2019 TOYOTA TUNDRA Owners Manual (in English)

649
10
For owners
Secure loose items to prevent weight shifts that could affect the bal-
ance of your vehicle. When the truck camper is loaded, drive to a
scale and weigh on the front and on the rear wheels separately to
determine axle loads. Individual axle loads should not exceed e ither
of the Gross Axle Weight Ratings (GAWR). The total of the axle loads
should not exceed the Gross Vehicle Weight Rating (GVWR). These
ratings are given on the vehicle certification label which is located on
the door latch post on the le ft side of the vehicle. (P. 599) If weight
ratings are exceeded, move or remove items to bring all weights
below the ratings.
Gross axle weight rating
Front GAWR
Rear GAWR
Gross vehicle weight rating
Not exceed GVWR
WARNING
■ Overloading
Be careful — overloading can cause dangerous braking and handli ng prob-
lems, and can damage your vehicle and its tires.
Gross axle and vehicle weight ratings
1
2
1

650
■GAWR and GVWR
Double Cab models
*:The model code is indicated on the Certification Label. (P. 5 9 9)
Model
code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
UPK51L-
CRTSKA 1UR-FE2WD
Stan-dard 3900 lb.
(1770 kg) 4000 lb.
(1815 kg) 6700 lb.
(3040 kg)
UPK56L-
CRTSKA 4WD
4000 lb.
(1815 kg)
4100 lb.
(1860 kg)6900 lb.
(3130 kg)
USK51L-
CRTSKA
3UR-FE2WD
3900 lb.
(1770 kg)
USK51L-
CRTLKA
USK52L-
CHTSKA
Long
4150 lb.
(1880 kg)
7000 lb.
(3175 kg)
USK56L-
CRTSKA
4WDStan-
dard
4000 lb.
(1815 kg)
7100 lb.
(3220 kg)
USK56L-
CRTLKA
USK57L-
CHTSKA Long
7200 lb.
(3265 kg)
USK56L-
CRTSGA
3UR-FBE Stan-
dard
7100 lb.
(3220 kg)
USK56L-
CRTLGA
USK57L-
CHTSGA Long
7200 lb.
(3265 kg)

651
10
For owners
CrewMax models
*:The model code is indicated on the Certification Label. (P. 5 9 9)
Model
code
*EngineDriving
systemBed
typeGAWRGVWRFrontRear
UPK51L-
PSTSKA 1UR-FE2WD
Short3900 lb.
(1770 kg) 4050 lb.
(1835 kg) 6800 lb.
(3085 kg)
UPK56L-
PSTSKA 4WD
4000 lb.
(1815 kg)
4150 lb.
(1880 kg)
7000 lb.
(3175 kg)
USK51L-
PSTSKA
3UR-FE2WD
3900 lb.
(1770 kg)
USK51L-
PSTLKA
USK51L-
PSTZKA
USK56L-
PSTSKA
4WD
4000 lb.
(1815 kg)7200 lb.
(3265 kg)
USK56L-
PSTLKA
USK56L-
PSTZKA
USK56L-
PSTSGA
3UR-FBE
USK56L-
PSTLGA
USK56L-
PSTZGA

652

653
Index
What to do if... (Troubleshooting) .................... 654
Alphabetical index ..................... 657
For vehicles with Entune Audio Plus or Entune Premium Audio,
refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER
’S MANUAL” for information regarding the multimedia
system.
Multimedia system types: P. 322

654What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys, new genuine keys can be made by your Toyota
dealer. (P. 111 )
●Is the wireless key battery weak or depleted? ( P. 516)
●The function may not operate properly due to the condition of t he radio
wave. ( P. 111)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. ( P. 116)
●Is the shift lever in P? ( P. 194)
●Is the battery discharged? ( P. 582)
●Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in the “ON” position. ( P. 200)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened
If you think something is wrongThe engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal

655What to do if... (Troubleshooting)
●It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. ( P. 195)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 147)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 548)
●The parking brake indicator is on
Is the parking brake released? ( P. 204)
Depending on the situation, other types of warning buzzer may also sound.
( P. 547, 555)
●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 85)
To stop the alarm, turn the engine switch to the “ACC” or “ON” position, or
start the engine.
●When a warning light turns on or a warning message is displayed , refer to
P. 547, 555.
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning light turns on or a warning message is displayed

656What to do if... (Troubleshooting)
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 565)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 588)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck
