Do not place an object such as a cushion
between the seatback and your back:
Putting an object such as a cushion
between the seatback and your back is
dangerous because you will be unable to
maintain a safe driving posture and the
seat belt cannot function at its full capacity
in a collision, which could result in a serious
accident, injury or death.
Do not place objects under the seat:
The object could get stuck and cause the
seat to not be fixed securely, and result in
an accident.
Do not stack cargo higher than the
seatbacks:
Stacking luggage or other cargo higher
than the seatbacks is dangerous. During
sudden braking or a collision, objects can
fly around and become projectiles that
may hit and injure passengers.
Make sure luggage and cargo is secured
before driving:
Not securing cargo while driving is
dangerous as it could move or be crushed
during sudden braking or a collision and
cause injury.Never allow a passenger to sit or stand on
the folded seatback while the vehicle is
moving:
Driving with a passenger on the folded
seatback is dangerous. Allowing a child to
sit up on the folded seatback while the
vehicle is moving is particularly dangerous.
In a sudden stop or even a minor collision,
a child not in a proper seat or
child-restraint system and seat belt could
be thrown forward, back or even out of the
vehicle resulting in serious injuries or death.
The child in the baggage area could be
thrown into other occupants and cause
serious injury.
Never give the car keys to children and do
not allow them to play in the vehicle (4–
Door):
Playing with the folding rear seats is
dangerous. Once the seatbacks are back
up, a child in the trunk would not be able to
get out the way they had entered. If you
have small children, keep the seatbacks
locked.
Always leave your car locked and keep the
car keys safely away from children (4–
Door):
Leaving your car unlocked or the keys in
reach of children is dangerous. Children
who find their way into the trunk through
an unlocked rear seatback or an open
trunk can become accidentally locked in
the trunk. This could result in death or
brain damage from heat prostration,
particularly in the summer. Always lock the
doors and the trunk, and as an added
measure, keep the rear seatbacks locked,
whether you have children in your home or
not.
Essential Safety Equipment
Seats
2-3
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

CAUTION
When operating a seat, be careful not to
put your hands or fingers near the
moving parts of the seat or on the side
trim to prevent injury.
 When moving the seats, make sure there
is no cargo in the surrounding area. If the
cargo gets caught it could damage the
cargo.
 (Manual Seat)
When moving the seats forward and
rearward or returning a rear-reclined
seatback to its upright position, make
sure you hold onto the seatback with
your hand while operating. If the
seatback is not held, the seat will move
suddenly and could cause injury.
 When inserting your hand under the seat
to clean the cabin or pick up something
you dropped under the seat, be careful
not to hurt yourself. If you contact the
moving parts of the seat rail or seat
frame, it could result in injury.
NOTE
When returning a rear seat to its
original position, place the seat belt in
its normal position. Verify that the seat
belt pulls out and retracts.
(Power Seat)
The seat-bottom power adjustment is
operated by motors. Avoid extended
operation because excessive use can
damage the motors.
To prevent the battery from running
down, avoid using the power
adjustment when the engine is
stopped. The adjuster uses a large
amount of electrical power.
Do not use the switch to make more
than one adjustment at a time.
Essential Safety Equipment
Seats
2-4
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Front Seat
▼Adjusting the Driver's Seat
Using the driving position set up
procedure recommended by Mazda allows
you to maintain a relaxed posture, drive
the vehicle for longer periods without
feeling tired, and make quick operations
naturally.
Also, you can be assured of a clear view in
the forward direction to help you drive
more safely and comfortably.
The adjustments for the driving position
recommended by Mazda are done using
the following procedures.
1. Moving the steering wheel and seat to
their default positions.
2. Adjusting the seatback angle.
3. Adjusting the seat position forward and back.
4. Adjusting the seat height.
5. Adjusting the height on the front edge of the seat bottom.
6. Adjusting the steering wheel position.
7. Adjusting the head restraint position.
Manual seat
1. Seat Slide
To move a seat forwa rd or backward,
raise the lever and slide the seat to the
desired position and release the lever.
Make sure the lever returns to its
original position a nd the seat is locked
in place by attempting to push it
forward and backward.
2. Height Adjustment
To adjust the seat height, move the
lever up or down.
3. Height Adjustment for Front Edge
of Seat Bottom
To adjust the height for front edge of
the seat bottom, rotate the dial to the
desired position.
Essential Safety Equipment
Seats
2-5
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

4.Seat Recline
To change the seatback angle, lean
forward slightly while raising the lever.
Then lean back to the desired position
and release the lever.
Make sure the lever returns to its
original position and the seatback is
locked in place by attempting to push
it forward and backward.

