2019 MERCEDES-BENZ C CLASS display

Reversing camera
Function oftherear view camera
Ifyou haveactivatedthe function inthe multime‐dia system,the image fromrear view camera1is shown inthe multimedia system display whenreversegear is selected. Dynamic guide linesshowthe paththevehicle willtakewiththesteering wheel in its current position. This helps
youtoorientyourself andto avoid obstacleswhen backing up.
Therear view camera is onlyan aid. It is not asubstituteforyour attentiontothe surroundings.Theresponsibilityfor safe maneuvering andparkingremains withyou. Make surethatthereare no persons, animals or objectsetc., inthemaneuvering area while maneuvering and park‐ing.
You can select fromthefollowing views:
RNormal view
RWide-angle view
The area behindthevehicle is displayed as amirror image, as inthe insiderearview mirror.
Vehicles withoutActiveParking AssistThefollowing camera viewsareavailable inthemultimedia system:
Normal view
1Yellow guide line,vehicle width (driven sur‐face) depending onthe currentsteeringwheel angle (dynamic)
2Yellow lane markingthe coursethe tires willtakeatthe currentsteering wheel angle(dynamic)
3Yellow guide line at a distance of approx‐imately 3.3ft(1.0 m) fromtherear area
4Bumper
5Red guide line at a distance of approximately1.0 in (0.3 m) fromtherear area
204Driving and parking

Wide-angle view
Vehicles withActiveParking AssistThefollowing camera viewsareavailable inthemultimedia system:
Normal view
1Yellow lane markingthe coursethe tires willtakeatthe currentsteering wheel angle(dynamic)
2Yellow guide line,vehicle width (driven sur‐face) depending onthe currentsteeringwheel angle (dynamic)
3Red guide line at a distance of approximately12in (0.3 m) fromtherear area
4Yellowwarning display ofParking AssistPARKTRONIC: obstacles are at a distance ofbetween approximately 2.0ft(0.6 m) and3.3ft(1.0 m)
5Redwarning display ofParking AssistPARKTRONIC: obstacles areveryclose(approximately1.0ft(0.3 m) or less)
6Orangewarning display ofParking AssistPARKTRONIC: obstacles are a medium dis‐tanceaway(between approximately1.0ft(0.3 m) and 2.0ft(0.6 m))
Ifthe entire systemfails,the inner segmentsofthewarning display are shown inred. Theindicator lamp onthePARKTRONIC buttonlights up andtheésymbol appears inthe multifunction display.Ifthe systemfails attherear,therear seg‐ments are shown inred when backing upand are hidden when drivingforwards.WhenActiveParking Assist is active,thelanes are displayed in green.IfParking AssistPARKTRONIC is deactivated,thewarning displayfades out.
Driving and parking205

Wide-angle view
System limitations
Therear view camera will not function or willonly partially function inthefollowing situations:
RThe trunk lid is open.
RThere is heavyrain, snow orfog.
RThe ambient light conditions are poor, e.g. atnight.
RThe camera lens is obstructed, dirty orfog‐ged up. Observethe notes on cleaningtherear view camera (page 364).
RCameras, orvehicle components in whichthe cameras are installed, are damaged. In
thisevent, havethe cameras,their positionsandtheir settingchecked at aqualified spe‐cialistworkshop.
Thefield of vision andother functions oftherearview camera may berestricted duetoadditionalaccessories ontherear ofthevehicle (e.g.license plate bracket or bicyclerack).
The display contrast may be impaired duetoincident sunlight orother light sources. Inthis case, pay particular attention.
Havethe displayrepaired orreplaced if,forexample, pixel errorsconsiderablyrestrict itsuse.
360° camera
Function ofthe 360° CameraThe 360° Camera is a systemthat consists offour cameras. The cameras coverthe immediatevehicle surroundings. The system assistsyou,e.g. when parking or atexits withreduced visibil‐ity.
The 360° Camera is only an aid. It is not a sub‐stituteforyour attentiontothe surroundings.
Theresponsibilityfor safe maneuvering andparkingremains withyou. Make surethatthereare no persons, animals or objectsetc., inthemaneuvering area while maneuvering and park‐ing.
The systemevaluates images fromthefollowingcameras:
RRear view camera
RFront camera
RTwo side cameras inthe outside mirrors
Views ofthe 360° CameraYou can select from different views:
206Driving and parking

1Wide-angle view,front
2Top view with image fromthe front camera
3Top view with images fromthe side camerasinthe outside mirrors
4Wide-angle view,rear
5Top view with image fromtherear view cam‐era
6Top view with trailer view (if trailer hitch isinstalled)
Top view
1Lane indicatingtheroutethevehicle willtakewiththesteering wheel in its currentposition
2Yellowwarning display ofParking AssistPARKTRONIC: obstacles at a distance ofapproximately 3.3ft(1.0 m) or less
3Yourvehicle from above
Ifthe distancetothe object lessens,the color ofwarning display2changes:
RFrom approx. 3.3ft(1.0 m):yellow
RFrom approx. 2.0ft(0.6 m): orange
RFrom approx.1.0ft(0.3 m):red
WhenParking AssistPARKTRONIC is operationaland no object is detected,the segments ofthewarning display are grayed out.
Ifthe entire systemfails,the segments ofthewarning display are shown inred andtheésymbol appearsinthe multifunctiondisplay inthe instrument cluster.
Ifthe systemfails attherear,the display ofthe segmentschanges asfollows:
RTherear segments are shown inredwhen backing up.
RTherear segments are hidden when driv‐ingforwards.
IfParking AssistPARKTRONIC is deactivated,thewarning displayfades out.
Driving and parking207

Guide lines
1Yellow lane markingthe coursethe tires willtakeatthe currentsteering wheel angle(dynamic)
2Yellow guide line,vehicle width (driven sur‐face) depending onthe currentsteeringwheel angle (dynamic)
3Red guide line at a distance of approximately12in (0.3 m) fromtherear area
4Mark at a distance of approx. 3.3ft(1.0 m)
WhenActiveParking Assist is active, lanes1are displayed in green.
The guide lines inthe multimedia system dis‐play showthe distancestoyourvehicle. Thedistances applytoroad level.
Side view ofthe mirror camerasThe sides ofthevehicle can be seen inthis view.
1Guide line ofexternalvehicle dimensionswith outside mirrorsfolded out
2Marker ofthe wheel contact points
SystemfailureIfthere is no operationalreadiness,thefollowingmessage appears inthe multimedia system:
System limitations
The 360° Camera will not function or will onlypartially function inthefollowing situations:
RThe doors are open.
RThe side mirrorsarefolded in.
RThe trunk lid is open.
RThere is heavyrain, snow orfog.
RThe ambient light conditions are poor, e.g. atnight.
RThe camera lens is obstructed, dirty orfog‐ged up.
RIf cameras orvehicle components in whichthe cameras are installed are damaged. In
208Driving and parking

thisevent, havethe cameras,their positionsandtheir settingchecked at aqualified spe‐cialistworkshop.
Do not usethe 360° Camera under such cir‐cumstances.You couldotherwise injureoth‐ers or collide with objects when parkingthevehicle.
Ifthevehicle is carrying a heavy load, leavingthestandard height canresult in inaccuracies intheguide lines and inthe display ofthegeneratedimages, depending ontechnical conditions.
Thefield of vision andother functions ofthecamerasystem may berestricted duetoaddi‐tional attachments onthevehicle (e.g. licenseplate bracket, bicyclerack).
The contrast ofthe display may be impairedbyabrupt direct sunlight orby other lightsources, e.g. when driving out of agarage. Inthis case, pay particular attention.
Havethe displayrepaired orreplaced if,forexample, pixel errorsconsiderablyrestrict itsuse.
Seethe notes on cleaningthe 360° Camera(page 364).
Selecting a viewfor the 360° Camera
Requirements:RTheAuto. Rear View Cam.function is selec‐ted inthe multimedia system.
Engagereversegear.
Inthe multimedia system, selectthe desiredview.
Openingthe camera cover of therear viewcameraMultimedia system:
VehiclekAssistanceCamera & Parking
SelectOpen Camera Cover.
The camera cover closes automaticallyaftersome time or after an ignition cycle.
Settingthe camera as afavoriteYou can call upthe camera view directly inthemultimedia systembysetting it as afavorite.
Pressthe

