Rear Tail/Stop, Turn Signal And Backup Lamps
1. Remove the two screws and push pins that pass throughthe bed sheet metal.
2. Pull the outboard side of the lamp rearward far enough to unsnap the two receptacles on the outboard side of
the lamp housing from the two plastic snap post retain-
ers in the outer box side panel. 3. Disconnect the wiring harness connectors from the bulb
socket.
4. Rotate the bulb socket counterclockwise 1/4 turn to unlock it from the housing.
5. Pull the bulb straight out of the socket.
Tail Lamp Locations
1 — Tail Lamp
2 — Fasteners
Tail Lamp Removed
1 — Tail Lamp Housing
2 — Bulb Socket Locations
7
IN CASE OF EMERGENCY 447
Page 450 of 698
CAUTION!
Do not contaminate the bulb glass by touching it with
your fingers or by allowing it to contact other oily
surfaces. Shortened bulb life will result.
6. Reverse the procedure to install the bulb and housing.
Center High-Mounted Stoplamp (CHMSL) With
Cargo Lamp
1. Remove the two screws holding the housing/lens to the body as shown. 2. Separate the connector holding the housing and wiring
harness to the body.
3. Turn the desired bulb socket ¼ turn and remove the socket and bulb from housing.
CHMSL Mounting Screw Locations
CHMSL Connector Location
448 IN CASE OF EMERGENCY
Page 451 of 698

4. Pull the desired bulb straight from the socket.
CAUTION!
Do not contaminate the bulb glass by touching it with
your fingers or by allowing it to contact other oily
surfaces. Shortened bulb life will result.• Outside Bulbs: Cargo Lamps
• Inside Bulb: Center High-Mounted Stop Lamp
5. Reverse the procedure for installation of bulbs and housing.
FUSES
WARNING!
•When replacing a blown fuse, always use an appro-
priate replacement fuse with the same amp rating as
the original fuse. Never replace a fuse with another
fuse of higher amp rating. Never replace a blown
fuse with metal wires or any other material. Do not
place a fuse inside a circuit breaker cavity or vice
versa. Failure to use proper fuses may result in
serious personal injury, fire and/or property damage.
• Before replacing a fuse, make sure that the ignition is
off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, transmission system) or steering
system blows, contact an authorized dealer.
CHMSL Bulb And Socket
7
IN CASE OF EMERGENCY 449
Page 452 of 698
Power Distribution Center
The Power Distribution Center is located in the engine
compartment near the battery. This center contains car-
tridge fuses, micro fuses, relays, and circuit breakers. A
description of each fuse and component may be stampedon the inside cover, otherwise the cavity number of each
fuse is stamped on the inside cover that corresponds to the
following chart.
Cavity
Cartridge Fuse Micro Fuse Description
F01 –25 Amp Clear Fuel Pump Motor
F03 –5 Amp Tan MGU – If Equipped
F04 –– Spare
F05 –– Spare
F06 –– Spare
F07 –– Spare
F08 20 Amp Blue –Trailer Tow Backup
F09 –20 Amp Yellow Trailer Stop / Turn Lamp Left
F10 –20 Amp Yellow Trailer Stop / Turn Lamp Right
F11 –– Spare
F12 20 Amp Blue –Trailer Tow Park Lamp
F13 –– Spare
F14 –10 Amp Red AC Clutch
F15 –5 Amp Tan IBS
F16 –– Spare
450 IN CASE OF EMERGENCY
Page 453 of 698
CavityCartridge Fuse Micro Fuse Description
F17 –20 Amp Yellow Air Suspension
F18 –15 Amp Blue AGS / Rear Axle Cooling Valve / Active Air
Dam
F19 –– Spare
F20 –20 Amp Yellow Adjustable Pedals
F21 –– Spare
F22 50 Amp Red – I Air Module
F23 –– Spare
F24 –20 Amp Yellow TCM SBW
F25 50 Amp Red –Power Side Step
F26 50 Amp Red – ESP Module
F27 30 Amp Pink – Front Wiper
F28 –10 Amp Red PCM / ECM
F29 40 Amp Green –ESP Module
F30 –– Spare
F31 –– Spare
F32 20 Amp Blue – ECM / PCM
F33 30 Amp Pink –Brake Vacuum Pump
F34 –– Spare
7
IN CASE OF EMERGENCY 451
Page 454 of 698
CavityCartridge Fuse Micro Fuse Description
F35 –10 Amp Red PCM / ECM / Power Pack Unit (PPU) Mo-
tor Generator Unit (MGU) Wake Up / EPS /Active Tuned Mass Module (ATMM) / ESP
F36 –– Spare
F37 –5 Amp Tan R / S Output to iPDC
F38 –10 Amp Red DTCM / Active CL TEMP VLV
F39 –– Spare
F40 40 Amp Green – Starter
F41 –10 Amp Red IRCAM Heaters
F42 –– Spare
F43 –20 Amp Yellow MGU Coolant Pump – If Equipped
F44 –– Spare
F45 –– Spare
F46 30 Amp Pink –Fuel Heater – If Equipped
F47 30 Amp Pink –Rear Defroster
F48 –– Spare
F49 30 Amp Pink –Htr Ctrl – If Equipped (Diesel Only)
F50 –– Spare
F51 –– Spare
F52 –– Spare
452 IN CASE OF EMERGENCY
Page 455 of 698

CavityCartridge Fuse Micro Fuse Description
F53 –10 Amp Red Supply / Purging Pump – If Equipped
F54 –15 Amp Blue PCM – If Equipped
F55 –15 Amp Blue Right HID Headlamp
F56 –– Spare
F57 –20 Amp Yellow Horn
F58 –– Spare
F59 –25 Amp Clear Injectors / IGN Coil / Glow Plug Module
F60 –20 Amp Yellow ECM / PCM / ACT Short Running Valve
F61 –15 Amp Blue Left HID Headlamp
F62 60 Amp Blue –Glow Plug – If Equipped
F63 –– Spare
F64 –10 Amp Red PM Sensor – If Equipped
CAUTION!
•When installing the power distribution center cover,
it is important to ensure the cover is properly posi-
tioned and fully latched. Failure to do so may allow
water to get into the power distribution center and
possibly result in an electrical system failure.
(Continued)
CAUTION! (Continued)
•When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it indicates a
problem in the circuit that must be corrected.
7
IN CASE OF EMERGENCY 453
Page 456 of 698

Internal Power Distribution Center
The Power Distribution Center is located under the drivers
side instrument panel. This center contains cartridge fuses,
micro fuses, relays, and circuit breakers. A description ofeach fuse and component may be stamped on the inside
cover, otherwise the cavity number of each fuse is stamped
on the inside cover that corresponds to the following chart.
Cavity
Cartridge Fuse Micro Fuse Description
F01 30 Amp Pink –Trailer Tow Receptacle
F03 –15 Amp Blue Module Seat Heater Front (Pass)
F04 –– Spare
F05 –20 Amp Yellow Module PPU Cooling Fan
F06 40 Amp Green –Mod CBC 4 Exterior Light 2
F07 40 Amp Green –Mod CBC 3 PWR Locks
F08 –– Spare
F09 –– Spare
F10 40 Amp Green –HVAC Blower Motor
F11 –5 Amp Tan Output to Underhood Power Distribition
Center (UPDC) Run Coil
F12 –25 Amp Clear Mod Audio Amplifier / Active Noise Can-
cellation / SW Inverter
F13 –20 Amp Yellow Mod Seat Heater Front (Driver)
F14 –15 Amp Blue Mod Seat Heater Front (Steering Wheel)
F15 –– Spare
454 IN CASE OF EMERGENCY
