82 2. Instrument cluster
RX350/RX350L_U * 1
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a sy stem if a light does
not come on, or turn off. Have the ve hicle inspected by your Lexus dealer.
* 2
: This light flashes to indicate a malfunction.
* 3
: This light flashes or illumina tes to indicate a malfunction.
* 4
: This light illuminates on the center panel.
* 5
:RX350
* 6
:RX350L
The indicators inform the driver of the op erating state of the vehicle’s various sys-
tems. Low fuel level warning light
(  P. 656)
* 4, 6
Rear passengers’ seat
belt reminder light
(  P. 656)
Driver’s and front
passenger’s seat belt
reminder light (  P. 656)
* 1
Tire pressure warning light
(  P. 656)
* 4, 5
Rear passengers’ seat
belt reminder light
(  P. 656) * 1
Master warning light
(  P. 657)
Indicators Turn signal indicator
(  P. 246) Fog light indicator
(  P. 260)
(U.S.A.)
Headlight indicator
(  P. 252) Cruise control indicator
(  P. 300)
(Canada)
Tail light indicator
(  P. 252) Radar cruise control
indicator (  P. 300)
Headlight high beam
indicator (  P. 253) Cruise control “SET”
indicator (  P. 300)
* 1
Automatic High Beam
indicator (  P. 256) LKA indicator (  P. 291)

156
RX350/RX350L_U 3-3. Adjusting the seats
Seat position adjustment switch
Seat cushion (front) angle adjust-
ment switch
Vertical height adjustment switch
Seatback angle adjustment switch
Lumbar support firmness adjust-
ment switch
Lumbar support height adjustment
switch (if equipped)
Seat cushion length adjustment
switch (if equipped) ■
Power easy access system
The driver’s seat (on some models) and steering wheel move in accordance with engine
switch mode and the driver’s seat belt condition. (  P. 172)Front seats Adjustment procedure 1
2
3
4
5
6
7
WARNING ■
When adjusting the seat position ●
Take care when adjusting the seat position to ensure that other passengers are not
injured by the moving seat. ●
Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the se at mechanism.●
Make sure to leave enough space around the feet so they do not get stuck. ■
Seat adjustment
To reduce the risk of sliding under the lap be lt during a collision, do not recline the seat
more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shou lder belt, increasing the risk
of death or serious injury in the event of an accident.
Adjustments should not be made while drivin g as the seat may unexpectedly move and
cause the driver to lose control of the vehicle.

160 3-3. Adjusting the seats
RX350/RX350L_U ■
Before folding the rear seatbacks
Stow the center seat seat belt buckle.
Lower the rear seat head restra ints to the lowest position. (  P. 177)■
Folding the rear seatbacks (manual seat) 
Using the seatback angle adjustment lever
Pull the lever and fold the rear seat-
back. 
Using the lever in the luggage compartment
Pull the lever and fold the rear seat-
back.Folding the second-row seat seatbacks (RX350) 1
2

1613-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U ■
Folding the rear seatbacks (power seat)
Press and hold the fold switch until the rear seatback begins to operate.A buzzer will sound and then the operation will start. When the operation is com-
pleted, the buzzer will sound again.
To stop the operation partway, press either side of the switch for the operating seat.
Any rear seat operation switch for the op erating seat, regardless of location, can
be used to stop the operation. (A buzzer may sound depending on the position
that the rear seatback is stopped.)
■
Returning the rear seatbacks (manual seat)
Lift the rear seatback until it locks
in position.
Check that the plate of the seat
belt is on the front side of the seat-
back. 
Using the seatback angle adjust-
ment switch 
Using the switch in the luggage
compartment
When using the seatback angle adjustme nt switch: If the rear seatback is
reclined, adjust it to the most upright position and then press the switch again.1
2

162 3-3. Adjusting the seats
RX350/RX350L_U ■
Returning the rear seatbacks (power seat)
Press and hold the return switch until the rear seatback begins to operate.A buzzer will sound and then the operation will start. When the operation is com-
pleted, the buzzer will sound twice again.
To stop the operation partway, press either side of the switch for the operating seat.
Any rear seat operation switch for the op erating seat, regardless of location, can
be used to stop the operation. (A buzzer may sound depending on the position
that the rear seatback is stopped.)
Check that the plate of the seat
belt is on the front side of the seat-
back.
■
Folding the rear center seatback only
Pull the lock release lever on the
back side of the seatback and fold
the center seatback. To return the rear center seatback to
its original position, li ft it until it locks
in position. 1
Using the seatback angle adjust-
ment switch 
Using the switch in the luggage
compartment
2

1633-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U ■
Before folding the second-row seat seatbacks
To prevent the seat belt from
being damaged, hook it to the
seat belt hanger.
Stow the center seat seat belt buckle.
Lower the second-row seat head re straints to the lowest position.
(  P. 177)■
Folding the second-row seat seatbacks 
Separate seat
Pull the seatback angle adjust-
ment lever and tilt the seatback
forward.
Pull the seatback folding lever
and fold the seatback.Folding the second-row seat seatbacks (RX350L) 1
2
3
1
2

1653-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U ■
Before moving the second-row seat
To prevent the seat belt from being
damaged, hook it to the seat belt
hanger.
■
When entering/exiting the vehicle
Pull the seatback angle adjustment
lever A or B to tilt the seatback for-
ward and then slide the seat forward. Make sure that th e second-row seat
is free of passengers and obstruc-
tions before operating the seatback
tilt lever.
■
After passengers have entered/exited the vehicle
Tilt back and slide the second-row seat until it locks in position.Moving the second-row seat for third-row seat access (RX350L)

166 3-3. Adjusting the seats
RX350/RX350L_U ■
Before folding the third-row seat seatbacks
To prevent the seat belt from
being damaged, hook it to the
seat belt hanger.
Lower the third-row seat head rest raints to the lowest position. (  P. 177)■
Folding the third-row seat seatbacks
Press and hold the side of the
switch until the seatback is folded
completely. A buzzer will sound twice before the
operation begins and twice when the
operation is complete.
If the switch is released while the
seatback is operating, the seatback
will stop and a buzzer will sound con-
tinuously.■
Returning the third-row seat seatbacks
Press and hold the side of the
switch until the seatback is fully
upright. A buzzer will sound twice before the
operation begins and twice when the
operation is complete.
If the switch is released while the
seatback is operating, the seatback
will stop and a buzzer will sound con-
tinuously.Folding the third-row se at seatbacks (RX350L) 1
2
