2019 LEXUS RX350 bulb

TABLE OF CONTENTS
6
RX350/RX350L_U 7-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ................ 576
Cleaning and protecting
the vehicle interior................... 581
7-2. Maintenance
Maintenance
requirements ............................ 584
General mainte nance.............. 586
Emission inspection and
maintenance (I/M)
programs....................................589
7-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions................................590
Hood ............................................... 592
Positioning a floor jack ............ 593
Engine compartment ............... 594
Tires ................................................. 604
Tire inflation pressure ................613
Wheels .............................................616
Air conditioning filter ................ 618
Windshield wiper inserts ..........621
Electronic key battery.............. 623
Checking and replacing
fuses.............................................. 625
Headlight aim .............................. 628
Light bulbs .................................... 630 8-1. Essential information
Emergency flashers .................. 644
If your vehicle has
to be stopped in
an emergency .......................... 645
8-2. Steps to take in
an emergency
If your vehicle needs
to be towed ............................... 646
If you think something is
wrong........................................... 652
Fuel pump shut off system...... 653
If a warning light turns
on or a warning buzzer
sounds ......................................... 654
If a warning message is
displayed ......................................661
If you have a flat tire .................. 666
If the engine will not start ........ 682
If the electronic key does
not operate properly ............. 684
If the vehicle battery is
discharged................................. 687
If your vehicle overheats......... 692
If the vehicle becomes
stuck ............................................. 6957
Maintenance and care 8
When trouble arises

15Pictorial index
RX350/RX350L_U Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 261 Precautions for winter season. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 384
To prevent freezing (windshield wiper de-icer)
* . . . . . . . . . . . . . . . . . . . . . . . . P. 513
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 578
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P . 269Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 271
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 700
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 604Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 704
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 38 4
Checking/rotation/tire pressure warning system . . . . . . . . . . . . . . . . . . . . . . P. 604
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 666
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 592Opening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 592
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 700
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 692
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 252
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 2 46
Parking lights/daytime running lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 252
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 252
Fog lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 260
Cornering lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 253
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P . 252
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 252
Back-up lights Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 240
Rear side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 252 4
5
6
7
Light bulbs of the exte rior lights for driving
(Replacing method: P. 630, Watts: P. 705)
* : If equipped8
9
10
11
12
13
14
15
16
17

246 4-2. Driving procedures
RX350/RX350L_U Right turn
Lane change to the right (move the
lever partway and release it) The right hand signals will flash 3 times.
Lane change to the left (move the
lever partway and release it) The left hand signals will flash 3 times.
Left turn
■
Turn signals can be operated when
The engine switch is in IGNITION ON mode. ■
If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned out.■
If the turn signals stop flashing befo re a lane change has been performed
Operate the lever again. ■
Customization
Some functions can be customized. (  P. 722)Turn signal lever Operating instructions 1
2
3
4

575
7Maintenance and care
RX350/RX350L_U 7-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ................ 576
Cleaning and protecting
the vehicle interior................... 581
7-2. Maintenance
Maintenance
requirements ............................584
General maintenance..............586
Emission inspection and
maintenance (I/M)
programs ....................................589
7-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions................................590
Hood ............................................... 592
Positioning a floor jack ............593
Engine compartment ............... 594
Tires .................................................604
Tire inflation pressure................ 613
Wheels ............................................ 616
Air conditioning filter ................ 618
Windshield wiper inserts ..........621
Electronic key battery .............. 623
Checking and replacing
fuses .............................................. 625
Headlight aim .............................. 628
Light bulbs.....................................630

590
RX350/RX350L_U 7-3. Do-it-yourself maintenance
Do-it-yourself service precautions If you perform maintenance by yourself, be sure to follow the correct proce-
dure as given in these sections. Items Parts and tools
Battery condition
(  P. 601) •Warm water • Baking soda •Grease
• Conventional wrench (for terminal clamp bolts)
Brake fluid level
(  P. 600) • FMVSS No.116 DOT 3 or SAE J1703 brake fluid
• Rag or paper towel
• Funnel (used only for adding brake fluid)
Engine coolant level
(  P. 598) • “Toyota Super Long Life Coolan t” or a similar high quality
ethylene glycol-based non-silicate, non-amine, non-nitrite
and non-borate coolant with long-life hybrid organic acid
technology
For the U.S.A.:
“Toyota Super Long Life Coolant” is pre-mixed with 50%
coolant and 50% deionized water.
For Canada:
“Toyota Super Long Life Cool ant” is pre-mixed with 55%
coolant and 45% deionized water.
• Funnel (used only for adding engine coolant)
Engine oil level
(  P. 595) • “Toyota Genuine Motor Oil” or equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)
Fuses (  P. 625) • Fuse with same amperage rating as original
Headlight aim
*(  P. 628) • Phillips-head screwdriver
Light bulbs
(  P. 630) • Bulb with same number and wattage rating as original
• Flathead screwdriver •Wrench
Radiator and con-
denser (  P. 599) 

626 7-3. Do-it-yourself maintenance
RX350/RX350L_U Remove the fuse with the pullout
tool.
Only some fuses can be removed
using the pullout tool.
Check if the fuse is blown.
Normal fuse
Blown fuse Replace the blown fuse with a new
fuse of an appropriate amperage rat-
ing. The amperage rating can be
found on the fuse box lid.
Many types of fuse are used on this
vehicle. This illustration shows a com-
mon type of fuse used on this vehicle.■
After a fuse is replaced ●
If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (  P. 630)●
If the replaced fuse blows again, have th e vehicle inspected by your Lexus dealer.■
If there is an overload in a circuit
The fuses are designed to blow, protec ting the wiring ha rness from damage.■
When replacing light bulbs
Lexus recommends that you use genuine Lexus products designed for this vehicle.
Because certain bulbs are conne cted to circuits designed to prevent overload, nongenu-
ine parts or parts not designed for this vehicle may be unusable. 3
4
1
2
WARNING ■
To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to th e vehicle, and possibly a fire or injury.●
Never use a fuse of a higher amperage rating than that indicated, or use any other
object in place of a fuse. ●
Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wi re, even as a temporary fix.●
Do not modify the fuses or fuse boxes.

630 7-3. Do-it-yourself maintenance
RX350/RX350L_U Check the wattage of the light bulb to be replaced. (  P. 705)
 P. 134Light bulbs You may replace the following bulbs by yo urself. The difficulty level of replace-
ment varies depending on the bulb. If necessary bulb replacement seems diffi-
cult to perform, contact your Lexus dealer.
For more information about replacing ot her light bulbs, contact your Lexus
dealer.
Preparing for light bulb replacement
Canceling the power back door system

6317-3. Do-it-yourself maintenance
7
Maintenance and care
RX350/RX350L_U ■
Front
Bulb locations
Front turn signal light (vehic les with single-beam headlights)
Front side marker light (vehic les with single-beam headlights)1
2