WhenActiveParking Assist has detected parkingspaces,thefollowing symbol appears inthe mul‐tifunction display inthe instrument cluster:
The arrows show on which side oftheroadwayfree parking spaces are located. They arethenshown inthe multimedia system display.
The parking space and, if necessary,the parkingdirection can be selected as desired.ActiveParking Assist calculates a suitablevehicle pathand assistsyou in parking andexitingthe park‐ing space.
Vehicles with automatic transmission:ActiveParking Assist supports withchanginggear,accelerating, braking andsteeringthevehicle.
ActiveParking Assist is only an aid. It is not asubstituteforyour attentiontothe surroundings.Theresponsibilityfor safe maneuvering andparkingremains withyou. Make surethat nopersons, animals or objectsetc. are inthemaneuveringrange.
ActiveParking Assist is canceled if, amongotherthings, one ofthefollowing actions is carriedout:
RYou deactivateParking AssistPARKTRONIC.
RYou deactivateActiveParking Assist.
RYou beginsteering.
RYou applythe parking brake.
RVehicles with automatic transmission:You engagetransmission position].
RESP®intervenes.
RYou openthe doors orthe trunk lid whiledriving.
System limitationsObjects located aboveor belowthe detectionrange ofActiveParking Assist are not detectedwhenthe parking space is being measured.These are also nottaken into account whentheparking maneuver is calculated, e.g.overhangingloads,overhangs or loadingramps of trucksorthe boundaries of parking spaces. In some cir‐cumstances,ActiveParking Assist maythereforeguideyou intothe parking space prematurely.
\nWARNINGRisk of accident duetoobjects located aboveor belowthedetectionrange ofActiveParking Assist
Ifthere are objects aboveor belowthedetectionrange,thefollowing situations mayarise:
RActiveParking Assist maysteertoo early.
RVehicles with automatic transmis‐sion:Thevehicle may notstop in front ofthese objects.
This could cause a collision.
Inthese situations, do not useActiveParking Assist.
Snowfall or heavyrain may leadtoa parkingspace being measured inaccurately.Parkingspacesthat are partiallyoccupiedbytrailerdrawbars might not be identified as such or bemeasured incorrectly. Only useActiveParkingAssist on level, high-gripground.
210Driving and parking

Do not useActiveParking Assist inthefollowingsituations:
RInextremeweather conditions such as ice,packed snow or in heavyrain.
RWhen transporting a loadthat protrudesbeyondthevehicle.
RIfthe parking space is on asteep downhill oruphill gradient.
RWhen snowchains are installed.
ActiveParking Assist may also display parkingspacesthat are not suitablefor parking, e.g.:
RParking spaces where parking is prohibited.
RParking spaces on unsuitable surfaces.
ActiveParking Assist will not assistyou withparking spaces atright anglestothe direction oftravel inthefollowing situations:
RIf two parking spaces are located immedi‐ately nexttoeachother.
RIfthe parking space is immediately nextto alow obstacle suchas a curb.
ActiveParking Assist will not assistyou withparking spaces parallel or atright anglestothedirection of travel inthefollowing situations:
RIfthe parking space is on a curb.
RIfthe parking space is borderedbyan obsta‐cle, e.g. a tree, a post or a trailer.
Parking withActiveParking Assist
Press button1.
TheActiveParking Assist view appears onthemultimedia system display.Area2displaysdetected parking spaces4andvehicle path3.
Vehicle path3shown onthe multimediasystem display may differ fromthe actualvehicle path.
Ifyou havedriven past a parking space: bringthevehicletoastandstill.
Select desired parking space4.
Driving and parking211
