Page 90 of 777

892. Instrument cluster
2
Instrument cluster
RX350/RX350L_U ■
The meters and display illuminate when
The engine switch is in IGNITION ON mode. ■
Brightness of the meters (d ay mode and night mode)
The brightness of the meters is changed between day mode and night mode. ●
Day mode: When the tail lights are off or when the tail lights are on but the surrounding
area is bright ●
Night mode: When the tail lights are on and the surrounding area is dark ■
Outside temperature display ●
In the following situations, the correct outside temperature may not be displayed, or the
display may take longer than normal to change:
• When stopped, or driving at low speeds (less than 12 mph [20 km/h])
• When the outside temperature has changed suddenly (at the entrance/exit of a
garage, tunnel, etc.) ●
When “ ” or “E” is displayed, the sy stem may be malfunctioning.
Take your vehicle to your Lexus dealer. ■
Clock settings screen (vehicles with a navigation system only)
If the clock adjustment screen is displayed continuously wh en attempting to change the
clock settings, the system may be malfunctioning.
Have the vehicle inspected by your Lexus dealer. ■
Customization
Some functions can be customized. ( P. 97)
NOTICE ■
To prevent damage to the engine and its components●
Do not let the indicator needle of the tachometer enter the red zone, which indicates
the maximum engine speed. ●
The engine may be overheating if the engine coolant temperature gauge is in the red
zone (H). In this case, immediately stop the vehicle in a safe place, and check the
engine after it has cooled completely. ( P. 692)
Page 91 of 777
90 2. Instrument cluster
RX350/RX350L_U The multi-information display presents the driver with a variety of driving-related
data, such as the current outside temperature. The multi-information display can
also be used to change the display settings and other settings.
Except F SPORT models
Menu icon display area Displays the following items.
When a menu icon is not selected, the outside temperature and clock are displayed.
•Menu icons ( P. 93)
• Outside temperature ( P. 86)
•Clock ( P. 86)
Content display area A variety of information can be displayed by selecting a menu icon. Additionally,
warning or suggestion/advice pop-up displa ys will be displayed in some situations.
• Menu icon content ( P. 93)
• Suggestion function ( P. 105)
• Warning message ( P. 661)
Indicator/shift position display area Displays the following items:
•Indicators ( P. 80)
• Shift position display ( P. 236, 240)Multi-information display Summary of functions
1
2
3
Page 101 of 777
100 2. Instrument cluster
RX350/RX350L_U ■
Clock (on the multi-information display) ( P. 86)
Vehicles with a navigation system
The following clock setting can be changed:
Vehicles with a Lexus Display Audio system
The following clock settings can be changed: Press the / switch to select an it em and then press the / switch to
change the setting or adjust the time. Item Settings Details
Display mode 12-hour display
Select to set the display mode of the
clock.
24-hour display
Item Settings Details
Display mode 12-hour display
Select to set the display mode of the
clock.
24-hour display
Adjust time Select to adjust the hour/minute.
Page 412 of 777

4115-2. Setup
5
Lexus Display Audio system
RX350/RX350L_U Go to “Display”: “MENU” button “Display”
Turn off screen.
Adjust screen quality.
Adjust screen quality of the rear
view monitor camera.
Change to day mode.
This setting turns the screen off. To tu rn it on, press any button such as the
“AUDIO” button or “MENU” button. If a screen off image has been se t, the set image will be displayed.
When the headlights are turned on, the screen dims.
However, the screen can be switched to day mode by selecting “Day Mode”.The screen will stay in day mode when the headlights are turned on until “Day Mode”
is selected again.
Select “General” or “Camera” on the “D isplay” screen or select “Display” on
audio menu screen. ( P. 417)
Adjust the display as desired by turning the controller clockwise (+) or coun-
terclockwise (-). To select “Contrast”, “Brightness”, “Color” or “Tone”, move the controller to the left.
(“Color” and “Tone” are available when “Display” on the audio settings screen for
each audio source is selected.) ■
Changing the sample image (when “General” is selected)
Move the controller to the right and select the desired sample image.Display settings Settings are available for adjusting the contrast and brightness of the screen.
The display can also be turned off.
Screen for display settings 1
2
3
4
Screen off
Day mode
Adjusting the screen quality 1
2
Page 768 of 777

767Alphabetical index
RX350/RX350L_U Maintenance
Do-it-yourself maintenance......... 590
General maintenance .................... 586
Maintenance data ............................. 698
Maintenance requirements.......... 584
Malfunction indicator lamp .............. 654
Memory recall function .......................175
Meter
Head-up display..................................108
Indicators.................................................. 80
Instrument panel light control ........ 88
Meters.........................................................86
Multi-information display ..................90
Settings ....................................................... 97
Warning lights .................................... 654
Warning messages............................ 661
Microphone ............................................ 456
Mirrors
Inside rear view mirror ..................... 182
Outside rear view mirror
defoggers ............................................ 513
Outside rear view mirrors .............. 184
Vanity mirrors ......................................543
Moon roof
Door lock linked moon roof
operation ............................................. 189
Jam protection function ................... 192
Operation ................................................. 191 MP3 disc .................................................. 427
Multi-information display
AWD Control display........................ 95
Clock .......................................................... 86
Drive information.................................. 94
Dynamic radar cruise control
with full-speed range .................. 300
G-force display ..................................... 96
Language.................................................102
LKA (Lane-Keeping Assist)......... 296
Outside temperature.......................... 86
PCS
(Pre-Collision System) .................281
Settings .......................................................97
Suggestion function........................... 105
Sway warning display......................... 95
Warning messages ............................661
Navigation system
* Noise from under vehicle ........................8M
N
* : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
