cool down, then slowly and
carefully open the cap, top up with coolant and check that the level is between the MIN and MAX marks on
the reservoir itself. Also check visually for any fluid leaks. Go to a Lancia Dealership if the warning light
switches on when the engine is started again;
if the vehicle is used under demanding conditions(e.g. towing trailers uphill or fully loaded): slow
down and, if the warning light stays on, stop the vehicle. Wait for 2 or 3 minutes with the engine running
and slightly accelerated to further favour the coolant circulation. Then stop the engine. Check that the
coolant level is correct as described above. If the fluid level is insufficient, top it up.
IMPORTANT On demanding routes, it is advisable to keep the engine on and slightly accelerated for a few
minutes before stopping it.
50
KNOWING THE INSTRUMENT PANEL

Warning light What it means
Versions with multifunction
displayDOORS/BONNET/LUGGAGE COMPARTMENT OPEN
The warning light switches on (on some versions along with a dedicated message and a symbol on the
display) when one or more doors, the bonnet or the tailgate are not properly closed. An acoustic signal is
activated with the doors open and the car moving.
Versions with reconfigurable
multifunction displayDOORS/BONNET/LUGGAGE COMPARTMENT OPEN
The symbols on the display switches on, together with a dedicated message, on some versions, when one
or more doors, the tailgate or the bonnet (for versions/markets, where provided) are not properly closed.
An acoustic signal is also emitted with the doors open and the car in motion.
"DUAL FUNCTION SYSTEM" GEARBOX FAULT
When the ignition key is turned to MAR, the warning light switches on but should switch off after a few
seconds.
The warning light comes on flashing, along with a dedicated message on the display and an acoustic
warning, to indicate transmission failure.
30)
WARNING
30)If the gearbox is faulty, contact a Lancia Dealership as soon as possible to have the system checked.
51

Amber warning lights / symbols
Warning light What it means
ABS FAILURE
The warning light switches on when the ignition key is turned to MAR, but it should switch off after a few
seconds.
The warning light switches on (on some versions, with a dedicated message on the display and a symbol
on the display) when the system is not efficient. In this case the braking system maintains its efficiency
unaltered but without the advantage of the ABS system.
Drive carefully and go to a Lancia Dealership as soon as possible.
PASSENGER AIRBAG/SIDE BAGS DEACTIVATED
The warning light switches on when the front passenger's airbag and side bag are disabled.
With passenger side front airbag on, when the key is turned to MAR, the warning light
switches on
constantly for several seconds, flashes for another few seconds and then should switch off.
39)
WARNING
39)A failure of thewarning light is indicated by thewarning light switching on. In addition, the airbag system automatically disables the
airbags on the passenger's side (both front and side airbags - for versions/markets where provided). Before continuing, contact a Lancia
Dealership immediately to have the system checked.
52
KNOWING THE INSTRUMENT PANEL

Warning light What it means
INJECTION / EOBD SYSTEM FAILURE
In normal conditions, the warning light switches on when the key is turned to MAR (on some versions, with
a dedicated message on the display), but should switch off as soon as the engine is started.
If the warning light remains on or switches on whilst driving, the injection system is not working properly; in
particular, if the warning light switches on steadily, this indicates a malfunction in the supply/ignition system
that could cause excessive exhaust emissions, a possible loss of performance, poor driveability and high
fuel consumption.
Under these conditions, the vehicle can continue travelling at moderate speed without demanding
excessive effort from the engine. Prolonged use of the car with the warning light on may cause damage.
Contact a Lancia Dealership as soon as possible.
The warning light switches off if the malfunction disappears, but is still stored by the system.
Petrol engines only
If the warning light flashes, it means that the catalytic converter may be damaged.
In this case, it is necessary to release the accelerator pedal to lower the speed of the engine until the
warning light stops flashing. Continue the journey at moderate speed, trying to avoid driving conditions that
may cause further flashing and contact a Lancia Dealership as soon as possible.
31)
WARNING
31)Go to a Lancia Dealership as soon as possible if thewarning light either does not light up when the key is turned to MAR or if while
travelling the warning light switches on or flashes (along with a message and a symbol on the display on some versions). The operation of the
warning light may be checked by the traffic police using specific devices. Comply with the laws and regulations of the country where
you are driving.
53

Warning light What it means
FUEL RESERVE / LIMITED RANGE
This warning light switches on when 5 to 7 litres of fuel are left in the tank. When the remaining range is
lower than approx. 50 km (or equivalent value in miles), on some versions the display will show a dedicated
message.
IMPORTANT The warning light will flash to indicate a system failure. Go to a Lancia Dealership to have the
system checked.
ESC SYSTEM
(for versions/markets, where provided)
The warning light switches on when the ignition key is turned to MAR, but it should switch off after a few
seconds.
ESC system activation
Flashing of the warning light while driving indicates the intervention of the ESC system.
ESC system failure
If the warning light does not switch off or remains on (together with a dedicated message and a symbol on
the display on some versions) whilst driving, contact a Lancia Dealership.
Hill Holder failure
This warning light comes on, on some versions together with the
symbol and a message is displayed,
in the event of a fault with the Hill Holder system.
In this case, go to a Lancia Dealership.
REAR FOG LIGHT
The warning light switches on when the rear fog light is turned on. The LED over the button
will also
light up.
54