Power seat
1. Seat Slide
To slide the seat, m ove the slide lifter
switch on the outside of the seat to the
front or back and hold it. Release the
switch at the desired position.
2. Height Adjustment
To adjust the seat height, move the
slide lifter switch up or down.
3.Height Adjustment for Front Edge
of Seat Bottom
To adjust the front height of the seat
bottom, raise or lower the front of the
slide lifter switch.
4. Seat Recline
To change the seatback angle, press the
front or rear side of the reclining
switch. Release the switch at the
desired position.
5. Lumbar Support Adjustment
To increase the seat firmness, press
and hold the front part of the switch to
the desired position, then release it.
Press the rear part of the switch to
decrease firmness.

Before making adjustments to the
driving position recommended by
Mazda
Before making adjustments, move the
steering wheel and s eat to their default
positions.
How to move the steering wheel to its
default position
WA R N I N G
Never adjust the steering wheel while the
vehicle is moving:
Adjusting the steering wheel while the
vehicle is moving is dangerous. Moving it
can very easily cause the driver to abruptly
turn to the left or righ t. This can lead to loss
of control or an accident.
Essential Safety Equipment
Seats
2-6
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

After adjusting the steering wheel position,
make sure it is securely locked by trying to
move it up and down:
Driving with the steering wheel not
securely locked in position is dangerous. If
the steering wheel moves unexpectedly
while driving, you could lose control of the
steering resulting in an accident.
Lower the lever, move the steering wheel
to the lowest position, and then push it
down and all the way back.
How to move a driver’s seat to its
default position
1. Slide the seat all the way back.
2. Lower the seat to its lowest height.
3. Lower the front edge of the seatbottom to its lowest height.
4. Sit squarely in the seat and rest your back against the seatback.
Seat adjustment pr ocedure for the
driving position recommended by
Mazda
Adjusting the seatba ck angle (reclining)
Adjust the seatback to the angle providing
a comfortable seated posture.
1. With your posture slightly slouched, move the seatback forward to the angle
where your waist feels slightly
cramped.
1. Manual Seat
2. Power Seat

Essential Safety Equipment
Seats
2-7
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

2. Move the seatback backward to acomfortable seated posture without any
feeling of cramping in your waist.
1. Manual Seat
2. Power Seat

Adjusting the seat p osition forward and
back (sliding)
Adjust the seat to the position best for
operating the accelerator and brake pedals.
1. Place your left foot on the footrest, your right foot between the accelerator
and brake pedals, and position your
heel to the position allowing easy
switching between the pedals.
2. With your heel set on the floor, set your right foot on the brake pedal and
move the seat forward as far as
possible until you feel a slight
cramping in your ankle.
1. Manual Seat
2. Power Seat

3. With your right foot set on the brake
pedal, move the seat back until you no
longer feel cramping in your ankle.
Essential Safety Equipment
Seats
2-8
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

4. With your heel set on the floor, make
sure you can move your foot between
the brake pedal and accelerator pedal
smoothly.
5. Depress the accelerator pedal
completely with your heel set on the
floor and make sure that your ankle
does not feel over-stretched.
1. Manual Seat
2. Power Seat

Adjusting the seat height
Adjust the seat height to a position where
you have a clear forward view and you can
drive the vehicle easily.
1. With your back resting against theseatback, raise the seat to the height
where you can see the rear edge area of
the hood surface from the windshield.
1. Manual Seat
2. Power Seat

Essential Safety Equipment
Seats
2-9
Mazda3_8HE9-EA-18K_Edition1 2018-10-17 19:05:10

Adjusting the height on the front edge
of the seat bottom
Adjust the height on the front edge of the
seat bottom to the position where the back
of your knees contacts the front edge of
the seat bottom.
1. With your right foot set on the accelerator pedal, adjust the height on
the front edge of the seat bottom so
that the back of your knees lightly
contacts the front edge of the seat
bottom.
2. Depress the accelerator pedal and
make sure that you no longer feel
cramping in the back of your knees.
1. Manual Seat
2. Power Seat

Adjusting the ste ering wheel position
Adjust the steering wh eel to the position
where it can be operated easily and the
gauges can be viewed easily.
1. With your back resting against the seatback, extend both arms, place them
on the top of the steering wheel, and
pull the steering wheel towards you to
the position of your wrists.
2. Adjust the steering wheel height sothat the gauges can be viewed easily.
3. Raise the lever to securely lock the
steering wheel.
Adjusting the head restraint position
To prevent shock to the head and neck,
adjust the head restra ints to their correct
positions.
Refer to Height Adjustment on page
2-17.
▼ Driving Position Memory (Power
Seat)*
The desired driving position can be called
up after programming the position.
The following driving positions can be
programmed.
Essential Safety Equipment
Seats
2-10*Some models.
Mazda3_8HE9-EA-18K_Edition1
2018-10-17 19:05:10
